Mazda 3 Hatchback (2021 year). Manual in english

When Driving

i-ACTIVSENSE



Tire chains or a temporary spare

^ If the Forward Sensing Camera (FSC)

tire is installed.

detects that the windshield is dirty or

^ The vehicle ahead has a special

foggy, the system functions related to

shape. For example, a vehicle

the Forward Sensing Camera (FSC)

towing a trailer house or a boat, or

are temporarily stopped and the

a vehicle carrier carrying a vehicle

following warning lights turn on.

with its front pointed rearward.

However, this does not indicate a

^ If the Forward Sensing Camera (FSC)

problem. Remove the dirt from the

cannot operate normally due to rain,

windshield or press the defroster

backlight, or fog, the system

switch and defog the windshield.

functions related to the Forward

^ High Beam Control System (HBC)

Sensing Camera (FSC) are

warning indication/warning light

temporarily stopped and the

(amber)

following warning lights turn on.

^ i-ACTIVSENSE warning indication/

However, this does not indicate a

warning light

malfunction.

^ If there are recognizable cracks or

^ High Beam Control System (HBC)

damage caused by flying gravel or

warning indication/warning light

debris on the windshield, always

(amber)

have the windshield replaced.

^ i-ACTIVSENSE warning indication/

Consult an Authorized Mazda Dealer

warning light

for replacement.

^ If the Forward Sensing Camera (FSC)

^ The Forward Sensing Camera (FSC)

cannot operate normally due to high

recognizes pedestrians when all of

temperatures, the system functions

the following conditions are met:

related to the Forward Sensing

^ The height of a pedestrian is about

Camera (FSC) are temporarily

1 to 2 meters.

stopped and the following warning

^ An outline such as the head, both

lights turn on. However, this does

shoulders, or the legs can be

not indicate a malfunction. Cool

determined.

down the area around the Forward

^ In the following cases, the Forward

Sensing Camera (FSC) such as by

Sensing Camera (FSC) may not be

turning on the air conditioner.

able to detect target objects

^ High Beam Control System (HBC)

correctly:

warning indication/warning light

^ Multiple pedestrians are walking,

(amber)

or there are groups of people.

^ i-ACTIVSENSE warning indication/

^ A pedestrian is close to a separate

warning light

object.

^ A pedestrian is crouching, lying, or

slouching.

^ A pedestrian suddenly jumps into

the road right in front of the

vehicle.

^ A pedestrian opens an umbrella, or

is carrying large baggage or

articles.

4-206

When Driving

i-ACTIVSENSE



A pedestrian is in a dark location

Front Radar Sensor*

such as during the night, or blends

into the background by wearing

▼ Front Radar Sensor

clothes matching the background

color.

Your vehicle is equipped with a front

radar sensor.

The following systems also use the

front radar sensor.

^ Distance & Speed Alert (DSA)

^ Mazda Radar Cruise Control

(MRCC)

^ Mazda Radar Cruise Control with

Stop & Go function (MRCC with

Stop & Go function)

^ Traffic Jam Assist (TJA)

^ Smart Brake Support (SBS)

The front radar sensor functions by

detecting the radio waves reflected off

a vehicle ahead or an obstruction sent

from the radar sensor.

The front radar sensor is mounted

behind the front emblem.

1. Front radar sensor

If “Safety and Driver Support Systems

Temporarily Disabled. Front Radar

Obscured. Drive Safely” is displayed on

the multi-information display of the

instrument cluster, clean the area

around the front radar sensor.

CAUTION

Heed the following precautions to

assure correct operation of each

system.

*Some models.

4-207

When Driving

i-ACTIVSENSE

¾ Do not adhere stickers (including

NOTE

transparent stickers) to the surface of

^ Under the following conditions, the

the radiator grille and front emblem

front radar sensor may not be able to

in and around the front radar sensor,

detect vehicles ahead or obstructions

and do not replace the radiator grille

correctly and each system may not

and front emblem with any product

operate normally.

that is not a genuine product

designed for use with the front radar

^ The rear surface of a vehicle ahead

sensor.

does not reflect radio waves

¾ The front radar sensor includes a

effectively, such as an unloaded

function for detecting soiling of the

trailer or an automobile with a

radar sensor's front surface and

loading platform covered by a soft

informing the driver, however,

top, vehicles with a hard plastic

depending on the conditions, it may

tailgate, and round-shaped

require time to detect or it may not

vehicles.

detect plastic shopping bags, ice or

^ Vehicles ahead with low vehicle

snow. If this occurs, the system may

height and thus less area for

not operate correctly, therefore

reflecting radio waves.

always keep the front radar sensor

^ Visibility is reduced due to a

clean.

vehicle ahead casting off water,

¾ Do not install a grille guard.

snow, or sand from its tires and

¾ If the front part of the vehicle has

onto your windshield.

been damaged in a vehicle accident,

^ The trunk/luggage compartment is

the position of the front radar sensor

loaded with heavy objects or the

may have moved. Stop the system

rear passenger seats are occupied.

immediately and always have the

^ Ice, snow, or soiling is on the front

vehicle inspected at an Authorized

surface of the front emblem.

Mazda Dealer.

^ During inclement weather such as

rain, snow, or sand storms.

¾ Do not use the front bumper to push

other vehicles or obstructions such

^ When driving near facilities or

objects emitting strong radio

as when pulling out of a parking

space. Otherwise, the front radar

waves.

^ Under the following conditions, the

sensor could be hit and its position

deviated.

front radar sensor may not be able to

detect vehicles ahead or

¾ Do not remove, disassemble, or

modify the front radar sensor.

obstructions.

¾ For repairs, replacement or paint

^ The beginning and end of a curve.

work around the front radar sensor,

^ Roads with continuous curves.

consult an Authorized Mazda Dealer.

^ Narrow lane roads due to road

¾ Do not modify the suspensions. If

construction or lane closures.

the suspensions are modified, the

^ The vehicle ahead enters the radar

vehicle's posture could change and

sensor's blind spot.

the front radar sensor may not be

^ The vehicle ahead is running

able to correctly detect a vehicle

abnormally due to accident or

ahead or an obstruction.

vehicle damage.

4-208

When Driving

i-ACTIVSENSE



Roads with repeated up and down

Front Side Radar Sensor*

slopes

^ Driving on poor roads or unpaved

▼ Front Side Radar Sensor

roads.

^ The distance between your vehicle

Your vehicle is equipped with front

and the vehicle ahead is extremely

side radar sensor. The following

short.

systems also use the front side radar

^ A vehicle suddenly comes close,

sensor.

such as by cutting into your lane.

^ Front Cross Traffic Alert (FCTA)

^ To prevent incorrect operation of the

system, use tires of the same

The front side radar sensor function by

specified size, manufacturer, brand,

detecting the radio waves reflected off

and tread pattern on all four wheels.

a vehicle approaching from the front or

In addition, do not use tires with

an obstruction sent from the radar

significantly different wear patterns

sensor.

or tire pressures on the same vehicle

(Including the temporary spare tire).

^ If the battery power is weak, the

system may not operate correctly.

^ When driving on roads with little

traffic and few vehicles ahead or

obstructions for the front radar

sensor to detect, “Safety and Driver

Support Systems Temporarily

Disabled. Front Radar Obscured.

1. Front side radar sensor

Drive Safely” may be temporarily

displayed, however, this does not

The front side radar sensors are

indicate a problem.

installed inside the front bumper, one

^ The radar sensors are regulated by

on each side.

the relevant radio wave laws of the

Always keep the surface of the front

country in which the vehicle is

bumper near the front side radar

driven. If the vehicle is driven

sensors clean so that they operate

abroad, authorization from the

normally. Also, do not apply items such

country in which the vehicle is driven

as stickers.

may be required.

Refer to Exterior Care on page 6-48.

CAUTION

If the front bumper receives a severe

impact, the system may no longer

operate normally. Stop the system

immediately and have the vehicle

inspected at an Authorized Mazda

Dealer.

*Some models.

4-209

When Driving

i-ACTIVSENSE

NOTE

^ The radar sensors are regulated by

the relevant radio wave laws of the

^ The detection ability of the front side

country in which the vehicle is

radar sensor has limitations. In the

driven. If the vehicle is driven

following cases, the detection ability

abroad, authorization from the

may lower and the system may not

country in which the vehicle is driven

operate normally.

may be required.

^ The front bumper near the front

side radar sensor has become

deformed.

^ Snow, ice or mud adheres to the

front side radar sensor on the front

bumper.

^ Under bad weather conditions

such as rain, snow and fog.

^ Under the following conditions, the

front side radar sensor cannot detect

target objects or it may be difficult to

detect them.

^ Small motorcycles, bicycles,

pedestrians, animals, shopping

carts, and stationary objects on a

road or a road side.

^ Vehicle shapes which do not

reflect radar waves well such as

empty trailers with a low vehicle

height and sports cars.

^ Vehicles are shipped with the

direction of the front side radar

sensor adjusted for each vehicle to a

loaded vehicle condition so that the

front side radar sensor detect

approaching vehicles correctly. If the

direction of the front side radar

sensor has deviated for some reason,

have the vehicle inspected at an

Authorized Mazda Dealer.

^ For repairs or replacement of the

front side radar sensor, or bumper

repairs, paintwork, and replacement

near the radar sensors, consult an

Authorized Mazda Dealer.

4-210

When Driving

i-ACTIVSENSE

Always keep the surface of the rear

Rear Side Radar Sensor*

bumper near the rear side radar

sensors clean so that they operate

▼ Rear Side Radar Sensor

normally. Also, do not apply items such

Your vehicle is equipped with rear side

as stickers.

radar sensor. The following systems

Refer to Exterior Care on page 6-48.

also use the rear side radar sensor.

CAUTION

^ Blind Spot Monitoring (BSM)

^ Rear Cross Traffic Alert (RCTA)

If the rear bumper receives a severe

^ Smart Brake Support [Rear Crossing]

impact, the system may no longer

(SBS-RC)

operate normally. Stop the system

The rear side radar sensors emit radio

immediately and have the vehicle

inspected at an Authorized Mazda

waves and detect the radio waves

reflected off a vehicle approaching

Dealer.

from the rear or an obstruction.

4-Door

NOTE

^ The detection ability of the rear side

radar sensor has limitations. In the

following cases, the detection ability

may lower and the system may not

operate normally.

^ The rear bumper near the rear side

radar sensor has become

deformed.

^ Snow, ice or mud adheres to the

1. Rear side radar sensor

rear side radar sensor on the rear

bumper.

5-Door

^ Under bad weather conditions

such as rain, snow and fog.

^ Under the following conditions, the

rear side radar sensor cannot detect

target objects or it may be difficult to

detect them.

^ Small motorcycles, bicycles,

pedestrians, animals, shopping

carts, and stationary objects on a

road or a road side.

1. Rear side radar sensor

^ Vehicle shapes which do not

reflect radar waves well such as

The rear side radar sensors are installed

empty trailers with a low vehicle

inside the rear bumper, one on each

height and sports cars.

side.

*Some models.

4-211

When Driving

i-ACTIVSENSE

 Vehicles are shipped with the

Rear/Rear corner/Rear

direction of the rear side radar

sensor adjusted for each vehicle to a

Side Ultrasonic Sensor*

loaded vehicle condition so that the

rear side radar sensor detect

▼ Rear/Rear corner/Rear Side

approaching vehicles correctly. If the

Ultrasonic Sensor

direction of the rear side radar

The ultrasonic sensors function by

sensor has deviated for some reason,

emitting ultrasonic waves which are

have the vehicle inspected at an

reflected off obstructions at the rear

Authorized Mazda Dealer.

and the returning ultrasonic waves are

^ For repairs or replacement of the rear

picked up by the ultrasonic sensors.

side radar sensor, or bumper repairs,

4-Door

paintwork, and replacement near the

radar sensors, consult an Authorized

Mazda Dealer.

^ The radar sensors are regulated by

the relevant radio wave laws of the

country in which the vehicle is

driven. If the vehicle is driven

abroad, authorization from the

country in which the vehicle is driven

1. Rear ultrasonic sensor

may be required.

2. Rear corner ultrasonic sensor

3. Rear side ultrasonic sensor

5-Door

1. Rear ultrasonic sensor

2. Rear corner ultrasonic sensor

3. Rear side ultrasonic sensor

The ultrasonic sensors are mounted in

the rear bumper.

4-212 *Some models.

When Driving

i-ACTIVSENSE

^ You are driving the vehicle with

Driver Monitoring

your head excessively tilted to one

Camera*

side or the other.

^ You are moving around extensively.

▼ Driver Monitoring Camera

^ Your face or your eyes frequently

turn in direction other than straight

The driver monitoring camera detects

ahead (direction of travel).

changes in the driver's facial features

^ Your line of sight moves or directly

and estimates the amount of

after it has moved.

accumulated fatigue and sleepiness of

^ There is a large difference between

the driver.

your line of sight and the direction

your face is pointed.

^ You are driving the vehicle with

your head largely tilted to one side.

1. Driver monitoring camera

NOTE

^ Driver Monitoring (DM) and the

earlier collision warning may not

operate normally under the following

conditions.

^ The driver monitoring camera is

covered with something.

^ You are driving the vehicle while

leaning on the steering wheel.

^ You are wearing glasses or

sunglasses.

^ A cap or hat you are wearing

partially blocks the driver

monitoring camera's view of your

eyes, you have long bangs partially

covering your eyes, or a part of

your face is invisible due to a face

mask.

^ The lighting conditions change

significantly (such as backlight,

light from the side, or direct light

from the setting sun, and the

headlights of on-coming vehicles).

4-214 *Some models.

When Driving

Cruise Control

NOTE

Cruise Control*

If your Mazda has the following

steering switch, your Mazda is

▼ Cruise Control

equipped with the Mazda Radar

Cruise Control (MRCC) system, the

With cruise control, you can set and

Mazda Radar Cruise Control with Stop

automatically maintain any speed of

& Go function (MRCC with Stop & Go

more than about 30 km/h (19 mph).

function) system.

WARNING

Do not use the cruise control under

the following conditions:

Using the cruise control under the

following conditions is dangerous and

could result in loss of vehicle control.

Refer to Mazda Radar Cruise Control

(MRCC) on page 4-120.

¾ Hilly terrain

Refer to Mazda Radar Cruise Control

¾ Steep inclines

with Stop & Go function (MRCC with

¾ Heavy or unsteady traffic

Stop & Go function) on page 4-128.

¾ Slippery or winding roads

If the Mazda Radar Cruise Control

¾ Similar restrictions that require

(MRCC) or Mazda Radar Cruise

inconsistent speed

Control with Stop & Go function

▼ Cruise Control Switch

(MRCC with Stop & Go function) is set

to inoperable using the personalization

feature, the system switches to the

cruise control function. In this case, the

MRCC functions as the cruise switch.

In addition, this personalization

feature setting is initialized by

switching the ignition OFF, and it turns

back on when the ignition is switched

ON the next time.

1. CANCEL switch

2. RES switch

▼

Cruise Standby Indication

3. Cruise switch

(White)/Cruise Set Indication

(Green)

Cruise standby Indication (White)

The indication turns on (white) when

the cruise control system is activated.

*Some models.

4-215

When Driving

Cruise Control

Cruise Set Indication (Green)

▼ To Set Speed

The indication turns on (green) when a

1. Activate the cruise control system

cruising speed has been set.

by pressing the cruise switch. The

cruise standby indication (white)

turns on.

2. Accelerate to the desired speed,

which must be more than 25 km/h

(16 mph).

▼ Activation/Deactivation

3. Adjust the system to the desired

vehicle speed using the accelerator

pedal. Press the RES switch up (SET

WARNING

+) or down (SET-) to start cruise

control. The cruise control

Always turn off the cruise control

indication (green) in the instrument

system when it is not in use:

cluster turns on at the same time.

Leaving the cruise control system in an

Quickly release the switch when the

activation-ready state while the cruise

cruise control indication (green)

control is not in use is dangerous as the

turns on.

cruise control could unexpectedly

activate if the activation button is

NOTE

accidentally pressed, and result in loss

^ If the RES switch is operated up (SET

of vehicle control and an accident.

+) or down (SET-) while the vehicle

speed is between 25 and 30 km/h

NOTE

(16 to 19 mph), the set speed is set

When the ignition is switched OFF, the

to 30 km/h (19 mph).

system status before it was turned off is

^ The cruise control speed setting

maintained. For example, if the

cannot be performed under the

ignition is switched OFF with the cruise

following conditions:

control system operable, the system

^ Any of the doors is opened.

will be operable when the ignition is

^ The driver's seat belt is unfastened.

switched ON the next time.

^ The brake pedal is depressed.

Activation

^ The parking brake is applied.



(Automatic transmission)

To activate the system, press the cruise

The selector lever is in the P, N, or

switch. The cruise standby indication

R position.

(white) turns on.



(Manual transmission)

Deactivation

The shift lever is in the neutral

position.

To deactivate the system, press the

^ On a steep grade, the vehicle may

cruise switch again.

momentarily slow down while

The cruise standby indication (white)

ascending or speed up while

turns off.

descending.

4-216

When Driving

Cruise Control



The cruise control will cancel if the

▼ Changing the Set Vehicle Speed

vehicle speed decreases below 20

Follow either of these procedures.

km/h (12 mph) when the cruise

control is activated, such as when

To increase/decrease speed using

climbing a steep grade.

cruise control switch

The vehicle speed preset using the

When the RES switch is pressed up

cruise control is displayed in the

(SET+), the vehicle accelerates and

instrument cluster and the active

when the RES switch is pressed down

driving display (vehicles with active

(SET-), it decelerates.

driving display).

^ Press and release immediately: 1

Instrument cluster (Basic display)

km/h (1 mph)

^ Press and hold: 10 km/h (5 mph)

NOTE

Even after releasing the RES switch, the

cruise control accelerates/decelerates

continuously until the set speed

displayed in the instrument cluster and

on the active driving display is reached.

If you want to stop accelerating/

decelerating, change the set speed or

cancel the system (such as by

depressing the brake pedal).

Instrument cluster (i-ACTIVSENSE

display)

To increase speed using accelerator

pedal

Depress the accelerator pedal and

press the RES switch up (SET+) or

down (SET-) at the desired speed. If

the switch is not operated, the system

returns to the set speed after you

release your foot from the accelerator

pedal.

NOTE

Accelerate if you want to speed up

temporarily when the cruise control is

Active driving display

on. Greater speed will not interfere

with or change the set speed. Take

your foot off the accelerator to return

to the set speed.

4-217

When Driving

Cruise Control

▼ To Resume Cruising Speed at More

NOTE

Than 30 km/h (19 mph)

^ If any of the following conditions

If the cruise control system is

occur, the cruise control system is

temporarily canceled (such as by

temporarily canceled.

applying the brake pedal) and the

^ Even when the brake pedal is

system is still activated, the most

slightly depressed.

recent set speed will automatically

^ The DSC is operating.

resume when the RES switch is

^ There is a problem in the system.

pressed.

^ Any of the doors is opened.

If vehicle speed is below 30 km/h (19

^ The driver's seat belt is unfastened.

mph), increase the vehicle speed up to

^ The parking brake is applied.

30 km/h (19 mph) or more and press

 (Automatic transmission)

the RES switch.

The selector lever is in the P, N, or

R position.

▼ To Temporarily Cancel

 (Manual transmission)

To temporarily cancel the system, use

The shift lever is in the neutral

one of these methods:

position.

^ When the cruise control system is

^ Slightly depress the brake pedal.

temporarily canceled by even one of

^ Press the CANCEL switch.



the applicable cancel conditions, the

(Manual transmission)

speed cannot be re-set.

Depress the clutch pedal.



(Automatic transmission)

If the RES switch is pressed when the

The cruise control cannot be

vehicle speed is 30 km/h (19 mph) or

canceled while driving in manual

higher, the system reverts to the

mode (selector lever shifted from D

previously set speed.

to M position). Therefore, engine

braking will not be applied even if

the transmission is shifted down to a

lower gear. If deceleration is

required, lower the set speed or

depress the brake pedal.

▼ To Deactivate

Press the cruise switch again.

4-218

When Driving

Tire Pressure Monitoring System (TPMS)

^ Before driving, visually inspect the

Tire Pressure Monitoring

tires for abnormalities. Additionally,

System (TPMS)

inspect the tire pressures monthly. A

digital type air pressure gauge is

▼ Tire Pressure Monitoring System

recommended for inspecting the tire

(TPMS)

pressures.

The TPMS monitors the air pressure of

The TPMS is not a substitute for your

each tire and if it decreases below the

own periodic inspection of the tires.

specified value, the system notifies the

Always inspect the tires yourself

driver by turning on the TPMS warning

periodically.

light in the instrument cluster and

indicating a message on the

CAUTION

multi-information display.

For the TPMS, the air pressure data

¾ Each tire, including the spare (if

sent from the tire pressure sensors

provided), should be checked

installed on each wheel via radio signal

monthly when cold and inflated to

is received by the receiver unit in the

the inflation pressure recommended

vehicle to monitor the tire pressures.

by the vehicle manufacturer on the

vehicle placard or tire inflation

pressure label. (If your vehicle has

tires of a different size than the size

indicated on the vehicle placard or

tire inflation pressure label, you

should determine the proper tire

inflation pressure for those tires.)

As an added safety feature, your

vehicle has been equipped with a

1. Tire pressure sensors

tire pressure monitoring system

(TPMS) that illuminates a low tire

In addition, the current tire pressures

pressure telltale when one or more

can be checked using the center

of your tires is significantly

display.

under-inflated. Accordingly, when

Refer to the Vehicle Status Monitor

the low tire pressure telltale

section in the Mazda Connect

illuminates, you should stop and

Owner's Manual.

check your tires as soon as possible,

NOTE

and inflate them to the proper

pressure. Driving on a significantly

^ When the ambient temperature is

under-inflated tire causes the tire to

low, the tire temperatures also

overheat and can lead to tire failure.

decrease. If the tire temperatures

Under-inflation also reduces fuel

decrease, the air pressure in the tires

efficiency and tire tread life, and may

will also decrease which could turn

affect the vehicle's handling and

on the TPMS warning light.

stopping ability.

4-219

When Driving

Tire Pressure Monitoring System (TPMS)

Please note that the TPMS is not a

▼

If there is a problem with the Tire

substitute for proper tire

Pressure Monitoring System

maintenance, and it is the driver's

(TPMS)

responsibility to maintain correct tire

If the TPMS warning light flashes, there

pressure, even if under-inflation has

may be a problem with the system.

not reached the level to trigger

Consult an Authorized Mazda Dealer

illumination of the TPMS low tire

to have the system inspected.

pressure telltale.

Refer to Tire Pressure Monitoring

Your vehicle has also been equipped

System (TPMS) Warning Indication/

with a TPMS malfunction indicator to

Warning Light (Flashing) on page

indicate when the system is not

7-33.

operating properly.

In the following cases, the system

The TPMS malfunction indicator is

cannot recognize the tire pressures

combined with the low tire pressure

correctly and the TPMS warning light

telltale. When the system detects a

may flash.

malfunction, the telltale will flash for

approximately one minute and then

^ There is equipment or a device

remain continuously illuminated.

nearby emitting radio signals the

This sequence will continue upon

same as a tire pressure sensor.

subsequent vehicle start-ups as long

^ A metallic object such as a

as the malfunction exists. When the

non-genuine electronic device is

malfunction indicator is illuminated,

installed near the center of the

the system may not be able to detect

dashboard (obstructs the radio

or signal low tire pressure as

signals from the tire pressure sensors

intended. TPMS malfunctions may

to the receiver).

occur for a variety of reasons,

^ A device such as one of the following

including the installation of

is used in the cabin.

replacement or alternate tires or

^ Electronic devices such as a

wheels on the vehicle that prevent

computer.

the TPMS from functioning properly.

^ Converter devices such as a

Always check the TPMS malfunction

DC-AC converter.

telltale after replacing one or more

^ There is a large accumulation of

tires or wheels on your vehicle to

snow or ice around the vehicle tires.

ensure that the replacement or

^ The battery in a tire pressure sensor

alternate tires and wheels allow the

is dead.

TPMS to continue to function

^ A wheel not equipped with a tire

properly.

pressure sensor is used.

¾ To avoid false readings, the system

^ Tires employing steel in the sidewall

samples for a little while before

of the tire are installed.

indicating a problem. As a result it

^ Tire chains are used.

will not instantaneously register a

rapid tire deflation or blow out.

4-220

When Driving

Tire Pressure Monitoring System (TPMS)

▼ When a tire pressure decreases

2. After more than 19 minutes have

passed, drive the vehicle at a speed

If the TPMS warning light turns on, a

of about 25 km/h (16 mph) or

tire pressure may be low. Inspect the

faster for 3 minutes or longer. While

tire pressures and adjust them to the

driving, the ID signal codes of the

correct inflation pressure.

tire pressure sensors are

Refer to Tire Pressure Monitoring

automatically registered.

System (TPMS) Warning Indication/

Warning Light (Turns on) on page

NOTE

7-37.

If you drive the vehicle within 19

minutes of changing a tire or wheel,

▼ Tires and Wheels

the TPMS warning light will flash

because the ID signal codes for the tire

pressure sensors were not registered.

CAUTION

In this case, stop the vehicle and

When inspecting/adjusting the tire

pressures, do not apply excessive force

pressure sensors following the

to the air valve of the tire pressure

procedure.

sensor. Otherwise, the tire pressure

When replacing tires and wheels

sensor could be damaged.

When changing tires and wheels

CAUTION

When changing the tires or wheels

(such as installing winter tires), it will

¾ When replacing the tires and wheels,

be necessary to register the ID signal

consult an Authorized Mazda Dealer

code of the tire pressure sensor to the

Otherwise, the tire pressure sensors

TPMS.

could be damaged when replacing

Have an Authorized Mazda Dealer do

them.

the registration or register the ID signal

¾ Do not install non-genuine wheels. If

codes of the tire pressure sensors using

wheels other than genuine ones are

the following procedure.

installed, it may not be possible to

install the tire pressure sensors.

NOTE

The tire pressure sensors on each

When replacing a tire or wheel, always

wheel have a unique ID signal code.

install the tire pressure sensor. The

For the TPMS to operate correctly, the

following combinations of tires,

ID signal codes of the tire pressure

wheels, or tires and wheels are

sensors need to be registered to the

possible.

system.

^ The tire pressure sensor from the old

wheel is removed and it is installed

1. Wait more than 19 minutes after

changing a tire or wheel.

to the new wheel.

^ Only a tire is replaced without

replacing the tire pressure sensor and

wheel.

^ A new tire pressure sensor is installed

to a new wheel.

4-221

When Driving

Rear View Monitor

¾ Do not apply excessive force to the

Rear View Monitor*

camera. The camera position and

angle may deviate.

▼ Rear View Monitor

¾ Do not disassemble, modify, or

The rear view monitor provides visual

remove it as it may no longer be

images of the rear of the vehicle when

waterproof.

reversing.

¾ The camera cover is made of plastic.

Do not apply degreasing agents,

WARNING

organic solvents, wax, or glass

coating agents to the camera cover.

Always drive carefully confirming the

If any are spilled on the cover, wipe

safety of the rear and the surrounding

off with a soft cloth immediately.

conditions by looking directly with

¾ Do not rub the camera cover

your eyes:

forcefully with an abrasive or hard

Reversing the vehicle by only looking at

brush. The camera cover or lens may

the screen is dangerous as it may cause

be scratched which might affect the

an accident or a collision with an

images.

object. The rear view monitor is only a

visual assist device when reversing the

NOTE

vehicle. The images on the screen may

^ If water, snow, or mud is stuck on

be different from the actual conditions.

the camera lens, wipe it off using a

soft cloth. If it cannot be wiped off,

CAUTION

use a mild detergent.

^ If the camera temperature changes

¾ Do not use the rear view monitor

rapidly (Hot to cold, cold to hot), the

under the following conditions:

rear view monitor may not operate

Using the rear view monitor under

correctly.

the following conditions is

^ When replacing the tires, consult an

dangerous and could result in injury

Authorized Mazda Dealer. Replacing

or vehicle damage or both.

the tires could result in deviation of

¾ Icy or snow-covered roads.

the guide lines which appear on the

¾ Tire chains or a temporary spare

display.

tire is installed.

^ If the vehicle's front, side, or rear has

¾ The vehicle is on a road incline.

been involved in a collision, the

¾ When the display is cold, images

alignment of the rear view parking

may course across the monitor or the

camera (location, installation angle)

screen and may be dimmer than

may have deviated. Always consult

usual, which could cause difficulty in

an Authorized Mazda Dealer to have

confirming the surrounding

the vehicle inspected.

conditions of the vehicle. Always

^ If “No camera signal.” is indicated in

drive carefully confirming the safety

the display, there could be a

of the rear and the surrounding

problem with the camera. Have your

conditions by looking directly with

vehicle inspected at an Authorized

your eyes.

Mazda Dealer.

*Some models.

4-223

When Driving

Rear View Monitor

▼ Switching to the Rear View Monitor Display

Shift the shift lever (manual transmission) or the selector lever (automatic

transmission) to reverse (R) position with the ignition switched ON to switch the

display to the rear view monitor display.

NOTE

When the shift lever (manual transmission) or the selector lever (automatic

transmission) is shifted from reverse (R) position to another shift lever (manual

transmission) or the selector lever (automatic transmission) position, the screen

returns to the previous display.

▼ Displayable Range on the Screen

The images on the screen may be different from the actual conditions.

(Screen display)

(Actual view)

3. Bumper

“Check surroundings for safety.” message is displayed

5. Object

NOTE

^ The displayable range varies depending on the vehicle and road conditions.

^ If the camera lens is touched or there is any dirt on it, it could affect the screen

image. Wipe the lens using a soft cloth.

^ The displayable range is limited. Objects under the bumper or around the bumper

ends cannot be displayed.

4-225

When Driving

Rear View Monitor



The distance appearing in the displayed image is different from the actual distance

because the rear view parking camera is equipped with a specific lens.

^ Images displayed on the monitor from the rear view parking camera are reversed

images (mirror images).

^ Some optionally installed vehicle accessories may be picked up by the camera. Do

not install any optional parts that can interfere with the camera view, such as

illuminating parts or parts made of reflective material.

^ It may be difficult to see the display under the following conditions, however, it

does not indicate a malfunction.

^ In darkened areas.

^ When the temperature around the lens is high/low.

^ When the camera is wet such as on a rainy day or during periods of high

humidity.

^ When foreign material such as mud is stuck around the camera.

^ When the camera lens reflects sunlight or headlight beams.

^ The surroundings are illuminated by vehicle lights, fluorescent lights, or LED

lights (display may flicker).

^ Extremely small dark or white dots appear on the screen (dots may flicker).

^ Image display may be delayed if the temperature around the camera is low.

▼ Viewing the Display

Predicted vehicle path assist lines display type

The projected path guidance mode displays the predicted path of the vehicle after

you turn the steering wheel.

Use this mode for parking your vehicle in a parking space or garage.

a) Projected vehicle path (yellow)

These lines are displayed as a reference for the projected path of the vehicle.

The lines displaying the projected vehicle path change after you turn the steering

wheel.

b) Extended vehicle width lines (blue)

These lines indicate the vehicle's extended width.

These lines are not displayed when the vehicle's wheels are in the straight-ahead

position.

4-226

When Driving

Rear View Monitor

c) Distance guide lines (red)

These lines indicate the approximate distance to a point measured from the

vehicle's rear (from the end of the bumper).

The blue line indicates the point about 0.5 m (19 in) from the rear bumper.

The red and yellow lines, which change position after you turn the steering wheel,

indicate the points about 0.5 m (19 in) for the red line and 1.0 m (39 in) and 2.0

m (78 in) for the yellow lines from the rear bumper (at the center point of each of

the lines).

A degree of error occurs when the wheels are not in the straight-ahead position.

In the above illustration, the right side of the vehicle is in a position closer to the

actual distance displayed by the distance guide lines (red: about 0.5 m (19 in)

point, yellow: about 1.0 m (39 in), and yellow: about 2.0 m (78 in) point behind

the rear bumper), whereas the left side is in a position farther away.

CAUTION

The indicated position of the guide lines on the display changes depending on the

vehicle conditions (such as the number of occupants/cargo load) and the road

conditions (such as a steep gradient to the rear of the vehicle).

Always check the area to the vehicle's rear and the surrounding area directly with

your eyes while backing up.

Fixed assist lines display type

Guide lines which indicate the width of the vehicle are displayed on the screen as a

reference to the approximate width of the vehicle in comparison to the width of the

parking space you are about to back into.

Use this display view for parking your vehicle in a parking space or garage.

a) Vehicle width guide lines

Guide lines serve as a reference to the approximate width of the vehicle.

4-227

When Driving

Rear View Monitor

b) Distance guide lines

These guide lines indicate the approximate distance to a point measured from the

vehicle's rear (from the end of the bumper).

The red line indicates the point about 0.5 m (19 in) from the rear bumper.

The yellow lines indicate the points about 1.0 m (39 in) and 2.0 m (78 in) from

the rear bumper.

CAUTION

The guide lines on the screen are fixed lines. They are not synced to the driver's

turning of the steering wheel. Always be careful and check the area to the vehicle's

rear and the surrounding area directly with your eyes while backing up.

▼ Rear View Monitor Operation

The operation of the rear view monitor when reversing the vehicle varies depending

on the traffic, road, and vehicle conditions. The amount of steering and the timing

also varies depending on conditions, so confirm the surrounding conditions directly

with your eyes and steer the vehicle in accordance with the conditions.

Be well aware of the above cautions prior to using the rear view monitor.

Predicted vehicle path assist lines display type

NOTE

The following shows an example of vehicle parking in which the steering wheel is

turned to the right when backing up the vehicle. The operation is reversed when

backing up the vehicle from the opposite direction.

1. Shift the shift lever (manual transmission) or the selector lever (automatic

transmission) to reverse (R) position to switch the display to the rear view

monitor display.

4-228

When Driving

Rear View Monitor

5. Once they are parallel, straighten the wheels and back your vehicle slowly into

the parking space. Continue checking the vehicle's surroundings and then stop

the vehicle in the best possible position. (If the parking space has division lines,

check whether the vehicle width guide lines are parallel to them.)

(Display condition)

(Vehicle condition)

6. When the shift lever (manual transmission) or the selector lever (automatic

transmission) is shifted from reverse (R) position to another shift lever (manual

transmission) or the selector lever (automatic transmission) position, the screen

returns to the previous display.

NOTE

Because there may be a difference between the displayed image, such as indicated

below, and the actual conditions when parking, always verify the safety at the rear of

the vehicle and the surrounding area directly with your eyes.

^ In the image of the parking space (or garage) displayed on the screen, the back

end and distance guide lines may appear aligned in the monitor, but they may not

actually be aligned on the ground.

4-231

When Driving

Rear View Monitor



When parking in a space with a division line on only one side of the parking space,

the division line and the vehicle width guide line appear aligned in the monitor,

but they may not actually be aligned on the ground.

Fixed assist lines display type

NOTE

Images displayed on the monitor from the rear view parking camera are reversed

images (mirror images).

1. Shift the shift lever (manual transmission) or the selector lever (automatic

transmission) to reverse (R) position to switch the display to the rear view

monitor display.

2. Confirming the surrounding conditions, reverse the vehicle.

4-232

When Driving

Rear View Monitor

5. Once they are parallel, straighten the wheels and back your vehicle slowly into

the parking space. Continue checking the vehicle's surroundings and then stop

the vehicle in the best possible position. (If the parking space has division lines,

check whether the vehicle width guide lines are parallel to them.)

(Display condition)

(Vehicle condition)

6. When the shift lever (manual transmission) or the selector lever (automatic

transmission) is shifted from reverse (R) position to another shift lever (manual

transmission) or the selector lever (automatic transmission) position, the screen

returns to the previous display.

NOTE

Because there may be a difference between the displayed image, such as indicated

below, and the actual conditions when parking, always verify the safety at the rear of

the vehicle and the surrounding area directly with your eyes.

^ In the image of the parking space (or garage) displayed on the screen, the back

end and distance guide lines may appear aligned in the monitor, but they may not

actually be aligned on the ground.

4-234

When Driving

Rear View Monitor



When parking in a space with a division line on only one side of the parking space,

the division line and the vehicle width guide line appear aligned in the monitor,

but they may not actually be aligned on the ground.

▼ Variance Between Actual Road Conditions and Displayed Image

Some variance occurs between the actual road and the displayed road. Such

variance in distance perspective could lead to an accident. Note the following

conditions that may cause a variance in distance perspective.

When the vehicle is tilted due to the weight of passengers and load

When the vehicle rear is lowered, the object displayed on the screen appears farther

than the actual distance.

1. Object

2. Variance

3. Object on screen

4-235

When Driving

Rear View Monitor

When there is a steep grade behind the vehicle

When there is a steep upgrade (downgrade) behind the vehicle, the object displayed

on the screen appears farther (downgrade: closer) than the actual distance.

1. Appears farther than actual distance

2. Appears closer than actual distance

3. Distance between the vehicle and object displayed on the screen.

4. Actual distance between the vehicle and object.

5. Object at actual position

6. Object on screen

Three-dimensional object on vehicle rear

Because the distance guide lines are displayed based on a flat surface, the distance

to the three-dimensional object displayed on the screen is different from the actual

distance.

(Screen display)

(Actual condition)

3. Sensed distance on screen A>B>C

4. Actual distance B>C=A

4-236

Mazda 3 Hatchback (2021 year). Manual in english - page 12
