Mazda CX-9 (2019 year). Instruction - part 32

Scheduled Maintenance (Mexico)

Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions
(severe driving conditions) apply.



Repeated short-distance driving



Driving in dusty conditions



Driving with extended use of brakes



Driving in areas where salt or other corrosive materials are used



Driving on rough or muddy roads



Extended periods of idling or low-speed operation



Driving for long periods in cold temperatures or extremely humid climates



Driving in extremely hot conditions



Driving in mountainous conditions continually

If any do apply, follow Schedule 2.

NOTE
For maintenance guidelines beyond the kilometers/months listed, follow the maintenance
intervals provided in the Scheduled Maintenance Tables.

▼ Schedule 1

Maintenance Interval

Number of months or kilometers, whichever comes first

Months

6

12

18

24

30

36

42

48

54

60

66

72

×1000 km

10

20

30

40

50

60

70

80

90 100 110 120

ENGINE
Drive belts

I

I

I

Engine oil & filter

*1

R

R

R

R

R

R

R

R

R

R

R

R

COOLING SYSTEM
Cooling system

I

I

I

Engine coolant

*2

Replace at first 200,000 km or 10 years; after that, every

100,000 km or 5 years

FUEL SYSTEM
Air filter

R

R

R

R

R

R

Fuel lines and hoses

I

*3

I

*3

I

Hoses and tubes for emission

I

*3

I

*3

I

Fuel filter

Replace every 60,000 km

IGNITION SYSTEM

Spark plugs

I

I

I

I

I

I

I

I

I

I

I

I

Replace every 64,000 km

Maintenance and Care

Scheduled Maintenance

6-10

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Maintenance Interval

Number of months or kilometers, whichever comes first

Months

6

12

18

24

30

36

42

48

54

60

66

72

×1000 km

10

20

30

40

50

60

70

80

90 100 110 120

CHASSIS and BODY
Brake lines, hoses and connections

I

I

I

I

I

I

Brake and clutch fluid level

I

I

I

I

I

I

I

I

I

Brake fluid

R

R

R

Disc brakes

I

I

I

I

I

I

I

I

I

I

I

I

Tire (Rotation)

*4

Rotate every 10,000 km

Tire inflation pressure and tire wear

*4

I

I

I

I

I

I

I

I

I

I

I

I

Steering operation and linkages

I

I

I

I

I

I

I

I

I

I

I

I

Front and rear suspension, ball joints and wheel
bearing axial play

I

I

I

I

I

I

Rear differential oil

*5

Transfer oil

*5

Driveshaft dust boots

I

I

I

I

I

I

Bolts and nuts on chassis and body

T

T

T

T

T

T

Exhaust system and heat shields

I

I

I

I

I

I

All locks and hinges

L

L

L

L

L

L

L

L

L

L

L

L

Washer fluid level

I

I

I

I

I

I

I

I

I

I

I

I

Emergency flat tire repair kit (if installed)

*6

Inspect annually.

AIR CONDITIONER SYSTEM
Cabin air filter

R

R

R

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
T: Tighten

Remarks:

*

1 Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light

display.

*

2 Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may

cause serious damage to the engine and cooling system.

*

3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not

void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or kilometer period to ensure long-term reliability.

*

4 The Tire Pressure Monitoring System (TPMS) initialization must be performed so that the system operates

normally (if equipped).

*

5 If this component has been submerged in water, the oil should be replaced.

*

6 Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the

tire repair fluid bottle with new one before the expiration date.

Maintenance and Care

Scheduled Maintenance

6-11

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

▼ Schedule 2

Maintenance Interval

Number of months or kilometers, whichever comes first

Months

3

6

9

12

15

18

21

24

27

30

33

36

×1000 km

5

10

15

20

25

30

35

40

45

50

55

60

ENGINE
Drive belts

I

Engine oil & filter

*1

R

R

R

R

R

R

R

R

R

R

R

R

COOLING SYSTEM
Cooling system

I

Engine coolant

*2

Replace at first 200,000 km or 10 years; after that, every

100,000 km or 5 years

Engine coolant level

I

I

I

I

I

I

I

I

I

I

I

I

FUEL SYSTEM
Air filter

C

R

C

R

C

R

Fuel lines and hoses

I

*3

Hoses and tubes for emission

I

*3

Fuel filter

Replace every 60,000 km

IGNITION SYSTEM

Spark plugs

I

I

I

I

I

I

Replace every 64,000 km

ELECTRICAL SYSTEM
Function of all lights

I

I

I

I

I

I

I

I

I

I

I

I

CHASSIS and BODY
Brake lines, hoses and connections

I

I

I

Brake and clutch fluid level

I

I

I

I

I

Brake fluid

R

Disc brakes

I

I

I

I

I

I

Tire (Rotation)

*4

Rotate every 10,000 km

Tire inflation pressure and tire wear

*4

I

I

I

I

I

I

Steering operation and linkages

I

I

I

I

I

I

Front and rear suspension, ball joints and wheel
bearing axial play

I

I

I

Rear differential oil

*5

Transfer oil

*5

Driveshaft dust boots

I

I

I

Bolts and nuts on chassis and body

T

T

T

Exhaust system and heat shields

I

I

I

All locks and hinges

L

L

L

L

L

L

Maintenance and Care

Scheduled Maintenance

6-12

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Maintenance Interval

Number of months or kilometers, whichever comes first

Months

3

6

9

12

15

18

21

24

27

30

33

36

×1000 km

5

10

15

20

25

30

35

40

45

50

55

60

Washer fluid level

I

I

I

I

I

I

Emergency flat tire repair kit (if installed)

*6

Inspect annually.

AIR CONDITIONER SYSTEM
Cabin air filter

R

R

R

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten

Remarks:

*

1 Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light

display.

*

2 Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may

cause serious damage to the engine and cooling system.

*

3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not

void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or kilometer period to ensure long-term reliability.

*

4 The Tire Pressure Monitoring System (TPMS) initialization must be performed so that the system operates

normally (if equipped).

*

5 If this component has been submerged in water, the oil should be replaced.

*

6 Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the

tire repair fluid bottle with new one before the expiration date.


(Cont.)

Maintenance Interval

Number of months or kilometers, whichever comes first

Months

39

42

45

48

51

54

57

60

63

66

69

72

×1000 km

65

70

75

80

85

90

95 100 105 110 115 120

ENGINE
Drive belts

I

I

Engine oil & filter

*1

R

R

R

R

R

R

R

R

R

R

R

R

COOLING SYSTEM
Cooling system

I

I

Engine coolant

*2

Replace at first 200,000 km or 10 years; after that, every

100,000 km or 5 years

Engine coolant level

I

I

I

I

I

I

I

I

I

I

I

I

FUEL SYSTEM
Air filter

C

R

C

R

C

R

Maintenance and Care

Scheduled Maintenance

6-13

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Maintenance Interval

Number of months or kilometers, whichever comes first

Months

39

42

45

48

51

54

57

60

63

66

69

72

×1000 km

65

70

75

80

85

90

95 100 105 110 115 120

Fuel lines and hoses

I

*3

I

Hoses and tubes for emission

I

*3

I

Fuel filter

Replace every 60,000 km

IGNITION SYSTEM

Spark plugs

I

I

I

I

I

I

Replace every 64,000 km

ELECTRICAL SYSTEM
Function of all lights

I

I

I

I

I

I

I

I

I

I

I

I

CHASSIS and BODY
Brake lines, hoses and connections

I

I

I

Brake and clutch fluid level

I

I

I

I

Brake fluid

R

R

Disc brakes

I

I

I

I

I

I

Tire (Rotation)

*4

Rotate every 10,000 km

Tire inflation pressure and tire wear

*4

I

I

I

I

I

I

Steering operation and linkages

I

I

I

I

I

I

Front and rear suspension, ball joints and wheel
bearing axial play

I

I

I

Rear differential oil

*5

Transfer oil

*5

Driveshaft dust boots

I

I

I

Bolts and nuts on chassis and body

T

T

T

Exhaust system and heat shields

I

I

I

All locks and hinges

L

L

L

L

L

L

Washer fluid level

I

I

I

I

I

I

Emergency flat tire repair kit (if installed)

*6

Inspect annually.

AIR CONDITIONER SYSTEM
Cabin air filter

R

R

R

Chart symbols:

I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten

Maintenance and Care

Scheduled Maintenance

6-14

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Remarks:

*

1 Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light

display.

*

2 Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may

cause serious damage to the engine and cooling system.

*

3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not

void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or kilometer period to ensure long-term reliability.

*

4 The Tire Pressure Monitoring System (TPMS) initialization must be performed so that the system operates

normally (if equipped).

*

5 If this component has been submerged in water, the oil should be replaced.

*

6 Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the

tire repair fluid bottle with new one before the expiration date.

Maintenance and Care

Scheduled Maintenance

6-15

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Maintenance Monitor

1. Select the   icon on the home screen to display the Applications screen.
2. Select “Vehicle Status Monitor”.
3. Select “Maintenance” to display the maintenance list screen.
4. Switch the tab and select the setting item you want to change.
You can customize settings in the setup display as follows:

Tab

Item

Explanation

Scheduled

Setting

Notification can be switched on/off.

Time (months)

Displays the time or distance until maintenance is due.
Select this item to set the maintenance period.
The wrench indication/indicator light in the instrument cluster
will be illuminated when the remaining distance is less than 1,000
km or 600 mile, or the remaining number of days is less than 15
(whichever comes first).

Distance (mile or km)

Reset

Resets the time and distance to the initial values.
Once the system turns on, it needs to be reset whenever carrying
out maintenance.

Tire Rotation

Setting

Notification can be switched on/off.

Distance (mile or km)

Displays the distance until tire rotation is due.
Select this item to set the tire rotation distance.
The wrench indication/indicator light in the instrument cluster
will be illuminated when the remaining distance is less than 1,000
km or 600 mile.

Reset

Resets the remaining distance to the initial value.
Once the system turns on, it needs to be reset whenever rotating
the tires.

Maintenance and Care

Scheduled Maintenance

6-16

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Tab

Item

Explanation

Oil Change

Setting Interval

Oil replacement period can be selected from the flexible setting
or fixed setting.
The flexible setting is available only in the United States and Pu‐
erto Rico. Once engine oil flexible maintenance is selected, the
vehicle calculates the remaining oil life based on the engine oper‐
ating conditions.
The vehicle lets you know when an oil change is due by illumi‐
nating the wrench indication/indicator light in the instrument
cluster.

Distance (mile or km)
(Displays only in fixed set‐
ting)

Displays the distance until the oil replacement is due.
Select this item to set the oil replacement distance.
The wrench indication/indicator light in the instrument cluster
will be illuminated when the remaining distance is less than 1,000
km or 600 mile.

Distance (mile or km)
(Displays only in flexible
setting)

Displays the distance until the oil replacement is due.
The wrench indication/indicator light in the instrument cluster
will be illuminated when the remaining distance is less than 1,000
km or 600 mile.

Reset

Resets the remaining distance to the initial value.
Once the system turns on, it needs to be reset whenever replacing
the engine oil.

Maintenance and Care

Scheduled Maintenance

6-17

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Owner Maintenance Precautions

The owner or a qualified service technician should make these vehicle inspections at the
indicated intervals to ensure safe and dependable operation.

Bring any problem to the attention of an Authorized Mazda Dealer or qualified service
technician as soon as possible.

When Refueling



Brake fluid level (page 6-27)



Engine coolant level (page 6-25)



Engine oil level (page 6-24)



Washer fluid level (page 6-27)

At Least Monthly



Tire inflation pressures (page 6-38)

At Least Twice a Year (For Example, Every Spring and Fall)

You can do the following scheduled maintenance items if you have some mechanical ability
and a few basic tools and if you closely follow the directions in this manual.



Engine coolant (page 6-25)



Engine oil (page 6-23)


Improper or incomplete service may result in problems. This section gives instructions only
for items that are easy to perform.

As explained in the Introduction (page 6-2), several procedures can be done only by a
qualified service technician with special tools.

Improper owner maintenance during the warranty period may affect warranty coverage.
Refer to Introduction (page 6-2) for owner's responsibility in protecting your investment.
For details, read the separate Mazda Warranty statement provided with the vehicle. If you
are unsure about any servicing or maintenance procedure, have it done by an Authorized
Mazda Dealer.

There are strict environmental laws regarding the disposal of waste oil and fluids. Please
dispose of your waste properly and with due regard to the environment.

We recommend that you entrust the oil and fluid changes of your vehicle to an Authorized
Mazda Dealer.

Maintenance and Care

Owner Maintenance

6-18

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

WARNING

Do not perform maintenance work if you lack sufficient knowledge and experience or the
proper tools and equipment to do the work. Have maintenance work done by a qualified
technician:
Performing maintenance work on a vehicle is dangerous if not done properly. You can be
seriously injured while performing some maintenance procedures.

If you must run the engine while working under the hood, make certain that you remove all
jewelry (especially rings, bracelets, watches, and necklaces) and all neckties, scarves, and
similar loose clothing before getting near the engine or cooling fan which may turn on
unexpectedly:
Working under the hood with the engine running is dangerous. It becomes even more
dangerous when you wear jewelry, loose clothing or have long hair or a long beard.
Either can become entangled in moving parts and result in injury.

Pull over to a safe location, then switch the ignition off and make sure the fan is not

running before attempting to work near the cooling fan:
Working near the cooling fan when it is running is dangerous. The fan could continue running
indefinitely even if the engine has stopped and the engine compartment temperature is high.
You could be hit by the fan and seriously injured.

Do not leave items in the engine compartment:
After you have finished checking or doing servicing in the engine compartment, do not forget
and leave items such as tools or rags in the engine compartment.
Tools or other items left in the engine compartment could cause engine damage or a fire
leading to an unexpected accident.

Maintenance and Care

Owner Maintenance

6-19

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Hood

WARNING

Always check that the hood is closed and
securely locked:
A hood that is not closed and securely
locked is dangerous as it could fly open
while the vehicle is moving and block the
driver's vision which could result in a
serious accident.

▼ Opening the Hood

1. With the vehicle parked, pull the

release handle to unlock the hood.


Release handle

2. Insert your hand into the hood

opening, slide the latch lever to the
right, and lift up the hood.


Lever

3. Grasp the support rod in the padded

area and secure it in the support rod
hole indicated by the arrow to hold the
hood open.


Pad

Support rod

Maintenance and Care

Owner Maintenance

6-20

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

▼ Closing the Hood

1. Check under the hood area to make

certain all filler caps are in place and
all loose items (e.g. tools, oil
containers, etc.) have been removed.

2. Lift the hood, grasp the padded area on

the support rod, and secure the support
rod in the clip. Verify that the support
rod is secured in the clip before closing
the hood.


Clip

Clip

Clip

3. Lower the hood slowly to a height of

about 20 cm (7.9 in) above its closed
position and then let it drop.

CAUTION

When closing the hood, do not push it
excessively such as by applying your
weight. Otherwise, the hood could be
deformed.

Maintenance and Care

Owner Maintenance

6-21

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Engine Compartment Overview

Engine oil dipstick

Brake fluid reservoir

Engine oil-filler cap

Fuse block

Battery

Cooling system cap

Engine coolant reservoir

Windshield washer fluid reservoir

Maintenance and Care

Owner Maintenance

6-22

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Engine Oil

NOTE
Changing the engine oil should be
performed by an Authorized Mazda
Dealer.
Refer to Introduction (page 6-2) for
owner's responsibility in protecting your
investment.

▼ Recommended Oil

U.S.A., Canada, and Puerto Rico

Use SAE 5W-30 engine oil.
Mazda Genuine Oil is used in your Mazda
vehicle. Mazda Genuine 5W-30 Oil is
required to achieve optimum fuel
economy.

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Castrol

®

 (U.S.A. only).





(ILSAC)

Only use SAE 5W-30 oil “Certified For
Gasoline Engines” by the American
Petroleum Institute (API).
Oil with this trademark symbol conforms
to the current engine and emission system
protection standards and fuel economy
requirements of the International
Lubricant Standardization and Approval
Committee (ILSAC), comprised of U.S.
and Japanese automobile manufacturers.


80

60

40

20

0

–40 –20

30

100

40

20

10

0

–10

–20

–30

–40

Maintenance and Care

Owner Maintenance

6-23

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

Except U.S.A., Canada, and Puerto Rico

Use SAE 5W-30 engine oil.
Oil container labels provide important
information.
A chief contribution this type of oil makes
to fuel economy is reducing the amount of
fuel necessary to overcome engine
friction.

For maintenance service, Mazda
recommends Mazda Genuine Parts and
Castrol

®

 (Mexico only).





(ILSAC)

(Mexico)
Use SAE 5W-30 engine oil. If SAE 5W-30
engine oil is not available, use SAE 0W-30
or SAE 10W-30 engine oil.

The quality designation SM or SN, or
ILSAC must be on the label.


80

60

40

20

0

–40 –20

30

100

40

20

10

0

–10

–20

–30

–40

▼ Vehicle Engine Control Unit Reset

Procedure

After replacing the engine oil, it is
recommended to have a repair shop such
as an Authorized Mazda Dealer perform
the initialization (engine oil data resetting)
of the recorded value. If the value
recorded by the computer is not initialized,
the wrench indicator light may not turn off
or it may turn on earlier than normal.
Refer to Maintenance Monitor on page
6-16.

▼ Inspecting Engine Oil Level

1. Be sure the vehicle is on a level

surface.

2. Warm up the engine to normal

operating temperature.

3. Turn it off and wait at least 5 minutes

for the oil to return to the oil pan.

Maintenance and Care

Owner Maintenance

6-24

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27

4. Pull out the dipstick, wipe it clean, and

reinsert it fully.


MAX

MIN

OK

5. Pull it out again and examine the level.

The level is normal if it is between the
MIN and MAX marks.
If it is near or below MIN, add enough
oil to bring the level to MAX.

CAUTION

Do not overfill the engine oil. This may
cause engine damage.

6. Make sure the O-ring on the dipstick is

positioned properly before reinserting
the dipstick.

7. Reinsert the dipstick fully.

Engine Coolant

▼ Inspecting Coolant Level

WARNING

Do not use a match or live flame in the
engine compartment. DO NOT ADD
COOLANT WHEN THE ENGINE IS HOT:
A hot engine is dangerous. If the engine has
been running, parts of the engine
compartment can become very hot. You
could be burned. Carefully inspect the
engine coolant in the coolant reservoir, but
do not open it.

Pull over to a safe location, then switch

the ignition off and make sure the fan is
not running before attempting to work
near the cooling fan:
Working near the cooling fan when it is
running is dangerous. The fan could
continue running indefinitely even if the
engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.

 Do not remove either cooling

system cap when the engine and radiator
are hot:
When the engine and radiator are hot,
scalding coolant and steam may shoot out
under pressure and cause serious injury.

Maintenance and Care

Owner Maintenance

6-25

CX-9_8HB2-EA-18G_Edition1

2018-5-11 13:09:27
