3. Remove the TCM. (See TCM REMOVAL/INSTALLATION [AW6A-EL, AW6AX-EL].)

4. Verify that continuity or resistance at terminal is as indicated in the terminal continuity/resistance table.



If there is any malfunction, inspect the parts under "Inspection item (s)".



If the system does not work properly even though the parts or related wiring harnesses do not
have any malfunction, replace the TCM. (See TCM REMOVAL/INSTALLATION
[AW6A-EL, AW6AX-EL].)

Fig. 38: Identifying Coupler Component
Courtesy of MAZDA MOTORS CORP.

Terminal Continuity/Resistance Table (Reference)

Fig. 39: Identifying Coupler Component & TCM Short Cord Connector (TCM Side)
Courtesy of MAZDA MOTORS CORP.

A14

CAN_H

PCM

serial communication,
good/no good judgment by
terminal voltage is not
possible. Carry out
inspection according to
DTCs.

-



Inspect related
harness



2008 Mazda CX-9 Grand Touring

2008 TRANSMISSION Automatic Transaxle (AW6A-EL, AW6AX-EL) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:29:30 AM

Page 37

© 2005 Mitchell Repair Information Company, LLC.

CONTINUITY RESISTANCE REFERENCE

Terminal

Signal

Connected

to

Test Condition

Continuity/Resistance

Inspection item

A9

System
GND

GND

Constant

Continuity



Inspect relate
harness

B1

Line
pressure
control
solenoid
control
GND

Line
pressure
control
solenoid



Inspect
resistance
between
couple
component
terminals
B3 and B1
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect line
pressure contr
solenoid (See
SOLENOID
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B2

Shift
solenoid B
control

Shift
solenoid B

ATF temperature: 20°C {68°
F}

11-15 (ohms)



Inspect sh

solenoid B

SOLENO

VALVE

INSPECTI

[AW6A-E

AW6AX-E



Inspect rela

harness

B3

Line
pressure
control
solenoid
control

Line
pressure
control
solenoid



Inspect
resistance
between
couple
component
terminals
B3 and B1
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect line
pressure contr
solenoid (See
SOLENOID
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B4

TCC control
solenoid
control
GND

TCC control
solenoid



Inspect
resistance
between
couple
component
terminals
B9 and B4
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect TCC
control soleno
(See SOLEN
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness



2008 Mazda CX-9 Grand Touring

2008 TRANSMISSION Automatic Transaxle (AW6A-EL, AW6AX-EL) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:29:30 AM

Page 38

© 2005 Mitchell Repair Information Company, LLC.

B5

Shift
solenoid A
control

Shift
solenoid A

ATF temperature: 20°C {68°
F}

11-15 (ohms)



Inspect sh

solenoid A

SOLENO

VALVE

INSPECTI

[AW6A-E

AW6AX-E



Inspect rela

harness

B7

TFT sensor
GND

TFT sensor



Inspect
resistance
between
couple
component
terminals
B7 and B8
(wiring
harness-
side).

ATF
temperature:
10°C {50°
F}

5.62-7.31 (kilohms)



Inspect TFT s
(See
TRANSAXL
FLUID
TEMPERAT
(TFT) SENS
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

ATF
temperature:
25°C {77°
F}

Approx. 3.5 (kilohms)

B8

TFT sensor

ATF
temperature:
110°C
{230°F}

0.22-0.27 (kilohms)

B9

TCC control
solenoid
control

TCC control
solenoid



Inspect
resistance
between
couple
component
terminals
B9 and B4
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect TCC
control soleno
(See SOLEN
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B10

Shift
solenoid C
control
GND

Shift
solenoid C



Inspect
resistance
between
couple
component
terminals
B11 and
B10
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect shift
solenoid C (S
SOLENOID
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B11

Shift
solenoid C
control

B12

Input/turbine
speed sensor



Inspect
input/turbine
sensor (See



2008 Mazda CX-9 Grand Touring

2008 TRANSMISSION Automatic Transaxle (AW6A-EL, AW6AX-EL) - Mazda CX-9



Microsoft



Sunday, November 15, 2009 10:29:30 AM

Page 39

© 2005 Mitchell Repair Information Company, LLC.

(-)

Input/turbine
speed sensor



Inspect for continuity
between couple
component terminals
B12 and B13 (wiring
harness-side).

Continuity

INPUT/TUR
SPEED SEN
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B13

Input/turbine
speed sensor
(+)

B14

Shift
solenoid E
control

Shift
solenoid E



Inspect
resistance
between
couple
component
terminals
B14 and
B22
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect shift
solenoid E (S
SOLENOID
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B16

Shift
solenoid F
control
GND

Shift
solenoid F



Inspect
resistance
between
couple
component
terminals
B21 and
B16
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect shift
solenoid F (Se
SOLENOID
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B17

Shift
solenoid D
control

Shift
solenoid D



Inspect
resistance
between
couple
component
terminals
B17 and
B18
(wiring
harness-
side).

ATF
temperature:
20°C {68°
F}

5.0-5.6 (ohms)



Inspect shift
solenoid D (S
SOLENOID
VALVE
INSPECTIO
[AW6A-EL,
AW6AX-EL]



Inspect relate
harness

B18

Shift
solenoid D
control
GND

B19

Vehicle
speed (-)

VSS



Inspect for continuity
between couple
component terminals

Continuity



Inspect VSS (
VEHICLE
SPEED SEN
(VSS)
INSPECTIO
