SECURITY AND LOCKS [KEYLESS ENTRY SYSTEM]
09–14B–1
09–14B
09–14B SECURITY AND LOCKS [KEYLESS ENTRY
SYSTEM]
SECURITY AND LOCKS OUTLINE . . . . 09–14B–1
Features . . . . . . . . . . . . . . . . . . . . . . . . 09–14B–1
KEYLESS ENTRY SYSTEM OUTLINE. . 09–14B–1
KEYLESS ENTRY SYSTEM
STRUCTURAL VIEW . . . . . . . . . . . . . . . 09–14B–2
KEYLESS ENTRY SYSTEM
WIRING DIAGRAM . . . . . . . . . . . . . . . . . 09–14B–3
End of Toc
SECURITY AND LOCKS OUTLINE
EHU091400001104
Features
End Of Sie
KEYLESS ENTRY SYSTEM OUTLINE
EHU091466000107
•
The following operations can be performed using the transmitter when away from the vehicle (approx. 2.5 m
{8.2 ft}):
—
Lock all doors (by pressing the LOCK button).
—
Unlock the driver-side door (by pressing the UNLOCK button one time).
—
Unlock the driver and passenger-side doors (by pressing the UNLOCK button two times within 5 s).
—
Unlock the trunk lid (by pressing the TRUNK LID button). (When the trunk lid opener cancel switch is at the
ON position, the trunk lid does not unlock even when the TRUNK LID button is pressed.)
—
Alarm (by pressing the PANIC button). (Cancelled by pressing any transmitter button, inserting the key into
the steering lock, or after 5 min.)
•
When the transmitter LOCK button is pressed two times within 5 s, the horn sounds once to indicate that all
doors are locked.
•
An auto-locking device has been adopted that automatically locks the doors if any of the following operations
are not performed within 30 s of pressing the transmitter UNLOCK button:
—
Any door is opened.
—
The door is lock/unlock using the door key cylinder.
—
The door is lock/unlock using the door lock switch.
—
The key is inserted the steering lock.
•
In order to prevent accidental operation when driving, pushing any transmitter button will have no affect when
the key is inserted into the steering lock.
End Of Sie
Improved marketability
•
Keyless entry system modified
Improved theft-
deterrence
