00–00–6

GENERAL INFORMATION

Body Dimensions (Straight-line Dimensions)

• Straight-line dimensions are the actual dimensions between two standard points.

• When there are no specific indications, the standard points and dimensions are symmetrical in regard to the

center of the vehicle.

817

FRONT FENDER INSTALLATION NUT

STRAIGHT-LINE DIMENSIONS

{32.17}

DPE2010B011

GENERAL INFORMATION

00–00–7

00

Example

Symbols of Body Dimensions

• The following 8 symbols are used to indicate the standard points.

End Of Sie

1,128

{44.41}

A

B

C

H

D

I

E

F

G

1,398

{55.04}

1,406

{55.35}

{42.01}

1,067

799

{31.46}

1,263

{49.72}

1,048

{41.26}

{33.50}

A

F

G

B

H

I

C

D

E,E'

Fr

Fr

Fr

Fr

Fr

Fr

Fr

Fr

Fr

Front pillar inner designation

Front pillar inner designation

Front floor pan designation

Adjuster installation hole

Trim installation hole
Harness installation hole

Chaker bracket installation hole

Chaker bracket installation hole

A

B

C

D

E

F
G

H

I

f16

f17

f16

M14

f31

f12

f16

f18

17 ´ 29.5

Harness installation hole

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}

Point

symbol

Designation

Hole diameter

or bolt or nut

size mm {in}

Shows bolt size

Shows hole diameter

Shows
slot

851

ROOM STRAIGHT-LINE DIMENSIONS (1)

Shows vehicle section

Shows dimension location

Shows outline drawing

Shows point
symbol

Shows point indication
Without apostrophe:RH

With apostrophe:LH

Shows details of the standard
point location

Shows position and shape of the points

Shows dimension

No indication are shown
within the outline drawing.

DPE2010B004

SYMBOL

MEANING

SYMBOL

MEANING

Center of circular hole

Center elliptical hole

Notch

Panel seam, bead, etc.

Bolt tip

(arrow only)

Center of rectangular-shaped hole

Edge of rectangular-shaped hole

MZZ2010B016

00–00–8

GENERAL INFORMATION

SERVICE PRECAUTIONS

DPE000000000B02

Arrangement of Workshop

• Arrangement of the workshop is important for safe and efficient work.

Safety Precautions

• Protective head covering and safety shoes should

always be worn. Depending upon the nature of
the work, gloves, safety glasses, ear protectors,
face shield, etc., should also be used.

Vehicle Protection

• Use seat covers and floor covers.

• Use heat-resistant protective covers to protect glass areas and seats from heat or sparks during welding.

• Protect items such as moldings, garnishes, and

ornaments with tape when welding.

Remove Dangerous Articles

• Remove the fuel tank before using an open flame

in that area. Plug connection piping to prevent
fuel leakage.

Use of Pulling Equipment

• When using pulling equipment, keep away from

the pulling area and use safety wires to prevent
accidents.

Welding
glasses

Ear
protectors

Weldlng
gloves

Cotton
gloves

Dust mask Safety glasses

Face shield

Safety shoes

MZZ2036B001

MZZ2036B002

MZZ2036B003

Safety wires

MZZ2036B004

GENERAL INFORMATION

00–00–9

00

Prevent Short Circuits

• Turn the ignition switch to the LOCK position.

• Disconnect the battery cables.

• Securely connect the welding machine ground

near the welding area.

End Of Sie

EFFICIENT REMOVAL OF BODY PANELS

DPE000000000B03

Body Measurements

• Before removal or rough-cutting, first measure the

body at and around the damaged area against
the standard reference dimension specifications.
If there is deformation, use frame repair
equipment to make a rough correction.

Prevention of Body Deformation

• Use a clamp or a jack for removal and reinforce at

and around the rough-cutting location to prevent
deforming of the body.

Battery cable

MZZ2036B005

Ground

MZZ2036B006

MZJ2038B001

MZJ2038B002
