TECHNICAL DATA
05–50–3
05
End Of Sie
Spring and retainer component
—
17.2 {0.677}
—
—
3-4 clutch
Spring and retainer component
—
17.2 {0.677}
—
—
Band servo
Servo return spring
34.0 {1.340}
36.4 {1.430}
2.5
4.0 {0.160}
Control valve body
Low and reverse shift valve spring
8.7 {0.343}
31.3 {1.232}
9.0
0.8 {0.031}
Solenoid reducing valve spring
8.7 {0.343}
44.2 {1.740}
16.0
1.1 {0.043}
Pressure regulator valve spring
7.9 {0.311}
36.3 {1.429}
13.2
0.9 {0.035}
Solenoid shift valve spring
8.3 {0.327}
35.1 {1.382}
12.0
0.6 {0.024}
Converter relief valve spring
9.0 {0.354}
42.5 {1.673}
14.2
1.3 {0.051}
Torque converter clutch control valve spring
8.7{0.343}
31.3 {1.232}
9.0
0.8 {0.031}
Bypass valve spring
8.7{0.343}
31.3 {1.232}
9.0
0.8 {0.031}
3-4 shift valve spring
8.7{0.343}
31.3 {1.232}
9.0
0.8 {0.031}
Pressure modifier accumulator spring
11.0 {0.433}
23.0 {0.906}
6.6
1.5 {0.059}
Spring name
Outer diameter
(mm {in})
Free length (mm
{in})
No. of coils
Wire diameter
(mm {in})
Accumulators
