Jaguar X-Type Sedan and Estate (Wagon). Manual

Published: 11-May-2011

Cellular Phone - Cellular Phone

Description and Operation

CELLULAR PHONE - UP TO 2006MY

The portable cellular phone system consists of:

Cellular phone handset (GSM).
Cradle (GSM).
Cellular portable (US Only).
Handset battery (US Only).
Hang up cup (US Only).
Roof console mounted microphone.
Steering wheel switch controls.
Portable support electronics (PSE) module (US Only).
Transceiver (GSM).
In-bumper cellular phone antenna.
Antenna cable.
Audio unit controls.

The cellular phone handset is located within the floor console armrest. The audio control unit and the steering wheel controls are utilized to
operate the system.

The vehicle utilizes two unique cellular phones systems:

GSM
US CDMA/TDMA digital and AMPS analogue systems

The voice activation control module provides the handsfree operation for cellular phone.

To activate the handsfree function:

1. Switch the ignition to the RUN position. After 4-6 seconds the system will be initialized and "VOICE READY" will be displayed in

the message center.

2. Operate the VOICE/PHONE switch on the steering wheel.

3. Clearly state the command when "LISTENING" is displayed in the message center.

4. Operate the VOICE/PHONE switch on the steering wheel or remain silent for 1 second. If speech is detected "PROCESSING" will be

displayed in the message center. Operating the VOICE/PHONE switch again will cancel the voice session.

Refer to the Cellular Phone user guide for complete operating instructions.

For additional information on the voice activation control module, refer to
For additional information, refer to:

Module Controlled Functions

(419-10 Multifunction Electronic Modules, Description and Operation).

CELLULAR PHONE - FROM 2006MY - UP TO 2009MY

The system allows the driver to use a Bluetooth™ equipped cellular phone handset through the vehicle's Information and Entertainment
system. Bluetooth™ is an international standard that allows electronic components to communicate with each other, using a short-range
radio link. Bluetooth eliminates the need for wires or cables: typically, devices can communicate at a range of up to 10 metres (33 feet).
Bluetooth™ is a registered trademark of Bluetooth SIG, Inc.

The Bluetooth™ system is as described in the following section for vehicles from 2009MY with the exception that only 1 telephone can be
paired with the system and the Bluetooth™ antenna is located in the floor console.

Telephone Voice Control

The vehicle system is able to use any voice tags which are stored in the mobile telephone. There is no voice dialling feature of the cellular
telephone system. Voice dialling is accessed via a long press of the voice button on the

LH (left-hand)

side of the steering wheel. The audio

unit displays that Voice Tag dialling is in progress and an audible prompt is generated from the Bluetooth™ phone module. After the prompt
the handset waits several seconds for the voice command. Refer to the Owners Handbook for further details on voice operation.

CELLULAR PHONE - FROM 2009MY

The system allows the driver to use a Bluetooth™ equipped cellular phone handset through the vehicles Information and Entertainment
system. Bluetooth™ is an international standard that allows electronic components to communicate with each other, using a short-range
radio link. Bluetooth eliminates the need for wires or cables: typically, devices can communicate at a range of up to 10 metres (33 feet).
Bluetooth™ is a registered trademark of Bluetooth SIG, Inc.

The Bluetooth in-car telephone system allows certain mobile phones to be used hands-free in your vehicle: there is no need to connect the
mobile phone to a cradle or cable. The vehicle’s Bluetooth telephone system can be used with an appropriate, Bluetooth™ equipped mobile
phone. The mobile phone must be paired with the vehicle system before use - Refer to the Owners Handbook for details.

• NOTE: There is no physical connection (cradle) between the phone handset and the telephone control module. Communications between
the 2 components are purely Bluetooth™. This can limit the available functions dependant on the handset used.

Once paired, the mobile phone can be operated via the steering wheel switches or the keypad and phone buttons on the audio panel or
touch-screen. The mobile phone doesn’t need to be physically connected to the vehicle: it can be left in a jacket pocket, for instance. Calls
are routed through the vehicle’s audio speakers, and a dedicated microphone is fitted in the overhead console, near the driver’s head.

The system can be used to answer or reject incoming calls, make outgoing calls or alter the call volume. The system does not support Short
Message Service (SMS) text messages. The vehicle starter switch must be set to position I or II in order to use the phone.

The volume of telephone calls can be adjusted for hands-free phone operation. To adjust the volume, operate the audio system’s ON/OFF
volume control on the steering wheel or audio unit during a phone call. If the audio system is in use when the phone becomes active, the
audio system source is suppressed for the duration of the call. The Jaguar telephone system is designed to function with a wide variety of
Bluetooth™ equipped mobile phones. The audio and echo characteristics vary between models of mobile phones: as a result, it may take a
few seconds for the vehicle system to adapt to provide optimal audio performance. In order to achieve the best possible audio performance,
