Index Jaguar Jaguar X-Type Sedan and Estate (Wagon) (2.0 L, 2.5 L and 3.0 L Gasoline; 2.0 L and 2.2 L, Diesel) - manual 2001-2009 year
|
|
Published: 11-May-2011 Rear Drive Axle/Differential - Drive Pinion Flange In-vehicle Repair Special Tool(s) Torque To Turn Rotary Tool 205-518 Wrench, Flange 205-053 Remover, Flange Plate 204-295 Remover, Flange Boss 204-266 Remover, Flange Shaft 204-268A Installer, Oil Seal 204-264 Removal 1. CAUTION: The following step must be carried out to make sure the correct drive pinion flange retaining nut torque is achieved. Remove the rear brake pads. Brake Pads (206-04 Rear Disc Brake, Removal and Installation). 2. Remove the driveshaft. For additional information, refer to: Driveshaft (205-01 Driveshaft, Removal and Installation). 3. Remove the vibration damper. |
