7A–84
AUTOMATIC TRANSMISSION (4L30–E)
ILLUSTRATION
TOOL NO.
TOOL NAME
5–8840–2268–0
(J–38588)
Guide pins; adapter
case to main case
5–8840–2269–0
(J–38555)
Overrun clutch piston
seal installer set
5–8840–2270–0
(J–3387–2)
Guide pins; gasket and
transfer plate to valve
body
5–8840–2271–0
(J–25022)
Turbine shaft puller (Use
with 5–8840–0618–0
(J–24773–1))
5–8840–0196–0
(J–23129)
Oil seal remover (Use
with 5–8840–2266–0
(J–23907) and
5–8840–0019–0
(J–38584))
5–8840–2272–0
(J–38557)
Oil pump centering tool
ILLUSTRATION
TOOL NO.
TOOL NAME
5–8840–2273–0
(J–23082–01)
Oil pump rotation tool
5–8840–0022–0
(J–25025–B)
Guide pins; valve body
to main case
5–8840–2274–0
(J–38428)
Servo piston fitter
5–8840–2275–0
(J–23327–91)
Overrun clutch spring
compressor
5–8840–2277–1
(J–38559–A)
3/4 Accumulator piston
cover compressor
5–8840–2278–0
(J–8763–02)
Holding fixture
