PCS-118

< ECU DIAGNOSIS >

[POWER DISTRIBUTION SYSTEM]

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)

This operation status can be confirmed on the IPDM E/R “Data Monitor” that displays “BLOCK” for the item
“WIP PROT” while the wiper is stopped.

STARTER MOTOR PROTECTION FUNCTION

IPDM E/R turns OFF the starter control relay to protect the starter motor when the starter control relay remains
active for 90 seconds.

DTC Index

INFOID:0000000000964256

*1: Only for the models with AFS

*2: Only for the models without AFS (The display is fixed to CRNT until the self-diagnosis results are erased when the malfunctions were
found in the past.)

NOTE:
The details of TIME display are as follows.
• CRNT: The malfunctions that are detected now
• 1 - 39: The number is indicated when it is normal at present and a malfunction was detected in the past. It

increases like 0

→

2 · · · 38

→

39 after returning to the normal condition whenever IGN OFF

→

ON. It is

fixed to 39 until the self-diagnosis results are erased if it is over 39. It returns to 0 when a malfunction is
detected again in the process.

CONSULT display

Fail-safe

TIME

NOTE

Refer to

No DTC is detected.
further testing
may be required.

—

U1000: CAN COMM CIRCUIT

CRNT

1 –39

PCS-15

CRNT

B2098: IGN RELAY ON

CRNT

1 – 39

PCS-16

B2099: IGN RELAY OFF

—

CRNT

1 – 39

PCS-17

B2108: STRG LCK RELAY ON

—

CRNT

1 – 39

SEC-89

B2109: STRG LCK RELAY OFF

—

CRNT

1 – 39

SEC-90

B210A: STRG LCK STATE SW

—

CRNT

1 – 39

SEC-91

B210B: START CONT RLY ON

—

CRNT

1 – 39

SEC-95

B210C: START CONT RLY OFF

—

CRNT

1 – 39

SEC-96

B210D: STARTER RELAY ON

—

CRNT

1 – 39

SEC-97

B210E: STARTER RELAY OFF

—

CRNT

1 – 39

SEC-98

B210F: INTRLCK/PNP SW ON

—

CRNT

1 – 39

SEC-100

B2110: INTRLCK/PNP SW OFF

—

CRNT

1 – 39

SEC-104

PCS

POWER DISTRIBUTION SYSTEM SYMPTOMS

PCS-119

< SYMPTOM DIAGNOSIS >

[POWER DISTRIBUTION SYSTEM]

SYMPTOM DIAGNOSIS

POWER DISTRIBUTION SYSTEM SYMPTOMS

Symptom Table

INFOID:0000000000964257

Before performing the diagnosis in the following table, check the contents of

PCS-35, "Work Flow"

Symptom

Suspect Systems

Refer to

The power supply changing operation is normal. But the
push-button ignition switch position indicator does not turn
on.

1. Check push-button ignition switch position indicator.

PCS-68

2. Check Intermittent Incident.

GI-39

PCS-120

< ON-VEHICLE MAINTENANCE >

[POWER DISTRIBUTION SYSTEM]

PRE-INSPECTION FOR DIAGNOSTIC

ON-VEHICLE MAINTENANCE

PRE-INSPECTION FOR DIAGNOSTIC

Basic Inspection

INFOID:0000000000964258

The engine start function, door lock function, power distribution system and NATS-IVIS/NMS in the Intelligent
Key system are closely related to each other regarding control. Narrow down the functional area in question
by performing basic inspection to identify which function is malfunctioning. The vehicle security function can
operate only when the door lock and power distribution system are operating normally. Therefore, it is easy to
identify any factor unique to the vehicle security system by performing the vehicle security operation check
after basic inspection.

CHECK DOOR LOCK OPERATION

Check the door lock for normal operation with the Intelligent Key controller and door request switch.
Successful door lock operation with the Intelligent Key and request SW indicates that the remote keyless
entry receiver and inside key antenna required for engine start are functioning normally.
Identify the malfunctioning point by referring to the DLK section if the door cannot be unlocked.

Can the door be locked with the Intelligent Key and door request switch?

YES

>> GO TO 2.

>> Refer to

DLK-167, "Symptom Table"

CHECK ENGINE STARTING

Checks that the engine starts when operating the Intelligent Key inserted into the key slot.

Does the engine start?

YES

>> GO TO 3.

>> Refer to

SEC-201, "Symptom Table"

CHECK STEERING LOCKING

Does the steering lock when operating door switch after switching the power supply from ON position (or
ACC position) to LOCK position?
If door switch is malfunctioning, BCM cannot lock the steering. If BCM does not detect DTC, steering lock
unit is normal.

Does steering lock?

YES

>> GO TO 4.

>> Refer to

DLK-65, "Component Function Check"

CHECK POWER SUPPLY INDICATOR SWITCHING

Press push-button ignition switch and position indicator will switch from LOCK, ACC to ON gradually
when steering is locked. Checks that the position indicator is illuminated at different positions of the circuit.

Is each position indicator illuminating?

YES

>> GO TO 5.

>> Refer to

PCS-68, "Component Function Check"

CHECK VEHICLE SECURITY SYSTEM

Check the vehicle security system for normal operation.
The vehicle security function can operate only when the door lock and power distribution functions are
operating normally.
Therefore, it is easy to identify any factor unique to the vehicle security by performing the vehicle security
operation check after this basic inspection.

>> Go to

SEC-204, "Vehicle Security Operation Check"
