PCS-110 < ECU DIAGNOSIS > [POWER DISTRIBUTION SYSTEM] IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) * 1 : Only for the models with ICC system * 2 : M/T models only 86 (W) Ground Front fog lamp (RH) Output Lighting • Front fog lamp switch ON • Daytime running light activated (Only for Can- Battery voltage Front fog lamp switch OFF 0 V 87 (L) Ground Front fog lamp (LH) Output Lighting • Front fog lamp switch ON • Daytime running light activated (Only for Can- Battery voltage Front fog lamp switch OFF 0 V 88 (G) Ground Washer pump power sup- Output Ignition switch ON Battery voltage 89 (BR) Ground Headlamp HI (RH) Output Ignition • Lighting switch HI Battery voltage Lighting switch OFF 0 V 90 (P) Ground Headlamp HI (LH) Output Ignition • Lighting switch HI Battery voltage Lighting switch OFF 0 V 91 (P) Ground Parking lamp (RH) Output Ignition Lighting switch 1ST Battery voltage Lighting switch OFF 0 V 92 (O) Ground Parking lamp (LH) Output Ignition Lighting switch 1ST Battery voltage Lighting switch OFF 0 V 97 (V) Ground Cooling fan control Output Engine idling 0 - 5 V 104 (LG) Ground Hood switch Input Close the hood Battery voltage Open the hood 0 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + − |
