All rights reserved. No part
of this Service Manual may
be reproduced or stored in a
retrieval system, or transmit-
ted in any form, or by any
means, electronic, mechani-
cal, recording or otherwise,
without the prior written per-
mission of Nissan Motor
Company Ltd., Tokyo, Japan.

Edition: November 2007
Publication No. SM8E-1J50U0

This manual contains maintenance and repair procedure for the 2008
INFINITI EX35.

In order to assure your safety and the efficient functioning of the vehicle,
this manual should be read thoroughly. It is especially important that the
PRECAUTIONS in the GI section be completely understood before starting
any repair task.

All information in this manual is based on the latest product information
at the time of publication. The right is reserved to make changes in specifi-
cations and methods at any time without notice.

IMPORTANT SAFETY NOTICE

The proper performance of service is essential for both the safety of
the technician and the efficient functioning of the vehicle.
The service methods in this Service Manual are described in such a
manner that the service may be performed safely and accurately.
Service varies with the procedures used, the skills of the technician
and the tools and parts available. Accordingly, anyone using service
procedures, tools or parts which are not specifically recommended
by NISSAN must first be completely satisfied that neither personal
safety nor the vehicle’s safety will be jeopardized by the service
method selected.

QUICK REFERENCE CHART EX35

PFP:00000

ENGINE TUNE-UP DATA (VQ35HR)

ELS0003W

Engine model

VQ35HR

Firing order

1-2-3-4-5-6

Idle speed
A/T (In “N” position)

rpm

650

Ignition timing
(BTDC at idle speed)

(without 4WAS)

(with 4WAS)

CO% at idle

0.7 - 9.9 % and engine runs smoothly

Tensions of drive belts

Auto adjustment by auto tensioner

Radiator cap relief pressure

kPa (kg/cm

, psi)

Standard

122.3 - 151.7 (1.2 - 1.5, 18 - 22)

Limit

107 (1.1, 16)

Cooling system leakage testing pressure

kPa (kg/cm

, psi)

157 (1.6, 23)

Compression pressure

kPa (kg/cm

, psi)/rpm

Standard

1,275 (13.0, 185)/300

Minimum

981 (10.0, 142)/300

Differential limit between cylinders

98 (1.0, 14)/300

Spark plug
(Iridium-tipped type)

Make

DENSO

Standard type

FXE22HR11

Gap (Nominal) mm (in)

1.1 (0.043)

2008

QUICK REFERENCE CHART EX35

FRONT WHEEL ALIGNMENT

ELS0003X

2WD

Measure value under unladen* conditions.
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.

AWD

Measure value under unladen* conditions.

*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.

Item

Standard

Camber
Degree minute (Decimal degree)

Minimum

–0

′

(–0.66

)

Nominal

′

(0.08

)

Maximum

′

(0.83

)

Left and right difference

′

(0.55

) or less

Caster
Degree minute (Decimal degree)

Minimum

′

(3.50

)

Nominal

′

(4.25

)

Maximum

′

(5.00

)

Left and right difference

′

(0.65

) or less

Kingpin inclination
Degree minute (Decimal degree)

Minimum

′

(6.09

)

Nominal

′

(6.83

)

Maximum

′

(7.58

)

Total toe-in

Distance

Minimum

0 mm (0 in)

Nominal

In 1 mm (0.04 in)

Maximum

In 2 mm (0.08 in)

Angle (Left wheel or right wheel)
Degree minute (Decimal degree)

Minimum

00 (0.00

)

Nominal

In 0

′

″

(0.04

)

Maximum

In 0

′

″

(0.08

)

Camber
Degree minute (Decimal degree)

Minimum

–1

′

(–1.08

)

Nominal

–0

′

(–0.33

)

Maximum

′

(0.42

)

Left and right difference

′

(0.55

) or less

Caster
Degree minute (Decimal degree)

Minimum

′

(3.42

)

Nominal

′

(4.17

)

Maximum

′

(4.91

)

Left and right difference

′

(0.65

) or less

Kingpin inclination
Degree minute (Decimal degree)

Minimum 6

′

(6.58

)

Nominal

′

(7.33

)

Maximum

′

(8.08

)

Total toe-in

Distance

Minimum

0 mm (0 in)

Nominal

In 1 mm (0.04 in)

Maximum

In 2 mm (0.08 in)

Angle (Left wheel or right wheel)
Degree minute (Decimal degree)

Minimum

′

(0.00

)

Nominal

In 0

′

″

(0.04

)

Maximum

In 0

′

″

(0.08

)

2008
