WARNING
Information
The steering wheel may not be
For more details on setting the
assisted if the steering wheel is held
functions in the infotainment system
very tight or the steering wheel is
Vehicle Settings, refer to “Vehicle
steered over a certain degree.
Settings” section in chapter 4.
Lane Keeping Assist does not operate
When lane markings (or road edges)
at all times. It is the responsibility of
are detected, the lane lines on the
the driver to safely steer the vehicle
cluster will change from grey to white
and to maintain the vehicle in its
and the green
indicator light will
lane.
illuminate.
The hands-off warning message
Lane undetected
Lane detected
may appear late depending on road
conditions. Always have your hands
on the steering wheel while driving.
If the steering wheel is held very
lightly, the hands-off warning
message may appear because Lane
Keeping Assist may not recognize
that the driver has their hands on the
steering wheel.
If you attach objects to the steering
OCN7N071140L
OCN7N071141L
wheel, the hands-off warning may
not work properly.
The images and colors in the
instrument cluster may differ
depending on the cluster type or theme
selected from the instrument cluster.
Even though the steering is assisted by
Lane Keeping Assist, the driver may
control the steering wheel.
The steering wheel may feel heavier
or lighter when the steering wheel is
assisted by Lane Keeping Assist than
when it is not.
7-17

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Lane Keeping Assist Malfunction
- The lane marking (or road edge) is
indistinct or damaged
and Limitations
- The shadow is on the lane marking
Lane Keeping Assist malfunction
(or road edge) by a median strip,
trees, guardrail, noise barriers, etc.
- The number of lanes change or the
lanes merge
There are more than two lane
markings (or road edges) on the road
The lane markings (or road edges) are
complicated or a structure substitutes
for the lines, such as a construction
area
There are road markings, such as
OTM070035N
zigzag lanes, crosswalk markings and
When Lane Keeping Assist is not working
road signs
properly, the ‘Check Lane Keeping Assist
The lane suddenly disappears, such as
(LKA) system’ warning message will
at the intersection
appear and the yellow
indicator
The lane (or road width) is very wide
light will illuminate on the cluster. If this
or narrow
occurs, have the vehicle inspected by an
authorized HYUNDAI dealer.
There is a road edge without a lane
There is a boundary structure in the
Limitations of Lane Keeping Assist
roadway, such as a tollgate, sidewalk,
Lane Keeping Assist may not operate
curb, etc.
properly or may operate unexpectedly
The distance to the front vehicle is
under the following circumstances:
extremely short or the vehicle in front
• The lane is contaminated or difficult
is covering the lane marking (or road
to detect:
edge)
- The lane markings (or road edge)
are covered with rain, snow, dirt,
Information
oil, etc.
For more details on the limitations of the
- The color of the lane marking (or
front view camera, refer to “Forward
road edge) is not distinguishable
Collision-Avoidance Assist (FCA)” section
from the road
in chapter 7.
- There are markings (or road
edges) on the road near the lane
or the markings (or road edges) on
the road look similar to the lane
markings (or road edge)
7-18

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
If any other system’s warning
WARNING
message is displayed or audible
Take the following precautions when
warning is generated, Lane Keeping
using Lane Keeping Assist:
Assist warning message may not be
The driver has the responsibility to
displayed and audible warning may
safely drive and control the vehicle,
not be generated.
and should not solely rely on Lane
You may not hear the warning
Keeping Assist
sound of Lane Keeping Assist if the
The operation of Lane Keeping
surrounding is noisy.
Assist can be cancelled or not
If you attach objects to the steering
work properly depending on road
wheel, steering may not be assisted
conditions and surroundings. Always
properly.
be cautious while driving.
Lane Keeping Assist may not operate
Refer to “Limitations of Lane Keeping
for 15 seconds after the vehicle is
Assist” if the lane is not detected
started, or the front view camera is
properly.
initialized.
When you are towing a trailer or
Lane Keeping Assist will not operate
another vehicle, we recommend that
when:
Lane Keeping Assist is turned off due
- The turn signal or hazard warning
to safety reasons.
flasher is turned on
If the vehicle is driven at high speed,
- The vehicle is not driven in the
the steering wheel will not be
center of the lane when Lane
controlled. The driver must always
Keeping Assist is turned on or right
follow the speed limit when using
after changing a lane
Lane Keeping Assist.
- ESC (Electronic Stability Control)
or VSM (Vehicle Stability
Management) is activated
- The vehicle is driven on a sharp
curve
- The vehicle speed is below 35 mph
(55 km/h) or above 130 mph (210
km/h)
- The vehicle makes sharp lane
changes
- The vehicle brakes suddenly
7-19

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
BLIND-SPOT COLLISION-AVOIDANCE ASSIST (BCA)
(IF EQUIPPED)
Blind-Spot Collision-Avoidance Assist
is designed to help detect and monitor
approaching vehicles in the driver’s
blind spot area and warn the driver
of a possible collision with a warning
message and audible warning.
In addition, if there is a risk of collision
when changing lanes or driving forward
out of a parking space, Blind-Spot
Collision-Avoidance Assist can help avoid
a collision by applying the brake.
OHY059002
Blind-Spot Collision-Avoidance Assist
helps detect and informs the driver that
a vehicle is approaching at high speed
from the blind spot area.
CAUTION
Warning timing may vary depending on
the speed of the vehicle approaching at
high speed.
OCN7N071096L
Blind-Spot Collision-Avoidance Assist
helps detect and inform the driver that a
vehicle is in the blind spot.
CAUTION
The detecting range may vary
depending on the speed of your
vehicle. Even if there is a vehicle in the
blind spot area, Blind-Spot Collision-
Avoidance Assist may not warn you
OCN7N071154N
when you pass by at high speeds.
When changing lanes by detecting
the lane ahead, if Blind-Spot Collision-
Avoidance Assist judges that there is a
collision risk with an approaching vehicle
in the blind spot, it can help avoid a
collision by applying the brake.
7-20

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
CAUTION
Take the following precautions to
maintain optimal performance of the
detecting sensor:
Never disassemble the rear corner
radar or radar assembly, or cause any
damage to it.
If the rear corner radar or near
the radar has been damaged or
impacted in any way even though the
OHY059004
warning message does not appear
When you are driving forward out of a
on the cluster, Blind-Spot Collision-
parking space, if Blind-Spot Collision-
Avoidance Assist may not operate
Avoidance Assist judges that there is a
properly. Have the vehicle inspected
collision risk with an approaching vehicle
by an authorized HYUNDAI dealer.
in the blind spot, it can help avoid a
If the rear corner radars have been
collision by applying the brake.
replaced or repaired, have the
vehicle inspected by an authorized
Detecting sensor
HYUNDAI dealer.
Use only genuine HYUNDAI parts to
repair the rear bumper where the
rear corner radar is located.
Do not apply license plate frame or
objects, such as a bumper sticker,
film or a bumper guard near the rear
corner radar.
Blind-Spot Collision-Avoidance
Assist may not work properly if the
bumper has been replaced, or the
surroundings of the rear corner radar
OCN7N071001N
have been damaged or paint has
been applied.
If a trailer, carrier, etc., is installed,
it may adversely affect the
performance of the rear corner radar
or Blind-Spot Collision-Avoidance
Assist may not operate.
OCN7N071127N
[1] : Front view camera,
[2] : Rear corner radar
Refer to the picture above for the
detailed location of the detecting
sensors.
7-21

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Information
For more details on the precautions of
the front view camera, refer to “Forward
Collision-Avoidance Assist (FCA)” section
in chapter 7.
Blind-Spot Collision-Avoidance
Assist Settings
Setting features
OTM070097N
When the engine is restarted with Blind-
Spot Collision-Avoidance Assist off,
the ‘Blind-Spot Safety System is Off’
message will appear on the cluster.
If you change the setting from ‘Off’ to
‘Active Assist’ or ‘Warning Only’, the
warning light on the side view mirror will
blink for three seconds.
In addition, if the engine is turned on,
OCN7N071097N
when Blind-Spot Collision-Avoidance
Blind-Spot Safety
Assist is set to ‘Active Assist’ or ‘Warning
Only’, the warning light on the side view
With the engine on, select or deselect
mirror will blink for three seconds.
‘Driver Assistance → Blind-Spot Safety’
from the Settings menu to set whether or
not to use each function.
- If ‘Active Assist’ is selected, Blind-Spot
Collision-Avoidance Assist will warn
the driver with a warning message, an
audible warning and braking assist will
be applied depending on the collision
risk levels.
- If ‘Warning Only’ is selected, Blind-
Spot Collision-Avoidance Assist
will warn the driver with a warning
message, an audible warning
depending on the collision risk levels.
Braking will not be assisted.
- If ‘Off’ is selected, Blind-Spot
Collision-Avoidance Assist will turn
off.
7-22

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Driving Safety Auto Off in N mode
OCN7N071091L
OCN7N071090L
Warning Timing
With the engine on, select ‘Driver
With the engine on, select ‘Driver
Assistance → Driving Safety Off in N
Assistance → Warning Timing’ from the
mode’ from the Settings menu to set
Settings menu to change the initial
whether to use the function.
warning activation time for Blind-Spot
Collision-Avoidance Assist.
- If ‘Driving Safety Off in N mode’
is selected, Blind-Spot Collision-
When the vehicle is first delivered,
Avoidance Assist turns off
Warning Timing is set to ‘Standard’. If you
automatically when N mode is
change the Warning Timing, the Warning
selected.
Timing of other Driver Assistance
systems may change.
- If ‘Driving Safety Off in N mode’ is
deselected, Blind-Spot Collision-
Avoidance Assist does not turn off
automatically even when N mode is
selected.
WARNING
If ‘Warning Only’ is selected, braking
is not assisted.
If ‘Off’ is selected, the driver should
always be aware of the surroundings
and drive safely.
Information
If the engine is restarted, Blind-Spot
Collision-Avoidance Assist will maintain
the last setting.
7-23

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Blind-Spot Collision-Avoidance
Assist Operation
Warning and control
OCN7N071092L
Warning Volume
With the engine on, select ‘Driver
Assistance → Warning Volume’ from the
OCN7N071151
Settings menu to change the Warning
Vehicle detection
Volume to ‘High’, ‘Medium’ or ‘Low’ for
Blind-Spot Collision-Avoidance Assist.
• To warn the driver a vehicle is
detected, the warning light on the
If you change the Warning Volume,
side view mirror will illuminate.
the warning volume of other Driver
Assistance systems may change.
• Blind-Spot Collision-Avoidance Assist
will operate when your vehicle speed
is above 12 mph (20 km/h) and the
CAUTION
speed of the vehicle in the blind spot
The setting of the Warning Timing
area is above 7 mph (10 km/h).
and Warning Volume applies to all
functions of Blind-Spot Collision-
Avoidance Assist.
Even though ‘Standard’ is selected
for Warning Timing, if a vehicle
approaches at high speed, the
warning may seem late.
Select ‘Late’ for Warning Timing
when traffic is light and when driving
speed is slow.
7-24

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Collision warning
Information
Collision Warning will operate when
If the driver's seat is on the left side, the
the turn signal is turned on in the
collision warning may occur when you
direction of the detected vehicle.
turn left. Maintain a proper distance
If ‘Warning Only’ is selected from the
with the vehicles in the left lane. If the
Settings menu, the collision warning
driver's seat is on the right side, the
will operate when your vehicle
collision warning may occur when you
approaches the lane the blind spot
turn right. Maintain a proper distance
vehicle is detected.
with the vehicles in the right lane.
To warn the driver of a collision, the
Images or colors may appear
warning light on the outside view
differently depending on the instrument
mirror will blink. At the same time, an
panel specifications or theme.
audible warning will sound.
When the turn signal is turned off or
you move away from the lane, the
collision warning will be cancelled and
Blind-Spot Collision-Avoidance Assist
will return to vehicle detection state.
WARNING
The detecting range of the rear
corner radar is determined by a
standard road width, therefore, on
a narrow road, Blind-Spot Collision-
OCN7N071004L
Avoidance Assist may detect other
Collision-avoidance assist (while driving)
vehicles two lanes over and warn
• To warn the driver of a collision, the
you. In contrast, on a wide road,
warning light on the side view mirror
Blind-Spot Collision-Avoidance
will blink and a warning message will
Assist may not be able to detect a
appear on the cluster. At the same
vehicle driving in the next lane and
time, an audible warning will sound,
may not warn you.
warning light on the head-up display
When the hazard warning flasher is
(if equipped) will blink.
on, the collision warning by the turn
• Blind-Spot Collision-Avoidance Assist
signal will not operate.
will operate when your vehicle speed
is between 40-120 mph (60-200
km/h). and both lane markings of the
driving lane are detected.
• Emergency Braking will be assisted to
help prevent collision with the vehicle
in the blind spot area.
7-25

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
WARNING
Collision-avoidance assist will
be cancelled under the following
circumstances:
- Your vehicle enters the next lane
by a certain distance
- Your vehicle is away from the
collision risk
- The steering wheel is sharply
steered
OCN7N071124L
- The brake pedal is depressed
Collision-avoidance assist (while
- Forward Collision-Avoidance Assist
departing)
is operating
• To warn the driver of a collision, the
After Blind-Spot Collision-Avoidance
warning light on the side view mirror
Assist operation or lane change,
will blink and a warning message will
you must drive to the center of the
appear on the cluster. At the same
lane. Blind-Spot Collision-Avoidance
time, an audible warning will sound.
Assist will not operate if the vehicle is
• Blind-Spot Collision-Avoidance Assist
not driven in the center of the lane.
will operate when your vehicle speed
is below 2 mph (3 km/h) and the
speed of the vehicle in the blind spot
area is above 3 mph (5 km/h).
• Emergency braking will be assisted to
help prevent collision with the vehicle
in the blind spot area.
7-26

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Blind-Spot Collision-Avoidance
Assist may not operate if the driver
applies the brake pedal to avoid
collision.
When Blind-Spot Collision-Avoidance
Assist is operating, braking control
by the function will automatically
cancel when the driver excessively
depresses the accelerator pedal or
sharply steers the vehicle.
During Blind-Spot Collision-
OCN7N071017L
Avoidance Assist operation, the
Stopping vehicle and ending brake control
vehicle may stop suddenly injuring
• When the vehicle is stopped due
passengers and shifting loose
to emergency braking, the ‘Drive
objects. Always have the seat belt on
carefully’ warning message will
and keep loose objects secured.
appear on the cluster.
Even if there is a problem with Blind-
For your safety, the driver should
Spot Collision-Avoidance Assist, the
depress the brake pedal immediately
vehicle’s basic braking performance
and check the surroundings.
will operate properly.
• Brake control will end after the vehicle
Blind-Spot Collision-Avoidance Assist
is stopped by emergency braking for
does not operate in all situations or
approximately 2 seconds.
cannot avoid all collisions.
Blind-Spot Collision-Avoidance
Assist may warn the driver late or
WARNING
may not warn the driver depending
Take the following precautions when
on the road and driving conditions.
using Blind-Spot Collision-Avoidance
Driver should maintain control of the
Assist:
vehicle at all times. Do not depend
For your safety, change the Settings
on Blind-Spot Collision-Avoidance
after parking the vehicle at a safe
Assist. Maintain a safe braking
location.
distance, and if necessary, depress
the brake pedal to reduce driving
If any other system’s warning
speed or to stop the vehicle.
message is displayed or audible
warning is generated, Blind-Spot
Never operate Blind-Spot Collision-
Collision-Avoidance Assist’s warning
Avoidance Assist on people, animal,
message may not be displayed
objects, etc. It may cause serious
and audible warning may not be
injury or death.
generated.
You may not hear the warning sound
of Blind-Spot Collision-Avoidance
Assist if the surrounding is noisy.
7-27

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
WARNING
The brake control may not operate
properly depending on the status of
ESC (Electronic Stability Control).
There will only be a warning when:
The ESC (Electronic Stability Control)
warning light is on
ESC (Electronic Stability Control) is
engaged in a different function
OTM070100N
Blind-Spot Collision-Avoidance
When the side view mirror warning
Assist Malfunction and
light is not working properly, the ‘Check
Limitations
side view mirror warning light’ warning
Blind-Spot Collision-Avoidance
message will appear on the cluster
Assist malfunction
for several seconds, and the master
(
) warning light will illuminate on the
cluster. If this occurs, have the vehicle
inspected by an authorized HYUNDAI
dealer.
OTM070099N
When Blind-Spot Collision-Avoidance
Assist is not working properly, the ‘Check
Blind-Spot Safety system(s)’ warning
message will appear on the cluster
for several seconds, and the master
(
) warning light will illuminate on the
cluster. If this occurs, have the vehicle
inspected by an authorized HYUNDAI
dealer.
7-28

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Blind-Spot Collision-Avoidance
WARNING
Assist disabled
Even though the warning message
does not appear on the cluster, Blind-
Spot Collision-Avoidance Assist may
not properly operate.
Blind-Spot Collision-Avoidance
Assist may not properly operate in
an area (for example, open terrain)
where any objects are not detected
right after the engine is turned on, or
when the detecting sensor is blocked
with foreign material right after the
engine is turned on.
OCN7N071098L
When the rear bumper around the rear
corner radar or sensor is covered with
CAUTION
foreign material, such as snow or rain,
Turn off Blind-Spot Collision-Avoidance
or installing a trailer or carrier, it can
Assist to install or remove a trailer,
reduce the detecting performance and
carrier, or another attachment. Turn on
temporarily limit or disable Blind-Spot
Blind-Spot Collision-Avoidance Assist
Collision-Avoidance Assist.
when finished.
If this occurs, the ‘Blind-Spot Safety
system is disabled. Radar blocked’
Limitations of Blind-Spot Collision-
warning message will appear on the
Avoidance Assist
cluster.
Blind-Spot Collision-Avoidance Assist
Blind-Spot Collision-Avoidance Assist
may not operate properly, or it may
will operate properly when such foreign
operate unexpectedly under the
material or trailer, etc. is removed, and
following circumstances:
then the engine is restarted.
• There is inclement weather such as
If Blind-Spot Collision-Avoidance Assist
heavy snow, heavy rain, etc.
does not operate properly after it is
• The rear corner radar is covered with
removed, have the vehicle inspected by
snow, rain, dirt, etc.
an authorized HYUNDAI dealer.
• The temperature around the rear
corner radar is high or low
• Driving on a highway ramp
7-29

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
The road pavement (or the peripheral
The speed of the other vehicle is very
ground) abnormally contains metallic
fast that it passes by your vehicle in a
components (for example, possibly
short time
due to subway construction)
Your vehicle passes by the other
There is a fixed object near the
vehicle
vehicle, such as sound barriers,
Your vehicle changes lane
guardrails, central dividers, entry
Your vehicle has started at the same
barriers, street lamps, signs,
time as the vehicle next to you and
tunnels, walls, etc. (including double
has accelerated
structures)
The vehicle in the next lane moves
Driving in vast areas where there
two lanes away from you, or when the
are few vehicles or structures (for
vehicle two lanes away moves to the
example, desert, meadow, suburb,
next lane from you
etc.)
A trailer, carrier or other attachment is
Driving through a narrow road where
installed around the rear corner radar
trees or grass are overgrown
The bumper around the rear corner
Driving on a wet road surface, such as
radar is covered with objects, such as
a puddle on the road
a bumper sticker, bumper guard, bike
The other vehicle drives very close
rack, etc.
behind your vehicle, or the other
The bumper around the rear corner
vehicle passes by your vehicle in close
radar is impacted, damaged or the
proximity
radar is out of position
Your vehicle height is low or high
due to heavy loads, abnormal tire
pressure, etc.
Blind-Spot Collision-Avoidance Assist
may not operate properly, or it may
operate unexpectedly when the
following objects are detected:
• A motorcycle or bicycle is detected
• A vehicle such as a flat trailer is
detected
• A big vehicle such as a bus or truck is
detected
• A moving obstacle such as a
pedestrian, animal, shopping cart or a
baby stroller is detected
• A vehicle with low height such as a
sports car is detected
7-30

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Braking control may not work, driver’s
WARNING
attention is required in the following
circumstances:
Driving on a curved road
• The vehicle severely vibrates while
driving over a bumpy road, uneven
road or concrete patch
• Driving on a slippery surface due to
snow, water puddle, ice, etc.
• The tire pressure is low or a tire is
damaged
• The braking system has been modified
• The vehicle makes abrupt lane
changes
OHY059008
Blind-Spot Collision-Avoidance
Information
Assist may not operate properly
For more details on the limitations of the
when driving on a curved road. The
front view camera, refer to “Forward
function may not detect the vehicle
Collision-Avoidance Assist (FCA)” and
in the next lane.
“Lane Keeping Assist (LKA)” section in
Always pay attention to road and
chapter 7.
driving conditions while driving.
OHY059009
Blind-Spot Collision-Avoidance
Assist may not operate properly
when driving on a curved road. The
function may recognize a vehicle in
the same lane.
Always pay attention to road and
driving conditions while driving.
7-31

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Driving where the road is merging/
Driving where the heights of the
dividing
lanes are different
OCN7N071099L
OCN7N071059
Blind-Spot Collision-Avoidance
Blind-Spot Collision-Avoidance
Assist may not operate properly
Assist may not operate properly
when driving where the road merges
when driving where the heights of
or divides. The function may not
the lanes are different. The function
detect the vehicle in the next lane.
may not detect the vehicle on a
road with different lane heights
Always pay attention to road and
driving conditions while driving.
(underpass joining section, grade
separated intersections, etc.).
Driving on an inclined road
Always pay attention to road and
driving conditions while driving.
WARNING
When you are towing a trailer or
another vehicle, make sure that
you turn off Blind-Spot Collision-
Avoidance Assist.
Blind-Spot Collision-Avoidance
Assist may not operate properly if
interfered by strong electromagnetic
OCN7N071058L
waves.
Blind-Spot Collision-Avoidance
Blind-Spot Collision-Avoidance
Assist may not operate properly
Assist may not operate for 15 seconds
after the vehicle is started, or the
when driving on a sloped road. The
function may not detect the vehicle
front view camera or rear corner
radars are initialized.
in the next lane or may incorrectly
detect the ground or structure.
Always pay attention to road and
driving conditions while driving.
7-32

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Information
This device complies with Part 15 of the
FCC rules.
Operation is subject to the following three
conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause undesired
operation.
3. Changes or modifications not expressly
approved by the party responsible
for compliance could void the user's
authority to operate the device.
Information
Radio frequency radiation exposure
information:
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment.
This equipment should be installed and
operated with minimum distance of 8 in.
(20 cm) between the radiator (antenna)
and your body.
This transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
7-33

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
SAFE EXIT WARNING (SEW) (IF EQUIPPED)
Detecting sensor
OHY050024
After the vehicle stops, when an
OCN7N071054N
approaching vehicle from the rear area
[1] : Rear corner radar
is detected after a passenger opens
Refer to the picture above for the
the door, Safe Exit Warning will warn
detailed location of the detecting
the driver with a warning message and
sensors.
an audible warning to help prevent a
collision.
CAUTION
CAUTION
For more details on the precautions of
the rear corner radars, refer to “Blind-
Warning timing may vary depending on
Spot Collision-Avoidance Assist (BCA)”
the speed of the approaching vehicle.
section in chapter 7.
7-34

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Safe Exit Warning Settings
Setting features
OCN7N071092L
Warning Volume
OCN7N071100L
With the engine on, select ‘Driver
Assistance → Warning Volume’ from the
Safe Exit Warning
Settings menu to change the Warning
With the engine on, select ‘Driver
Volume to ‘High’, ‘Medium’ or ‘Low’ for
Assistance → Blind-Spot Safety → Safe Exit
Safe Exit Warning.
Warning’ from the Settings menu to turn
If you change the warning volume,
on Safe Exit Warning and deselect to turn
the Warning Volume of other Driver
off the function.
Assistance systems may change.
WARNING
CAUTION
The driver should always be aware
The setting of the Warning Timing
of his or her surroundings. If ‘Safe
and Warning Volume applies to all
Exit Warning’ is deselected, Safe Exit
functions of Safe Exit Warning.
Warning cannot assist you.
Even though ‘Standard’ is selected
for Warning Timing, if a vehicle
Information
approaches at high speed from the
rear, the warning may seem late.
If the engine is restarted, Safe Exit
Warning will maintain the last setting.
Select ‘Late’ for Warning Timing
when traffic is light and when driving
speed is slow.
7-35

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Safe Exit Warning Operation
WARNING
Warning
Take the following precautions when
using Safe Exit Warning:
For your safety, only change the
Settings after parking the vehicle at a
safe location.
If any other system’s warning
message is displayed or audible
warning is generated, Safe Exit
Warning's warning message may not
be displayed and audible warning
may not be generated.
OCN7N071151
You may not hear the warning
sound of Safe Exit Warning if the
surrounding is noisy.
Safe Exit Warning does not operate
in all situations and cannot prevent
all collisions.
Safe Exit Warning may warn the
driver late or may not warn the driver
depending on the road and driving
conditions. Always check vehicle
surroundings.
The driver and passengers are
OCN7N071101L
responsible for accidents that occur
Collision Warning when exiting vehicle
while exiting the vehicle. Always
• When an approaching vehicle from
check the surroundings before you
the rear is detected at the moment a
exit the vehicle.
door is opened, the ‘Watch (out) for
Never deliberately operate Safe
traffic’ warning message will appear
Exit Warning. Doing so may lead to
on the cluster, and an audible warning
serious injury or death.
will sound.
Safe Exit Warning does not operate
• Safe Exit Warning will warn the driver
if there is a problem with Blind- Spot
when your vehicle speed is below 2
Collision-Avoidance Assist. The
mph (3 km/h), and the speed of the
warning message of Blind- Spot
approaching vehicle from the rear is
Collision-Avoidance Assist will
above 3 mph (5 km/h).
appear when:
- Blind- Spot Collision-Avoidance
Assist sensor or the sensor
surrounding is polluted or covered
- Blind- Spot Collision-Avoidance
Assist fails to warn passengers or
falsely warn passengers
7-36

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Safe Exit Warning Malfunction
Information
and Limitations
After the engine is turned off, Safe Exit
Safe Exit Warning malfunction
Warning operates approximately for 3
minutes, but turns off immediately if
the doors are locked.
Images or colors may appear
differently depending on the instrument
panel specifications or theme.
OTM070099N
When Safe Exit Warning is not working
properly, the ‘Check Blind-Spot Safety
system’ warning message will appear on
the cluster for several seconds, and the
master (
) warning light will illuminate
on the cluster. If the master warning light
illuminates, have the vehicle inspected
by an authorized HYUNDAI dealer.
7-37

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Safe Exit Warning disabled
OTM070100N
When the side view mirror warning
OCN7N071098L
light is not working properly, the ‘Check
When the rear bumper around the rear
side view mirror warning light’ warning
corner radar or sensor is covered with
message will appear on the cluster
foreign material, such as snow or rain,
for several seconds, and the master
or installing a trailer or carrier, it can
( ) warning light will illuminate on
reduce the detecting performance and
the cluster. If the master warning light
temporarily limit or disable Safe Exit
illuminates, have the vehicle inspected
Warning.
by an authorized HYUNDAI dealer.
If this occurs, the ‘Blind-Spot Safety
system disabled. Radar blocked’ warning
message will appear on the cluster.
Safe Exit Warning will operate properly
when such foreign material or trailer,
etc., is removed, and then the engine is
restarted.
If Safe Exit Warning does not operate
properly after it is removed, have the
vehicle inspected by an authorized
HYUNDAI dealer.
7-38

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Limitations of Safe Exit Warning
WARNING
Safe Exit Warning may not operate
Even though the warning message
properly, or it may operate unexpectedly
does not appear on the cluster,
under the following circumstances:
Safe Exit Warning may not properly
operate.
• Getting out of the vehicle where trees
or grass are overgrown
Safe Exit Warning may not properly
operate in an area (for example,
• Getting out of the vehicle where the
open terrain) where any objects are
road is wet
not detected right after the engine
• The approaching vehicle is very fast or
is turned on, or when the detecting
very slow
sensor is blocked with foreign
material right after the engine is
turned on.
Information
For more details on the limitations of the
rear corner radar, refer to “Blind- Spot
CAUTION
Collision-Avoidance Assist (BCA)” section
Turn off Safe Exit Warning to install
in this chapter.
or remove a trailer, carrier, or
another attachment. Turn on Safe
WARNING
Exit Warning when finished.
Safe Exit Warning may not operate
properly if interfered by strong
electromagnetic waves.
Safe Exit Warning may not operate
for 3 seconds after the vehicle is
started, or the rear corner radars are
initialized.
7-39

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
MANUAL SPEED LIMIT ASSIST (MSLA)
Manual Speed Limit Assist
Operation
Setting speed limit
OJK071213N
(1) Manual Speed Limit Assist enabled
indicator
(2) Set speed
OCN7N071006
You can set the speed limit when you do
1. Press and hold Driving Assist button
not want to drive over a specific speed.
at the desired speed. The Manual
If you drive over the preset speed limit,
Speed Limit Assist enabled (
)
Manual Speed Limit Assist operates
indicator will illuminate on the cluster.
(set speed limit will blink and chime will
sound) until the vehicle speed returns
within the speed limit.
Information
The Driving Assist button symbol may
vary depending on your vehicle option.
7-40

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
OCN7N071132L
OJK071214N
2. Push the + switch up or - switch down,
3. The set speed limit will be displayed
and release it at the desired speed.
on the cluster.
Push the + switch up or - switch down
If you would like to drive over the
and hold it. The speed will increase
preset speed limit, depress the
or decrease to the nearest multiple of
accelerator pedal beyond the pressure
ten (multiple of five in mph) at first,
point to activate the kickdown
and then increase or decrease by 5
mechanism.
mph (10 km/h).
The set speed limit will blink and
chime will sound until you return the
vehicle speed within the speed limit.
Information
When the accelerator pedal is not
depressed beyond the pressure point,
vehicle speed will maintain within the
speed limit.
7-41

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Temporarily pausing Manual Speed
Turning off Manual Speed Limit
Limit Assist
Assist
OCN7N071133L
OCN7N071006
Push the
switch to temporarily
Press the Driving Assist button to turn
pause the set speed limit. The set speed
Manual Speed Limit Assist off. The
limit will turn off but the Manual Speed
Manual Speed Limit Assist enabled
Limit Assist enabled (
) indicator
(
) indicator will go off.
will stay on.
WARNING
Resuming Manual Speed Limit Assist
Take the following precautions when
using Manual Speed Limit Assist:
Always set the vehicle speed under
the posted speed limit.
Keep Manual Speed Limit Assist off
when the function is not in use, to
avoid inadvertently setting a speed.
Check that the Manual Speed Limit
Assist enabled (
) indicator is
off.
Manual Speed Limit Assist does
OCN7N071132L
not substitute for proper and safe
To resume Manual Speed Limit Assist
driving. It is the responsibility of
after Manual Speed Limit Assist was
the driver to always drive safely
paused, push the +, - switch or
and should always be aware of
button.
unexpected and sudden situations
If you push the + switch up or - switch
from occurring. Pay attention to the
down, vehicle speed will be set to the
road conditions at all times.
current speed on the cluster.
If you push the
button, vehicle
speed will resume to the preset speed.
7-42

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
DRIVER ATTENTION WARNING (DAW)
Basic function
Driver Attention Warning
Driver Attention Warning can help
Settings
determine the driver's attention level
Setting features
by analyzing driving pattern and driving
time while the vehicle is driven. Driver
Attention Warning will recommend a
break when the driver’s attention level
falls below a certain level.
Leading Vehicle Departure Alert
function
Leading Vehicle Departure Alert function
will inform the driver when a detected
vehicle in front departs from a stop.
OCN7N071102L
Detecting sensor
Driver Attention Warning
With the engine on, select or deselect
‘Driver Assistance → Driver Attention
Warning (or DAW (Driver Attention
Warning))’ from the Settings menu to set
whether or not to use each function.
- If ‘Inattentive Driving Warning’ (or
‘Swaying warning’) is selected, Driver
Attention Warning will inform the
driver the driver’s attention level and
will recommend taking a break when
the level falls below a certain level.
OCN7N071001N
[1] : Front view camera
The front view camera is used to help
detect driving patterns and front vehicle
departure while vehicle is being driven.
Refer to the picture above for the
detailed location of the detecting sensor.
CAUTION
Always keep the front view camera in
good condition to maintain optimal
OCN7N071103L
performance of Driver Attention
Warning.
Leading Vehicle Departure Alert
For more details on the precautions
- If ‘Leading Vehicle Departure Alert’ is
of the front view camera, refer to
selected, the function will inform the
“Forward Collision-Avoidance Assist
driver when a detected vehicle in front
(FCA)” section in chapter 7.
departs from a stop.
7-43

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Driving Safety Auto Off in N mode
OCN7N071091L
OCN7N071090L
Warning Timing
With the engine on, select ‘Driver
With the engine on, select ‘Driver
Assistance → Driving Safety Off in N
Assistance → Warning Timing’ from the
mode’ from the Settings menu to set
Settings menu to change the initial
whether to use the function.
warning activation time for Driver
Attention Warning.
- If ‘Driving Safety Off in N mode’ is
selected, Driver Attention Warning
When the vehicle is first delivered,
turns off automatically when N mode
Warning Timing is set to ‘Standard’. If you
is selected.
change the Warning Timing, the Warning
Timing of other Driver Assistance
- If ‘Driving Safety Off in N mode’ is
systems may change.
deselected, Driver Attention Warning
does not turn off automatically even
when N mode is selected.
Information
If the engine is restarted, Driver Attention
Warning will maintain the last setting.
7-44

-------------------------------------------------------------------------------------------------------------------------------------------------------------

07
Driver Attention Warning
• The driver’s attention level is displayed
on the scale of 1 to 5. The lower the
Operation
level is, the more inattentive the driver
Basic function
is.
Display and warning
• The level decreases when the driver
The basic function of Driver Attention
does not take a break for a certain
Warning is to inform the driver of their
period of time.
‘Attention Level’ and to warn the driver to
‘Consider taking a break’.
Taking a break
Attention Level
Function off
Standby
OUS4071057L
OUS4071053L
OTM070106N
• The ‘Consider taking a break’ message
Attentive driving
Inattentive driving
will appear on the cluster and an
audible warning will sound to suggest
that the driver take a break, when the
driver’s attention level is below 1.
• Driver Attention Warning will not
suggest a break when the total driving
time is shorter than 10 minutes or 10
minutes has not passed after the last
break was suggested.
WARNING
OSU2B071088
OCN7N071155N
The driver can monitor his/her driving
For your safety, only change the
conditions on the cluster.
Settings after parking the vehicle at a
safe location.
- When the ‘Inattentive Driving
Warning’ is deselected from the
Settings menu, ‘System Off’ is
displayed.
- Driver Attention Warning will
operate when the vehicle speed is
between 0-110 mph (0-180 km/h).
- When the vehicle speed is not
within the operating speed,
the message ‘Standby’ will be
displayed.
7-45

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driver Assistance System
Leading Vehicle Departure Alert
CAUTION
function
Driver Attention Warning may
suggest a break depending on the
driver’s driving pattern or habits,
even if the driver doesn’t feel
fatigued.
Driver Attention Warning is a
supplemental function and may not
be able to determine whether the
driver is inattentive.
The driver who feels fatigued should
take a break at a safe location, even
though there is no break suggestion
OCN7N071016L
by Driver Attention Warning.
When a detected vehicle in front departs
from a stop, Leading Vehicle Departure
Alert will inform the driver by displaying
Information
the ‘Leading vehicle is driving away’
For more details on setting the
message on the cluster and an audible
functions in the infotainment system
warning will sound.
Vehicle Settings, refer to “Vehicle
Settings” section in chapter 4.
Driver Attention Warning will reset the
WARNING
last break time to 0:00 in the following
If any other system’s warning
situations:
message is displayed or audible
- The engine is turned off
warning is generated, Driver
Attention Warning message may not
- The driver unfastens the seat belt
be displayed and audible warning
and opens the driver’s door
may not be generated.
- The vehicle is stopped for more than
The driver has the responsibility to
10 minutes
safely drive and control the vehicle.
- When the driver resets Driver
Attention Warning, the last break
time is set to 0:00 and the driver’s
CAUTION
attention level is set to High.
Leading Vehicle Departure Alert is a
supplemental function and may not
alert the driver whenever the front
vehicle departs from a stop.
Always check the front of the
vehicle and road conditions before
departure.
Information
Images or colors may appear
differently depending on the instrument
panel specifications or theme.
7-46















Content      ..     10      11      12      13     ..
