Convenience Features

WARNING

ś The doors should always be fully

If you stay in the vehicle for a long time

closed and locked while the

while the weather is very hot or cold,

vehicle is in motion. If the doors

there are risks of injuries or danger to

are unlocked, the risk of being

life. Do not lock the vehicle from the

thrown from the vehicle in a crash is

outside when someone is in the vehicle.

increased.

ś Do not pull the inner door handle of

WARNING

the driver’s or passenger’s door while

the vehicle is moving.

Opening a door when something is

approaching may cause damage or

injury. Be careful when opening doors

WARNING

and watch for vehicles, motorcycles,

bicycles or pedestrians approaching the

Do not leave the elderly, children or

vehicle in the path of the door.

animals unattended in your vehicle. An

enclosed vehicle can become extremely

hot, causing death or serious injury

to the elderly, unattended children

or animals who cannot escape from

the vehicle. Children might operate

features of the vehicle that could injure

them, or they could encounter other

harm, possibly from someone gaining

entry to the vehicle.

WARNING

Always secure your vehicle.

Leaving your vehicle unlocked increases

the potential risk to you or others from

someone hiding in your vehicle.

To secure your vehicle, while depressing

the brake, move the shift lever to the

P (Park) position, engage the parking

brake, and place the ignition switch

in the LOCK/OFF position, close all

windows, lock all doors, and always

take the key with you.

5-34

Automatic Door Lock and Unlock

Child-Protector Rear Door Locks

Features

Impact sensing door unlock system

(if equipped)

All doors will be automatically unlocked

when an impact causes the air bags to

deploy.

Speed sensing door lock system (if

equipped)

All doors will be automatically locked

OCN7H050007

when vehicle speed exceeds 9 mph (15

km/h).

The child safety lock is provided to help

prevent children seated in the rear from

You can activate or deactivate the Auto

accidentally opening the rear doors.

Door Lock/Unlock features from the User

Settings Mode on the LCD display.

The rear door safety locks should be used

whenever children are in the vehicle.

For more details, refer to “LCD Display”

in chapter 4. If your vehicle is equipped

The child safety lock is located on the

with additional navigation, please refer

edge of each rear door. When the child

to the infotainment system manual

safety lock is in the lock position, the

separately supplied.

rear door will not open if the inner door

handle is pulled.

To lock the child safety lock, insert a key

(or screwdriver) (1) into the hole and turn

it to the lock position.

To allow a rear door to be opened from

inside the vehicle, unlock the child safety

lock.

WARNING

If children accidently open the rear

doors while the vehicle is in motion,

they could fall out of the vehicle. The

rear door safety locks should always

be used whenever children are in the

vehicle.

5-35

Convenience Features

5($5 2&&83

$17

$/(57 ǣ52$Ǥ

Rear Occupant Alert helps prevent the

driver from leaving a passenger in the

rear seats.

Rear Occupant Alert Operation

OCN7050135L

When the driver turns off the engine and

opens the driver’s door after opening and

closing a rear door, a warning message

“Check rear seats” appears.

WARNING

Rear Occupant Alert provides

information to the driver to check

the rear seats but it does not detect

whether there is an object or passenger.

Always check the rear seats when

leaving the vehicle.

Information

The open and close history of the rear

door is initialized if the driver turns off the

engine and lock vehicle doors.However,

the alarm may sound again whenever the

driver’s door is opened if the previous

history of the rear door is not initialized.

5-36

7+()7ǘ$/$50 6<67(0

This system helps to protect your vehicle

Information

and valuables. The horn will sound and

the hazard warning lights will blink

Do not lock the doors until all

continuously if any of the following

passengers have left the vehicle. If the

occur:

remaining passenger leaves the vehicle

when the system is armed, the alarm

- A door is opened without using the

will be activated.

remote key or smart key.

If the vehicle is not disarmed with the

- The trunk is opened without using the

remote key or smart key, open the

remote key or smart key.

doors by using the mechanical key and

- The engine hood is opened.

place the ignition switch in the ON

The alarm continues for 30 seconds, then

position (for remote key) or start the

the system resets. To turn off the alarm,

engine (for smart key) and wait for 30

unlock the doors with the remote key or

seconds.

smart key.

When the system is disarmed but a

The Theft Alarm System automatically

door or trunk is not opened within 30

sets 30 seconds after you lock the doors

seconds, the system will be rearmed.

and the trunk. For the system to activate,

you must lock the doors and the trunk

from outside the vehicle with the remote

key or smart key or by pressing the

button on the outside of the door handle

with the smart key in your possession.

The hazard warning lights will blink and

the chime will sound once to indicate the

system is armed.

Once the security system is set, opening

any door, the trunk, or the hood without

using the remote key or smart key will

cause the alarm to activate.

The Theft Alarm System will not set if the

hood, the trunk, or any door is not fully

closed. If the system will not set, check

the hood, the trunk, or the doors are fully

closed.

Do not attempt to alter this system or

add other devices to it.

5-37

Convenience Features

'5,9(5 326,7,21 0(025< 6<67(0 ǣ,) (48,33('Ǥ

Storing Memory Positions

1. Shift to P (Park) while the Engine

Start/Stop button is in the ON

position.

2. Adjust the driver’s seat position and

instrument panel illumination intensity

to the desired position.

3. Press the SET button. The system

will beep once and notify you ‘Press

button to save settings’ on the cluster

OCN7050012

LCD display.

The Driver Position Memory System is

4. Press one of the memory buttons (1

provided to store and recall the following

or 2) within 4 seconds. The system

memory settings with a simple button

will beep twice when the memory has

operation.

been successfully stored.

- Driver’s seat position

5. “Settings 1 (or 2) saved” will appear on

the LCD display.

- Instrument panel illumination

intensity

Recalling Memory Positions

1. The ignition switch is in the ON

WARNING

position.

Never attempt to operate the driver

2. Press the desired memory button

position memory system while the

(1 or 2). The system will beep once,

vehicle is moving.

and then the driver’s position and

This could result in loss of control, and

instrument panel illumination intensity

an accident causing death, serious

will automatically adjust to the stored

injury, or property damage.

positions.

3. “Settings 1 (or 2) applied“ will appear

on the LCD display.

Information

If your vehicle is equipped with

ś If the battery connector is disconnected,

additional navigation, please refer

the memory settings will be erased.

to the infotainment system manual

ś If the Driver Position Memory

separately supplied.

System does not operate normally, we

recommend that you have the system

checked by an authorized HYUNDAI

dealer.

5-38

Initialization in the process:

Information

1. Initialization begins as the alarm

ś While recalling the “1” memory

sounds.

position, pressing the SET or 1 button

temporarily stops the adjustment of

2. The seat and seatback will

automatically move backwards. The

the recalled memory position. Pressing

the 2 button recalls the “2” memory

alarm sound will continue while the

system is in operation.

position.

ś While recalling the “2” memory

3. Initialization will be complete after

the seat and seatback move to

position, pressing the SET or 2 button

temporarily stops the adjustment of

the center with an alarm sound. If,

however, cases as follows occur, the

the recalled memory position. Pressing

the 1 button recalls the “1” memory

initialization process will come to a

stop and the alarm sound will stop as

position.

well.

ś While recalling the stored positions,

When pushing driving position

pressing one of the control buttons for

the driver’s seat or instrument panel

memory system button

illumination will cause the movement

When pushing driver’s seat height

of that component to stop and move in

adjustment switch

the direction that the control button is

When shifting from P (Park) to other

pressed.

positions

When driving speed exceeds 3 km/h

Driver Position Memory System

When the driver’s door is closed

Reset

If the Driver position memory system

does not work properly, initialize the

system as follows.

How to initialize:

1. Stop the vehicle and open the driver’s

door with the ignition switch in the

ON position and the vehicle shifted to

P (Park).

2. Pull the driver’s seat forward as far

as possible and have the seatback

upright as much as possible using

the driver’s seat forward/backward

adjustment and seatback angle

(recline) switches.

3. Push the SET button and seat forward

movement switch for 2 seconds

simultaneously.

5-39

Convenience Features

Easy Access Function (if

equipped)

The system will move the driver’s seat

automatically as follows:

Without smart key system

- It will move the driver’s seat

rearward when the ignition key is

removed and the driver’s door is

opened.

- It will move the driver’s seat forward

when the ignition switch is in the

ACC or ON position.

With smart key system

- It will move the driver’s seat

rearward when the Engine Start/

Stop button is in the OFF position

and the driver’s door is opened.

- It will move the driver’s seat forward

when the vehicle is turned ON or

the driver’s door is closed with the

smart key with you.

You can activate or deactivate the

Easy Access Function from the User

Settings Mode on the LCD display. For

more details, refer to “LCD Display”

in chapter 4. If your vehicle is

equipped with additional navigation,

please refer to the infotainment

system manual separately supplied.

5-40

STEERING WHEEL

Motor Driven Power Steering

Information

(MDPS)

The following symptoms may occur during

The system assists you with steering the

normal vehicle operation:

vehicle. If the vehicle is turned off or

The steering effort may be high

if the power steering system becomes

immediately after placing the ignition

inoperative, you may still steer the

switch in the ON position.

vehicle, but it will require increased

steering effort.

This happens as the system performs

the MDPS system diagnostics. When

Also, the steering effort becomes heavier

the diagnostics are completed, the

as the vehicle’s speed increases and

steering wheel effort will return to its

becomes lighter as the vehicle’s speed

normal condition.

decreases for better control of the

steering wheel.

When the battery voltage is low, you

may have to put more steering effort.

Should you notice any change in the

However, it is a temporary condition so

effort required to steer during normal

that it will return to normal condition

vehicle operation, have the system

after charging the battery.

checked by an authorized HYUNDAI

dealer.

A click noise may be heard from the

MDPS relay after the ignition switch is

in the ON or LOCK/OFF position.

CAUTION

Motor noise may be heard when the

If the Motor Driven Power Steering

vehicle is at a stop or at a low driving

System does not operate normally,

speed.

the warning light (

) will illuminate

When you operate the steering wheel

on the instrument cluster. You may

in low temperatures, abnormal noise

steer the vehicle, but it will require

may occur. If the temperature rises, the

increased steering efforts. Take your

noise will disappear. This is a normal

vehicle to an authorized HYUNDAI

condition.

dealer and have the system checked

When an error is detected from the

as soon as possible.

MDPS, the steering effort assist

When an abnormality is detected

function may become inoperative

in the Motor Driven Power Steering

in order to prevent fatal accidents.

system, to prevent an accident, the

Instrument cluster warning lights may

steering assist function may become

be on or the steering effort may be

inoperative. At this time, the warning

high. If these symptoms occur, drive

light turns on or blinks on the cluster.

the vehicle to a safe area as soon as it is

The steering wheel may become

safe to do so. Have the system checked

difficult to control or operate. Have

by an authorized HYUNDAI dealer as

your vehicle checked immediately,

soon as possible.

after moving the vehicle to a safe

area.

5-41

Convenience Features

Tilt Steering / Telescope Steering

When adjusting the steering wheel to a

comfortable position, adjust the steering

wheel so that it points toward your chest,

not toward your face. Make sure you can

see the instrument cluster warning lights

and gauges. After locking the lever, push

the steering wheel both up and down to

be certain it is locked in position. Always

adjust the position of the steering wheel

before driving.

OCN7050013

To adjust the steering wheel angle and

WARNING

height:

NEVER adjust the steering wheel while

1. Pull down the lock-release lever (1).

driving. This may cause loss of vehicle

2. Adjust the steering wheel to the

control resulting in an accident.

desired angle (2) and distance

forward/back (3).

3. Pull up the lock-release lever to lock

the steering wheel in place.

Information

Sometimes the lock release lever may not

engage completely. This may occur when

the gears of the locking mechanism do not

completely mesh. If this occurs, pull down

on the lock release lever, readjust the

steering wheel again, and then pull back

up on the release lever to lock the steering

wheel in place.

CAUTION

While adjusting the steering wheel

height, please do not push or pull it

hard since the fixture can be damaged.

5-42

Convenience Features

0,55256

Inside Rearview Mirror

Day/night rearview mirror

(if equipped)

Before driving your vehicle, check to

see that your inside rearview mirror is

properly positioned. Adjust the rearview

mirror so that the view through the rear

window is properly centered.

WARNING

Make sure your line of sight is not

obstructed. Do not place objects in the

rear seat, cargo area, or behind the rear

head restraints which could interfere

with your vision through the rear

OCN7050017L

window.

[A] : Lever, [B] : Day, [C] : Night

Make this adjustment before you start

WARNING

driving and while the day/night lever is in

the day position.

To prevent serious injury during an

accident or deployment of the air bag,

Pull the day/night lever towards you to

do not modify the rearview mirror and

reduce glare from the headlights of the

do not install a wide mirror.

vehicles behind you during night driving.

Remember that you lose some rearview

clarity in the night position.

WARNING

NEVER adjust the mirror while driving.

This may cause loss of vehicle control

resulting in an accident.

NOTICE

When cleaning the mirror, use a paper

towel or similar material dampened

with glass cleaner. Do not spray glass

cleaner directly on the mirror as this

may cause the liquid cleaner to enter

the mirror housing.

5-44

Electrochromic mirror (ECM) with

Automatic-Dimming Night Vision Safety™

HomeLink® system (if equipped)

(NVS^®) Mirror (if equipped)

The NVS® Mirror automatically helps

reduce glare by monitoring light levels in

the front and the rear of the vehicle. Any

object that obstructs either light sensor

will degrade the automatic dimming

control feature.

For more information regarding NVS®

mirrors and other applications, please

refer to the Gentex website:

www.gentex.com

OCN7050084N

Your mirror will automatically dim

Your vehicle may be equipped with

upon detecting glare from the vehicles

a Gentex Automatic-Dimming Mirror

traveling behind you.

with an Integrated HomeLink® Wireless

The mirror defaults to the ON position

Control System.

each time the vehicle is started.

During nighttime driving, this feature will

automatically detect and help reduce

Integrated HomeLink^® Wireless Control

rearview mirror glare. The HomeLink®

System

Universal Transceiver allows you to

activate your garage door(s), electric

The HomeLink® Wireless Control System

gate, home lighting, etc.

can replace up to three hand-held

radio-frequency (RF) transmitters with

(1) HomeLink Channel 1

a single built-in device. This innovative

(2) HomeLink Channel 2

feature will learn the radio frequency

(3) HomeLink Channel 3

codes of most current transmitters to

(4) Garage Door Opener Status Indicator :

operate devices such as gate operators,

Closing or Closed

garage door openers, entry door locks,

security systems, even home lighting.

(5) HomeLink Operation Indicator

Both standard and rolling code-equipped

(6) Garage Door Opener Status Indicator :

transmitters can be programed by

Opening or Opened

following the outlined procedures.

(7) HomeLink User Interface Indicator

Additional HomeLink® information can

be found at: www.homelink.com, www.

youtube.com/HomeLinkGentex or by

calling 1-800-355-3515.

Retain the original transmitter of the

RF device you are programing for use

in other vehicles as well as for future

HomeLink® programing. It is also

suggested that upon the sale of the

vehicle, the programed HomeLink®

buttons be erased for security purposes.

5-45

Convenience Features

Programing

WARNING

To program most devices, follow these

Before programing HomeLink® to a

instructions:

garage door opener or gate operator,

make sure people and objects are out

of the way of the device to prevent

potential harm or damage. Do not

use the HomeLink® with any garage

door opener that lacks the safety

stop and reverse features required

by U.S. federal safety standards (this

includes any garage door opener model

manufactured before April 1, 1982).

A garage door that cannot detect an

object - signaling the door to stop and

reverse - does not meet current U.S.

OCN7050085N

federal safety standards. Using a garage

Press and release (1), (2) or (3) button.

door opener without these features

ś ,I WKH LQGLFDWRU

LV WXUQHG 21 LQ

increases the risk of serious injury or

Orange, go to Step 3) since it is a

death.

new programing.

ś ,I WKH LQGLFDWRU

LV FRQWLQXRXVO\

Programing HomeLink^®

turned ON or flashes in Green rapidly

Please note the following:

several times, go to Step 2) since it is

a programed button.

:KHQ SURJUDPLQJ D JDUDJH GRRU

opener, it is advised to park the

Press and hold the button you wish

vehicle outside of the garage.

to program for approximately 15-

25 seconds until the LED flashes in

,W LV UHFRPPHQGHG WKDW D QHZ EDWWHU\

Orange for several times.

be placed in the hand-held transmitter

of the device being programed to

3. Hold the Garage Door Opener Original

HomeLink® for quicker training and

Transmitter near the HomeLink Mirror.

accurate transmission of the radio-

frequency signal.

6RPH YHKLFOHV PD\ UHTXLUH WKH

Engine Start/Stop button to be in

the ACC (or “Accessories”) position

for programing and/or operation of

HomeLink®.

,Q WKH HYHQW WKDW WKHUH DUH VWLOO

programing difficulties or questions

after following the programing steps

listed below, contact HomeLink® at:

www.homelink.com, www.youtube.

com/HomeLinkGentex or by calling

1-800-355-3515.

5-46

7. Return to the vehicle and firmly press,

hold for two seconds and release the

HomeLink button up to three times.

Do not press the HomeLink button

rapidly. At this point programing is

complete and your device should

operate when the HomeLink button is

pressed and released.

Information

OCN7050086N

ś Some garage door openers require to

press the programed button on the

4. Press the Original Transmitter

button until the indicator (4) is

mirror up to three times right after

the programing is just completed to

turned continuously ON or flashes in

Green for approximately 10 seconds

operate the garage door.

and it indicates the programing is

ś The indicator (4) is turned ON in

completed.

Orange and flashes for about 60

seconds, during the programing mode

5. However, the indicator (4) flashes

in Green continuously, but if the

and if a programing is not succeeded

within the 60 seconds, the programing

garage door opener does not operate,

please continue to follow the step

mode will be abort.

6 and 7 (“Rolling Code Programing”

procedures).

HomeLink® should now activate your

6. Firmly press and release the “Learn,”

rolling code equipped device.

“Smart,” or “Program” button while

the indicator (4) flashes in Green.

Once the button is pressed, you have

approximately 30 seconds to initiate

the next step.

Information

At the garage door opener motor, (security

gate motor, etc.) locate the “Learn,”

“Smart,” or “Program” button. This

can usually be found where the hanging

antenna wire is attached to the motor-head

unit (see the device’s manual to identify

this button). The name and color of the

button may vary by manufacturer. A

ladder and/or second person may simplify

the following steps.

5-47

Convenience Features

Gate operator & Canadian programing

During programing, your handheld

transmitter may automatically stop

transmitting. Continue to press the

Integrated HomeLink® Wireless Control

System button while you press and re-

press (“cycle”) your handheld transmitter

every two seconds until the frequency

signal has been learned. The indicator

light will flash slowly and then rapidly

after several seconds upon successful

training.

OCN7050087N

Erasing HomeLink® buttons

1. Press and hold the button (1) and (3)

simultaneously.

2. The indicator (4) is turned

continuously ON in orange for about

10 seconds.

3. Then the indicator (4) color changes

to Green and flashes rapidly.

Release the buttons once the green

indicator flashes.

4. Now HomeLink button (1), (2) and (4)

OCN7050085N

memories are all cleared.

Operating HomeLink®

NVS® is a registered trademark and

1. Press and release one of the

Z-Nav™ is a trademark of the Gentex

HomeLink buttons (1, 2 or 3) that

Corporation, Zeeland, Michigan.

programed.

HomeLink® is a registered trademark

2. The HomeLink indicator (4) will

owned by Johnson Controls,

operate as below:

Incorporated, Milwaukee, Wisconsin.

- Indicates Green and is continuously

FCC ID: NZLUAHL5A

ON (Fixed Code Garage Door

IC: 4112A-UAHL5A

Opener)

- Flashes in Green rapidly (Rolling

Code Garage Door Opener)

5-48

Two Way Communication Programing

Information

1. Complete the HomeLink

This device complies with Part 15 of the

“Programing” first.

FCC Rules.

2. Before the first 10 times HomeLink

Operation is subject to the following three

button is pressed after the

conditions:

programing, the following steps

This device may not cause harmful

MUST occur to program two way

interference, and

communication. (only for some older

This device must accept any

garage doors)

interference received, including

interference that may cause undesired

operation.

The transceiver has been tested

and complies with FCC and

Industry Canada rules. Changes or

modifications not expressly approved

by the party responsible for compliance

could void the user’s authority to

operate the device.

OCN7050088N

3. Press and release the programed

HomeLink button to activate the

garage door.

4. Once the garage door is stopped,

press and release the “Learn” or

“Smart” button on the Garage door

opener within 1 minute from the time

of pressing the programed HomeLink

button on mirror.

5-49

Recalling Garage Door Status

Homelink mirror with two way

communication provides a way to view

the last stored message from the garage

door opener. In order to recall the last

known status of the last activated device,

press the buttons “1 and 2” OR “2 and 3”

simultaneously.

,I WKH LQGLFDWRU

LV 21 FRQWLQXRXVO\

in Green, it indicates that the last

activated device was “closed” properly.

OCN7050089N

,I WKH LQGLFDWRU

LV 21 FRQWLQXRXVO\

2. The indicator (4) and (5) operates as

in Green, it indicates that the last

below:

activated device was “open” properly.

- If the indicator (4) flashes in Orange,

it indicates that the garage door is

“closing”.

Information

- If the indicator (4) is ON continuously

Two way communication range distance

in Green, it indicates that the garage

between “vehicle” and “garage door

door is “closed”.

opener” is 100m.

- If the indicator (5) flashes in Orange,

The range may be reduced or increased

it indicates that the garage door is

a little due to obstacle conditions around

“Opening”.

the garage door opener, such as houses or

trees.

- If the indicator (5) is ON

continuously in Green, it indicates

that the garage door is “Opened”.

- If the indicator (4) or (5) does not

turn to Green, it indicates that the

last status of garage door was not

received properly. The HomeLink

mirror tries to receive the last

known status of the garage door for

a few seconds.

5-51

Convenience Features

Side View Mirrors

WARNING

Do not adjust or fold the side view

mirrors while driving. This may cause

loss of vehicle control resulting in an

accident.

NOTICE

Do not scrape ice off the mirror face;

this may damage the surface of the

glass.

If the mirror is jammed with ice, do

OCN7050019

not adjust the mirror by force. Use

Make sure to adjust the side view mirrors

an approved de-icer (not radiator

to your desired position before you begin

antifreeze) spray, or a sponge or soft

driving.

cloth with very warm water, or move

the vehicle to a warm place and

Your vehicle is equipped with both

allow the ice to melt.

left-hand and right-hand side view

mirrors. The mirrors can be adjusted

remotely with the remote switch. The

side view mirrors can be folded to help

prevent damage when going through

an automatic car wash or when passing

through a narrow street.

The right side view mirror is convex.

Objects seen in the mirror are closer than

they appear.

Use the inside rear view mirror or look

back directly to determine the actual

distance of other vehicles prior to

changing lanes.

5-52

Side View Mirror Adjustment

Folding the side view mirrors

OCN7N050001N

OCN7050022

1. Press either the L (left side) or R (right

To fold the side view mirrors, grasp the

side) button (1) to select the side view

housing of the mirror and then fold it

mirror you would like to adjust.

inwards.

2. Use the mirror adjustment control (2)

to position the selected mirror up,

down, left or right.

3. After adjustment, put the button into

neutral (center) position to prevent

inadvertent adjustment.

NOTICE

ś The mirrors stop moving when

they reach the maximum adjusting

angles, but the motor continues to

operate while the switch is pressed.

Do not press the switch longer than

necessary, because this can damage

the motor.

ś Do not attempt to adjust the side

view mirrors by hand, because this

can damage the motor.

5-53

Power Windows

Window opening and closing

The ignition switch must be in the ON

position to be able to raise or lower

the windows. Each door has a Power

Window switch to control that door’s

window. The driver has a Power Window

Lock switch which can block the

operation of rear passenger windows.

The power windows will operate for

approximately 30 seconds after the

ignition switch is placed in the ACC or

LOCK/OFF position. However, if the front

doors are opened, the Power Windows

OCN7050082

will not operate even within the 30

To open:

second period.

Press the window switch down to the

first detent position (5). Release the

WARNING

switch when you want the window to

stop.

To avoid serious injury or death, do not

extend your head, arms or body outside

the windows while driving.

To close:

Pull the window switch up to the first

detent position (5). Release the window

Information

switch when you want the window to

In cold and wet climates, power

stop.

windows may not work properly due to

freezing conditions.

Auto down window (if equipped)

While driving with the rear windows

Pressing the power window switch

down or with the sunroof (if equipped)

down momentarily to the second

opened (or partially opened), your

detent position (6) completely lowers

vehicle may demonstrate a wind

the window even when the switch is

buffeting or pulsation noise. This

released. To stop the window at the

noise is normal and can be reduced

desired position while the window is in

or eliminated by taking the following

operation, pull up or press down and

actions. If the noise occurs with one

release the switch.

or both of the rear windows down,

partially lower both front windows

Auto up/down window (if equipped)

approximately one inch. If you

Pressing or pulling up the power window

experience the noise with the sunroof

switch momentarily to the second

open, slightly close the sunroof.

detent position (6) completely lowers or

lifts the window even when the switch

is released. To stop the window at the

desired position while the window is in

operation, pull up or press down and

release the switch.

5-55

Convenience Features

To reset the power windows

Automatic reverse (if equipped)

If the power windows do not operate

normally, the automatic power window

system must be reset as follows:

1. Place the ignition switch to the ON

position.

2. Close the window and continue

pulling up on the power window

switch for at least one second.

If the power windows do not operate

properly after resetting, have the system

checked by an authorized HYUNDAI

OCN7050026

dealer.

If a window senses any obstacle while it

is closing automatically, it will stop and

WARNING

lower approximately 12 inches (30 cm) to

allow the object to be cleared.

The automatic reverse feature doesn’t

activate while resetting the power

If the window detects the resistance

window system. Make sure body parts

while the power window switch is

or other objects are safely out of the

pulled up continuously, the window

way before closing the windows to

will stop upward movement then lower

avoid injuries or vehicle damage.

approximately 1 inch (2.5 cm).

If the power window switch is pulled

up continuously again within 5 seconds

after the window is lowered by the

automatic window reverse feature,

the automatic window reverse will not

operate.

Information

The automatic reverse feature is only

active when the “Auto Up” feature is used

by fully pulling up the switch to the second

detent.

WARNING

Make sure body parts or other objects

are safely out of the way before closing

the windows to avoid injuries or vehicle

damage.

Objects less than 0.16 inch (4 mm) in

diameter caught between the window

glass and the upper window channel

may not be detected by the automatic

reverse window and the window will

not stop and reverse direction.

5-56

NOTICE

WARNING

Do not install any accessories on the

NEVER leave the keys in your vehicle

windows. The automatic reverse

with unsupervised children, when

feature may not operate.

the engine is running.

NEVER leave any child unattended in

Power window lock switch

the vehicle. Even very young children

may inadvertently cause the vehicle

to move, entangle themselve s in

the windows, or otherwise injure

themselves or others.

Always double check to make

sure arms, hands, head and other

obstructions are safely out of the

way before closing a window.

Do not allow children to play with the

power windows. Keep the driver’s

door power window lock switch in

OCN7050027

the LOCK position (pressed). Serious

The driver can disable the power window

injury can result from unintentional

switches on the rear passenger doors by

window operation by the child.

pressing the power window lock switch.

Do not extend your head, arms or

When the power window lock switch is

body outside the windows while

pressed:

driving.

ś The rear passenger control will not

be able to operate the rear passenger

power window

ś Note that the front passenger control

is still able to operate the front

passenger window, and that the driver

master control can still operate all the

power windows.

NOTICE

ś To prevent possible damage to the

power window system, do not open

or close two windows or more at the

same time. This will also ensure the

longevity of the fuse.

ś Never try to operate the main

switch on the driver’s door and the

individual door window switch in

opposite directions at the same time.

If this is done, the window will stop

and cannot be opened or closed.

5-57

Convenience Features

681522) ǣ,) (48,33('Ǥ

If your vehicle is equipped with a

Sunshade

sunroof, you can slide or tilt your sunroof

with the sunroof switch located on the

overhead console.

OCN7050029

Use the sunshade to block direct sunlight

coming through the sunroof glass.

OCN7050028

Open or close the sunshade by hand.

The sunroof can only be operated when

the ignition switch or Engine Start/Stop

button is in the ON or START position.

Information

The sunroof can be operated for

The sunshade opens automatically when

approximately 3 minutes after the

the sunroof glass is opened, but the

ignition switch or Engine Start/Stop

sunshade does not close automatically

button is in the ACC or LOCK/OFF

when the sunroof glass is closed. Also, only

position. However, if the front door is

the sunshade cannot be closed when the

open, the sunroof cannot be operated

sunroof glass is opened.

even within the 3 minute period.

NOTICE

WARNING

Do not pull the sunshade up or down,

ś Adjust the sunroof or sunshade when

or apply excessive force as such action

your vehicle stops. This could result

may damage the sunshade or cause it

in loss of control and an accident

to malfunction.

that may cause injury, or property

damage.

ś Do not leave the engine running

and the key in your vehicle with

unsupervised children. Unattended

children could operate the sunroof,

which could result in serious injury.

ś Do not sit on the top of the vehicle. It

may cause injury or vehicle damage.

NOTICE

Do not operate the sunroof when roof

bars are installed on the vehicle or

when there is luggage on the roof.

5-58

Tilt Open/Close

Slide Open/Close

OCN7051144

OCN7N051031

[1] : Tilt open

Push the sunroof switch rearward,

[2] : Tilt close

the sunshade and sunroof glass slide

open.

ś Push the sunroof switch upward, the

sunroof glass tilts open.

Push the sunroof switch forward, only

the sunroof glass closes.

ś Push the sunroof switch forward, the

sunroof glass automatically closes.

Push the sunroof switch forward or

rearward to the first detent position,

the sunroof glass moves until the

To stop the sunroof movement at any

switch is released.

point, push the sunroof switch in any

direction.

Push the sunroof switch forward

or rearward to the second detent

position, the sunroof glass operates

Information

automatically (auto slide feature). To

The sunroof glass cannot slide open and

stop the sunroof movement at any

tilt open at the same time. You cannot tilt

point, push the sunroof switch in any

the sunroof glass open while the sunroof

direction.

glass is slide open. Also, you cannot slide

The sunroof glass stops halfway

the sunroof glass open while the sunroof

(first detent position) before it is fully

is tilt open. Slide open or tilt open the

opened. To fully open the sunroof

sunroof glass when the sunroof glass is

glass, push the sunroof switch

completely closed.

rearward once more. At this time, the

sunroof glass opens only while the

switch is pushed.

Information

To reduce wind noise while driving,

we recommend that you drive at the

recommended position before the

maximum slide open position.

5-59

Convenience Features

Automatic Reversal (if equipped)

NOTICE

Do not continue to push the sunroof

switch after the sunroof is fully

opened, closed, or tilted. Damage to

the sunroof motor could occur.

Continuous operations such as slide

open/close, tilt open/close, etc. may

cause the motor or sunroof system to

malfunction.

Regularly remove any accumulated

dust on the sunroof rail.

Dust accumulated between the

ODH043039

sunroof and roof panel can make

If the sunroof glass senses any obstacle

noise. Open the sunroof and remove

while it is closing automatically, it will

dust regularly using a clean cloth.

reverse direction then stop at a certain

Do not try to open the sunroof when

position.

the temperature is below freezing

The auto reverse function may not

or when the sunroof is covered

work if an object thin or soft is caught

with snow or ice. The sunroof may

between the sliding sunroof glass and

not work properly and may break if

sunroof sash.

opened by force.

Do not open or drive with the sunroof

WARNING

glass open immediately after rain or

washing the vehicle. Water may wet

ś Make sure heads, hands, arms or

the interior of the vehicle.

any other body parts or objects are

out of the way before operating the

Do not extend any luggage outside

the sunroof while driving. Vehicle

sunroof. Body parts or objects may

get caught causing injuries or vehicle

damage may occur if the vehicle

suddenly stops.

damage.

ś Never deliberately use your body

parts to test the automatic reversal

WARNING

function. The sunroof glass may

Do not extend your head, arms, body

reverse direction, but there is a risk

parts or objects outside the sunroof

of injury.

while driving. Injuries may occur if the

vehicle suddenly stops.

5-60

Resetting the Sunroof

Information

If the sunroof is not reset when the vehicle

battery connector is disconnected or

discharged, or the sunroof fuse is blown,

the sunroof may not operate normally.

Sunroof Open Warning

(if equipped)

OCN7051028L

In some circumstances resetting the

sunroof operation may need to be

performed. Some instances where

resetting the sunroof may be required

include:

ś When the battery connector is either

disconnected or discharged

OCN7040018

ś When the sunroof fuse is replaced

If the driver turns off the engine when

ś If the sunroof one-touch AUTO OPEN/

the sunroof is not fully closed, the

CLOSE operation is not functioning

warning chime will sound for several

properly

seconds and the sunroof open warning

will appear on the cluster LCD display.

Sunroof resetting procedure:

Close the sunroof securely when leaving

1. It is recommended to perform the

your vehicle.

reset procedure with the vehicle

engine running. Start the vehicle in P

CAUTION

(Park).

2. Make sure the sunroof glass is in the

Make sure the sunroof is closed fully

fully closed position. If the sunroof

when leaving your vehicle.

glass is open, push the switch forward

If the sunroof is left open, rain or snow

until the sunroof glass is fully closed.

may wet the interior of the vehicle.

3. Release the switch when the sunroof

Also, leaving the sunroof open when the

glass is fully closed.

vehicle is unattended may invite theft.

4. Push the switch forward until the

sunroof glass moves slightly. Then

release the switch.

5. Once again push and hold the sunroof

switch forward until the sunroof glass

slides open and close. Do not release

the switch until the operation is

completed. If you release the switch

during operation, start the procedure

again from step 2.

5-61

Convenience Features

HOOD

Opening the hood

OCN7050035

OCN7050033

5. Hold the hood open with the support

rod (3).

1. Park the vehicle and set the parking

brake.

2. Pull the release lever to unlatch the

WARNING

hood. The hood should pop open

Support rod

slightly.

ś After driving, the engine

compartment and support rod will

be hot. Grasp the support rod in the

area wrapped in rubber to prevent

burns.

ś The support rod must be inserted

completely into the hole provided

whenever you inspect the engine

compartment. This will prevent

the hood from falling and possibly

injuring you.

OCN7H050008

3. Go to the front of the vehicle, raise

the hood slightly, push the secondary

latch up (1) inside of the hood center

and lift the hood (2).

4. Pull out the support rod.

5-62

Closing the hood

WARNING

1. Before closing the hood, check the

ś Before closing the hood, ensure

following:

all obstructions are removed from

ś All filler caps in engine

around the hood opening.

compartment must be correctly

ś Always double check to be sure that

installed.

the hood is firmly latched before

ś Gloves, rags or any other

driving away. Check there is no

combustible material must

hood open warning light or message

be removed from the engine

displayed on the instrument cluster.

compartment.

Driving with the hood opened may

2. Return the support rod to its clip to

cause a total loss of visibility, which

prevent it from rattling.

might result in an accident.

3. Lower the hood halfway (lifted

ś Do not move the vehicle with the

approximately 30 cm from the closed

hood in the raised position, as vision

position) and push down to securely

is obstructed, which might result in

lock in place. Then double check to be

an accident, and the hood could fall

sure the hood is secure.

or be damaged.

If the hood can be raised slightly, it is

not securely locked. Open it again and

close it with more force.

5-63

Convenience Features

TRUNK

Opening the trunk

Inside

1. Make sure the shift lever is in P

(Park, for Dual clutch transmission/

Intelligent variable transmission) or

first gear or R (Reverse, for manual

transmission) and set the parking

brake.

Outside

OCN7050037

- Use the trunk release lever.

3. Lift the trunk lid up.

Closing the trunk

Lower the trunk lid and press down

until it locks. To be sure the trunk lid is

OCN7H050002

securely fastened, always check by trying

2. Then do one of the following:

to pull it up again.

ś Hold down the trunk unlock button

located on your remote key or smart

WARNING

key for more than 1 second.

Always keep the trunk lid completely

ś Additionally, for vehicles equipped

closed while the vehicle is in motion. If

with smart key :

it is left open or ajar, poisonous exhaust

- While all doors are unlocked, press

gases containing carbon monoxide

the switch in the trunk to open the

(CO) may enter the vehicle and serious

trunk with or without the smart key

illness or death may result.

in your possession.

- If any door is locked or all doors are

Information

locked, the switch can still be used

to open the trunk, as long as the

To prevent damage to the trunk lift

smart key is in your possession.

cylinders and the attached hardware,

always close the trunk before driving.

NOTICE

In cold and wet climates, trunk lock

and trunk mechanisms may not work

properly due to freezing conditions.

5-64

Hyundai Elantra Hybrid (2023 year). Manual in english - page 7
