Hyundai Grand Santa Fe (2016 year). Instruction - part 40

Maintenance

License plate lamp bulb

Door courtesy lamp bulb

replacement

replacement (if equipped)

ODM072039

ODM042261

1. Loosen the lens retaining screws

If the light bulb does not operate, we

with a philips head screwdriver.

recommend that the vehicle be

checked by an authorized HYUNDAI

2. Remove the lens.

dealer.

3. Remove the bulb by pulling it

straight out.

4. Install a new bulb.

5. Reinstall the lens securely with the

lens retaining screws.

7 95

Maintenance

■ Map lamp

■ Luggage room lamp (if equipped)

Interior lamp bulb replacement

1. Using a flat-blade screwdriver,

gently pry the lens from the interi-

or lamp housing.

2. Remove the bulb by pulling it

straight out.

WARNING

■ Room lamp

■ Sunvisor lamp

Prior to working on the Interior

• Type A

lamps, ensure that the “OFF”

button is depressed to avoid

burning your fingers or receiv-

ing an electric shock.

3. Install a new bulb in the socket.

4. Align the lens tabs with the interior

lamp housing notches and snap

the lens into place.

• Type B

■ Glove box lamp (if equipped)

CAUTION

Use care not to dirty or damage

lens, lens tab, and plastic hous-

ings.

ODM072040/ODM072042/ODM072052

OXM079044/ODM072041/ODM072043

7 96

Maintenance

APPEARANCE CARE

Exterior care

Finish maintenance

CAUTION

Exterior general caution

Washing

•

Do not use strong soap, chem-

To help protect your vehicle’s finish

It is very important to follow the label

ical detergents or hot water,

directions when using any chemical

from rust and deterioration, wash it

and do not wash the vehicle in

thoroughly and frequently at least

cleaner or polish. Read all warning

direct sunlight or when the

and caution statements that appear

once a month with lukewarm or cold

body of the vehicle is warm.

water.

on the label.

If you use your vehicle for off-road

•

Be careful when washing the

driving, you should wash it after each

side windows of your vehicle.

off-road trip. Pay special attention to

Especially, with high-pressure

the removal of any accumulation of

water. Water may leak through

salt, dirt, mud, and other foreign

the windows and wet the inte-

materials. Make sure the drain holes

rior.

in the lower edges of the doors and

•

To prevent damage to the

rocker panels are kept clear and

plastic parts and lamps, do

clean.

not clean with chemical sol-

Insects, tar, tree sap, bird droppings,

vents or strong detergents.

industrial pollution and similar

deposits can damage your vehicle’s

finish if not removed immediately.

WARNING - Wet brakes

Even prompt washing with plain

After washing the vehicle, test

water may not completely remove all

the brakes while driving slowly

these deposits.

to see if they have been affected

A mild soap, safe for use on painted

by water. If braking performance

surfaces, may be used.

is impaired, dry the brakes by

After washing, rinse the vehicle thor-

applying them lightly while

oughly with lukewarm or cold water.

maintaining a slow forward

Do not allow soap to dry on the fin-

speed.

ish.

7 97

Maintenance

Waxing

Finish damage repair

Wax the vehicle when water will no

Deep scratches or stone chips in the

longer bead on the paint.

painted surface must be repaired

Always wash and dry the vehicle

promptly. Exposed metal will quickly

before waxing. Use a good quality

rust and may develop into a major

liquid or paste wax, and follow the

repair expense.

manufacturer’s instructions. Wax all

metal trim to protect it and to main-

✽ NOTICE

tain its luster. Removing oil, tar, and

similar materials with a spot remover

If your vehicle is damaged and

will usually strip the wax from the fin-

requires any metal repair or

OJB037800

ish. Be sure to re-wax these areas

replacement, be sure the body shop

even if the rest of the vehicle does

applies anti-corrosion materials to

not yet need waxing.

the parts repaired or replaced.

CAUTION

•

Water washing in the engine

CAUTION

compartment including high

pressure water washing may

•

Wiping dust or dirt off the

cause the failure of electrical

body with a dry cloth will

circuits located in the engine

scratch the finish.

compartment.

•

Do not use steel wool, abra-

•

Never allow water or other liq-

sive cleaners, or strong deter-

uids to come in contact with

gents containing highly alka-

electrical/electronic compo-

line or caustic agents on

nents inside the vehicle as

chrome-plated or anodized

this may damage them.

aluminum parts. This may

result in damage to the pro-

tective coating and cause dis-

coloration or paint deteriora-

tion.

7 98

Maintenance

Bright-metal maintenance

Underbody maintenance

WARNING

•

To remove road tar and insects,

Corrosive materials used for ice and

use a tar remover, not a scraper or

snow removal and dust control may

After washing the vehicle, test

other sharp object.

collect on the underbody. If these

the brakes while driving slowly

materials are not removed, acceler-

to see if they have been affected

•

To protect the surfaces of bright-

ated rusting can occur on underbody

by water. If braking performance

metal parts from corrosion, apply a

parts such as the fuel lines, frame,

is impaired, dry the brakes by

coating of wax or chrome preser-

floor pan and exhaust system, even

applying them lightly while

vative and rub to a high luster.

though they have been treated with

maintaining a slow forward

•

During winter weather or in coastal

rust protection.

speed.

areas, cover the bright metal parts

Thoroughly flush the vehicle under-

with a heavier coating of wax or

preservative. If necessary, coat the

body and wheel openings with luke-

warm or cold water once a month,

parts with non-corrosive petroleum

jelly or other protective compound.

after off-road driving and at the end

of each winter. Pay special attention

to these areas because it is difficult

to see all the mud and dirt. It will do

more harm than good to wet down

the road grime without removing it.

The lower edges of doors, rocker

panels, and frame members have

drain holes that should not be

allowed to clog with dirt; trapped

water in these areas can cause rust-

ing.

7 99

Maintenance

Aluminum wheel maintenance

Corrosion protection

High-corrosion areas

The aluminum wheels are coated

Protecting your vehicle from corro-

If you live in an area where your car

with a clear protective finish.

sion

is regularly exposed to corrosive

materials, corrosion protection is

•

Do not use any abrasive cleaner,

By using the most advanced design

particularly important. Some of the

polishing compound, solvent, or

and construction practices to combat

common causes of accelerated cor-

wire brushes on aluminum wheels.

corrosion, we produces cars of the

rosion are road salts, dust control

They may scratch or damage the

highest quality. However, this is only

chemicals, ocean air and industrial

finish.

part of the job. To achieve the long-

pollution.

term corrosion resistance your vehi-

•

Clean the wheel when it has

cooled.

cle can deliver, the owner's coopera-

tion and assistance is also required.

•

Use only a mild soap or neutral

detergent, and rinse thoroughly

Common causes of corrosion

with water. Also, be sure to clean

the wheels after driving on salted

The most common causes of corro-

roads. This helps prevent corro-

sion on your car are:

sion.

• Road salt, dirt and moisture that is

•

Avoid washing the wheels with

allowed to accumulate underneath

high-speed car wash brushes.

the car.

•

Do not use any alkaline or acid

• Removal of paint or protective

detergent. It may damage and cor-

coatings by stones, gravel, abra-

rode the aluminum wheels coated

sion or minor scrapes and dents

with a clear protective finish.

which leave unprotected metal

exposed to corrosion.

7 100

Maintenance

Moisture breeds corrosion

Keep your car clean

• When cleaning lower door panels,

rocker panels and frame mem-

Moisture creates the conditions in

The best way to prevent corrosion is

bers, be sure that drain holes are

which corrosion is most likely to

to keep your car clean and free of

kept open so that moisture can

occur. For example, corrosion is

corrosive materials. Attention to the

escape and not be trapped inside

accelerated by high humidity, partic-

underside of the car is particularly

to accelerate corrosion.

ularly when temperatures are just

important.

above freezing. In such conditions,

the corrosive material is kept in con-

• If you live in a high-corrosion area

Keep your garage dry

tact with the car surfaces by moisture

— where road salts are used, near

Don't park your car in a damp, poor-

that is slow to evaporate.

the ocean, areas with industrial

ly ventilated garage. This creates a

Mud is particularly corrosive

pollution, acid rain, etc.—, you

favorable environment for corrosion.

because it is slow to dry and holds

should take extra care to prevent

This is particularly true if you wash

moisture in contact with the vehicle.

corrosion. In winter, hose off the

your car in the garage or drive it into

Although the mud appears to be dry,

underside of your car at least once

the garage when it is still wet or cov-

it can still retain the moisture and

a month and be sure to clean the

ered with snow, ice or mud. Even a

promote corrosion. High tempera-

underside thoroughly when winter

heated garage can contribute to cor-

tures can also accelerate corrosion

is over.

rosion unless it is well ventilated so

of parts that are not properly ventilat-

moisture is dispersed.

ed so the moisture can be dispersed.

•

When cleaning underneath the car,

For all these reasons, it is particular-

give particular attention to the

ly important to keep your car clean

components under the fenders and

and free of mud or accumulations of

other areas that are hidden from

other materials. This applies not only

view. Do a thorough job; just damp-

to the visible surfaces but particular-

ening the accumulated mud rather

ly to the underside of the car.

than washing it away will acceler-

ate corrosion rather than prevent

To help prevent corrosion

it. Water under high pressure and

steam are particularly effective in

You can help prevent corrosion from

removing accumulated mud and

getting started by observing the fol-

corrosive materials.

lowing:

7 101

Maintenance

Keep paint and trim in good con-

Don't neglect the interior

Interior care

dition

Moisture can collect under the floor

Interior general precautions

Scratches or chips in the finish

mats and carpeting to cause corro-

Prevent chemicals such as perfume,

should be covered with "touch-up"

sion. Check under the mats periodi-

cosmetic oil, sun cream, hand clean-

paint as soon as possible to reduce

cally to be sure the carpeting is dry.

er and air freshener from contacting

the possibility of corrosion. If bare

Use particular care if you carry fertil-

the interior parts because they may

metal is showing through, the atten-

izers, cleaning materials or chemi-

cause damage or discoloration. If

tion of a qualified body and paint

cals in the car.

they do contact the interior parts,

shop is recommended.

These should be carried only in

wipe them off immediately.

proper containers and any spills or

See the instructions that follow for

leaks should be cleaned up, flushed

Bird droppings : Bird droppings are

the proper way to clean vinyl.

highly corrosive and may damage

with clean water and thoroughly

dried.

painted surfaces in just a few hours.

CAUTION

Always remove bird droppings as

soon as possible.

Never allow water or other liq-

uids to come in contact with

electrical/electronic

compo-

nents inside the vehicle as this

may damage them.

7 102

Maintenance

Cleaning the upholstery and inte-

Cleaning the lap/shoulder belt

CAUTION

rior trim

webbing

When cleaning leather products

Vinyl

Clean the belt webbing with any mild

(steering wheel, seats etc.), use

soap solution recommended for

Remove dust and loose dirt from

neutral detergents or low alco-

cleaning upholstery or carpet. Follow

vinyl with a whisk broom or vacuum

hol content solutions. If you use

the instructions provided with the

cleaner. Clean vinyl surfaces with a

high alcohol content solutions

soap. Do not bleach or re-dye the

vinyl cleaner.

or acid/alkaline detergents, the

webbing because this may weaken

color of the leather may fade or

it.

Fabric

the surface may get stripped off.

Remove dust and loose dirt from fab-

ric with a whisk broom or vacuum

Cleaning the interior window

cleaner. Clean with a mild soap solu-

glass

tion recommended for upholstery or

If the interior glass surfaces of the

carpets. Remove fresh spots imme-

vehicle become fogged (that is, cov-

diately with a fabric spot cleaner. If

ered with an oily, greasy or waxy

fresh spots do not receive immediate

film), they should be cleaned with

attention, the fabric can be stained

glass cleaner. Follow the directions

and its color can be affected. Also, its

on the glass cleaner container.

fire-resistant properties can be

reduced if the material is not proper-

ly maintained.

CAUTION

Do not scrape or scratch the

inside of the rear window. This

CAUTION

may result in damage to the rear

Using anything but recommend-

window defroster grid.

ed cleaners and procedures

may affect the fabric’s appear-

ance and fire-resistant proper-

ties.

7 103

Maintenance

EMISSION CONTROL SYSTEM

The emission control system of your

Caution for the Inspection and

2. Evaporative emission con-

vehicle is covered by a written limited

Maintenance Test (With Electronic

trol System

warranty. Please see the warranty

Stability Control (ESC) system)

The Evaporative Emission Control

information contained in the Service

• To prevent the vehicle from mis-

System is designed to prevent fuel

Passport in your vehicle.

firing during dynamometer test-

vapors from escaping into the atmos-

Your vehicle is equipped with an

ing, turn the Electronic Stability

phere.

emission control system to meet all

Contol

(ESC) system off by

emission regulations.

pressing the ESC switch.

Canister

There are three emission control

• After dynamometer testing is

Fuel vapors generated inside the fuel

systems which are as follows.

completed, turn the ESC system

tank are absorbed and stored in the

back on by pressing the ESC

onboard canister. When the engine is

switch again.

running, the fuel vapors absorbed in

(1) Crankcase emission control sys-

the canister are drawn into the surge

tem

tank through the purge control sole-

(2) Evaporative emission control sys-

1. Crankcase emission control

noid valve.

tem

system

(3) Exhaust emission control system

The positive crankcase ventilation

Purge Control Solenoid Valve

system is employed to prevent air

(PCSV)

pollution caused by blow-by gases

The purge control solenoid valve is

In order to assure the proper function

being emitted from the crankcase.

controlled by the Engine Control

of the emission control systems, it is

This system supplies fresh filtered air

Module

(ECM); when the engine

recommended that you have your

coolant temperature is low during

to the crankcase through the air

car inspected and maintained by an

idling, the PCSV closes so that evap-

intake hose. Inside the crankcase,

authorized HYUNDAI dealer in

orated fuel is not taken into the

the fresh air mixes with blow-by

accordance with the maintenance

engine. After the engine warms-up

gases, which then pass through the

schedule in this manual.

during ordinary driving, the PCSV

PCV valve into the induction system.

opens to introduce evaporated fuel to

the engine.

7 104

Maintenance

3. Exhaust emission control

Engine exhaust gas precautions

•

Do not operate the engine in con-

system

(carbon monoxide)

fined or closed areas

(such as

garages) any more than what is

The Exhaust Emission Control

• Carbon monoxide can be present

necessary to move the vehicle in or

System is a highly effective system

with other exhaust fumes.

out of the area.

which controls exhaust emissions

Therefore, if you smell exhaust

while maintaining good vehicle per-

fumes of any kind inside your vehi-

•

When the vehicle is stopped in an

cle, have it inspected and repaired

open area for more than a short

formance.

immediately. If you ever suspect

time with the engine running,

exhaust fumes are coming into

adjust the ventilation system

(as

Vehicle modifications

your vehicle, drive it only with all

needed) to draw outside air into the

This vehicle should not be modified.

the windows fully open. Have your

vehicle.

Modification of your vehicle could

vehicle checked and repaired

•

Never sit in a parked or stopped

affect its performance, safety or

immediately.

vehicle for any extended time with

durability and may even violate gov-

the engine running.

ernmental safety and emissions reg-

WARNING - Exhaust

•

When the engine stalls or fails to

ulations.

start, excessive attempts to restart

Engine exhaust gases contain

In addition, damage or performance

the engine may cause damage to

carbon monoxide (CO). Though

problems resulting from any modifi-

the emission control system.

colorless and odorless, it is

cation may not be covered under

dangerous and could be lethal if

warranty.

inhaled. Follow the instructions

• If you use unauthorized electronic

following to avoid CO poison-

devices, it may cause the vehicle to

ing.

operate abnormally, wire damage,

battery discharge and fire. For your

safety, do not use unauthorized

electronic devices.

7 105

Maintenance

Operating precautions for catalyt-

Your vehicle is equipped with a cat-

Failure to observe these precautions

ic converters (if equipped)

alytic converter emission control

could result in damage to the catalyt-

device.

ic converter and to your vehicle.

Additionally, such actions could void

WARNING - Fire

Therefore, the following precautions

your warranties.

must be observed:

•

A hot exhaust system can

ignite flammable items under

•

Use only UNLEADED FUEL for

your vehicle. Do not park,

gasoline engine.

idle, or drive the vehicle over

•

Do not operate the vehicle when

or near flammable objects,

there are signs of engine malfunc-

such as dry grass, paper,

tion, such as misfire or a noticeable

leaves, etc.

loss of performance.

•

The exhaust system and cat-

•

Do not misuse or abuse the

alytic system are very hot

engine. Examples of misuse are

while the engine is running or

coasting with the ignition off and

immediately after the engine

descending steep grades in gear

is turned off. Keep away from

with the ignition off.

the exhaust system and cat-

•

Do not operate the engine at high

alytic, you may get burned.

idle speed for extended periods (5

Also, do not remove the heat

minutes or more).

sink around the exhaust sys-

•

Do not modify or tamper with any

tem, do not seal the bottom of

part of the engine or emission con-

the vehicle or do not coat the

trol system. All inspections and

vehicle for corrosion control.

adjustments must be made by an

It may present a fire risk under

authorized HYUNDAI dealer.

certain conditions.

•

Avoid driving with a very low fuel

level. If you run out of gasoline, it

could cause the engine to misfire

and result in excessive loading of

the catalytic converter.

106

Maintenance

Diesel Particulate Filter

When the malfunction indicator light

(if equipped)

blinks, it may stop blinking by driving

CAUTION - Diesel Fuel

the vehicle at more than 60km/h (37

(if equipped with DPF)

The Diesel Particulate Filter (DPF)

mph) or at more than second gear

It is recommended to use the

system removes the soot emitted

with 1500 ~ 2000 engine rpm for a

regulated automotive diesel fuel

from the vehicle.

certain time (for about 25 minutes).

for diesel vehicle equipped with

Unlike a disposable air filter, the DPF

If the malfunction indicator light con-

the DPF system.

system automatically burns

(oxi-

tinues to be blinked in spite of the

If you use diesel fuel including

dizes) and removes the accumulated

procedure, please visit an authorized

high sulfur (more than 50 ppm

soot according to the driving condi-

HYUNDAI dealer and then check the

sulfur) and unspecified addi-

tion. In other words, the active burn-

DPF system.

tives, it can cause the DPF sys-

ing by engine control system and

high exhaust gas temperature

If you continue to drive with the mal-

tem to be damaged and white

caused by normal/high driving condi-

function indicator light blinking for a

smoke can be emitted.

tion burns and removes the accumu-

long time, the DPF system can be

lated soot.

damaged and fuel consumption can

be worsen.

However, if the vehicle continues to

be driven at low speed for long time,

the accumulated soot may not be

automatically removed because of

low exhaust gas temperature. In this

particular case, the amount of soot is

out of detection limit, the soot oxida-

tion process by engine control sys-

tem may not happen and the mal-

function indicator light may blink.

7 107

Specifications & Consumer information

Dimensions

8-2

Engine

8-2

Bulb wattage

8-3

Tires and wheels

8-4

Load and speed capacity tires

8-4

Gross vehicle weight

8-5

Luggage volume

8-5

Recommended lubricants and capacities

8-6

• Recommended SAE viscosity number

8-8

Vehicle identification number (VIN)

8-9

Vehicle certification label

8-9

Tire specification and pressure label

8-10

Engine number

8-10

Air conditioner compressor label

8-10

Refrigerant label

8-11

Declaration of conformity

8-11

Specifications & Consumer information

DIMENSIONS

item

mm(in)

Overall length

4,915 (193.5)

Overall width

1,885 (74)

For Europe

1,685 (66.3)/1,695 (66.7) *1

Overall height

Except Europe

1,690 (66.5)/1,700 (66.9) *1

235/60R18

1,628 (64.1)

Front tread

235/55R19

1,628 (64.1)

235/60R18

1,639 (64.5)

Rear tread

235/55R19

1,639 (64.5)

Wheelbase

2,800 (110)

with roof rack

ENGINE

Gasoline

Item

Diesel R2.2

lambda II 3.3

Displacement

3,342

2,199

cc (cu. in)

(203.94)

(134.19)

Bore x Stroke

92X83.8

85.4X96

mm (in.)

(3.62X3.29)

(3.34X3.77)

Firing order

1-2-3-4-5-6

1-3-4-2

No. of cylinders

V - type

4. In-line

8 2

Specifications & Consumer information

BULB WATTAGE

Light Bulb

Wattage

Bulb type

Headlights(Low)

55 or 35(HID) *

H7L or D3S

Headlights(High)

H7L

Front turn signal lamps

PY21W

Front

Front position lights

5 or LED

W5W or LED

Front fog lights

Side Repeater lamps (Outside Mirror)

LED

Daytime running lights *

LED

Rear fog lights *

P21W

Rear Stop/Tail lights (outside)

21/5, LED

P21/5W, LED

Rear tail lights (Inside)

W8W

Rear Stop/Tail lights (Inside)

LED

Rear

Rear turn signal lights

PY21W

Back-up lights

W16W

High mounted stop light

LED

License plate lights

W5W

Map lamps

FESTOON

Room lamps

FESTOON

Vanity mirror lamps

FESTOON

Interior

Glove box lamp

FESTOON

Door courtesy lamps

FESTOON

Luggage lamp

FESTOON

* If equipped

Specifications & Consumer information

TIRES AND WHEELS

Inflation pressure bar (psi, kPa)

Normal load

Maximum load

Wheel lug nut torque

Item

Tire size

Wheel size

(

)

(

)

kg•m (lb•ft, N•m)

Front

Rear

Front

Rear

235/60R18

7.5J×18

2.3

Full size tire

235/55R19

7.5J×19

(33,230)

9~11

(65~79, 88~107)

Compact spare tire

4.2

T165/90R17

4.0T×17

(if equipped)

(60,420)

CAUTION

When replacing tires, use the same size originally supplied with the vehicle.

Using tires of a different size can damage the related parts or make it work irregularly.

LOAD AND SPEED CAPACITY TIRES

Load Capacity

Speed Capacity

Item

Tire size

Wheel size

LI *1

SS *2

km/h

235/60R18

7.5J×18

103

875

210

Full size tire

235/55R19

7.5J×19

101

825

210

Compact spare tire

T165/90R17

4.0T×17

116

1250

130

(if equipped)

*1 LI

: LOAD INDEX

*2 SS : SPEED SYMBOL

8 4

Content .. 38 39 40 41 ..
