1 CONTROLS AND EQUIPMENT

B670D05A-EAT

Air Flow Control

HFC2046-D

HFC2047-D

Face-Level

Bi-Level

HFC2068

Selecting the "Face" mode will cause

Air is discharged through the face vents

This is used to direct the flow of air. Air

air to be discharged through the face

and the floor vents. This makes it pos-

can be directed to the floor, dashboard

level vents.

sible to have cooler air from the dash-

outlets, or windscreen. Five symbols

board vents and warmer air from the

are used to represent Face, Bi-Level,

floor outlets at the same time.

Floor, Floor-Defrost and Defrost air po-

sition.

fcuk-1.p65

12/27/2006, 10:12 AM

CONTROLS AND EQUIPMENT

HFC2048-D

HFC2049-D

HFC2050-D

Floor-Level

Floor-Defrost Level

Defrost-Level

Air is discharged through the floor vents.

Air is discharged through the windscreen

defrost vents and the floor vents.

defrost vents.

If the "Floor-Defrost" mode is selected,

If the "Defrost" mode is selected, the A/

the A/C will turn on automatically and

C will turn on automatically and "Fresh"

"Fresh" mode will be activated.

mode will be activated.

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

HEATING CONTROLS

B670C02FC-EAT

With the "Fresh" mode selected, air

B690A02S-AAT

Air Intake Control

enters the vehicle from the outside and

is heated or cooled according to the

function selected.

With the "Recirculation" mode selected,

air from within the passenger compart-

ment will be drawn through the heating

system and heated or cooled according

to the function selected.

NOTE:

B690A02FC

o It should be noted that prolonged

HFC2067

operation of the heating in "Recir-

For normal heating operation, set the air

This is used to select fresh outside air

culation" mode will increase fog-

intake control to the "Fresh" position

or recirculation inside air.

ging of the windscreen and side

and the air flow control to "Floor".

To change the air intake control mode,

windows and the air within the

(Fresh mode, Recirculation mode) push

passenger compartment will be-

For faster heating, the air intake control

the control button.

come stale. In addition, prolonged

should be in the "Recirculation" posi-

use of the air conditioning with

tion.

FRESH MODE (

)

: The indicator

the "Recirculation" mode selected

light on the button goes off when the air

may result in the air within the

If the windows fog up, move the air flow

intake control is in fresh mode.

passenger compartment becom-

control to the "Def" (defroster) position.

ing excessively dry.

(The A/C will turn on automatically and

RECIRCULATION MODE (

): The

o When the ignition switch is turned

"Fresh" mode will be activated.)

indicator light on the button is illuminat-

"ON" the air intake control will

ed when the air intake control is in

change to (

) mode (regardless

For maximum heat, rotate the tempera-

recirculation mode.

of switch position). This is normal

ture control to "Warm".

operation.

fcuk-1.p65

12/27/2006, 10:13 AM

CONTROLS AND EQUIPMENT

BI-LEVEL HEATING

VENTILATION

DEFROSTING/DEFOGGING

B700A01S-AAT

B710A01S-AAT

B720A02FC-EAT

HFC2111

B710A01FC

HFC2107

Your Hyundai is equipped with bi-level

To operate the ventilation system:

Use the heating/ventilation system to

heating controls. This makes it pos-

defrost or defog the windscreen:

sible to have cooler air from the dash-

o Set the air intake control to "Fresh"

board vents and warmer air from the

mode (

To remove interior fog on the

floor outlets at the same time. To use

o To direct all intake air to the dash-

windscreen;

this feature:

board vents, set the airflow control to

o Set the air flow control to the defrost

"Face" (

(

) position. (The A/C will turn on

o Set the air intake control to "Fresh"

o Adjust the fan speed control to the

automatically and "Fresh" mode will

mode (

desired speed.

be activated.)

o Set the air flow control at the "Bi-

o Set the temperature control between

o Set the temperature control to the

Level" position.

"Cool" and "Warm".

desired position.

o Adjust the fan speed control to the

o Set the fan speed control between

desired speed.

"1" and "4" position.

o Set the temperature control between

"Cool" and "Warm".

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

AIR CONDITIONING SYSTEM

B730A01L-EAT

B740A01S-EAT

Operation Tips

Air Conditioning Switch

To keep dust or unpleasant fumes

(Not all models)

from entering the car through the

ventilation system, temporarily set

the air intake control at "Recircula-

tion". Be sure to return the control to

"Fresh" when the irritation has

passed to keep fresh air in the ve-

hicle. This will help keep the driver

alert and comfortable.

HFC2108

Air for the heating/cooling system is

To remove the frost or exterior fog on

drawn in through the grilles just ahead

the windscreen;

of the windscreen. Care should be

HFC2069

o Set the air flow control to the defrost

taken that these are not blocked by

The air conditioning is turned on or off

(

) position. (The A/C will turn on

leaves, snow, ice or other obstruc-

by pushing the A/C button on the heat-

automatically and "Fresh" mode will

tions.

ing/air conditioning control panel.

be activated.)

To prevent interior fog on the

o Set the temperature control to warm.

windscreen, set the air intake control

o Set the fan speed control to position

to the fresh air (

) position, and

"3" or "4".

fan speed to the desired position,

turn on the air conditioning system,

NOTE:

and adjust temperature control to

When the A/C is operated continu-

desired temperature.

ously on the floor-defrost level (

) or

defrost level (

), it may cause fog to

form on the exterior windscreen. If

this occurs, set the air flow control to

the face level position (

)and fan

speed control to the low position.

fcuk-1.p65

12/27/2006, 10:13 AM

CONTROLS AND EQUIPMENT

B740B01FC-GAT

o Adjust the fan control to the desired

B740C01FC-GAT

Air Conditioning Operation

speed. For greater cooling, turn the

Dehumidified Heating

Cooling

fan control to

one of the higher

speeds or temporarily

select

the "Recirculation" position on the air

intake control.

B740C01FC

B740B01FC

For dehumidified heating:

To use the air conditioning to cool the

interior:

o Turn on the fan control switch.

o Turn on the air conditioning switch.

o Turn on the fan control switch.

The air conditioning indicator light

o Turn on the air conditioning switch by

should come on at the same time.

pushing in on the switch. The air

o Set the air intake control to "Fresh"

conditioning indicator light should

mode (

come on at the same time.

o Set the air flow control to the desired

o Set the air intake control to "Fresh"

position.

mode (

o Adjust the fan control to the desired

o Set the temperature control to "Cool".

speed.

("Cool" provides maximum cooling.

o For more rapid action, set the fan at

The temperature may be moderated

one of the higher speeds.

by moving the control toward

o Adjust the temperature control to

"Warm".)

provide the desired amount of

warmth.

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

B740D01A-AAT

Operation Tips

If the interior of the car is hot when

you first get in, open the windows for

a few minutes to expel the hot air.

When you are using the air condition-

ing system, keep all windows closed

to keep hot air out.

When moving slowly, as in heavy

traffic, shift to a lower gear. This

increases engine speed, which in

turn increases the speed of the air

conditioning compressor.

On steep grades, turn the air condi-

tioning off to avoid the possibility of

the engine over-heating.

During winter months or in periods

when the air conditioning is not used

regularly, run the air conditioning once

every month for a few minutes. This

will help circulate the lubricants and

keep your system in peak operating

condition.

fcuk-1.p65

12/27/2006, 10:13 AM

CONTROLS AND EQUIPMENT

AUTOMATIC HEATING AND COOLING CONTROL SYSTEM

B970A01FC-EAT

TYPE A (Without Air Quality System)

(Not aII models)

Your Hyundai is equipped with an auto-

matic heating and cooling control sys-

tem controlled by simply setting the

desired temperature.

B970B01FC-EAT

Heating and Cooling Controls

1. Temperature Control

2. Display Window

HFC224-3

3. Blower Fan Control

4. AUTO (Automatic Control) Switch

TYPE B (With Air Quality System)

5. Air Flow Control Switch

6. Air Conditioning Switch

7. Air Intake Control Switch

8. Air Quality System Switch

(Not all models)

9. Defroster Switch

10.OFF Switch

HFC224-2

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

B970C01NF-EAT

Press the "OFF" and "AUTO" but-

Automatic Operation

ton simultaneously for 3 seconds.

The display shows that the unit of

temperature is adjusted to Centi-

grade or Fahrenheit.

(°C  °F or °F  °C)

Photo Sensor

HFC229

2. Turn the "TEMP" knob to set the

HFC227

desired temperature.

The FATC (Full Automatic Tempera-

The temperature will increase to the

ture Control) system automatically con-

maximum 90°F(32°C) by turning the

trols the heating and cooling by doing

knob clockwise.

as follows:

The temperature will decrease to the

B970C01FC-D

minimum 62°F(17°C) by turning the

1. Push the "AUTO" switch. The indi-

knob counterclockwise.

o Never place anything covering the

cator light will illuminate confirming

photo sensor which is located in

that the Face, Floor and/or Bi-Level

NOTE:

the car on the instrument panel to

modes as well as the blower speed

ensure better control of the heat-

o If the battery has been discharged

and air conditioner will be controlled

ing and cooling system.

or disconnected, the temperature

automatically.

mode will reset to Centigrade de-

gree.

This is a normal condition and

you can adjust the temperature

mode from Centigrade to Fahren-

heit as follows;

fcuk-1.p65

12/27/2006, 10:13 AM

CONTROLS AND EQUIPMENT

B980A01Y-AAT

B980B01NF-AAT

B670C02Y-EAT

MANUAL OPERATION

Fan Speed Control Switch

Air Intake Control Switch

(Without A.Q.S)

The heating and cooling system can be

controlled manually as well as by push-

ing buttons other than the "AUTO" but-

ton. In this state, the system sequen-

tially works according to the order of

buttons selected.

The function of the buttons which are

not selected will be controlled automati-

cally.

Press the "AUTO" button in order to

convert to automatic control of the sys-

HFC225

tem.

The fan speed can be set to the desired

HFC240

speed by turning the appropriate fan

This is used to select fresh outside air

speed control knob. The higher the fan

or recirculation inside air.

speed is, the more air is delivered.

To change the air intake control mode,

Pressing the "OFF" button turns off the

(Fresh mode, Recirculation mode) push

fan.

the control button.

FRESH MODE (

) : The indicator

light on the button comes on when the

air intake control is fresh mode.

RECIRCULATION MODE (

) : The

indicator light on the button is illumi-

nated when the air intake control is

recirculation mode.

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

With the "Fresh" mode selected, air

o When the ignition switch is turned

B980C04Y-EAT

enters the vehicle from the outside and

"ON" the air intake control will

Air Intake Control Switch

is heated or cooled according to the

change to " " mode (regardless

(With A.Q.S) (Not all models)

function selected.

of switch position). This is normal

operation. The air intake control

With the "Recirculation" mode selected,

operates in "AUTO" mode when

and air from within the passenger com-

turning the ignition to the ON po-

partment will be drawn through the heat-

sition if the "AUTO" mode was

ing system and heated or cooled ac-

used before shutting off the en-

cording to the function selected.

gine.

NOTE:

o It should be noted that prolonged

operation of the heating system in

HFC240-1

"recirculation" mode will give rise

This is used to select fresh outside air

to fogging of the windscreen and

or recirculate inside air automatically.

side windows and the air within

the passenger compartment will

OFF

become stale. In addition, pro-

longed use of the air conditioning

with the "Recirculation" mode se-

Fresh mode :

lected may result in the air within

the passenger compartment be-

Air enters the vehicle from the outside

coming excessively dry.

and is heated or cooled according to the

function selected.

fcuk-1.p65

12/27/2006, 10:13 AM

CONTROLS AND EQUIPMENT

Recirculation mode :

B980D01Y-AAT

Heating and Cooling System Off

Air from within the passenger compart-

CAUTION:

ment will be drawn through the heating

If the windows fog up with the Recir-

system and heated or cooled according

culation or A.Q.S mode selected, set

to the function selected.

the air intake control to the Fresh air

position or A.Q.S control to "OFF".

Exhaust gas cutoff mode :

Air enters the vehicle from the outside.

But if exhaust gas enters the vehicle

from the outside, the exhaust gas cut-

off mode (

) is automatically conv-

erted to the (

) mode, to prevent

HFC239

exhaust gas from entering the vehicle.

Press the "OFF" button to stop the

operation of the heating and cooling

NOTE:

system.

It should be noted that prolonged

operation of the heating system in

recirculation mode (

) will give

rise to misting of the windscreen and

side windows and the air within the

passenger compartment will become

stale. In addition, prolonged use of

the air conditioning with the recircu-

lation mode (

) selected may

result in the air within the passenger

compartment becoming excessively

dry.

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

B980E01FC-EAT

Air Flow Control

HFC231-D

HFC232-D

Face-Level

Bi-Level

HFC230

This is used to direct the flow of air. Air

When selecting the "Face-Level", the

When selecting the "Bi-Level", the indi-

can be directed to the floor, dashboard

indicator light will come on, causing air

cator light will come on and the air will

outlets, or windscreen. Four symbols

to be discharged through the face level

be discharged through the face vents

are used to represent Face, Bi-Level,

vents.

and the floor vents. This makes it pos-

Floor and Floor-Defrost position.

sible to have cooler air from the dash-

board vents and warmer air from the

floor outlets at the same time.

fcuk-1.p65

12/27/2006, 10:13 AM

CONTROLS AND EQUIPMENT

B980F02E-EAT

Defrost Switch

HFC233-D

HFC234-D

Floor-Level

Floor-Defrost Level

HFC241

When the "Defrost" button is pressed,

When selecting the "Floor-Level", the

When selecting the "Floor-Defrost Level"

the "

" mode will be automatically

indicator light will come on and the air

mode, the indicator light will come on

selected and the air will be discharged

will be discharged through the floor

and the air will be discharged through

through the windshield defroster nozzle,

vents, windscreen defroster nozzle,

the windscreen defroster nozzle, the

side defroster nozzle and side ventila-

floor vents, side defroster nozzle and

tor. To assist in defrosting, the air

tor.

side ventilator.

conditioning will operate if ambient tem-

perature is higher than 38.3°F (3.5°C)

and automatically turns off if the ambi-

ent temperature drops below 38.3°F

(3.5°C).

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

POLLEN FILTER

STEREO SOUND SYSTEM

(IN FRONT OF BLOWER UNIT)

B760A04FC-EAT

B750A02A-AAT

How Car Audio Works

Inside air

Outside air

CAUTION:

FM reception

Filter

o Replace the filter every 10,000

Ionosphere

miles or once a year. If the car is

being driven in severe conditions

such as dusty, rough roads, more

frequent air filter inspections and

changes are required.

Blower fan

o When the air flow rate is suddenly

Inside air

Evaporator core

decreased, it must be checked at

Heater core

an Hyundai authorised repairer.

B760A01E

B750A01L

The pollen filter is located in front of the

blower unit behind the glove box.

AM and FM radio signals are broadcast

It operates to decrease pollutants en-

from transmitter towers located around

tering the car and to filter the air.

your city. They are intercepted by the

To replace the pollen filter, refer to

radio antenna on your car. This signal is

page 6-25.

then received by the radio and sent to

your car speakers.

When a strong radio signal has reached

your vehicle, the precise engineering of

your audio system ensures high quality

reproduction. However, in some cases

the signal coming to your vehicle is not

strong and clear. This can be due

to factors such as the distance from the

radio station, closeness of other strong

radio stations or the presence of build-

ings, bridges and other large obstruc-

tions in the area.

fcuk-1.p65

12/27/2006, 10:13 AM

CONTROLS AND EQUIPMENT

AM reception

FM radio station

Ionosphere

Unobstructed

Mountains

area

Buildings

Obstructed area Iron bridges

B750A03L

B750A02L

B750A04L

AM broadcasts can be received at

FM broadcasts are transmitted at high

o Fading - As your car moves away

greater distances than FM broadcasts.

frequency and do not bend to follow the

from the radio station, the signal will

This is because AM radio waves are

earth's surface. Because of this, FM

weaken and sound will begin to fade.

transmitted at low frequency. These

broadcasts generally begin to fade at

When this occurs, we suggest that

long, low frequency radio waves can

short distances from the station. Also,

you select another stronger station.

follow the curvature of the earth rather

FM signals are easily affected by build-

o Flutter/Static - Weak FM signals or

than travelling straight out into the at-

ings, mountains, or other obstructions.

large obstructions between the trans-

mosphere. In addition, they curve

These can result in certain listening

mitter and your radio can disturb the

around obstructions so that they can

conditions which might lead you to

signal causing static or fluttering

provide better signal coverage.

believe a problem exists with your ra-

noises to occur. Reducing the treble

dio. The following conditions are normal

level may lessen this effect until the

and do not indicate radio trouble:

disturbance clears.

fcuk-1.p65

12/27/2006, 10:13 AM

1 CONTROLS AND EQUIPMENT

B750B03Y-EAT

Using a cellular phone or a two-

way radio

CAUTION:

When a cellular phone is used inside

When using a communication sys-

the vehicle, noise may be produced

tem such as a mobile phone or a

from the audio equipment. This does

radio inside the vehicle, a separate

not mean that something is wrong with

external antenna must be fitted.

the audio equipment. In such a case,

When a mobile phone or a radio set is

use the cellular phone at a place as far

used with an internal antenna alone,

as possible from the audio equipment.

it may interfere with the vehicle's

electrical system and adversely affect

B750A05L

safe operation of the vehicle.

Station Swapping - As a FM signal

weakens, another more powerful sig-

nal near the same frequency may

begin to play. This is because your

WARNING:

radio is designed to lock onto the

Don't use a cellular phone whilst you

clearest signal. If this occurs, select

are driving.

another station with a stronger sig-

nal.

Multi-Path Cancellation - Radio sig-

nals being received from several di-

rections can cause distortion or flut-

tering. This can be caused by a

direct and a reflected signal from the

same station, or by signals from two

stations with close frequencies. If

this occurs, select another station

until the condition has passed.

fcuk-1.p65

12/27/2006, 10:13 AM

Hyundai Matrix (2007 year). Instruction - part 22
