Features of your vehicle
✽ NOTICE FOR USING THE
(Continued)
CAUTION IN USING THE
iPod® DEVICE
•
Deactivate (turn off) the equalizer
iPod® DEVICE
function of an iPod when adjust-
•
Some iPod models might not sup-
port the communication protocol
•
The Hyundai iPod Power Cable is
ing the audio system’s volume,
and the files will not be played.
needed in order to operate iPod
and turn off the equalizer of the
Supported iPod models:
with the audio buttons on the
audio system when using the
- iPod Mini
equalizer of an iPod.
audio system. The USB cable pro-
- iPod 4th(Photo) ~ 6th(Classic)
•
When the iPod cable is connect-
vided by Apple may cause mal-
generation
ed, the system can be switched to
function and should not be used
- iPod Nano 1st~4th generation
AUX mode even without iPod
for Hyundai vehicles.
- iPod Touch 1st~2nd generation
device and may cause noise.
•
The order of search or playback of
❋ The Hyundai iPod Power Cable
Disconnect the iPod cable when
songs in the iPod can be different
may be purchased through
you are not using the iPod device.
from the order searched in the
your Hyundai Dealership.
•
When not using iPod with car
audio system.
•
When connecting iPod with the
audio, detach the iPod cable from
•
If the iPod disabled due to its own
iPod Power Cable, insert the con-
iPod. Otherwise, iPod may remain
malfunction, reset the iPod. (Reset:
in accessory mode, and may not
nector to the multimedia socket
Refer to iPod manual)
work properly.
completely. If not inserted com-
•
An iPod may not operate normally
pletely, communications between
on low battery.
•
Some iPod devices, such as the
iPod and audio may be interrupted.
iPhone, can be connected through
•
When adjusting the sound effects
the Bluetooth® wireless technology
of the iPod and the audio system,
interface. The device must have
the sound effects of both devices
audio Bluetooth® wireless technolo-
will overlap and might reduce or
gy capability
(such as for stereo
distort the quality of the sound.
headphone Bluetooth® wireless
(Continued)
technology). The device can play,
but it will not be controlled by the
audio system.
4 120
Features of your vehicle
RADIO, SETUP, VOLUME CONTROL (PA760) (IF EQUIPPED)
■ Type A
1. FM Selection Button
2. AM Selection Button
3. CD Selection Button
4. AUX Selection Button
5. Automatic Channel Selection Button
6. Power ON/OFF & Volume Control Button
■ Type B
7. AUTO STORE Button
8. Screen ON/ OFF Button
9. Information Display Button
10. SETUP/CLOCK Button
11. TUNE/ENTER Button
12. Preset Button
4 121
Features of your vehicle
1. FM Selection Button
5. Automatic Channel Selection
7. AUTO STORE Button
Turns to FM mode and toggles FM1 and
Button
When the button is pressed, it automati-
FM2 when the button is pressed each
• When the [SEEK
]button is pressed,
cally selects and saves channels with
time.
it reduces the band frequency by
high reception rate to PRESET buttons
(1~6) and plays the channel saved in
100kHz to automatically select chan-
PRESET1.
2. AM Selection Button
nel. Stops at the previous frequency if
no channel is found.
If no channel is saved after AST, it will
Turns to AM mode, and toggles in the
play the previous channel.
order of AM1➟AM2➟AM1··· when the
• When the [SEEK
]button is pressed,
button is pressed each time.
it increases the band frequency by
100kHz to automatically select chan-
8. Screen ON/ OFF Button
nel. Stops at the previous frequency if
Turns off/on the displayed data and light
3. CD Selection Button
no channel is found.
on LCD.
If there is a CD in the CDP DECK it plays
The screen and light will be turned on by
the CD.
6. Power ON/OFF & Volume
pressing any button except DARK button
Press CD button to automatically insert
Control Button
when the screen is turned off.
CD when the disc is ejected from the
deck by pressing CD EJECT.
• Turns on/off the set when the IGNI-
TION SWITCH is on ACC or ON. If the
9. Information Display Button
button is turned to the right, it increas-
Displays the information of the channel
4. AUX Selection Button
es the volume and left, decreases the
currently played.
If the auxiliary device is connected, it
volume.
turns to AUX MODE to play the sound
• In AUX mode, the volume and tone
from the auxiliary player.
(BASS, MID, TRE) are adjusted in a
If no Disc and auxiliary device is connected,
separate way.
it displays “NO Media” for 5 seconds and
If you pull out AUX from a jack and
returns to the previous mode.
insert it again, then only volume goes
back to step 10.
4 122
Features of your vehicle
10. SETUP/CLOCK Button
11. TUNE/ENTER Button
Press this button to turn to the SOUND,
Turn this button clockwise by one notch
clock setting, time display, SCROLL,
to increase frequency by 0.05MHz from
SDVC, temperature display and adjust-
current frequency.
ment mode.
Turn this button counterclockwise by one
If no action is taken for 5 seconds after
notch to decrease frequency by 0.05MHz
pressing the button, it will return to the
from current frequency.
play mode.(After entering SETUP mode,
Press this button while holding SETUP
move between items using the left, right
button to activate / inactivate the item to.
and PUSH functions of the TUNE button.)
Select SETUP item using left and right
The setup item changes from AUDIO➟
function of the Tune button.
CLOCK➟TIME➟SCROLL➟SDVC➟
TEMP➟AUDIO...
12. Preset Button
Push [1]~[6] buttons less than 0.8 second
to play the channel saved in each button.
Push preset button for
0.8 second or
longer to save current channel to the
respective button with a beep.
4 123
Features of your vehicle
CD (PA760) (IF EQUIPPED)
■ Type A
1. CD Loading Slot
2. CD Indicator
3. CD Eject Button
4. LOAD Button
5. AUX Selection Button
6. Automatic Track Selection Button
7. INFO Button
8. TUNE/ENTER Button
■ Type B
9. REPEAT Button
10. RANDOM Play Button
11. DISC selection Button
12. SCAN Play Button
13. FOLDER Moving Button
4 124
Features of your vehicle
1. CD Loading Slot
4. CD LOAD Button
• Push [SEEK
] button for 0.8 second
Please face printed side upward and
Push [LOAD] button to load CDs to avail-
or longer to initiate high speed sound
gently push in. When the ignition switch
able CDC deck (from 1~6). Push [LOAD]
search of current song.
is on ACC or ON and power is off, power
button for more than 2 seconds to load
is automatically turned on if the CD is
into all available decks.
7. INFO Button
loaded. This CDP supports both 8cm and
The last CD will play. 10 seconds idle sta-
Displays the information of the current CD
12 cm CDs. But if VCD, Data CD, are
tus will disable loading process.
TRACK in the order of DISC TITLE➟
loaded, "Er-6" message will appear and
DISC ARTIST➟TRACK TITLE➟TRACK
CD will be ejected.
5. AUX Selection Button
ARTIST➟TOTAL TRACK➟Play Screen➟
If the auxiliary device is connected, it
DISC TITLE➟···.(not displayed if the infor-
2. CD Indicator
mation is not available on the DISC.)
turns to AUX MODE to play the sound
CD is loaded, this slot icon is displayed.
from the auxiliary player.
(If MP3 is displayed FILE NAME➟TITLE
If the CD is ejected the slot icon is display
If no auxiliary device is connected, it dis-
➟ARTIST➟ALBUM➟FOLDER➟TOTAL
off.
plays "NO CONNECT" for 3 seconds and
FILE➟FILE NAME➟···)
returns to the previous mode.
3. CD Eject Button
8. TUNE/ENTER Button
• Pressing the button for less than 0.8
6. Automatic Track Selection
Turn this button clockwise to display
second will eject 1 disc while pressing
Button
songs after current song.
for 0.8 second ~ 3 seconds will eject all
• Push [SEEK
] button for less than
Also, turn this button counterclockwise to
discs.
0.8 second to play from the beginning
display songs before current song.
• Pressing the button for over 5 seconds
of current song.
To listen to the displayed song, press the
will eject all discs by force. (EMER-
button to skip to the song and play.
• Push [SEEK
] button for less than
GENCY EJECT)
0.8 second and press again within 3
9. REPEAT Button
seconds to play the previous song.
Repeats current song when the button is
• Push [SEEK
] button for 0.8 second
pressed for less than 0.8 second.
or longer to initiate reverse direction
Repeats the entire DISC when the button
high speed sound search of current
is pressed for 0.8 second or longer.
song.
• Push [SEEK
] button for less than
0.8 second to play the next song.
4 125
Features of your vehicle
10. RANDOM Play Button
Turns on/off the randomization of the play
list of files in the currently played DISC.
To cancel the mode, press the key once
again.
11. DISC Selection Button
•
[DISC
] Change Button
Changes disc to the previous disc.
•
[DISC
] Change Button
Changes disc to the next disc.
12. SCAN Play Button
Plays first 10 seconds of each song in the
DISC.
To cancel the mode, press the key once
again.
13. FOLDER Moving Button
• Moves [FLDR
] button child folder of
the current folder and displays the first
song in the folder. Press TUNE/ENTER
button to move to the folder displayed.
It will play the first song in the folder.
• Moves [FLDR
] button parent folder
and displays the first song in the folder.
Press TUNE/ENTER button to move to
the folder displayed. It will play the first
song in the folder.
4 126
Features of your vehicle
USING USB (PA760) (IF EQUIPPED)
■ Type A
1. AUX Selection Button
2. Track moving Button
3. INFO Selection Button
4. Folder moving Button
5. TUNE/ENTER Button
■ Type B
6. RANDOM Playback Button
7. REPEAT Selection Button
8. SCAN Selection Button
4 127
Features of your vehicle
In case USB is connected to the multi-
3. INFO Button
6. RANDOM Playback Button
media jack inside the console on the right
Displays the information of the file cur-
Press the button for less than 0.8 second
hand side of the driver’s seat. When USB
rently played in the order of FILE NAME
to start or stop the random playback of
is connected, the ‘USB’ icon will be dis-
➟TITLE➟ARTIST➟ALBUM➟FOLDER➟
the songs in the current folder.
played on the top right corner of the dis-
TOTAL FILE➟FILE NAME➟… (Displays
Press the button for more than 0.8 sec-
play screen.
no information if the file has no song
ond to randomly play the entire songs in
information.)
the USB device.
1.AUX Selection Button
Press the button again to cancel the mode.
If USB is not connected, it switches to the
4. Folder moving Button
USB mode from the Radio and CD mode
• Moves [FLDR
] button child folder of
7. REPEAT Button
to play the song files stored in the USB.
the current folder and displays the first
Press the button for less than 0.8 second
If AUX is not connected, it is invalid key.
song in the folder. Press TUNE/ENTER
to repeat the song currently played.
button to move to the folder displayed.
Press the button for more than 0.8 sec-
2. Track Moving Button
It will play the first song in the folder.
ond to repeat the entire songs in the USB
•
Press the [SEEK
] button for less
• Moves [FLDR
] button parent folder
device.
than 0.8 second to play from the begin-
and displays the first song in the folder.
ning of the song currently played.
Press TUNE/ENTER button to move to
8. SCAN Button
Press the button for less than 0.8 sec-
the folder displayed. It will play the first
Plays 10 seconds of each song in the USB
ond and press it again within 1 second
song in the folder.
device.
to move to and play the previous track.
Press the button once again to cancel
Press the button for
0.8 second or
5. TUNE/ENTER Button
scanning.
longer to play the song in reverse
Turn this button clockwise to display the
direction in fast speed.
songs next to the currently played song.
•
Press the [SEEK
] button button for
Turn the button counterclockwise to dis-
less than 0.8 second to move to the
play the songs before the currently
next track.
played song.
Press the button for
0.8 second or
Press the button to skip to and play the
longer to play the song in forward
selected song.
direction in fast speed.
4 128
Features of your vehicle
(Continued)
(Continued)
CAUTION IN USING
•
An encrypted MP3 PLAYER is not
•
If you disconnect the external USB
USB DEVICE
recognizable.
device during playback in USB
•
To use an external USB device,
•
Depending on the condition of
mode, the external USB device can
make sure the device is not con-
the external USB device, the con-
be damaged or may malfunction.
nected when starting up the vehi-
nected external USB device can
Therefore, disconnect the external
cle. Connect the device after
be unrecognizable.
USB device when the audio is
starting up.
turned off or in another mode. (e.g,
•
When the formatted byte/sector
•
If you start the engine when the
Radio or CD)
setting of External USB device is
USB device is connected, it may
not either 512BYTE or 2048BYTE,
•
Depending on the type and capac-
damage the USB device. (USB
then the device will not be recog-
ity of the external USB device or
flashdrives are very sensitive to
nized.
the type of the files stored in the
electric shock.)
device, there is a difference in the
•
Use only a USB device formatted
•
If the engine is started up or
time taken for recognition of the
to FAT 12/16/32.
turned off while the external USB
device.
•
USB devices without USB I/F
device is connected, the external
•
Do not use the USB device for pur-
authentication may not be recog-
USB device may not work.
poses other than playing music
nizable.
•
It may not play inauthentic MP3 or
files.
•
Make sure the USB connection
WMA files.
•
Use of USB accessories such as
terminal does not come in contact
1) It can only play MP3 files with
rechargers or heaters using USB
with the human body or other
the compression rate between
I/F may lower performance or
objects.
8Kbps~320Kbps.
cause trouble.
•
If you repeatedly connect or dis-
2) It can only play WMA music
•
If you use devices such as a USB
connect the USB device in a short
files with the compression rate
hub purchased separately, the
period of time, it may break the
between 8Kbps~320Kbps.
vehicle’s audio system may not
device.
•
Take precautions for static electrici-
recognize the USB device. In that
•
You may hear a strange noise
ty when connecting or disconnect-
case, connect the USB device
when connecting or disconnect-
ing the external USB device.
directly to the multimedia termi-
ing a USB device.
(Continued)
nal of the vehicle.
(Continued)
(Continued)
4 129
Features of your vehicle
(Continued)
(Continued)
•
If the USB device is divided by
•
Please avoid using USB memory
logical drives, only the music files
products which can be used as
on the highest-priority drive are
key chains or cellular phone
recognized by car audio.
accessories as they could cause
•
Devices such as MP3 Player/
damage to the USB jack. Please
Cellular phone/Digital camera can
make certain only to use plug type
be unrecognizable by standard
connector products as shown
USB I/F can be unrecognizable.
below.
•
Some non-standard USB devices
(METAL COVER TYPE USB) can
be unrecognizable.
•
Some USB flash memory readers
(such as CF, SD, microSD, etc.) or
external-HDD type devices can be
unrecognizable.
•
Music files protected by DRM
(DIGITAL RIGHTS MANAGE-
MENT) are not recognizable.
•
The data in the USB memory may
be lost while using this audio.
Always back up important data on
a personal storage device.
(Continued)
4 130
Features of your vehicle
RUNNING iPod® (PA760) (IF EQUIPPED)
■ Type A
1. iPod Selection Button
2. Track moving Button
3. INFO Selection Button
4. Category Selection Button
5. TUNE/ENTER Button
6. RANDOM Playback Button
■ Type B
7. REPEAT Selection Button
❈ iPod® is a trademark of Apple Inc.
4 131
Features of your vehicle
In case the iPod exclusive cable is con-
3. INFO Button
If you want to listen to the song displayed
nected to the multimedia jack inside the
in the song category, press the button,
Displays the information of the file cur-
console on the right hand side of the dri-
then it will skip to the selected song and
rently played in the order of FILE NAME
ver’s seat. When the iPod is connected,
play.
➟TITLE➟ARTIST➟ALBUM➟FILE
the ‘iPod’ icon will be displayed on the top
NAME➟…
right corner of the display screen.
(Displays no information if the file has no
6. RANDOM Playback Button
song information.)
Press the button for less than 0.8 second
1. iPod Selection Button
to activate or deactivate the random play-
If iPod is connected, it switches to the
back of the songs within the current cat-
4. Category Selection Button
iPod mode from the Radio and CD mode
egory.
Moves to the upper category from cur-
to play the song files stored in the iPod.
Press the button for longer than 0.8 sec-
rently played category of the iPod.
If there are no CD and AUX, it displays
ond to randomly play all songs in the
You will be able to search through the
‘NO MEDIA’.
entire album of the iPod.
lower category of the selected category.
Press the button once again to cancel the
The order of iPod’s category is SONG,
2. Track Moving Button
mode.
ALBUMS, ARTISTS, GENRES, and
•
Press the [SEEK
] button for less
iPod. (Refer to the iPod user’s manual for
than 0.8 second to play from the begin-
more information)
7. REPEAT Button
ning of the song currently played.
Repeats the song currently played.
Press the button for less than 0.8 sec-
5. TUNE/ENTER Button
ond and press it again within 1 second
When you turn the button clockwise, it
to move to and play the previous track.
will display the songs (category) next to
Press the button for
0.8 second or
the song currently played (category in
longer to play the song in reverse
the same level).
direction in fast speed.
Also, when you turn the button counter-
•
Press the [SEEK
] button for less
clockwise, it will display the songs (cate-
than 0.8 second to move to the next
gory) before the song currently played
track.
(category in the same level).
Press the button for
0.8 second or
longer to play the song in forward
direction in fast speed.
4 132
Features of your vehicle
✽ NOTICE FOR USING THE
(Continued)
CAUTION IN USING THE
•
Deactivate (turn off) the equalizer
iPod® DEVICE
iPod® DEVICE
function of an iPod when adjust-
•
Some iPod models might not sup-
port the communication protocol
•
The Hyundai iPod Power Cable is
ing the audio system’s volume,
and the files will not be played.
needed in order to operate iPod
and turn off the equalizer of the
Supported iPod models:
with the audio buttons on the
audio system when using the
- iPod Mini
audio system. The USB cable pro-
equalizer of an iPod.
- iPod 4th(Photo) ~ 6th(Classic)
vided by Apple may cause mal-
•
When the iPod cable is connect-
generation
ed, the system can be switched to
function and should not be used
- iPod Nano 1st~4th generation
AUX mode even without iPod
for Hyundai vehicles.
- iPod Touch 1st~2nd generation
device and may cause noise.
•
The order of search or playback of
❋ The Hyundai iPod Power Cable
Disconnect the iPod cable when
songs in the iPod can be different
may be purchased through your
you are not using the iPod device.
from the order searched in the
Hyundai Dealership.
•
When not using iPod with car
audio system.
•
When connecting iPod with the
audio, detach the iPod cable from
•
If the iPod disabled due to its own
iPod Power Cable, insert the con-
iPod. Otherwise, iPod may remain
malfunction, reset the iPod. (Reset:
nector to the multimedia socket
in accessory mode, and may not
Refer to iPod manual)
completely. If not inserted com-
work properly.
•
An iPod may not operate normally
pletely, communications between
on low battery.
•
Some iPod devices, such as the
iPod and audio may be interrupted.
iPhone, can be connected through the
•
When adjusting the sound effects
Bluetooth® wireless technology inter-
of the iPod and the audio system,
face. The device must have audio
the sound effects of both devices
Bluetooth® wireless technology capa-
will overlap and might reduce or
bility (such as for stereo headphone
distort the quality of the sound.
Bluetooth® wireless technology). The
(Continued)
device can play, but it will not be con-
trolled by the audio system.
4 133
Features of your vehicle
RADIO, SETUP, VOLUME CONTROL (PA710S) (IF EQUIPPED)
■ Type A
1. FM Selection Button
2. AM Selection Button
3. CD/AUX Selection Button
4. Automatic Channel Selection Button
5. Power ON/OFF Button & Volume Control
Knob
6. SCAN Button
■ Type B
7. Screen ON/ OFF Button
8. INFO Button
9. SETUP/CLOCK Button
10. Manual Channel Selection Knob &
SETUP Button
11. Preset Button
4 134
Features of your vehicle
1. FM Selection Button
4. Automatic Channel Selection
6. SCAN Button
Turns to FM mode and toggles FM1 and
Button
If this button is pressed, the frequencies
FM2 when the button is pressed each
• When the [SEEK
] button is pressed,
will become increased and receive the
time.
it reduces the band frequency by
corresponding broadcasts. This function
100kHz to automatically select chan-
will play the frequencies for 5 seconds
2. AM Selection Button
nel. Stops at the previous frequency if
(XM MODE:10 seconds) each and find
no channel is found.
other broadcasts as the frequency
Turns to AM mode when the button is
increases. Press the button again when
pressed.
• When the [SEEK
] button is pressed,
desire to continue listening to the cur-
it increases the band frequency by
rently playing broadcast.
100kHz to automatically select chan-
3. CD/AUX Selection Button
nel. Stops at the previous frequency if
If the auxiliary device is connected, it
no channel is found.
7. Screen ON/ OFF Button
switches to the AUX mode from the other
Turns on/off the display data and light on
mode to play the sound from the auxiliary
5. Power ON/OFF Button &
LCD.
player.
Volume Control Knob
The screen and light will be turned on by
If the CD is loaded, turns to CD mode,
pressing any button except [DISP
] but-
• Turns on/off the set when the IGNI-
and if a device is connected to AUX then
ton when the screen is turned off.
TION SWITCH is on ACC or ON. If the
it toggles CD ➟ AUX ➟ CD... when the
button is turned to the right, it increas-
button is pressed each time.(It will not
es the volume and left, decreases the
8. INFO Button
turn to AUX if the auxiliary device is not
connected)
volume.
Displays the information of the channel
If no CD and auxiliary device is not con-
• In AUX mode, the volume and tone
currently played.
nected, it displays "NO Media" for 3 sec-
(BASS, MID, TRE) are adjusted in a
onds and returns to the previous mode.
separate way.
If you pull out AUX from a jack and
insert it again, then only volume goes
back to step 10.
4 135
Features of your vehicle
9. SETUP/CLOCKButton
11. Preset Button
Press this button to turn to the SOUND,
Push [1]~[6] buttons less than 0.8 second
XM setting, clock setting, time display,
to play the channel saved in each button.
SCROLL, SDVC, temperature display
Push [PRESET] button for 0.8 second or
and adjustment mode.
longer to save current channel to the
If no action is taken for 5 seconds after
respective button with a beep.
pressing the button, it will return to the play
mode.(After entering SETUP mode, move
between items using the left, right and
PUSH functions of the [TUNE] button.)
The setup item changes from AUDIO➟
XM➟CLOCK➟TIME➟SCROLL➟SDVC➟
TEMP➟P.BASS➟AUDIO
10. Manual Channel Selection
Knob & SETUP Button
Turn this button clockwise by one notch
to increase frequency by 0.2MHz from
current frequency.
Turn this button counterclockwise by one
notch to decrease frequency by 0.2MHz
from current frequency.
4 136
