Hyundai Elantra Touring (2012 year). Instruction - part 7
Features of your vehicle
CAUTION
Do not scrape ice off the mirror
face; this may damage the surface
of the glass. If ice should restrict
movement of the mirror, do not
force the mirror for adjustment. To
remove ice, use a deicer spray, or a
sponge or soft cloth with very warm
water.
B510A01E
OFD047032
CAUTION
D140201AFD
Electric type (if equipped)
If the mirror is jammed with ice, do
Remote control
The electric remote control mirror switch
not adjust the mirror by force. Use
an approved spray de-icer (not radi-
Manual type (if equipped)
allows you to adjust the position of the
ator antifreeze) to release the
The outside rearview mirrors are
left and right outside rearview mirrors. To
frozen mechanism or move the
equipped with a remote control for your
adjust the position of either mirror, move
vehicle to a warm place and allow
convenience. It is operated by the control
the lever (1) to R or L to select the right
the ice to melt.
lever in the bottom front corner of the
side mirror or the left side mirror, then
window.
press a corresponding point on the mirror
adjustment control to position the select-
Before driving away, always check that
ed mirror up, down, left or right.
your mirrors are positioned so you can
WARNING
see behind you, both to the left and right
After adjustment, put the lever into neu-
Do not adjust or fold the outside
sides, as well as directly behind your
tral position to prevent inadvertent
rearview mirrors while the vehicle
vehicle. When using the mirror, always
adjustment.
is moving. This could result in loss
exercise caution when attempting to
of control, and an accident which
judge the distance of vehicles behind or
could cause death, serious injury
along side of you.
or property damage.
4 35
Features of your vehicle
CAUTION
•
The mirrors stop moving when
they reach the maximum adjust-
ing angles, but the motor contin-
ues to operate while the switch is
depressed. Do not depress the
switch longer than necessary, the
motor may be damaged.
•
Do not attempt to adjust the out-
side rearview mirror by hand.
Doing so may damage the parts.
B510E01E
OFD047033
D140202AFD
Electric type (if equipped)
Folding the outside rearview mirror
To fold the outside rearview mirror,
Manual type
depress the button.
To fold outside rearview mirror, grasp the
To unfold it, depress the button again.
housing of mirror and then fold it toward
the rear of the vehicle.
CAUTION
In case of the electric type of out-
side rearview mirror, don’t fold it by
hand. It could cause the failure of
the motor.
4 36
Features of your vehicle
INSTRUMENT CLUSTER
1. Tachometer
2. Engine temperature gauge
3. Fuel gauge
4. Speedometer
5. Turn signal indicators
6. Warning and indicator lights (if equipped)
7. Odometer/Trip computer (if equipped)
* The actual cluster in the vehicle may differ from the illustration.
For more details refer to the "Gauges" in the next pages.
OFD041034N-1
D150000AFD
4 37
Features of your vehicle
OFD047035
OFD049037N
OFD047039
D150100AFD
Gauges
D150202AFD
Instrument panel illumination
Tachometer
D150201AUN
When the vehicle’s parking lights or
The tachometer indicates the approxi-
Speedometer
headlights are on, rotate the illumination
mate number of engine revolutions per
The speedometer indicates the forward
minute (rpm).
control knob to adjust the brightness of
speed of the vehicle.
the instrument panel illumination.
Use the tachometer to select the correct
The speedometer is calibrated in miles
shift points and to prevent lugging and/or
The instrument cluster illumination intensity
per hour and/or kilometers per hour.
over-revving the engine.
can be adjusted by rotating the control knob
with the headlight switch in any position
The tachometer pointer may move slight-
when the ignition switch is in ON position.
ly when the ignition switch is in ACC or
ON position with the engine OFF. This
movement is normal and will not affect
the accuracy of the tachometer once the
engine is running.
CAUTION
Do not operate the engine within
the tachometer's RED ZONE. This
may cause severe engine damage.
4
38
Features of your vehicle
WARNING
Never remove the radiator cap
when the engine is hot. The engine
coolant is under pressure and
could cause severe burns. Wait
until the engine is cool before
adding coolant to the reservoir.
OFD047041
OFD047042
D150203AUN
D150204AUN
Engine temperature gauge
Fuel gauge
This gauge shows the temperature of the
The fuel gauge indicates the approxi-
engine coolant when the ignition switch
mate amount of fuel remaining in the fuel
is ON.
tank. The fuel tank capacity is given in
Do not continue driving with an overheat-
section 8. The fuel gauge is supplement-
ed engine. If your vehicle overheats, refer
ed by a low fuel warning light, which will
to “If the engine overheats” in section 6.
illuminate when the fuel tank is nearly
empty.
On inclines or curves, the fuel gauge
CAUTION
pointer may fluctuate or the low fuel
If the gauge pointer moves beyond
warning light may come on earlier than
the normal range area toward the
usual due to the movement of fuel in the
“H” position, it indicates overheat-
tank.
ing that may damage the engine.
4 39
Features of your vehicle
WARNING - Fuel gauge
Running out of fuel can expose
vehicle occupants to danger.
You must stop and obtain addition-
al fuel as soon as possible after the
warning light comes on or when the
gauge indicator comes close to the
E level.
CAUTION
OFD049043N
OFD049049N
Avoid driving with a very low fuel
D150205AFD
Tripmeter
level. If you run out of fuel, it could
Odometer/Tripmeter (if equipped)
The tripmeter indicates the distance of
cause the engine to misfire and
Odometer
individual trip selected by the driver.
result in excessive loading of the
The odometer indicates the total dis-
Tripmeter can be reset to 0 by pressing
catalytic converter.
tance the vehicle has been driven.
the TRIP button for 1 second or more,
and then releasing.
You will also find the odometer useful to
determine when periodic maintenance
should be performed.
✽ NOTICE
Federal and state laws forbid alteration
of the odometer of any vehicle with the
intent to change the mileage registered
on the odometer. The alteration may
void your warranty coverage.
4 40
Features of your vehicle
Push the TRIP button for less than 1 sec-
ond to select distance to empty, average
fuel consumption, average speed or trip-
meter function as follows :
Distance to empty
Average fuel consumption
OFD047045
OFD049046N
D150206AFD
Distance to empty (km or miles)
Trip computer (if equipped)
This mode indicates the estimated dis-
Average speed
The trip computer is a microcomputer-
tance to empty based on the current fuel
controlled driver information system that
in the fuel tank and the amount of fuel
displays information related to driving,
delivered to the engine. When the
including distance to empty, tripmeter,
Tripmeter
remaining distance is below 30 miles (50
average fuel consumption and average
km), “---” will be displayed and the dis-
speed on the display when the ignition
tance to empty indicator will blink.
switch is in the ON position. All stored
The meter’s working range is from 30 to
driving information (except odometer) is
999 miles (50 to 999 km).
reset if the battery is disconnected. The
odometer is always displayed until the
display is turned off.
4 41
Features of your vehicle
Average
speed
Tripmeter
Odometer
Odometer
OFD049047N
OFD049048N
OFD049049N
Average fuel consumption
Average speed
Tripmeter
This mode calculates the average fuel
This mode calculates the average speed
This mode indicates the distance of indi-
consumption from the total fuel used and
of the vehicle since the last average
vidual trip since the last tripmeter reset.
the distance since the last average con-
speed reset.
The meter's working range is from 0.0 to
sumption reset. The total fuel used is cal-
Even if the vehicle is not in motion, the
999.9 miles (km).
culated from the fuel consumption input.
average speed keeps going while the
Pressing the TRIP button for more than 1
For an accurate calculation, drive more
engine is running.
second when the tripmeter is being dis-
than 0.03 mile (50 m).
Pressing the TRIP button for more than 1
played clears the tripmeter to zero (0.0).
Pressing the TRIP button for more than 1
second, when the average speed is
second, when the average fuel consump-
being displayed, clears the average
tion is being displayed, clears the aver-
speed to zero (---).
age fuel consumption to zero (---).
4 42
Features of your vehicle
D150300AFD
D150302AFD
✽ NOTICE
• If the vehicle is not on level ground or
Warnings and indicators
Air bag warning light
(if equipped)
the battery power has been interrupt-
All warning lights are checked by turning
ed, the “Distance to empty” function
the ignition switch ON (do not start the
This warning light will illuminate for
may not operate correctly.
engine). Any light that does not illuminate
approximately 6 seconds each time you
The trip computer may not register
should be checked by an authorized
turn the ignition switch to the ON posi-
additional fuel if less than 1.6 gallons
HYUNDAI dealer.
tion.
(6 liters) of fuel are added to the vehi-
After starting the engine, check to make
This light also comes on when the
cle.
sure that all warning lights are off. If any
Supplemental Restraint System (SRS) is
• The fuel consumption and distance to
are still on, this indicates a situation that
not working properly. If the air bag warn-
empty values may vary significantly
needs attention. When releasing the
ing light does not come on, or continu-
based on driving conditions, driving
parking brake, the brake system warning
ously remains on after operating for
habits, and condition of the vehicle.
light should go off. The fuel warning light
about 6 seconds when you turned the
• The distance to empty value is an esti-
will stay on if the fuel level is low.
ignition switch to the ON position or start-
mate of the available driving distance.
ed the engine, or if it comes on while
This value may differ from the actual
driving, have the SRS inspected by an
driving distance available.
authorized HYUNDAI dealer.
4 43
Features of your vehicle
D150303AFD
Electronic brake force distri-
C150304AFD-EU
Anti-lock brake system
bution (EBD) system warning
Seat belt warning
(ABS) warning light
light
(if equipped)
This light illuminates if the ignition switch
As a reminder to the driver, the seat belt
is turned to ON and goes off in approxi-
warning light will blink for approximately
mately 3 seconds if the system is operat-
6 seconds each time you turn the ignition
ing normally.
switch ON, regardless of belt fastening.
If the ABS warning light remains on,
If these two warning lights illuminate at
The driver's seat belt warning light and
comes on while driving, or does not
the same time while driving, your vehicle
chime will activate according to the fol-
come on when the ignition switch is
may have a malfunction with ABS and
lowing table.
turned to the ON position, this indicates
EBD system.
that there may be a problem with the
In this case, your ABS and regular brake
ABS.
system may not work normally. Have the
If this occurs, have your vehicle checked
vehicle checked by an authorized
by an authorized HYUNDAI dealer as
HYUNDAI dealer as soon as possible.
soon as possible. The normal braking
system will still be operational, but with-
WARNING
out the assistance of the anti-lock brake
system.
If the both ABS and brake warning
lights are on and stay on, your vehi-
cle’s brake system will not work
normally during sudden braking. In
this case, avoid high speed driving
and abrupt braking. Have your vehi-
cle checked by an authorized
HYUNDAI dealer as soon as possi-
ble.
4 44
Features of your vehicle
Conditions
Warning Pattern
D150305AFD
D150307AFD
Vehicle
Chime-
Turn signal indicator lights
Engine oil pressure warn-
Seat Belt
Light-Blink
Speed
Sound
ing
Unbuckled
6 seconds
The blinking green arrows on the instru-
This warning light indicates the engine oil
Buckled
6 seconds
None
ment panel show the direction indicated
pressure is low.
Below 3 mph
by the turn signals. If the arrow comes on
6 seconds
None
but does not blink, blinks more rapidly
If the warning light illuminates while driv-
(5 km/h)
Buckled →
than normal, or does not illuminate at all,
ing:
3 mph~6 mph
6 seconds
Unbuckled
a malfunction in the turn signal system is
1. Drive safely to the side of the road and
Above 6 mph
6 sec. on / 24 sec. off
indicated. Your dealer should be consult-
stop.
(10 km/h)
(11 times)
ed for repairs.
2. With the engine off, check the engine
Above 6 mph
This indicator also blinks when the haz-
oil level. If the level is low, add oil as
6 sec. on / 24 sec. off
(10 km/h)
ard warning switch is turned on.
required.
(11 times)
Unbuckled
↓
If the warning light remains on after
↓
Below 3 mph
adding oil or if oil is not available, call an
Stop
D150306AUN
(5 km/h)
authorized HYUNDAI dealer.
High beam indicator
If the driver's seat belt is buckled while
CAUTION
This indicator illuminates when the head-
unbuckled, the seat belt warning light
If the engine is not stopped imme-
lights are on and in the high beam posi-
and chime will stop immediately
diately after the engine oil pressure
tion or when the turn signal lever is pulled
warning light is illuminated, severe
into the Flash-to-Pass position.
damage could result.
4 45
Features of your vehicle
D150308AFD
Your vehicle is equipped with dual-diago-
CAUTION
Parking brake & brake fluid
nal braking systems. This means you still
If the oil pressure warning light
warning
have braking on two wheels even if one
stays on while the engine is run-
of the dual systems should fail. With only
ning, serious engine damage may
one of the dual systems working, more
Parking brake warning
result. The oil pressure warning
than normal pedal travel and greater
This light is illuminated when the parking
light comes on whenever there is
pedal pressure are required to stop the
brake is applied with the ignition switch in
insufficient oil pressure. In normal
car. Also, the car will not stop in as short
the START or ON position. The warning
operation, it should come on when
a distance with only a portion of the
light should go off when the parking
the ignition switch is turned on,
brake system working. If the brakes fail
brake is released.
then go out when the engine is
while you are driving, shift to a lower gear
started. If the oil pressure warning
for additional engine braking and stop the
light stays on while the engine is
Low brake fluid level warning
car as soon as it is safe to do so.
running, there is a serious malfunc-
If the warning light remains on, it may
To check bulb operation, check whether
tion.
indicate that the brake fluid level in the
the parking brake and brake fluid warning
reservoir is low.
If this happens, stop the car as
light illuminates when the ignition switch
soon as it is safe to do so, turn off
If the warning light remains on:
is in the ON position.
the engine and check the oil level. If
1. Drive carefully to the nearest safe
the oil level is low, fill the engine oil
location and stop your vehicle.
WARNING
to the proper level and start the
2. With the engine stopped, check the
Driving the vehicle with a warning
engine again. If the light stays on
brake fluid level immediately and add
light on is dangerous. If the brake
with the engine running, turn the
fluid as required. Then check all brake
warning light remains on, have the
engine off immediately. In any
components for fluid leaks.
brakes checked and repaired imme-
instance where the oil light stays on
3. Do not drive the vehicle if leaks are
diately by an authorized HYUNDAI
when the engine is running, the
found, the warning light remains on or
dealer.
engine should be checked by an
the brakes do not operate properly.
authorized HYUNDAI dealer before
Have it towed to any authorized
the car is driven again.
HYUNDAI dealer for a brake system
inspection and necessary repairs.
4 46
Features of your vehicle
D150331AFD
The warning light also comes on and
Low tire pressure
WARNING - Low tire pres-
stays on when there is a problem with the
telltale (if equipped)
sure
Tire Pressure Monitoring System.
Significantly low tire pressure
If this happens, the system may not mon-
makes the vehicle unstable and can
itor the tire pressure. Have the system
The low tire pressure telltale comes on
for 3 seconds after the ignition switch is
contribute to loss of vehicle control
checked by an authorized HYUNDAI
turned to the ON position.
and increased braking distances.
dealer as soon as possible.
If the warning lights do not come on, or
Continued driving on tires with low
continuously remains on after coming on
pressure will cause the tires to
WARNING - Safe stopping
for about 3 seconds when you turned the
overheat and fail.
•
The TPMS cannot alert you to
ignition switch to the ON position, the
severe and sudden tire damage
Tire pressure Monitoring System may not
caused by external factors.
be working properly. To confirm this, first
D150332AEN
• If you feel any vehicle instability,
check and adjust the tire pressure of
TPMS (Tire Pressure
immediately take your foot off the
each wheel. If the low tire pressure tell-
Monitoring System)
TPMS
accelerator, apply the brakes
tale light goes off, the system is working
malfunction indicator
gradually and with light force,
properly. If the low tire pressure telltale
(if equipped)
and slowly move to a safe posi-
light still stays ON, the Tire Pressure
The TPMS malfunction indicator comes
tion off the road.
Monitoring System is not working proper-
on for 3 seconds after the ignition switch
ly. If this occurs, have your vehicle
is turned to the ON position. If the warn-
checked by an authorized HYUNDAI
ing light does not come on, or remains on
dealer as soon as possible.
after 3 seconds when the ignition switch
This warning lights will also illuminate if
is turned to the ON position, the Tire
one or more of your tires is significantly
Pressure Monitoring System is not work-
under-inflated. You should stop and
ing properly. If this occurs, have your
check your tires as soon as possible. If
vehicle checked by an authorized
the warning lights illuminate while driv-
HYUNDAI dealer as soon as possible.
ing, reduce vehicle speed immediately
and stop the vehicle. Avoid hard braking
and overcorrecting at the steering wheel.
Inflate the tires to the proper pressure as
indicated on the vehicle’s tire information
placard.
4 47
Features of your vehicle
D150309AUN
D150315AUN
D150319AUN
Front fog light indicator
Tailgate open warning light
Low washer fluid level
(if equipped)
warning indicator
(if equipped)
This warning light indicates the washer
This light comes on when the front fog
This warning light blinks when the tail-
fluid reservoir is near empty. Refill the
lights are ON.
gate is not closed securely with the igni-
washer fluid as soon as possible.
tion in any position.
D150312AUN
D150320AFD
Shift pattern indicators
D150316AUN
Malfunction indicator lamp
(if equipped)
Door ajar warning light
(MIL) (check engine light)
The indicator displays which automatic
This indicator light is part of the Engine
transaxle shift position is selected.
This warning light illuminates when a
Control System which monitors various
door is not closed securely with the igni-
emission control system components. If
D150313AFD
tion in any position.
this light illuminates while driving, it indi-
Charging system warning
cates that a potential problem has been
detected somewhere in the emission
D150318AFD
control system.
Low fuel level warning
This light will also illuminate when the
This warning light indicates a malfunction
ignition switch is turned to the ON posi-
of either the generator or electrical
tion, and will go out in a few seconds
charging system.
This warning light indicates the fuel tank
after the engine is started. If it illuminates
If the warning light comes on while the
is nearly empty. When it comes on, you
while driving, or does not illuminate when
vehicle is in motion:
should add fuel as soon as possible.
the ignition key is turned to the ON posi-
1. Drive to the nearest safe location.
Driving with the fuel level warning light on
tion, take your vehicle to your nearest
or with the fuel level below “E” can cause
2. With the engine off, check the genera-
authorized HYUNDAI dealer and have
the engine to misfire and damage the
tor drive belt for looseness or breakage.
the system checked.
catalytic converter.
3. If the belt is adjusted properly, a prob-
Generally, your vehicle will continue to be
lem exists somewhere in the electrical
drivable, but have the system checked by
charging system. Have an authorized
an authorized HYUNDAI dealer promptly.
HYUNDAI dealer correct the problem
as soon as possible.
4 48
Features of your vehicle
When a slippery or low traction condition
ESC/ESC OFF indicator (Electronic
CAUTION
is encountered, the ESC will operate,
Stability Control) (Type B, if equipped)
•
Prolonged driving with the
and the ESC indicator will blink to indi-
Emission
Control
System
cate the ESC is operating.
ESC indicator
Malfunction Indicator Light illumi-
nated may cause damage to the
ESC OFF indicator
ESC
emission control systems which
The ESC indicator will illuminate when the
could effect drivability and/or fuel
OFF
ignition switch is turned ON, but should go
economy.
The ESC OFF indicator will illuminate
off after approximately 3 seconds. When
•
If the Emission Control System
when the ignition switch is turned ON,
the ESC is on, it monitors the driving con-
Malfunction Indicator Light illumi-
but should go off after approximately 3
ditions. Under normal driving conditions,
nates, potential catalytic converter
seconds. To switch to ESC OFF mode,
the ESC indicator will remain off. When a
damage is possible. This could
press the ESC OFF button. The ESC
slippery or low traction condition is
result in loss of engine power.
OFF indicator will illuminate indicating
encountered, the ESC will operate, and
Have the Engine Control System
the ESC is deactivated. If this indicator
the ESC indicator will blink to indicate the
inspected as soon as possible by
stays on when ESC OFF is not selected,
ESC is operating.
an authorized HYUNDAI dealer.
the ESC may have a malfunction. Take
But, if the ESC system malfunctions the
your car to an authorized HYUNDAI deal-
indicator illuminates and stays on. Take
er and have the system checked.
your vehicle to an authorized HYUNDAI
D150323AFD
dealer and have the system checked.
ESC/ESC OFF indicator (Electronic
✽ NOTICE
Stability Control) (Type A, if equipped)
After reconnecting or recharging a dis-
✽ NOTICE
ESC indicator
charged battery, the ESC OFF indicator
After reconnecting or recharging a dis-
ESC
may illuminate. In this case, turn the
charged battery, the ESC indicator may
steering wheel 360 degrees to the left
illuminate. In this case, turn the steering
The ESC indicator will illuminate when
and 360 degrees to the right while the
wheel 360 degrees to the left and 360
the ignition switch is turned ON, but
ignition switch is in the ON position.
degrees to the right while the ignition
should go off after approximately 3 sec-
Then, restart the engine after the igni-
switch is in the ON position. Then, restart
onds. When the ESC is on, it monitors
tion is off. If the ESC OFF indicator
the engine after the ignition is off. If the
the driving conditions and under normal
does not turn off, have the system
ESC indicator does not turn off, have the
driving conditions, the ESC light will
checked by an authorized HYUNDAI
system checked by an authorized
remain off.
dealer as soon as possible.
HYUNDAI dealer as soon as possible.
4 49
Features of your vehicle
ESC OFF indicator
D150325AEN
D150327AUN
Cruise indicator
CRUISE
Key reminder warning chime
(if equipped)
If the driver’s door is opened while the
ignition key is left in the ignition switch
The ESC OFF indicator will illuminate
CRUISE indicator
(ACC or LOCK position), the key
when the ignition switch is turned ON,
The indicator light illuminates when the
reminder warning chime will sound. This
but should go off after approximately 3
cruise control system is enabled.
is to prevent you from locking your keys
seconds. To switch to ESC OFF mode,
in the vehicle. The chime sounds until the
The cruise indicator light in the instru-
press the ESC OFF button. The ESC
key is removed from the ignition switch or
ment cluster is illuminated when the
the driver’s door is closed.
OFF indicator will illuminate indicating
cruise control ON/OFF button on the
the ESC is deactivated.
steering wheel is pushed.
D150334AFD
The indicator light turns off when the
cruise control ON/OFF button is pushed
Electric power steering
EPS
again. For more Information about the
(EPS) system warning light
use of cruise control, refer to
“Cruise
control system” in section 5.
This indicator light comes on after the
ignition key is turned to the ON position
Cruise SET indicator
and then it will go out after the engine is
SET
started.
This light also comes on when the EPS
has some troubles. If it comes on while
driving, have your vehicle inspected by
The indicator light illuminates when the
an authorized HYUNDAI dealer.
cruise function switch
(COAST/SET or
RES/ACCEL) is ON.
The cruise SET indicator light in the
instrument cluster is illuminated when
the cruise control switch (COAST/SET or
RES/ACCEL) is pushed. The cruise SET
indicator light does not illuminate when
the cruise control switch (CANCEL) is
pushed or the system is disengaged.
4 50
Features of your vehicle
REAR PARKING ASSIST SYSTEM (IF EQUIPPED)
D170102AEN
WARNING
Types of warning sound
The rear parking assist system is a
• When an object is 47 in. to 32 in. (120
supplementary function only. The
cm to 81 cm) from the rear bumper:
operation of the rear parking assist
Buzzer beeps intermittently.
system can be affected by several
• When an object is 31 in. to 16 in. (80
factors
(including environmental
cm to 41 cm) from the rear bumper:
conditions). It is the responsibility
Buzzer beeps more frequently.
of the driver to always check the
• When an object is within 15 in. (40 cm)
area behind the vehicle before and
of the rear bumper:
while backing up.
Buzzer sounds continuously.
Sensors
OFD049050N
Operation of the rear parking
D170200AEN
D170000AEN
assist system
Non-operational conditions of
The rear parking assist system assists
D170101AEN
rear parking assist system
the driver during backward movement of
the vehicle by chiming if any object is
Operating condition
The rear parking assist system may
sensed within a distance of 47 in. (120
• This system will activate when backing
not operate properly when:
cm) behind the vehicle. This system is a
up with the ignition switch ON.
1. Moisture is frozen to the sensor. (It will
supplemental system and it is not intend-
If the vehicle is moving at a speed over
operate normally when the moisture
ed to nor does it replace the need for
3 mph (5 km/h), the system may not be
has been cleared.)
extreme care and attention of the driver.
activated correctly.
2. The sensor is covered with foreign
The sensing range and objects
• The sensing distance while the rear
matter, such as snow or water, or the
detectable by the back sensors are limit-
parking assist system is in operation is
sensor cover is blocked. (It will operate
ed. Whenever backing-up, pay as much
approximately 47 in. (120 cm).
normally when the material is removed
attention to what is behind you as you
or the sensor is no longer blocked.)
• When more than two objects are
would in a vehicle without a rear parking
sensed at the same time, the closest
3. Driving on uneven road surfaces
assist system.
one will be recognized first.
(unpaved roads, gravel, bumps, gradi-
ent).
4 51
