EMISSION CONTROL SYSTEMS

H020B01A-GAT

Do not touch the catalytic converter or any

About the Catalytic Converter

other part of the exhaust system while the

Exhaust gases passing through the catalytic

engine is running as it is very hot and could

converter cause it to operate at very high tem-

result in burns.

peratures. As a result, the introduction of large

Remember that your Hyundai dealer is your

amounts of unburned gasoline may cause it to

best source of assistance.

overheat and create a fire hazard. This can be

avoided by observing the following:

o Use unleaded fuel only.

o Maintain your engine in good condition. Ex-

tremely high converter temperatures can

result from improper operation of the electri-

cal, ignition or fuel injection systems.

o If your engine stalls, pings, knocks, or is

hard to start, take your car to your Hyundai

dealer as soon as possible and have the

difficulty corrected.

o Avoid driving with a very low fuel level. If

your run out of gasoline, it could cause the

engine to misfire and result in excessive

loading of the catalytic converter.

o Avoid idling the engine for periods longer

than 10 minutes.

o Your Hyundai should not be either pushed

or pulled to get it started. This can cause the

catalytic converter to overload.

o Take care not to stop your Hyundai over any

combustible material such as grass, paper,

leaves or rags. As these materials could

come in contact with the catalytic converter

and could cause a fire.

7-2

CONSUMER INFORMATION

ZI010B1-A

XI020A1-E

ZI000A1-E

Engine Number

TYRE PRESSURES

8. CONSUMER IN

FORMATION

ZI010A1-E

VEHICLE IDENTIFICATION

NUMBER (VIN)

I010B01A

XV80030E

The engine number is stamped on the engine

In modern high-speed motoring, correct tyre

block as shown in the drawing.

pressures are vitally important.

Incorrect pressures can reduce adhesion, af-

fect the steering, and cause excessive tyre

ZI010C1-E

wear. Check the pressures before you start a

TYRE INFORMATION

trip, when tyres are cold. If the pressures are

I010A01A

The tires supplied on your new Hyundai are

measured when the tyres are warm, a higher

chosen to provide the best performance for

reading will be obtained.

The vehicle identification number (VIN) is the

normal driving.

number used in registering your car and in all

PRESSURE. kPa (PSI)

legal matters pertaining to its ownership, etc.

RIM

TIRE

UP TO 2

UP TO MAX.

SIZE

PERSONS

LOAD

o On the identification plate attached to the

FRONT

REAR

FRONT

REAR

engine side of the firewall between the en-

4.0BX13

155/70R13

207(30)

221(32)

gine and passenger compartments.

4.5JX13

155/70R13

207(30)

221(32)

5.0JX13

175/60R13

207(30)

221(32)

8-1

CONSUMER INFORMATION

ZI030A1-E

XI050A1-E

DI060B1-E

SNOW TYRES

TYRE ROTATION

TYRE REPLACEMENT

If you equip your car with snow tyres, they

1.6 mm (0.06 in.)

should be the same size and have the same

load capacity as the original tyres. Do not drive

faster than 60 mph when your car is equipped

with snow tyres.

SI040A1-E

TYRE CHAINS

Tyre chains, if necessary, should be installed

Wear indicator

on the front wheels. Be sure that the chains are

the proper size and that they are installed in

HGK248

Spare tyre

HA1409

accordance with the manufacturer’s instruc-

tions.

Tyre wear will vary for each wheel. In order to

Tyres must be replaced when the wear indica-

To minimize tyre and chain wear, do not contin-

increase the life of each tyre and keep wear

tors appear as a solid bar across the tyre tread.

ue to use tyre chains when they are no longer

uniform, tyre rotation should be performed ev-

At this point, the remaining tread depth will be

needed.

ery 6,000 miles (10,000 km) as shown in figure.

approximately 0.06 in. (1.6 mm). In addition to

this, the tyre must be replaced if any portion of

CAUTION:

NOTE:

the tread has become bald or if there are any

When driving on roads covered with snow

Do not mix bias-ply and radial-ply tyres

lumps, bulges or deep cuts in the sidewalls or

or ice, drive at less than 20 mph (30 km/h).

under any circumstances. This may cause

tread.

dan-gerous handling characteristics.

Replacement tyres must be of the recommend-

ed size and rating and should be of the same

manufacture and tread pattern on each axle.

ZI060A1-E

TYRE BALANCING

A tyre that is out of balance may affect handling

and tyre wear. The tyres on your Hyundai were

balanced before the car was delivered but may

need balancing again during the years you own

the car. Whenever a tyre is dismounted for

repair, it should be rebalanced.

8-2

CONSUMER INFORMATION

DI060C1-E

I100A02A-EAT

WHEEL REPLACEMENT

SPARE TYRE AND TOOLS

The original wheels may only be replaced with

Hyundai Approved wheels.

CAUTION:

Driving on worn or defective tyres is dan-

gerous. Worn tyres may cause loss of steer-

ing control and a serious deterioration of

braking efficiency. Defective tyres may cause

vibration and loss of control through blow

outs.

Tyres of different size, construction or tread

D060J01X

pattern should not be intermixed on the same

axle. Radial and cross ply tyres should not be

Your Hyundai is delivered with the following:

used on the same vehicle.

The use of tyres and wheels of non approved

Spare tyre and wheel

sizes can be dangerous.

Wheel nut wrench, Wrench bar, Spanner,

Screwdriver

Jack

8-3

VEHICLE SPECIFICATIONS

J030A02X-EAT

ZJ000A1-A

TYRE

9. VEHICLE SPECIFICATIONS

Standard

155/70 R 13

J010A02X-EAT

Option

175/60 R 13

MEASUREMENT

in. (mm)

Spare

Full size spare

Overall length

137.6 (3495)

Overall width

58.9 (1495)

J040A01X-GAT

Overall height

ATOZ

63.6 (1615)

ELECTRICAL

(unladen)

AMICA

62.2 (1580)

Battery

MF 12V 40AH

Wheel base

93.7 (2380)

Alternator

13.5V 60A

Front

51.8 (1315)

Starting motor

0.8 KW

Wheel tread

Rear

51.2 (1300)

J050A02X-GAT

J020A01X-EAT

BRAKE

POWER STEERING

Type

Dual hydraulic with brake booster

Type

Rack and pinion

Front brake type

Ventilated disc

Wheel free play

0 ~ 1.181 in. (0 ~ 30 mm)

Rear brake type

Drum

Rack stroke

5.354 in. (136 mm)

Parking brake

Cable operated on rear wheel

Oil pump type

Vane type

J060A01X-EAT

FUEL SYSTEM

lmp.gal

Litres

Fuel tank Capacity

7.7

9-1

VEHICLE SPECIFICATIONS

J070A01X-GAT

ENGINE

Specifications

ITEMS

1.0 MFI

Engine type

4-Cylinder in-line SOHC

Idle Speed (RPM)

900 ± 100

Ignition Timing (Base)

BTDC 5° ± 2°

Firing order

1 - 3 - 4 - 2

J090A02A-EAT

SPARK PLUG

ITEM

UNLEADED

Spark plug

NGK : BKR5ES-11

CHAMPION : RC9YC4, RC10YC4

Spark plug gap

0.039 ~ 0.043 in. (1.0 ~ 1.1 mm)

9-2

VEHICLE SPECIFICATIONS

J080A06X-EAT

LUBRICATION CHART

Item

Oil & Coolant Standard

Q'ty

SAE 20W-40, 20W-50 (ABOVE -14°F)

API SG

SAE 15W-40, 15W-50 (ABOVE 5°F)

SAE 10W-30 (-13°F ~ 104°F)

Engine Oil

ABOVE

SAE 10W-40, 10W-50 (ABOVE -13°F)

SAE 5W-20 *1, *2 (BELOW 14°F)

2.72 lmp.qts (3.26 us-qts, 3.1 litres)

SAE 5W-30 *1 (BELOW 50°F)

SAE 5W-40 *1 (BELOW 68°F)

*1. Restricted by driving condition and dealing area

*2. Not recommended for sustained high speed vehicle operation

Engine oil consumption

Normal driving condition

MAX. 1L / 1500 Km

Severe driving condition

MAX. 1L / 1000 Km

Transaxle

Manual

HYUNDAI GENUINE PARTS MTF 75W/90 (API GL-4)

2.15 lmp.qts (2.58 us-qts, 2.45 litres)

Auto

ESSO JWS3314

4.56 lmp.qts (5.48 us-qts, 5.2 litres)

Power steering

PSF-3

As required

Brake fluid

DOT 3, DOT 4 or equivalent

As required

Engine coolant

Ethylene glycol base for aluminum radiator

3.95 lmp.qts (4.74 us-qts, 4.5 litres)

9-3

INDEX

ZK000A1-E

CENTRAL DOOR LOCKING SYSTEM

1-7

CHANGING THE OIL AND FILTER

6-4 ~ 6-5

10. INDEX

CHARGING WARNING LIGHT

1-19

CHILD PROTECTOR REAR DOOR LOCKS

1-4

CHILD RESTRAINT SYSTEM

1-10 ~ 1-11

ABS SYSTEM

2-7

CIGAR LIGHTER

1-24

ADJUSTABLE FRONT SEATS

1-5

CLOCK

1-24

AIR CLEANER FILTER

6-8

CLUTCH PEDAL FREEPLAY

6-13

AIR CONDITIONER CARE

6-12

COMPACT DISK PLAYER OPERATION (H922M)

1-47 ~ 1-48

AIR CONDITIONING SWITCH

1-36

COMPRESSOR DRIVE BELT

6-12

AIR CONDITIONING OPERATION

1-37

COOLING FANS

6-15

ANTENNA

1-52

APPEARANCE CARE

4-1 ~ 4-2

ASHTRAY

1-25

DAY-NIGHT REAR VIEW MIRROR

1-26

AUDIO FAULT CODE

1-49

DOOR LOCKS

1-3

AUTOMATIC TRANSAXLE

2-5 ~ 2-6

DRIVE BELTS

6-14

DRIVING FOR ECONOMY

2-8

BATTERY MAINTENANCE

6-15

BEFORE STARTING THE ENGINE

2-2

EFFECTIVE BRAKING

2-7

BONNET RELEASE

1-30

EMERGENCY TOWING

3-8

BRAKE CIRCUIT FAILURE WARNING LAMP

1-18

EMISSION CONTROL SYSTEM

7-1

BRAKE PEDAL CLEARANCE

6-14

ENGINE COMPARTMENT (For MFI Engine)

6-1

BRAKE PEDAL FREEPLAY

6-13

ENGINE COOLANT

6-5

BRAKES

6-11

ENGINE COOLANT TEMPERATURE GAUGE

1-20

ENGINE OIL CONSUMPTION

6-3

CARE OF SEAT BELTS

1-7

CARE OF CASSETTE TAPE

1-50 ~ 1-51

FILLING THE WASHER RESERVOIR

6-9

CARE OF DISC

1-50

FOLDING REAR SEAT BACK AND SEAT CUSHION

1-27

CATALYTIC CONVERTER (For MFI)

7-1

FOLDING THE OUTSIDE REAR VIEW MIRRORS

1-26

10-1

INDEX

FRONT FOG LIGHT SWITCH

1-29

INSTRUMENTS AND CONTROLS

1-16

FUEL ECONOMY

2-3

INTERIOR LIGHT

1-25

FUEL GAUGE

1-20

FUEL RECOMMENDATIONS

1-1

FUSIBLE LINKS

6-14

JUMP STARTING

3-1~3-2

GENERAL CHECKS

6-2

KEY POSITIONS

2-2

KEYS

1-2

HAZARD WARNING SYSTEM

1-24

HEADLIGHT BULB

6-16

LIGHT BULBS

6-16

HEADLIGHT LEVELING DEVICE SYSTEM

1-23

LIMP HOME PROCEDURES

1-2

HEADRESTRAINT

1-5

LOW FUEL LEVEL WARNING LAMP

1-19

HEADLIGHT FLASHER

1-22

HEADLIGHT SWITCH

1-21

HEATED REAR WINDOW

1-24

MAINTENANCE AND SERVICING REQUIREMENTS

5-1

HEATING AND VENTILATION

1-32

MAINTENANCE UNDER SEVERE USAGE CONDITIONS

5-4

HIGH AND LOW BEAM

1-21

MANUAL TRANSAXLE LUBRICANT

6-9

HIGH-MOUNTED REAR STOPLIGHT

1-27

MANUAL TRANSAXLE

2-4

HORN

1-32

MULTI FUNCTION SWITCH

1-21

IF THE ENGINE CANNOT BE CRANKED

3-1

ODOMETER

1-21

IF THE ENGINE OVERHEATS

3-2

OIL PRESSURE WARNING LIGHT

1-18

IF THE ENGINE WILL NOT START

3-1

OUTSIDE REAR VIEW MIRROR

1-25

IGNITION SWITCH

2-2

IMMOBILIZER SYSTEM

1-2

INDIVIDUAL CIRCUIT FUSES

6-15

PARKING BRAKE

1-26

INSTRUMENT CLUSTER AND INDICATOR

1-17

POWER STEERING FLUID LEVEL

6-16

10-2

INDEX

POWER STEERING HOSES

6-16

POWER WINDOWS

1-6

TAIL GATE

1-28

TRAILER OR VEHICLE TOWING

2-10 ~ 2-12

TRANSAXLE FLUID (AUTOMATIC)

6-10 ~ 6-11

REAR FOG LIGHT SWITCH

1-29

TYRE BALANCING

8-2

REAR WINDOW WIPER AND WASHER

1-23

TYRE INFORMATION

8-1

REMOTE FUEL FILLER LID RELEASE

1-29

TYRE PRESSURES

8-1

REMOTE TAIL GATE RELEASE

1-29

TYRE REPLACEMENT

8-2

RUNNING IN

1-1

TYRE ROTATION

8-2

SCHEDULED MAINTENANCE

5-2 ~ 5-3

VEHICLE IDENTIFICATION NUMBER (VIN)

8-1

SEAT BELT PRECAUTIONS

1-7

VEHICLE TOWING OR RECOVERY

3-6~3-8

SEAT BELTS

1-8 ~ 1-10

SNOW TYRES

8-1

SPARE TYRE

3-3, 8-3

WHEEL AND TYRE CHANGING

3-3 ~3-6

SPARK PLUG REPLACEMENT

6-7

WHEEL REPLACEMENT

8-2

SPECIFIATIONS

9-1, 9-3

WINDOW GLASS

1-6

SPEEDOMETER

1-21

WINDSCREEN WIPER AND WASHER SWITCH

1-22

SRS AIRBAG SYSTEM

1-12 ~ 1-15

WINDSHIELD WASHER OPERATION

1-22

STARTING

2-3

WINDSHIELD WIPER BLADES

6-9

STEERING WHEEL FREEPLAY

6-13

WINTER MOTORING

2-9

STEREO RADIO AND CASSETTE TAPE PLAYER

OPERATION (H900)

1-42 ~ 1-44

STEREO RADIO OPERATION (H922M)

1-45 ~ 1-46

STEREO RADIO OPERATION (HMR90)

1-40 ~ 1-41

STEREO SOUND SYSTEM

1-38 ~ 1-39

SUN-VISOR

1-31

10-3

Content .. 13 14 15
