27

BODY CONSTRUCTION - Front body <Fender apron panel>

3. FENDER APRON PANEL

1

No.

1
2
3
4

PART NAME

Fender apron inner panel
Fender apron inner front panel
Front shock absorber cover panel
Relay box mounting bracket

CON-0140

4

3

2

28

 SECTION A-A'

SECTION B-B'

BODY CONSTRUCTION - Front body <Fender apron panel>

CON-0152

CON-0151

<Cross-Sectional Views>

Fender apron panel

Front shock absorber cover panel

Fender apron inner panel

A

Î

A'

Î

B

B'

Î

Î

CON-0150

29

BODY CONSTRUCTION - Front body <Dash panel>

4. DASH PANEL

2

10

15

13

14

9

1

6

3

No.

1
2
3
4
5
6
7
8
9

10
11
12
13
14
15
16
17

PART NAME

Dash panel
Dash panel reinforcement
Dust cover panel
Clutch pedal mounting bracket
Heater lower mounting bracket
Evaporator & blower mounting bracket
Side sill inner front extension (LH)
Side sill inner front extension (RH)
Dash lower side reinforcement (LH)
Dash lower side reinforcement (RH)
Dash lower side panel (LH)
Dash lower side panel (RH)
Dash lower center reinforcement
Dash panel anti pad
Fuse box mounting bracket
Foot rest mounting bracket
Accelerator pedal mounting bracket

CON-0160

8

12

13

16

5

17

4

11

7

30

BODY CONSTRUCTION - Front body <Dash panel>

SECTION B-B'

SECTION A-A'

SECTION C-C'

SECTION D-D'

<Cross-Sectional Views>

PRO-0170

CON-0171

CON-0172

CON-0173

CON-0174

A

A'

C

C'

B'

B

Ð

Ð

D

D'

Dash panel
reinforcement

Dash panel

Dust cover panel

Dash panel

Dash panel reinforcement

Foot rest bracket

Dash panel anti pad

Dash panel anti pad

Front  side rear
lower member

Ð

Ð

Ð

Ð

Ð

Ð

Dash panel

Dash lower side reinforcement

Dash lower side panel

Dash panel

Heater lower mounting bracket

Dash panel
reinforcement
