23

BODY CONSTRUCTION - Front body <Radiator support panel>

1. RADIATOR SUPPORT PANEL

5

7

6

2

8

4

PART NAME

No.

Head lamp support panel
Radiator support member mounting reinforcement
Radiator support member mounting reinforcement
Front bumper mounting reinforcement
Radiator support upper side member
Radiator support center member
Radiator support upper center member
Radiator support center cross member
Horn mounting bracket
Radiator support upper center reinforcement

1
2
3
4
5
6
7
8
9

10

CON-0110

9

10

9

3

1

24

SECTION B-B'

SECTION A-A'

SECTION D-D'

SECTION C-C'

BODY CONSTRUCTION-Front body <Radiator support panel>

CON-0110

CON- 0113

CON- 0112

CON- 0111

CON- 0114

A'

A

B

B'

C'

D

D'

Í

Í

Í

Í

Í

C

Í

Í

Í

Head lamp support panel

Radiator support
upper center
member

Head lamp support panel

Front bumper mounting
reinforcement

Radiator support upper side member

Head lamp support panel

Radiator support center
cross member

Radiator support center
cross member

Radiator support upper
center member

<Cross-Sectional Views>

Radiator support
upper side
member

Radiator support center
member

25

BODY CONSTRUCTION - Front body <Front side member>

2. FRONT SIDE MEMBER

6

13

10

5

1

3

8

9

PART NAME

Front side member inner
Front side member inner reinforcement
Sub frame front mounting bracket
Side member front mounting reinforcement
Battery tray mounting bracket
Front side outer member
Front side outer member gusset
Brake hose mounting bracket
Front side rear lower member
Front side rear upper member
Sub frame rear mounting reinforcement
Sub frame front mounting nut
Sub frame rear mounting retainer

No.

1
2
3
4
5
6
7
8
9

10
11
12
13

CON-0120

12

11

4

2

7

26

SECTION B-B'

SECTION A-A'

SECTION C-C'

BODY CONSTRUCTION - Front body <Front side member, LH/RH>

<Cross-Sectional Views>
LH

CON-0132

CON-0131

CON-0134

CON-0130

A

A'

C'

C

D

D'

Í

Í

Í

Í

Í

Í

Sub frame front
mounting bracket

CON-0133

Front side outer member

Front side inner member

Front side outer member

Front side inner
member

Front side inner member

Front side outer
member gusset

RH

SECTION D-D'

CON-0135

B

B'

Í

Í

Front side outer member

Front side inner member

Front side outer member
