Honda Civic (2024 year). Manual in english - page 19





615

uu

Braking

u

Brake System

Driving

Turning off the automatic brake hold system

Only the automatic brake hold system
indicator comes on:

Press the automatic brake hold button.

u

The automatic brake hold system
indicator goes off.

When the automatic brake hold indicator
comes on at the same time:

Press the automatic brake hold button with
the brake pedal depressed.

u

The automatic brake hold system
indicator and the automatic brake hold
indicator go off.

Automatic Brake
Hold Button

Goes
Off

Goes
Off

616

uu

Braking

u

Anti-lock Brake System (ABS)

Driving

Anti-lock Brake System (ABS)

Helps prevent the wheels from locking up, and helps you retain steering control by
pumping the brakes rapidly, much faster than you can.

The electronic brake distribution (EBD) system, which is part of the ABS, also
balances the front-to-rear braking distribution according to vehicle loading.

You should never pump the brake pedal. Let the ABS work for you by always
keeping firm, steady pressure on the brake pedal. This is sometimes referred to as
“stomp and steer.”

ABS operation

The brake pedal may pulsate slightly when the ABS is working. Depress the brake
pedal and keep holding the pedal firmly down. On dry pavement, you will need to
press on the brake pedal very hard before the ABS activates. However, you may feel
the ABS activate immediately if you are trying to stop on snow or ice.

ABS may activate when you depress the brake pedal when driving on:

Wet or snow covered roads.

Roads paved with stone.

Roads with uneven surfaces, such as potholes, cracks, manholes, etc.

When the vehicle speed goes under 6 mph (10 km/h), the ABS stops.

ABS

1

Anti-lock Brake System (ABS)

NOTICE

The ABS may not function correctly if you use a tire of
the incorrect size or type.

If the

ABS

 indicator comes on while driving, there

may be a problem with the system.
While normal braking will not be affected, there is a
possibility that the ABS will not be operating. Have
your vehicle checked by a dealer immediately.

The ABS is not designed for the purpose of reducing
the time or distance it takes for a vehicle to stop: It is
designed to limit brake lockup which can lead to
skidding and loss of steering control.

In the following cases, your vehicle may need more
distance to stop than a vehicle without the ABS:

You are driving on rough or uneven road surfaces,
such as gravel or snow.

The tires are equipped with tire chains

*

.

The following may be observed with the ABS system:

Motor sounds coming from the engine
compartment when the brakes are applied, or
when system checks are being performed after the
engine has been started and while the vehicle
accelerates.

Brake pedal and/or the vehicle body vibration when
ABS activates.

These vibrations and sounds are normal to ABS
systems and are no cause for concern.

* Not available on all models

617

uu

Braking

u

Brake Assist System

Driving

Brake Assist System

Designed to assist the driver by generating greater braking force when you depress
the brake pedal hard during emergency braking.

Brake assist system operation

Press the brake pedal firmly for more powerful braking.

When brake assist operates, the pedal may wiggle slightly and an operating noise
may be heard. This is normal. Keep holding the brake pedal firmly down.

618

Driving

Parking Your Vehicle

When Stopped

1.

Depress the brake pedal firmly.

2.

With the brake pedal depressed, pull up the electric parking brake switch slowly,
but fully.

3.

Put the transmission into

(

P

.

4.

Turn off the engine.

u

The parking brake and brake system indicator (red) goes off in about 30
seconds.

3.

Move the shift lever to

(

N

.

4.

Turn off the engine and move the shift lever to

(

R

 or

(

1

.

u

The parking brake and brake system indicator (red) goes off in about 30
seconds.

Always set the parking brake, in particular if you are parked on an incline.

1

Parking Your Vehicle

3

WARNING

The vehicle can roll away if left unattended
without confirming that Park is engaged.

A vehicle that rolls away could cause a crash
resulting in serious injury or death.

Always keep your foot on the brake pedal
until you have confirmed that

(

P

 is shown

on the shift position indicator.

Continuously variable transmission models

1

When Stopped

NOTICE

The following can damage the transmission:

Depressing the accelerator and brake pedals
simultaneously.

Holding the vehicle in place when facing uphill by
depressing the accelerator pedal.

Putting the transmission into

(

P

 before the vehicle

stops completely.

Do not park your vehicle near flammable objects,
such as dry grass, oil, or timber.
Heat from the exhaust can cause a fire.

Continuously variable transmission models

Continuously variable transmission models

Manual transmission models

619

uu

Parking Your Vehicle

u

When Stopped

Driving

1

When Stopped

In extremely cold temperatures, the parking brake
may freeze up if applied. If such temperatures are
expected, do not apply the parking brake but, if
parking on a slope, either turn the front wheels so
they will contact the curb if the vehicle rolls down the
slope or block the wheels to keep the vehicle from
moving. If you do not take either precaution, the
vehicle may roll unexpectedly, leading to a crash.

620

uu

Parking Your Vehicle

u

Parking Sensor System

*

Driving

Parking Sensor System

*

The corner and center sensors monitor obstacles around your vehicle, and the
beeper, driver information interface and audio/information screen let you know the
approximate distance between your vehicle and the obstacle.

The sensor location and range

1

Parking Sensor System

*

Even when the system is on, always confirm if there is
no obstacle near your vehicle before parking.

The system may not work properly when:

The sensors are covered with snow, ice, mud, or dirt.

The vehicle has been out in hot or cold weather.

There is something nearby that emits ultrasonic
waves or high frequency sounds.

Driving in bad weather (rain, fog, snow, etc.).

The system may not detect these obstacles:

Thin or low objects.

Sonic-absorptive materials, such as snow, cotton,
or sponge.

Objects directly under the bumper.

The system may falsely detect obstacles in the
following situations:

The vehicle is on uneven surface, such as grass,
bumps, or a hill.

When close to other vehicles with sonar sensors or
other objects that emit ultrasonic waves.

There is splashing water near the sensors due to
heavy rains, etc.

Do not put any accessories on or around the sensors.

u

If you put any accessories (such as a bicycle rack)

on or around the rear sensors, the system may
activate if it detects these accessories as an
obstacle. In this case, turn off the rear sensor.

2

Turning off All Rear Sensors

 P. 624

Front Corner Sensors

Rear Corner Sensors

Rear Center Sensors

Front Center Sensors

Within about 24 in (60 cm) or less

Front: Within about 39 in (100 cm) or less
Rear: Within about 43 in (110 cm) or less

* Not available on all models

Continued

621

uu

Parking Your Vehicle

u

Parking Sensor System

*

Driving

Parking sensor system on and off

With the power mode in ON, press the
parking sensor system button to turn on or off
the system. The indicator in the button comes
on when the system is on.

The front corner, rear corner and rear center
sensors start to detect an obstacle when the
transmission is in

(

R

, and the vehicle speed is

less than 5 mph (8 km/h).

The front corner and front center sensors start
to detect an obstacle when the transmission is
in any position other than

(

P

 or

(

R

, and the

vehicle speed is less than 5 mph (8 km/h).

 You also need to release the parking brake.

1

Parking Sensor System

*

When you set the power mode to ON, the system will
be in the previously selected condition.

Parking Sensor System Button

Manual transmission models

* Not available on all models

622

uu

Parking Your Vehicle

u

Parking Sensor System

*

Driving

Screen Operation

You can switch between split view off and
split view on by touching the split screen tab.

Split Screen
Tab

Split View Off

Split View On

623

uu

Parking Your Vehicle

u

Parking Sensor System

*

Continued

Driving

When the distance between your vehicle and detected obstacles becomes shorter

*1:On the driver information interface
*2:On the audio/information screen
*3:At this stage, only the center sensors detect obstacles.

Interval

between

beeps

Distance between the Bumper and Obstacle

Indicator

Driver information

interface

Audio/Information Screen

Corner Sensors

Center Sensors

Moderate

Front: About 39-24 in

(100-60 cm)

Rear: About 43-24 in

(110-60 cm)

Comes on

*1

/Blinks

*2



in Yellow

*3

Short

About 24-18 in

(60-45 cm)

About 24-18 in

(60-45 cm)

Comes on

*1

/

Blinks

*2

 in Amber

Very short

About 18-14 in

(45-35 cm)

About 18-14 in

(45-35 cm)

Continuous

About 14 in

(35 cm) or less

About 14 in

(35 cm) or less

Comes on

*1

/

Blinks

*2

 in Red

Indicators light up
where the sensor
detects an obstacle.

Indicators light up where the
sensor detects an obstacle.

Indicators light up where the
sensor detects an obstacle.

Indicators light up where the
sensor detects an obstacle.

uu

Parking Your Vehicle

u

Parking Sensor System

*

624

Driving

To deactivate the rear sensors, please take the following steps:

1.

Make sure that the parking sensor system is not activated.

u

The indicator in the button turns off.

2.

Set the power mode to VEHICLE OFF.

3.

Press and hold the parking sensor system button, and set the power mode to ON.

4.

Keep pressing the button for 10 seconds. Release the button when the indicator
in the button flashes.

u

The beeper sounds once.

5.

While the indicator is flashing, press the button again. The indicator in the button
turns off.

u

The beeper sounds twice. The rear sensors are now turned off. They will remain
turned off until manually turned back on again. To turn the rear sensors on
again, follow the above procedure. The beeper sounds three times when the
rear sensors come back on.

Turning off All Rear Sensors

1

Turning off All Rear Sensors

When you put the transmission into

(

R

, the indicator

in the parking sensor system button blinks as a
reminder that the rear sensors have been turned off.

If the rear sensors are turned off when using the
parking sensor system, the Low Speed Braking
Control System will not activate while reversing.

2

Low Speed Braking Control

*

 P. 517, 523

* Not available on all models

625

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

Continued

Driving

Cross Traffic Monitor

*

Monitors the rear corner areas using the radar sensors when reversing, and alerts
you if a vehicle approaching from a rear corner is detected.

The system is convenient when you are backing out of a parking space.

1

Cross Traffic Monitor

*

The parking sensor system’s alerting buzzer overrides
the Cross Traffic Monitor buzzer when the sensors
are detecting obstacles at the closest range.

3

CAUTION

Cross Traffic Monitor cannot detect all
approaching vehicles and may not detect
an approaching vehicle at all.

Failure to visually confirm that it is safe to
back up the vehicle before doing so may
result in a collision.

Do not solely rely on the system when
reversing; always also use your mirrors, and
look behind and to the sides of your vehicle
before reversing.

Models with parking sensor system

* Not available on all models

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

626

Driving

The system activates when:

The power mode is in ON.

The Cross Traffic Monitor is turned on.

2

Cross Traffic Monitor On and Off

 P. 628

The transmission is in

(

R

.

Your vehicle is moving at 3 mph (5 km/h) or
lower.

When a vehicle is detected approaching from a rear corner, Cross Traffic Monitor
alerts you with a buzzer and a displayed warning.

The system will not detect a vehicle that approaches from directly behind your
vehicle, nor will it provide alerts about a detected vehicle when it moves directly
behind your vehicle.

The system does not provide alerts for a vehicle that is moving away from your
vehicle, and it may alert for pedestrians, bicycles, or stationary objects.

How the System Works

1

Cross Traffic Monitor

*

Cross Traffic Monitor may not detect or may delay
alerting an approaching vehicle, or may alert without
an approaching vehicle under the following
conditions:

An obstacle, such as another vehicle and a wall,
near your vehicle’s rear bumper, is blocking the
radar sensor’s scope.

Your vehicle is moving at the speed of about 3 mph
(5 km/h) or higher.

A vehicle is approaching at the speed other than
between about 6 mph (10 km/h) and 16 mph (25
km/h).

The system picks up external interference such as
other radar sensors from another vehicle or strong
radio wave transmitted from a facility nearby.

Either corner of the rear bumper is covered with
snow, ice, mud or dirt.

When there is bad weather.

Your vehicle is on an incline.

Your vehicle is tilted due to a heavy load in the rear.

Your vehicle is reversing towards a wall, a pole, a
vehicle, and so on.

The rear bumper or the sensors have been improperly
repaired or the rear bumper has been deformed.
Have your vehicle checked by a dealer.

For proper operation, always keep the rear bumper
corner area clean.
Do not cover the rear bumper corner area with labels
or stickers of any kind.

Radar sensors:
Underneath the rear bumper
corners

* Not available on all models

Continued

627

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

Driving

An arrow icon appears on the side a vehicle is approaching on the audio/information
screen.

When the System Detects a Vehicle

1

When the System Detects a Vehicle

If the

 on the lower right changes to

 in amber

when the transmission is in

(

R

, mud, snow or ice,

etc. may have accumulated in the vicinity of the
sensor. The system is temporarily canceled. Check the
bumper corners for any obstructions, and thoroughly
clean the area if necessary.

If the

 comes on when the transmission is in

(

R

there may be a problem with the Cross Traffic
Monitor system. Do not use the system and have your
vehicle checked by a dealer.

If the display remains the same with the transmission
in

(

R

, there may be a problem with the rear camera

system and the Cross Traffic Monitor system.
Do not use the system and have your vehicle checked
by a dealer.

Wide View

Normal View

Arrow Icon

Top Down View

628

uu

Parking Your Vehicle

u

Cross Traffic Monitor

*

Driving

The system can be turned on and off on the
audio/information screen by pressing the
Cross Traffic Monitor icon.

You can also switch the system on and off
from the customized feature on the audio/
information screen.

2

Customized Features

 P. 380

Cross Traffic Monitor On and Off

Cross Traffic Monitor
icon

629

Continued

Driving

Multi-View Rear Camera

About Your Multi-View Rear Camera

The audio/information screen can display your vehicle’s rear view.
The display automatically changes to the rear view when the transmission is put into

(

R

.

Multi-View Rear Camera Display Area

1

About Your Multi-View Rear Camera

The rear camera view is restricted. You cannot see
the corner ends of the bumper or what is underneath
the bumper. Its unique lens also makes objects
appear closer or farther than they actually are.

Visually confirm that it is safe to drive before backing
up. Certain conditions (such as weather, lighting, and
high temperatures) may also restrict the rear view. Do
not rely on the rearview display which does not give
you all information about conditions at the back of
your vehicle.

If the camera lens is covered with dirt or moisture,
use a soft, moist cloth to keep the lens clean and free
of debris.

You can change the

Fixed Guideline

 and

Dynamic

Guideline

 settings.

2

Customized Features

 P. 375, 380

Fixed Guideline
ON:

Guidelines appear when you put the

transmission into

(

R

.

OFF:

Guidelines do not appear.

Dynamic Guideline
ON:

Guidelines move according to the steering

wheel direction.

OFF:

Guidelines do not move.

Approx. 39 inches (1 m)

Approx. 20 inches (50 cm)

Camera

630

uu

Multi-View Rear Camera

u

About Your Multi-View Rear Camera

Driving

You can view three different camera modes on the rearview display.
Touch the appropriate icon to switch the mode.

If you were last using Wide view mode or Normal view mode, the same view
mode will be activated the next time you put the transmission into

(

R

.

If you were using Top down view mode before you turned off the engine, Wide
view mode will be activated the next time you set the power mode to ON and put
the transmission into

(

R

.

If you were using Top down view mode and 10 seconds elapsed after you took
the transmission out of

(

R

, Wide view mode will be activated the next time you

put the transmission into

(

R

.

If you were using Top down view mode and put the transmission back into

(

R



within 10 seconds after you took it out of

(

R

, Top down view mode will be

activated.

Bumper

Wide View Mode

Normal View Mode

Top Down View Mode

Bumper

Bumper

631

Driving

Refueling

Fuel Information

Fuel recommendation

Use of a lower octane gasoline can cause a persistent, heavy metallic knocking noise
that can lead to engine damage.

Use of a lower octane gasoline can cause occasional metallic knocking noise in the
engine and will result in decreased engine performance.
Use of a gasoline with a pump octane less than 87 can lead to engine damage.

Top tier detergent gasoline

Because the level of detergency and additives in gasoline vary in the market, Honda
endorses the use of “TOP TIER Detergent Gasoline” where available to help
maintain the performance and reliability of your vehicle. TOP TIER Detergent
Gasoline meets a new gasoline standard jointly established by leading automotive
manufacturers to meet the needs of today’s advanced engines.

Qualifying gasoline retailers will, in most cases, identify their gasoline as having met
“TOP TIER Detergent Gasoline” standards at the retail location. This fuel is
guaranteed to contain the proper level of detergent additives and be free of metallic
additives. The proper level of detergent additives, and absence of harmful metallic
additives in gasoline, help avoid buildup of deposits in your engine and emission
control system.

For further important fuel-related information for your vehicle, or on information on
gasoline that does not contain MMT, visi

www.hondacars.com.

 In Canada, visit

www.honda.ca

 for additional information on gasoline. For more information on top

tier gasoline, visit

www.toptiergas.com

.

Fuel tank capacity: 12.39 US gal (46.9 L)

Unleaded gasoline, pump octane number 87 or higher

Unleaded premium gasoline, pump octane number 91 or higher

1

Fuel Information

NOTICE

We recommend quality gasoline containing
detergent additives that help prevent fuel system and
engine deposits. In addition, in order to maintain
good performance, fuel economy, and emissions
control, we strongly recommend the use of gasoline
that does NOT contain harmful manganese-based
fuel additives such as MMT, if such gasoline is
available.

Use of gasoline with these additives may adversely
affect performance, and cause the malfunction
indicator lamp on your instrument panel to come on.
If this happens, contact a dealer for service.
Some gasoline today is blended with oxygenates such
as ethanol. Your vehicle is designed to operate on
oxygenated gasoline containing up to 15% ethanol
by volume. Do not use gasoline containing methanol.
If you notice any undesirable operating symptoms, try
another service station or switch to another brand of
gasoline.

Continuously variable transmission models

Manual transmission models

632

uu

Refueling

u

How to Refuel

Driving

How to Refuel

Your fuel tank is not equipped with a fuel filler cap. You can insert the filler nozzle
directly into the filler neck. The tank seals itself again when you pull out the filler
nozzle.

1.

Stop your vehicle with the service station
pump on the left side of the vehicle in the
rear.

2.

Turn off the engine.

3.

Unlock the driver’s door.

u

The fuel fill door on the outer side of the
vehicle will unlock.

4.

Press and release the area indicated by the
arrow to release the fuel fill door. You will
hear a click and the lid will open slightly.

5.

Manually pull the fuel fill door to a fully
open position.

1

How to Refuel

The fuel filler opening is designed to accept only
service station filler nozzles for refueling. Use of
smaller diameter tubes (e.g., those used to siphon
fuel for other uses) or other non-service station
devices can damage the area in and around the filler
opening.

Use the lock tab or the master door lock switch to
unlock the fuel fill door.
The vehicle doors and fuel fill door automatically
relock if the remote unlock function is used. This can
be deactivated by briefly opening then closing the
driver’s door.

Using the Walk away auto lock

®

 feature will also lock

the fuel fill door. Always make sure both the driver’s
door and fuel fill door are unlocked before
attempting to open the fuel fill door.

2

Locking the doors and trunk (Walk away
auto lock

®

)

 P. 177

3

WARNING

Gasoline is highly flammable and explosive.
You can be burned or seriously injured
when handling fuel.

Stop the engine, and keep heat, sparks,
and flames away.

Handle fuel only outdoors.

Wipe up spills immediately.

Press

Fuel Fill Door

633

uu

Refueling

u

How to Refuel

Driving

6.

Place the end of the filler nozzle on the
lower part of filler opening, then insert it
slowly and fully.

u

Make sure that the end of the filler
nozzle goes down along with the filler
pipe.

u

Keep the filler nozzle level.

u

When the tank is full, the filler nozzle will
click off automatically.

u

If you do not fill up the tank to full,
always add a minimum of 1.3 US gal (5 L)
of fuel.

u

After filling, wait about five seconds
before removing the filler nozzle.

7.

Shut the fuel fill door by hand.

1

How to Refuel

If the filler nozzle keeps turning off when the tank is
not full, there may be a problem with the pump’s fuel
vapor recovery system. Try filling at another pump. If
this does not fix the problem, consult a dealer.

The filler nozzle automatically stops to leave space in
the fuel tank so that fuel does not overflow as a result
of changes in air temperature.

Do not continue to add fuel after the filler nozzle has
automatically stopped. Additional fuel can exceed
the full tank capacity and cause fuel to spill.

If you repeatedly fill the tank with less than the
specified minimum amount of fuel, the malfunction
indicator lamp may come on. If this happens, have
your vehicle checked by a dealer.

If you have to refuel your vehicle from a portable
container, use the funnel provided with your vehicle.

2

Refueling From a Portable Fuel Container



P. 743

634

Driving

Fuel Economy and CO

2

 Emissions

Improving Fuel Economy and Reducing CO

2



Emissions

Achieving fuel economy and reducing CO

2

 emissions is dependent on several

factors, including driving conditions, load weight, idling time, driving habits, and
vehicle condition. Depending on these and other factors, you may not achieve the
rated fuel economy of this vehicle.

You can optimize your fuel economy with proper maintenance of your vehicle.
Always maintain your vehicle in accordance with the messages displayed on the
driver information interface.

Use engine oil with the viscosity recommended.

2

Recommended Engine Oil

 P. 654

Maintain the specified tire pressure.

Do not load the vehicle with excess cargo.

Keep your vehicle clean. A buildup of snow or mud on your vehicle's underside
adds weight and increases wind resistance.

Maintenance and Fuel Economy

1

Improving Fuel Economy and Reducing CO

2

 Emissions

Direct calculation is the recommended method to
determine actual fuel consumed while driving.

In Canada, posted fuel economy numbers are
established following a simulated test. For more
information on how this test is performed, please visit

https://www.nrcan.gc.ca

 and search for “fuel

consumption testing” in the search field at the top of
the page.

Miles driven

Gallons of

fuel

Miles per

Gallon

100

Liters of

fuel

Kilometers

driven

L per 100 km

635

Driving

Turbo Engine Vehicle

*

Handling Precautions

The turbocharger is a high-precision device to obtain greater horsepower by
delivering a large volume of compressed air into the engine using a turbine driven by
the engine’s exhaust gas pressure.

When the engine is cold just after starting, avoid revving the engine or sudden
acceleration.

Always replace the engine oil and engine oil filter according to the Maintenance
Minder

TM

. The turbine rotates at very high speeds over 100,000 rpm and its

temperature reaches over 1,292°F (700°C). It is lubricated and cooled by engine
oil. If you fail to replace the engine oil and filter at the scheduled distance or
interval, deteriorated engine oil may cause failure such as sticking and abnormal
noise of the turbine bearing.

1

Turbo Engine Vehicle

*

The scheduled maintenance intervals for replacing
the filter is indicated on the driver information
interface. Follow the information on replacement
timing.

2

Maintenance Minder

TM

 P. 641

The

Engine temperature too hot. Do not drive.

Allow engine to cool.

 or

Engine temperature

near limit. Avoid heavy acceleration and high
speed.

 message may appear on the driver

information interface when you restart the engine
after driving under high load conditions such as at
high speed or in hilly terrain.
This is normal. The message goes off after you idle or
drive the vehicle for about one minute.

The temperature gauge pointer is at the

 mark

when you restart the engine after driving under high
load conditions such as at high speed or in hilly
terrain. This is normal. The gauge goes down after
you idle or drive the vehicle for about one minute.

Models with B-type meter

H

* Not available on all models

636

This page intentionally left blank.

637

Maintenance

This chapter discusses basic maintenance.

Before Performing Maintenance

Inspection and Maintenance ............ 638
Safety When Performing Maintenance .... 639
Parts and Fluids Used in Maintenance

Service ........................................... 640

Maintenance Minder

TM

..................... 641

Maintenance Under the Hood

Maintenance Items Under the Hood .... 651
Opening the Hood ........................... 653
Recommended Engine Oil ................ 654
Oil Check ......................................... 655
Adding Engine Oil ............................ 657
Changing the Engine Oil and Oil Filter..... 658

Engine Coolant ................................ 661
Transmission Fluid............................ 663
Brake/Clutch

*

 Fluid .......................... 664

Refilling Window Washer Fluid......... 665

Replacing Light Bulbs

....................... 666

Checking and Maintaining Wiper Blades

.... 671

Checking and Maintaining Tires

Checking Tires ................................. 673
Tire and Loading Information Label ... 674
Tire Labeling .................................... 674
DOT Tire Quality Grading (U.S. Vehicles)....676
Wear Indicators................................ 678
Tire Service Life ................................ 678

Tire and Wheel Replacement ........... 679
Tire Rotation.................................... 680
Winter Tires ..................................... 681

Battery

............................................... 683

Remote Transmitter Care

Replacing the Remote Battery .......... 685

Climate Control System Maintenance

....686

Cleaning

Interior Care .................................... 687
Exterior Care.................................... 689

Accessories and Modifications

Accessories ...................................... 692
Modifications................................... 693

* Not available on all models

638

Main

tenan

ce

Before Performing Maintenance

Inspection and Maintenance

For your safety, perform all listed inspections and maintenance to keep your vehicle
in good condition. If you become aware of any abnormality (noise, smell, insufficient
brake fluid, oil residue on the ground, etc.), have your vehicle inspected by a dealer.
(Note, however, that service at a dealer is not mandatory to keep your warranties in
effect.)

Routine inspections

Perform inspections before long distance trips, when washing the vehicle, or when
refueling.

2

Maintenance

 P. 33

Periodic inspections

Check the brake/clutch

*

 fluid level monthly.

2

Brake/Clutch

*

 Fluid

 P. 664

Check the tire pressure monthly. Examine the tread for wear and foreign objects.

2

Checking and Maintaining Tires

 P. 673

Check the operation of the exterior lights monthly.

2

Replacing Light Bulbs

 P. 666

Check the condition of the wiper blades at least every six months.

2

Checking and Maintaining Wiper Blades

 P. 671

Types of Inspection and Maintenance

1

Inspection and Maintenance

Maintenance, replacement, or repair of
emissions control devices and systems may be
done by any automotive repair establishment or
individuals using parts that are “certified” to
EPA standards.

According to state and federal regulations, failure to
perform maintenance on the maintenance main
items marked with # will not void your emissions
warranties. However, all maintenance services should
be performed in accordance with the intervals
indicated by the driver information interface.

2

Maintenance Service Items

 P. 646

If you want to perform complex maintenance tasks
that require more skills and tools, you can purchase a
subscription to the Service Express website at

www.techinfo.honda.com

.

2

Authorized Manuals

 P. 759

If you want to perform maintenance yourself, make
sure that you have the necessary tools and skills first.
After performing maintenance, update the records in
the separate maintenance booklet.

U.S. models

* Not available on all models

639

uu

Before Performing Maintenance

u

Safety When Performing Maintenance

Main

tenan

ce

Safety When Performing Maintenance

Some of the most important safety precautions are given here. However, we cannot
warn you of every conceivable hazard that can arise in performing maintenance.
Only you can decide whether you should perform a given task.

To reduce the possibility of fire or explosion, keep cigarettes, sparks, and flames
away from the battery and all fuel related parts.

Never leave rags, towels, or other flammable objects under the hood.

u

Heat from the engine and exhaust can ignite them, causing a fire.

To clean parts, use a commercially available degreaser or parts cleaner, not
gasoline.

Wear eye protection and protective clothing when working with the battery or
compressed air.

Engine exhaust contains carbon monoxide, which is poisonous and can kill you.

u

Only operate the engine if there is sufficient ventilation.

The vehicle must be in a stationary condition.

u

Make sure your vehicle is parked on level ground, the parking brake is set, and
the engine is off.

Be aware that hot parts can burn you.

u

Make sure to let the engine and exhaust system cool thoroughly before
touching vehicle parts.

Be aware that moving parts can injure you.

u

Do not start the engine unless instructed, and keep your hands and limbs away
from moving parts.

u

Do not open the hood while the Auto Idle Stop function is activated.

Maintenance Safety

Vehicle Safety

1

Safety When Performing Maintenance

3

WARNING

Improperly maintaining this vehicle or
failing to correct a problem before driving
can cause a crash in which you can be
seriously hurt or killed.

Always follow the inspection and
maintenance recommendations according
to the schedules in this owner’s manual.

3

WARNING

Failure to properly follow maintenance
instructions and precautions can cause you
to be seriously hurt or killed.

Always follow the procedures and
precautions in this owner’s manual.

640

uu

Before Performing Maintenance

u

Parts and Fluids Used in Maintenance Service

Main

tenan

ce

Parts and Fluids Used in Maintenance Service

The use of Honda genuine parts and fluids is recommended when maintaining and
servicing your vehicle. Honda genuine parts are manufactured according to the
same high quality standards used in Honda vehicles.

1

Parts and Fluids Used in Maintenance Service

NOTICE

Do not press the engine cover forcibly. This may
damage the engine cover and component parts.

2.0 L engine models

641

Main

tenan

ce

Maintenance Minder

TM

If the engine oil life is less than 15%, you will see the Maintenance Minder messages
appear on the driver information interface every time you set the power mode to
ON. The messages notify you when to change the engine oil, or when to bring your
vehicle to a dealer for indicated maintenance services.

642

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

To Use Maintenance Minder

TM

Maintenance items, which should be serviced at the same time that you replace the
engine oil, appear on the driver information interface.
You can view them on the engine oil life screen at any time.

1.

Set the power mode to ON.

2.

Press the

 (home) button.

3.

Roll the left selector wheel until

 is displayed.

4.

Press the left selector wheel to go to the Maintenance Minder screen. The engine
oil life appears on the driver information interface along with maintenance items
due soon.

Displaying the Maintenance Minder Information

1

Displaying the Maintenance Minder Information

Based on the engine operating conditions, the
remaining engine oil life is calculated and displayed
as a percentage.

There is a list of maintenance main and sub items you
can view on the driver information interface.

2

Maintenance Service Items

 P. 646

Displayed Engine Oil

Life (%)

Calculated Engine Oil

Life (%)

100

100 to 91

90

90 to 81

80

80 to 71

70

70 to 61

60

60 to 51

50

50 to 41

40

40 to 31

30

30 to 21

20

20 to 16

15

15 to 11

10

10 to 6

5

5 to 1

0

0

Models with A-type meter

 (home) Button

Engine Oil Life

Main Item

Sub Item

Left Selector Wheel

643

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

1.

Set the power mode to ON.

2.

Roll the right selector wheel until the Maintenance Minder screen is displayed.
The engine oil life appears on the driver information interface along with
maintenance items due soon.

Models with B-type meter

Engine Oil Life

Main Item

Sub Item

Right Selector Wheel

644

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

*1:Models with A-type meter
*2:Models with B-type meter

Maintenance Minder Messages on the Driver Information

Interface

Maintenance Message

Oil Life Display

Explanation

Information

-

When you select the
Maintenance Minder screen,
it displays codes for
maintenance items due at
the next engine oil change,
along with the percentage of
engine oil life remaining.

-

Maintenance Due Soon

15 %

The remaining engine oil life
is 15 to 6 percent.

Press the

 (home) button

to switch to another display.

Roll the right selector wheel
to switch to another display.

The engine oil is approaching
the end of its service life, and
the maintenance items should
be inspected and serviced
soon.

*1

*2

*1

*2

Models with A-type meter

Models with B-type meter

645

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Continued

Main

tenan

ce

*1:Models with A-type meter
*2:Models with B-type meter

The system message indicator (

) comes on along with the Maintenance Minder

message.

Maintenance Message

Oil Life Display

Explanation

Information

Maintenance Due Now

5 %

The remaining engine oil life
is 5 to 1 percent.

Press the

 (home) button

to switch to another display.

Roll the right selector wheel
to switch to another display.

The engine oil has almost
reached the end of its service
life, and the maintenance items
should be inspected and
serviced as soon as possible.

Maintenance Past Due

Negative Distance

The engine oil life has passed
its service life, and a negative
distance appears after driving
over 10 miles (U.S. models) or
10 km (Canadian models).
The negative distance on the
display blinks.

Press the

 (home) button

to switch to another display.

Roll the right selector wheel
to switch to another display.

The engine oil life has passed.
The maintenance items must
be inspected and serviced
immediately.

*1

*2

Models with A-type meter

Models with B-type meter

*1

*2

Models with A-type meter

Models with B-type meter

646

uu

Maintenance Minder

TM

u

To Use Maintenance Minder

TM

Main

tenan

ce

*1 : Models with A-type meter
*2 : Models with B-type meter

Maintenance Service Items

Maintenance Minder Message

System Message
Indicator

Sub Items

Main Item

*1

*2















Content      ..     17      18      19      20     ..
