Honda e (2021 year). Manual in english - page 23





uu

Display Audio

u

Hands-Free Telephone System

354

Features

When your phone is paired, the contents of its phonebook and recent calls are
automatically imported to the system.

1.

Select

Phone

.

2.

Select

Settings

.

3.

Select

Auto Sync Phone

.

4.

Select

ON

 or

OFF

.

u

The default setting is

ON

.

Automatic Import of Mobile Phonebook and Recent calls

1

Automatic Import of Mobile Phonebook and Recent calls

On some phones, it is necessary to set up it enabled
to be imported the mobile phonebook.

When you select a name from the list in the mobile
phonebook, you can see a category icon. The icons
indicate what types of numbers are stored for that
name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Recent calls are updated after every connection or
call.

Pref

Fax

Home

Car

Mobile

Voice

Work

Other

Pager

Continued

355

uu

Display Audio

u

Hands-Free Telephone System

Features

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFT.

1.

Select

Phone

.

2.

Select

Settings

.

3.

Select

Auto Phone Call Transfer

.

4.

Select

ON

 or

OFF

.

u

The default setting is

ON

.

You can change the ring tone setting.

1.

Select

Phone

.

2.

Select

Settings

.

3.

Select

Ringtone

.

4.

Select

Vehicle

 or

Phone

.

u

The default setting is

Phone

.

Automatic Transferring

Ring Tone

1

Ring Tone

Vehicle

: The fixed ring tone sounds from the

speakers.

Phone

: Depending on the make and model of the

mobile phone, the ring tone stored in the phone will
sound if the phone is connected.

356

uu

Display Audio

u

Hands-Free Telephone System

Features

To add a Favourite contacts

1.

Select

Phone

.

2.

Select

Recent calls

Contacts

, or

Keypad

.

3.

Select the star icon.

3.

Select

Add to Favourite Contacts

.

u

A notification appears on the screen if
the Favourite contacts is successfully
stored.

u

To remove the Favourite contacts, select
the star icon again.

Favourite Contacts

Recent calls Screen

a

Star Icon

On the Recent calls or Contacts screen

On the Keypad screen

Contacts Screen

a

Star Icon

357

uu

Display Audio

u

Hands-Free Telephone System

Continued

Features

To edit a Favourite contacts

1.

Select

Phone

.

2.

Select

Favourite contacts

.

3.

Select

Edit

 on the Favourite contacts entry

you want to edit.

4.

Select a setting you want.

5.

Select

Done

.

To delete a Favourite contacts

1.

Select

Phone

.

2.

Select

Favourite contacts

.

3.

Select

Edit

 on the Favourite contacts entry

you want to delete.

4.

Select

Remove

.

5.

A confirmation message appears on the
screen. Select

Yes

.

Keypad Screen

a

Add to Favourite Contacts

uu

Display Audio

u

Hands-Free Telephone System

358

Features

You can make calls by inputting any phone
number, or by using the imported

Recent

calls

Favourite contacts

, and

Contacts



entries.

To make a call using the recent calls

Recent calls are stored by

All

Dialled

Missed

, and

Received

.

1.

Select

Phone

.

2.

Select

Recent calls

.

u

You can sort by

All

Dialled

Missed

, or

Received

. Select the icon on the

upper right of the screen.

3.

Select a number.

u

Dialing starts automatically.

To make a call using a Favourite contacts entry

1.

Select

Phone

.

2.

Select

Favourite contacts

.

u

You can change the order of Favourite contacts entries by selecting

Reorder

.

3.

Select a number.

u

Dialing starts automatically.

Making a Call

1

Making a Call

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

While there is an active connection with Apple
CarPlay, phone calls cannot be made with Hands-
Free Telephone (HFT) system and are only made from
Apple CarPlay.

1

To make a call using the recent calls

The recent calls appear only when a phone is
connected to the system.

All:

Displays the last outgoing, incoming, and missed

calls.

Dialled:

Displays the last outgoing calls.

Missed:

Displays the last missed calls.

Received:

Displays the last incoming calls.

359

uu

Display Audio

u

Hands-Free Telephone System

Continued

Features

To make a call using the imported phonebook

1.

Select

Phone

.

2.

Select

Contacts

.

3.

Select a name.

u

You can sort by

First Name

 or

Surname

. Select the icon on the upper right of

the screen.

4.

Select a number.

u

Dialing starts automatically.

To make a call using a phone number

1.

Select

Phone

.

2.

Select

Keypad

.

3.

Select a number.

u

Use the keyboard on the touch screen for entering numbers.

4.

Select

Call

.

u

Dialing starts automatically.

uu

Display Audio

u

Hands-Free Telephone System

360

Features

When there is an incoming call, an audible
notification sounds (if activated) and the

Incoming Call...

 screen appears.

You can answer the call using the left selector
wheel.
To pick the call, roll up or down to select



(answer) on the driver information interface
and then press the left selector wheel.

u

If you want to decline or end the call,
select

 (ignore) on the driver

information interface using the left
selector wheel.

Receiving a Call

1

Receiving a Call

Call Waiting
Select

 (answer) to put the current call on hold to

answer the incoming call.
Select

 using the left selector wheel to return to

the current call.

Select

 (ignore) to ignore the incoming call if you

do not want to answer it.
Select

 if you want to hang up the current call.

You can select the icons on the audio/information
screen instead of

 and

 on the driver

information interface.

361

uu

Display Audio

u

Hands-Free Telephone System

Features

The following options are available during a call.

Keypad:

Send numbers during a call. This is useful when you call a menu-driven

phone system.

Mute:

Mute your voice.

Use Handheld:

Transfer a call from the system to your phone.

The available options are shown on the lower half of the centre screen.

Select the option.

u

The mute icon appears when

Mute

 is selected when the other source screen

other than the phone screen is displayed. Select

Mute

 again to turn it off.

Options During a Call

1

Options During a Call

You can select the icons on the audio/information
screen.

362

Features

Audio Error Messages

iPod/USB Flash Drive

If an error occurs while playing an iPod or USB flash drive, you may see the following
error messages. If you cannot clear the error message, contact a dealer.

Error Message

Solution

No response from device

Appears when the system does not acknowledge the iPod. Reconnect the iPod.

Connect Retry

Unplayable File

Appears when the files in the USB flash drive are copyright protected or an unsupported
format. This error message appears for about five seconds, then plays the next song.

Unsupported Device

Appears when the system does not communicate with a connected device. If it appears
when a device is connected, contact your place of device purchase.

A charging error has occurred with the
connected USB device. When safe please
check the compatibility of the device and
USB cable and try again.

Appears when an incompatible device is connected. Disconnect the device. Then turn
the audio system off, and turn it on again. Do not reconnect the device that caused the
error.

363

Continued

Features

General Information on the Audio System

Compatible iPod, iPhone, and USB Flash Drives

A USB flash drive of 256 MB or higher is recommended.

Some digital audio players may not be compatible.

Some USB flash drives (e.g., a device with security lockout) may not work.

Some software files may not allow for audio play or text data display.

Some versions of MP3, WMA, AAC, FLAC, WAV, PCM/WAVE, MP4, AVI, MKV, or
ASF/WMV formats may be unsupported.

iPod and iPhone Model Compatibility

Model

iPod touch (5th to 6th generation) released between 2012 and 2015
iPhone 5/iPhone 5s/iPhone 5c/iPhone 6/iPhone 6 Plus/iPhone 6S/iPhone 6S Plus/
iPhone SE/iPhone 7/iPhone 7 Plus/iPhone 8/iPhone 8 Plus/iPhone X/iPhone XS/
iPhone XS Max/iPhone XR

USB Flash Drives

1

iPod and iPhone Model Compatibility

This system may not work with all software versions
of these devices.

1

USB Flash Drives

Files on the USB flash drive are played in their stored
order. This order may be different from the order
displayed on your PC or device.

364

uu

General Information on the Audio System

u

Compatible iPod, iPhone, and USB Flash Drives

Features

MP4 File

AVI File

Recommended Devices

Media

USB Flash Drive

Profile (MP4 version)

BaselineProfile/Level 3,

MailProfile/Level 3.1

(MPEG4-AVC)

SimpleProfile/Level 5 (MPEG4)

File extension (MP4 version)

.mp4/.m4v

Compatible audio codec

AAC, MP3

Compatible video codec

MPEG4-AVC (H.264)

MPEG4 (ISO/IEC 14496 Part.2)

Bit rate

10 Mbps, 14 Mbps

(MPEG4-AVC)

8 Mbps (MPEG4)

Maximum image

1,280 × 720 pixels (MPEG4-AVC)

720 × 576 pixels (MPEG4)

Media

USB Flash Drive

Profile (AVI version)

BaselineProfile/Level 3,

MailProfile/Level 3.1

(MPEG4-AVC)

SimpleProfile/Level 5 (MPEG4)

AdvancedProfile/Level 2,

MainProfile/Level Medium,

SimpleProfile/Level Medium (VC-1)

File extension (AVI version)

.avi

Compatible audio codec

AAC, MP3, WMA

Compatible video codec

MPEG4-AVC (H.264)

MPEG4 (ISO/IEC 14496 Part.2)

VC-1

Bit rate

10 Mbps, 14 Mbps

(MPEG4-AVC)

8 Mbps (MPEG4)

20 Mbps, 10 Mbps, 384 kbps

(VC-1)

Maximum image

1,280 × 720 pixels

(MPEG4-AVC)

720 × 576 pixels (MPEG4)

1,280 × 720 pixels,

720 x 480 pixels,

352 x 288 pixels (VC-1)

365

uu

General Information on the Audio System

u

Compatible iPod, iPhone, and USB Flash Drives

Features

MKV File

ASF/WMV File

Media

USB Flash Drive

Profile (MKV version)

BaselineProfile/Level 3,

MailProfile/Level 3.1

(MPEG4-AVC)

SimpleProfile/Level 5 (MPEG4)

AdvancedProfile/Level 2,

MainProfile/Level Medium,

SimpleProfile/Level Medium (VC-1)

File extension (MKV version)

.mkv

Compatible audio codec

AAC, MP3

Compatible video codec

MPEG4-AVC (H.264)

MPEG4 (ISO/IEC 14496 Part.2)

VC-1

Bit rate

10 Mbps, 14 Mbps

(MPEG4-AVC)

8 Mbps (MPEG4)

20 Mbps, 10 Mbps, 384 kbps

(VC-1)

Maximum image

1,280 × 720 pixels

(MPEG4-AVC)

720 × 576 pixels

(MPEG4)

1,280 × 720 pixels,

720 x 480 pixels,

352 x 288 pixels (VC-1)

Media

USB Flash Drive

Profile (ASF/WMV version)

BaselineProfile/Level 3,

MailProfile/Level 3.1

(MPEG4-AVC)

AdvancedProfile/Level 2,

MainProfile/Level Medium,

SimpleProfile/Level Medium (VC-1)

File extension

(ASF/WMV version)

.asf/.wmv

Compatible audio codec

WMA

Compatible video codec

MPEG4-AVC (H.264)

VC-1

Bit rate

10 Mbps, 14 Mbps (MPEG4-AVC)

20 Mbps, 10 Mbps, 384 kbps (VC-1)

Maximum image

1,280 × 720 pixels (MPEG4-AVC)

1,280 × 720 pixels,

720 x 480 pixels,

352 x 288 pixels (VC-1)

366

uu

General Information on the Audio System

u

About Open Source Licences

Features

About Open Source Licences

To see the open source licence information, follow these steps.

1.

Select

General Settings

.

2.

Select

System

.

3.

Select

Detail Information

.

Copyright 2014 jQuery Foundation and other contributors

http://jquery.com/

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the
“Software”), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish,
distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the
following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF
CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS
IN THE SOFTWARE.

Software for the Display Audio

367

uu

General Information on the Audio System

u

Legal Information on Apple CarPlay/Android Auto

Continued

Features

Legal Information on Apple CarPlay/Android Auto

USE OF APPLE CARPLAY IS SUBJECT TO YOUR AGREEMENT TO THE CARPLAY TERMS OF USE, WHICH ARE INCLUDED AS PART OF THE
APPLE iOS TERMS OF USE. IN SUMMARY, THE CARPLAY TERMS OF USE DISCLAIM APPLE AND ITS SERVICE PROVIDERS’ LIABILITY IF THE
SERVICES FAIL TO PERFORM CORRECTLY OR ARE DISCONTINUED, STRICTLY LIMIT APPLE AND ITS SERVICE PROVIDERS’ OTHER
LIABILITIES, DESCRIBE THE KINDS OF USER INFORMATION (INCLUDING, FOR EXAMPLE, VEHICLE LOCATION, VEHICLE SPEED, AND
VEHICLE STATUS) BEING GATHERED AND STORED BY APPLE AND ITS SERVICE PROVIDERS, AND DISCLOSE CERTAIN POSSIBLE RISKS
ASSOCIATED WITH THE USE OF CARPLAY, INCLUDING THE POTENTIAL FOR DRIVER DISTRACTION. SEE APPLE’S PRIVACY POLICY FOR
DETAILS REGARDING APPLE’S USE AND HANDLING OF DATA UPLOADED BY CARPLAY.

USE OF ANDROID AUTO IS SUBJECT TO YOUR AGREEMENT TO THE ANDROID AUTO TERMS OF USE WHICH MUST BE AGREED TO WHEN
THE ANDROID AUTO APPLICATION IS DOWNLOADED TO YOUR ANDROID PHONE. IN SUMMARY, THE ANDROID AUTO TERMS OF USE
DISCLAIM GOOGLE AND ITS SERVICE PROVIDERS’ LIABILITY IF THE SERVICES FAIL TO PERFORM CORRECTLY OR ARE DISCONTINUED,
STRICTLY LIMIT GOOGLE AND ITS SERVICE PROVIDERS’ OTHER LIABILITIES, DESCRIBE THE KINDS OF USER INFORMATION (INCLUDING,
FOR EXAMPLE, VEHICLE LOCATION, VEHICLE SPEED, AND VEHICLE STATUS) BEING GATHERED AND STORED BY GOOGLE AND ITS
SERVICE PROVIDERS, AND DISCLOSE CERTAIN POSSIBLE RISKS ASSOCIATED WITH THE USE OF ANDROID AUTO, INCLUDING THE
POTENTIAL FOR DRIVER DISTRACTION. SEE GOOGLE’S PRIVACY POLICY FOR DETAILS REGARDING GOOGLE’S USE AND HANDLING OF
DATA UPLOADED BY ANDROID AUTO.

OWNER’S MANUAL LICENSE/LIABILITY STATEMENTS

368

uu

General Information on the Audio System

u

Legal Information on Apple CarPlay/Android Auto

Features

YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT USE OF APPLE CARPLAY OR ANDROID AUTO (“THE APPLICATIONS”) IS AT YOUR
SOLE RISK AND THAT THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE, ACCURACY AND EFFORT IS WITH YOU TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, AND THAT THE APPLICATIONS AND INFORMATION ON THE APPLICATIONS IS
PROVIDED “AS IS” AND “AS AVAILABLE,” WITH ALL FAULTS AND WITHOUT WARRANTY OF ANY KIND, AND HONDA HEREBY
DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO THE APPLICATIONS AND INFORMATION ON THE APPLICATIONS,
EITHER EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES AND/OR CONDITIONS OF
MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, ACCURACY, QUIET ENJOYMENT, AND NON-
INFRINGEMENT OF THIRD PARTY RIGHTS. NO ORAL OR WRITTEN INFORMATION OR ADVICE GIVEN BY HONDA OR AN AUTHORISED
REPRESENTATIVE SHALL CREATE A WARRANTY. AS EXAMPLES, AND WITHOUT LIMITATION, HONDA DISCLAIMS ANY WARRANTY
REGARDING THE ACCURACY OF DATA PROVIDED BY THE APPLICATIONS, SUCH AS THE ACCURACY OF DIRECTIONS, ESTIMATED
TRAVEL TIME, SPEED LIMITS, ROAD CONDITIONS, NEWS, WEATHER, TRAFFIC, OR OTHER CONTENT PROVIDED BY APPLE, GOOGLE, THEIR
AFFILIATES, OR THIRD PARTY PROVIDERS; HONDA DOES NOT GUARANTEE AGAINST LOSS OF APPLICATION DATA, WHICH MAY BE LOST
AT ANY TIME; HONDA DOES NOT GUARANTEE THAT THE APPLICATIONS OR ANY SERVICES PROVIDED THROUGH THEM WILL BE
PROVIDED AT ALL TIMES OR THAT ANY OR ALL SERVICES WILL BE AVAILABLE AT ANY PARTICULAR TIME OR LOCATION. FOR EXAMPLE,
SERVICES MAY BE SUSPENDED OR INTERRUPTED WITHOUT NOTICE FOR REPAIR, MAINTENANCE, SECURITY FIXES, UPDATES, ETC.,
SERVICES MAY BE UNAVAILABLE IN YOUR AREA OR LOCATION, ETC. IN ADDITION, YOU UNDERSTAND THAT CHANGES IN THIRD PARTY
TECHNOLOGY OR GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE.

TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL HONDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY
INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT LIMITATION, DAMAGES FOR
LOSS OF PROFITS, CORRUPTION OR LOSS OF DATA, FAILURE TO TRANSMIT OR RECEIVE ANY DATA, BUSINESS INTERRUPTION OR ANY
OTHER COMMERCIAL DAMAGES OR LOSSES, ARISING OUT OF OR RELATED TO THE APPLICATIONS OR YOUR USE OF OR INABILITY TO
USE THE APPLICATIONS OR INFORMATION ON THE APPLICATIONS, HOWEVER CAUSED, REGARDLESS OF THE THEORY OF LIABILITY
(CONTRACT, TORT OR OTHERWISE) AND EVEN IF HONDA WERE ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME REGIONS AND
JURISDICTIONS MAY DISALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR DAMAGES, SO THESE LIMITATIONS AND EXCLUSIONS
MAY NOT APPLY TO YOU. THE FOREGOING LIMITATIONS WILL APPLY EVEN IF THE ABOVE STATED REMEDY FAILS OF ITS ESSENTIAL
PURPOSE.

DISCLAIMER OF WARRANTIES; LIMITATION ON LIABILITY

369

Continued

Features

Emergency Call (eCall)

Automatic emergency call

If your vehicle is involved in a collision, the SRS
unit in the vehicle will attempt to connect to a
Public Safety Answering Point (PSAP)
operator. Once a connection is established,
various information about the vehicle will be
sent to a PSAP operator with whom you will
be able to speak. This information includes:

Vehicle identification number (VIN)

Type of vehicle (passenger vehicle or light-weight commercial vehicle)

Type of energy stored for vehicle propulsion (gasoline/diesel/CNG/LPG/electricity/
hydrogen)

Last three locations of the vehicle

Direction of travel

Triggering mode (automatic or manual)

Timestamp

When an emergency call is initiated, the vehicle speakers are disabled so that you
can hear the operator.

When the power mode is set to ON, the eCall indicator lights up in green for 1
second, then in red for 1 second.

1

Emergency Call (eCall)

Your vehicle is equipped with the 112-based eCall
service system.

The 112-based eCall service is a public service of
general interest and is accessible free of charge.

The 112-based eCall in-vehicle system is activated
when the power mode is set to ON. In the event of a
collision, the system will determine the degree of the
impact based on information collected from the on-
board sensors and, depending on the severity of the
collision, will initiate the emergency call.

The 112-based eCall in-vehicle system can also be
triggered manually, if needed.

2

Manual emergency call

 P. 371

Any processing of personal data through the 112-
based eCall in-vehicle system shall comply with the
personal data protection rules provided for in
Directives 95/46/EC (replaced by 2016/679/EC) and
2002/58/EC, and in particular, shall be based on the
necessity to protect the vital interests of the
individuals in accordance with Article 7(d) of Directive
95/46/EC (replaced by 2016/679/EC).

Processing of such data is strictly limited to the
purpose of for which the single European emergency
number 112 is designated.

a

eCall Indicator















Content      ..     21      22      23      24     ..
