Honda e (2021 year). Manual in english - page 22





338

uu

Display Audio

u

Customized Features

Features

*1:Default Setting

Customizable Features

Description

Selectable Settings

Blind spot information

*

Selects On/Off the blind spot information system audible alert.

2

Blind spot information System

*

 P. 423

Audible and visual alert

*1

/

Visual Alert Only

Traffic Sign Recognition
System Display

Displays the traffic sign recognition system on the instrument panel.

2

Traffic Sign Recognition System

 P. 488

Display

*1

/

None

Traffic Sign Recognition
System Speed Limit
Warning

Enables over speed limit warning when speed limit is exceeded.

2

Traffic Sign Recognition System

 P. 488

ON

*1

/

OFF

Side Camera Mirror View

Selects the side camera mirror view.

2

Side Camera Mirror System

 P. 221

Wide

/

Normal

*1

Reference Line Display

Turns on/off the reference line display during indicator activation.

2

Reference Lines

 P. 224

ON with Indicator

*1

/

ON

with Indicator + 2 Seconds

/

OFF

Reference Line Display
(Reverse)

Turns on/off the reference line display while in

(

R

.

2

Reference Lines

 P. 224

ON

*1

/

OFF

Apply Parking Brake after
Honda Parking Pilot

*

Automatically applies the parking brake at the completion of a
Honda Parking Pilot manoeuvre.

2

Honda Parking Pilot

*

 P. 537

ON

*1

/

OFF

Honda Parking Pilot Space
Detect Beep

*

Turns on/off the audible notification when Honda Parking Pilot
detects an available parking space.

2

Honda Parking Pilot

*

 P. 537

ON

*1

/

OFF

* Not available on all models

339

uu

Display Audio

u

Customized Features

Continued

Features

Meter setup

*1:Default Setting

Customizable Features

Description

Selectable Settings

Warning message

Selects whether to display the warning message.

2

Driver Information Interface Warning and Information
Messages

 P. 130

ON

/

OFF

*1

Adjust outside temp. display

Selects to adjust outside temperature reading by a few degrees.

2

Outside Temperature

 P. 155

-3°C

 ~

±0°C

*1

 ~

+3°C

Trip A reset timing

Selects the timing to reset Trip A.

2

Range / Energy Consumption / Trip Meter

 P. 158

2

Speed & Time

 P. 160

When charged

/

Manual reset

*1

/

POWER OFF

Trip B reset timing

Selects the timing to reset Trip B.

2

Range / Energy Consumption / Trip Meter

 P. 158

2

Speed & Time

 P. 160

When charged

/

Manual reset

*1

/

POWER OFF

Alarm volume control

Changes volume level of all system warnings, door opening
warning and indicator.

Max

/

Mid

*1

/

Min

Indicator tone

Selects the indicator tone.

Tone1

*1

/

Tone2

/

Tone3

Reverse position alert tone

Turns on/off the reverse alert sound.

ON

*1

/

OFF

Turn by turn display

Turns on/off the pop-up warning in the turn-by-turn navigation
in the driver information interface.

2

Turn-by-turn directions

 P. 162

ON

*1

/

OFF

340

uu

Display Audio

u

Customized Features

Features

*1:Default Setting

Keyless Access Setup

*1:Default Setting

Customizable Features

Description

Selectable Settings

Speed/distance units

Selects the trip computer units.

2

Unit Change

 P. 168

km/h · km

*1

/

mph · miles

km/h · km

/

mph · miles

*1

Rear seat reminder

Turns on/off notifications when there may be an object in the
rear seats.

2

Driver Information Interface Warning and Information
Messages

 P. 130

ON

*1

/

OFF

Customizable Features

Description

Selectable Settings

Smart Entry Light Flash

Turns on/off the flash of the exterior lights when doors are
unlocked/locked by holding or touching the sensor switch on outer
door handles.

2

Using the Keyless Access System

 P. 175

ON

*1

/

OFF

Auto Power ON/OFF

Turns on/off automatically in conjunction with bringing in and
taking out the key.

2

Auto Power ON/OFF

 P. 198

ON

*1

/

OFF

Left-hand drive type

Right-hand drive type

341

uu

Display Audio

u

Customized Features

Continued

Features

Lighting Setup

*1:Default Setting

Customizable Features

Description

Selectable Settings

Interior light dimmer
duration

Selects the length of time the interior lights stay on after doors are
closed.

2

Interior Lights

 P. 235

60sec

/

30sec

*1

/

15sec

Headlight auto OFF timer

Selects the length of time the exterior lights stay on after you close
the driver's door.

2

Automatic Lighting Off Feature

 P. 203

60sec

/

30sec

/

15sec

*1

/

0sec

Headlight integration with
wipers

Selects On/Off headlight function and wiper operation when the
headlight is in

AUTO

 setting.

2

Headlight Integration with Wipers

 P. 203

ON

*1

/

OFF

342

uu

Display Audio

u

Customized Features

Features

Door/Window Setup

*1:Default Setting

Maintenance Info.

*

Customizable Features

Description

Selectable Settings

The outer handle pop-out
setting

Turns on/off to activate the custom settings on key fob for the outer
handle auto pop-out function.

2

Using the Keyless Access System

 P. 175

ON

*1

/

OFF

Keyless lock notification

Turns on/off flash of exterior lights when doors are locked/unlocked
by remote.

2

Using the Keyless Access System

 P. 175

ON

*1

/

OFF

Security relock timer

Selects relock timing after unlocking vehicle with the key fob
without opening any doors.

2

Using the Remote Transmitter

 P. 178

90sec

/

60sec

/

30sec

*1

Customizable Features

Description

Selectable Settings

Maintenance Info.

Resets the maintenance information.

2

Service Reminder System

*

 P. 582

Selects Reset Items

* Not available on all models

343

uu

Display Audio

u

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1.

Select

General Settings

.

2.

Select

System

.

3.

Select

Factory Data Reset

.

u

A confirmation message appears on the screen.

4.

Select

Continue

 to reset the settings.

5.

Select

Continue

 again to reset the settings.

u

The system will reboot.

1.

Select

Vehicle Settings

.

2.

Select

Default

.

3.

Select

Yes

.

Defaulting General Settings

Defaulting Vehicle Settings

1

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform

Factory Data Reset

, it will reset the

preinstalled apps to their factory default.

344

uu

Display Audio

u

Hands-Free Telephone System

Features

Hands-Free Telephone System

Hands-Free Telephone (HFT) system allows you to place and receive phone calls
using your vehicle’s audio system, without handling your mobile phone.

HFT Buttons

1

Hands-Free Telephone System

Place your phone where you can get good reception.

To use HFT, you need a

Bluetooth

-compatible mobile

phone. For a list of compatible phones, pairing
procedures, and special feature capabilities, ask a
dealer or your local Honda.

To use the system, the

Bluetooth

 setting must be

ON

.

2

Phone Setup

 P. 351

Voice control tips

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphones.

Press the

 button when you want to call a

number using a phonebook name or a number.
Speak clearly and naturally after a beep.

If the microphone picks up voices other than yours,
the command may be misinterpreted.

To change the volume level, select the audio
system’s

VOL

 (Volume) or use the remote audio

controls on the steering wheel.

If there is no Favourite contacts entry in the system,
the pop-up notification appears on the screen.

2

Favourite Contacts

 P. 356

a

VOL



(

+

/

VOL



(

-

 (Volume) Buttons

b

 (Talk) Button

c

 (Home) Button

d

Left Selector Wheel

e

 (Back) Button

Continued

345

uu

Display Audio

u

Hands-Free Telephone System

Features

 (Talk) button:

Press to access Voice Portal.

 (Home) button:

Press to go back to the home screen of the driver information

interface.

Left Selector Wheel:

Press the

 (home) button, then roll up or down to select

 (phone) on the driver information interface, and then press the left selector

wheel.
While receiving a call, the incoming call screen is displayed on the driver information
interface. You can pick up the call using the left selector wheel.

2

Receiving a Call

 P. 360

 (Back) button:

Press to go back to the previous screen or cancel a command.

1

Hands-Free Telephone System

Bluetooth

®

 Wireless Technology

The

Bluetooth

®

 word mark and logos are registered

trademarks owned by

Bluetooth

 SIG, Inc., and any

use of such marks by Honda Motor Co., Ltd., is under
licence. Other trademarks and trade names are those
of their respective owners.

HFT Limitations
An incoming call on HFT will interrupt the audio
system when it is playing. It will resume when the call
is ended.

uu

Display Audio

u

Hands-Free Telephone System

346

Features

The audio/information screen notifies you when there is an incoming call.

HFT Status Display

1

HFT Status Display

The information that appears on the audio/
information screen varies between phone models.

a

Bluetooth

®

 Indicator

Appears when your phone is connected to HFT.

b

Signal Strength

c

Battery Level Status

d

HFT Mode

e

Caller’s Name (If registered)/Caller’s Number (If not registered)

347

uu

Display Audio

u

Hands-Free Telephone System

Continued

Features

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored phonebook names or numbers can be called using voice
commands while the vehicle is in motion.

2

Favourite Contacts

 P. 356

Limitations for Manual Operation

uu

Display Audio

u

Hands-Free Telephone System

348

Features

The power mode must be in ACCESSORY or ON to use the system. Select

Phone

 to

display the phone screen.

HFT Menus

1

HFT Menus

Some functions are limited while driving.

a

Recent calls

b

Favourite contacts

c

Settings

d

Contacts

e

Keypad

349

uu

Display Audio

u

Hands-Free Telephone System

Continued

Features

Recent calls:

Displays the last outgoing, incoming, and missed calls.

2

To make a call using the recent calls

 P. 358

Favourite contacts:

Dials the selected number in the Favourite contacts entry.

2

To make a call using a Favourite contacts entry

 P. 358

Settings:

Changes the phone settings.

2

Phone Settings Screen

 P. 350

Contacts:

Displays the phonebook of the paired phone.

2

To make a call using the imported phonebook

 P. 359

Keypad:

Enters a phone number to dial.

2

To make a call using a phone number

 P. 359

350

uu

Display Audio

u

Hands-Free Telephone System

Features

To display the phone settings screen, select

Settings

 on the phone screen.

Change Devices:

Pairs a new phone to the system and connect, disconnect, or

delete a paired device.

2

Phone Setup

 P. 351

Auto Sync Phone:

Sets phonebook and recent calls data to be automatically

imported when a phone is paired to HFT.

2

Automatic Import of Mobile Phonebook and Recent calls

 P. 354

Auto Phone Call Transfer:

Sets calls to automatically transfer from your phone to

HFT when you enter the vehicle.

2

Automatic Transferring

 P. 355

Ringtone:

Selects the ring tone.

2

Ring Tone

 P. 355

Phone Settings Screen

351

uu

Display Audio

u

Hands-Free Telephone System

Continued

Features

Bluetooth

®

 setup

You can turn

Bluetooth

®

 function on and off.

1.

Select

General Settings

.

2.

Select

Connections

.

3.

Select

Bluetooth

.

4.

Select

Options

.

5.

Select

Bluetooth

, then select

ON

.

Phone Setup

uu

Display Audio

u

Hands-Free Telephone System

352

Features

To pair a mobile phone (when there is
no phone paired to the system)

1.

Select

Phone

.

2.

Select

Connect New Device

.

3.

Make sure your phone is in search or
discoverable mode.

4.

Select

Honda HFT

 from your phone.

u

If you want to pair a phone from this
audio system, select

Search for

Devices

, and then select your phone

when it appears on the list.

5.

The system gives you a pairing code on the
audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by a phone.

6.

Select desired functions and then select

Connect

.

7.

A notification appears on the screen if
pairing is successful.

8.

Select

OK

.

1

Phone Setup

Your

Bluetooth

-compatible phone must be paired to

the system before you can make and receive hands-
free calls.

Phone Pairing Tips:

You cannot pair your phone while the vehicle is
moving.

Up to six phones can be paired.

Your phone’s battery may drain faster when it is
paired to the system.

Once you have paired a phone, you can see it
displayed on the screen with the following icons.

: The phone is compatible with

Bluetooth

®

 Audio.

: The phone can be used with HFT.

: The phone is compatible with Apple CarPlay.

If there is an active connection to Apple CarPlay
pairing of additional

Bluetooth

®

 compatible devices is

unavailable.

Continued

353

uu

Display Audio

u

Hands-Free Telephone System

Features

To change the currently paired phone

1.

Select

Phone

.

2.

Select

Settings

.

3.

Select

Change Devices

.

4.

Select a phone to connect.

u

HFT disconnects the connected phone
and starts searching for another paired
phone.

u

You can set the connected phone
priority. Select the box checked on the
phone you want to prioritize.

5.

Select

 (audio),

 (phone), or

 (Apple

CarPlay).

u

 and

 can be selected

simultaneously, however, when

 is

selected,

 and

 cannot be selected.

6.

Select

Apply

.

To delete a paired phone

1.

Select

Phone

.

2.

Select

Settings

.

3.

Select

Change Devices

.

4.

Select a phone you want to delete.

5.

Select

Delete

.

6.

A confirmation message appears on the
screen. Select

Delete

.

1

To change the currently paired phone

If no other phones are found or paired when trying to
switch to another phone, HFT will inform you that the
original phone is connected again.

To pair other phones, select

+ Connect New Device



from the

Bluetooth

 screen.















Content      ..     20      21      22      23     ..
