Honda Clarity Plug-in Hybrid (2018 year). Instruction

512

Climate Control System Maintenance

Dust and Pollen Filter

Main

tenan

Dust and Pollen Filter

The climate control system is equipped with a dust and pollen filter that collects
pollen, dust, and other debris in the air. The Maintenance Minder

messages will let

you know when to replace the filter.

We recommend that you replace the dust and pollen filter sooner when using your
vehicle in areas with high concentrations of dust.

Dust and Pollen Filter

If the airflow from the climate control system
deteriorates noticeably, and the windows fog up
easily, the filter may need to be replaced. Please
contact an authorized Honda Clarity Plug-In Hybrid
dealer for replacement.

513

Continued

Main

tenan

Cleaning

Interior Care

Use a damp cloth with a mixture of mild detergent and warm water to remove dirt.
Use a clean cloth to remove detergent residue.

Use a soft brush with a mixture of mild soap and warm water to clean the seat belts.
Let the belts air dry. Wipe the openings of the seat belt anchors using a clean cloth.

■

Cleaning Seat Belts

Interior Care

Do not spill liquids inside the vehicle. Electrical
devices and systems may malfunction if liquids are
splashed on them.

Do not use silicone based sprays on electrical devices
such as audio devices and switches. Doing so may
cause the items to malfunction or cause a fire inside
the vehicle.
If a silicone based spray is inadvertently used on
electrical devices, consult an authorized Honda
Clarity Plug-In Hybrid dealer.

Depending on their composition, chemicals and
liquid aromatics may cause discoloration, wrinkles,
and cracking to resin-based parts and textiles.
Do not use alkali solvents or organic solvents such as
benzene or gasoline.

After using chemicals, make sure to gently wipe them
away using a dry cloth.
Do not place used cloths on top of resin based parts
or textiles for long periods of time without washing.

Opening

Cleaning

Interior Care

514

Main

tenan

Wipe using a glass cleaner.

The front and rear floor mats hook over floor
anchors, which keep them from sliding
forward. To remove a mat for cleaning, turn
the anchor knobs to the unlock position.
When reinstalling the mat after cleaning, turn
the knobs to the lock position.

Do not put additional floor mats on top of
the anchored mats.

To properly clean leather:
1. Use a vacuum or soft dry cloth first to remove any dirt or dust.
2. Clean the leather with a soft cloth dampened with a solution comprised of 90%

water and 10% neutral soap.

3. Wipe away any soap residue with a clean damp cloth.
4. Wipe away residual water and allow leather to air dry in the shade.

■

Cleaning the Window

■

Floor Mats

Cleaning the Window

Wires are mounted to the inside of the rear window.
Wipe along the same direction as the wires with a
soft cloth so as not to damage them.

Be careful not to spill fluids, such as water or glass
cleaner, on or around the cover of the front sensor
camera.

2 Front Sensor Camera P. 394

Floor Mats

If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position the rear seat floor mats properly. If they are
not properly positioned, the floor mats can interfere
with the front seat functions.

Unlock

Lock

■

Maintaining Genuine Leather

Maintaining Genuine Leather

It is important to clean or wipe away dirt or dust as
soon as possible. Spills can soak into leather resulting
in stains. Dirt or dust can cause abrasions in the
leather. In addition, please note that some dark
colored clothing can rub onto the leather seats
resulting in discoloration or stains.

* Not available on all models

515

Cleaning

Exterior Care

Continued

Main

tenan

Exterior Care

Dust off the vehicle body after you drive. Regularly inspect your vehicle for scratches
on painted surfaces. A scratch on a painted surface can result in body rust. If you
find a scratch, promptly repair it.

Wash the vehicle regularly. Wash more frequently when driving in the following
conditions:
• If driving on roads with road salt.
• If driving in coastal areas.
• If tar, soot, bird droppings, insects, or tree sap are stuck to painted surfaces.

• Make sure to follow the instructions indicated on the automated car wash.
• Fold in the door mirrors.

■

Washing the Vehicle

■

Using an Automated Car Wash

Washing the Vehicle

Do not spray water into the air intake vents. It can
cause a malfunction.

If you need to lift the wiper arms away from the
windshield, first set the wiper arms to the
maintenance position.

2 Changing the Wiper Blade Rubber P. 496

Air Intake Vents

Using an Automated Car Wash

When using an automated car wash that pulls the
vehicle through with a conveyor, make sure vehicle is
in car wash mode.

2 If you want to keep the transmission in

(

position [car wash mode] P. 386

Cleaning

Exterior Care

516

Main

tenan

• Keep sufficient distance between the cleaning nozzle and the vehicle body.
• Take particular care around the windows. Standing too close may cause water to

enter the vehicle interior.

• Do not spray water into the engine compartment.

A good coat of automotive body wax helps protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.

If you get gasoline, oil, coolant, or battery fluid on resin coated parts, they may be
stained or the coating may peel. Promptly wipe it away using a soft cloth and clean
water.

Wipe using a glass cleaner.

■

Using High Pressure Cleaners

■

Applying Wax

■

Maintaining the Bumpers and Other Resin Coated Parts

■

Cleaning the Window

Applying Wax

NOTICE

Chemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe
away spills immediately.

Maintaining the Bumpers and Other Resin Coated Parts

Ask an authorized Honda Clarity Plug-In Hybrid
dealer about the correct coating material when you
want to repair the painted surface of the parts made
of resin.

Cleaning the Window

When you raise a wiper arm, you may inadvertently
alter the position of the arm by applying undue force.
If you notice that an arm is not in its proper return
position, active the wipers once and they will
automatically reset.

2 Wipers and Washers P. 166

517

Cleaning

Exterior Care

Continued

Main

tenan

Aluminum is susceptible to deterioration caused by salt and other road
contaminants. When necessary, as early as possible use a sponge and mild detergent
to wipe away these contaminants. Do not use a stiff brush or harsh chemicals
(including some commercial wheel cleaners). These can damage the protective finish
on aluminum alloy wheels, resulting in corrosion. Depending on the type of finish,
the wheels also may lose their luster or appear burnished. To avoid water stains,
wipe the wheels dry with a cloth while they are still wet.

The inside lenses of exterior lights (headlights, brake lights, etc.) may fog temporarily
if you have driven in the rain, or after the vehicle has been run through a car wash.
Dew condensation also may build up inside the lenses when there is a significant
enough difference between the ambient and inside lens temperatures (similar to
vehicle windows fogging up in rainy conditions). These conditions are natural
processes, not structural design problems in the exterior lights.
Lens design characteristics may result in moisture developing on the light lens frame
surfaces. This also is not a malfunction.
However, if you see large amounts of water accumulation, or large water drops
building up inside the lenses, have your vehicle inspected by an authorized Honda
Clarity Plug-In Hybrid dealer.

■

Maintaining Aluminum Wheels

■

Fogged Exterior Light Lenses

Cleaning

Exterior Care

518

Main

tenan

Refer to the temperature notice label affixed to the driver’s doorjamb before
painting the vehicle.

■

Painting the Vehicle

Painting the Vehicle

U.S. models

Canadian models

519

Main

tenan

Accessories and Modifications

Accessories

When installing accessories, check the following:
• Do not install accessories on the windshield. They can obstruct your view and

delay your reaction to driving conditions.

• Do not install any accessories over areas marked SRS Airbag, on the sides or backs

of the front seats, on front or side pillars, or near the side windows. Accessories
installed in these areas may interfere with proper operation of the vehicle’s
airbags or may be propelled into you or another occupant if the airbags deploy.

• Be sure electronic accessories do not overload electrical circuits or interfere with

proper operation of your vehicle.

2 Fuses P. 553

• Before installing any electronic accessory, have the installer contact an authorized

Honda Clarity Plug-In Hybrid dealer for assistance. If possible, have an authorized
Honda Clarity Plug-In Hybrid dealer inspect the final installation.

Accessories and Modifications

Honda Genuine accessories are recommended to
ensure proper operation on your vehicle.

WARNING

Improper accessories or modifications can
affect your vehicle’s handling, stability, and
performance, and cause a crash in which
you can be seriously hurt or killed.

Follow all instructions in this owner’s
manual regarding accessories and
modifications.

WARNING

Use of improperly designed, engineered or
manufactured high-voltage battery
assemblies could cause a fire in your
vehicle.

A vehicle fire could result in a crash or
injury.

Only use a genuine Honda high-voltage
battery assembly, or its equivalent, in your
vehicle.

520

Accessories and Modifications

Modifications

Main

tenan

Modifications

Do not modify your vehicle in a manner that may affect its handling, stability, or
reliability, or install non-genuine Honda parts or accessories that may have a similar
effect.

Even minor modifications to vehicle systems can affect overall vehicle performance.
Always make sure all equipment is properly installed and maintained, and do not
make any modification to your vehicle or its systems that might cause your vehicle
to no longer meet federal, state, province, territory, and local regulations.

The on-board diagnostic port (OBD-II/SAE J1962 connector) installed on this vehicle
is intended to be used with automobile system diagnostic devices or with other
devices that Honda has approved. Use of any other type of device may adversely
affect the vehicle’s electronic systems or allow them to be compromised, possibly
resulting in a system malfunction, drained battery, or other unexpected problems.

Do not modify or attempt to repair your vehicle’s high-voltage hybrid power system
or otherwise modify vehicle electrical systems. Disassembling or modifying electrical
equipment can result in a crash or a fire.

If you ever need to replace your vehicle’s high-voltage battery assembly outside of
warranty coverage, we highly recommend that you only use a genuine Honda high-
voltage battery assembly. Genuine Honda high-voltage battery assemblies are
designed to work with your vehicle’s hybrid power system and have been designed,
engineered and manufactured to avoid overcharging situations. Non-genuine high-
voltage battery assemblies may not have been similarly designed, engineered and
manufactured, and installation of such assemblies could result in overcharging, fires,
loss of power, or other conditions that may increase the likelihood of a crash or
injury.

522

Han

lin
g the U

expected

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

If the tire has a large cut or is otherwise severely damaged, you will need to have the
vehicle towed. If the tire only has a small puncture, from a nail for instance, you can
use the temporary tire repair kit so that you can drive to the nearest service station
for a more permanent repair.

If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then stop in a safe place.

1. Park the vehicle on a firm, level, and non-slippery surface and apply the parking

brake.

2. Change the gear position to

(

3. Turn on the hazard warning lights and set the power mode to VEHICLE OFF

(LOCK).

Temporarily Repairing a Flat Tire

The kit should not be used in the following situations.
Instead, contact an authorized Honda Clarity Plug-In
Hybrid dealer or roadside assistance to have the
vehicle towed.

•

The tire sealant has expired.

•

More than one tire is punctured.

•

The puncture or cut is larger than 3/16 inch (4 mm).

•

The tire side wall is damaged or the puncture is
outside the contact area.

•

Damage has been caused by driving with the tire
extremely under inflated.

•

The tire bead is no longer seated.

•

The rim is damaged.

Do not remove a nail or screw that punctured the
tire. If you remove it from the tire, you may not be
able to repair the puncture using the kit.

When the puncture is:

Kit Use

Smaller than 3/16 inch

(4 mm)

Yes

Larger than 3/16 inch

(4 mm)

Contact
Area

Continued

523

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

Han

lin
g the U

expected

■

Getting Ready to Temporarily Repair the Flat Tire

Getting Ready to Temporarily Repair the Flat Tire

Repair notification label and speed restriction label
are applied to the side of temporary tire repair kit.

When making a temporary repair, carefully read the
instruction manual provided with the kit.

Pressure Gauge

AIR

Power Plug

Pressure Relief Button

Repair Notification Label

Instruction Manual

Sealant/Air Hose

REPAIR

Inflator Switch

Speed Restriction Label

Selector Knob

U.S.

Canada

U.S.

Canada

524

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

Han

lin
g the U

expected

1. Remove the charging cable by releasing the

belt.

2. Pull the strap on the right side of the trunk

and open the lid.

3. Open the fastener and take the kit out of

the trunk.

4. Place the kit face up, on flat ground near

the flat tire, and away from traffic. Do not
place the kit on its side.

Charging Cable

Fastener

Strap

Lid

Continued

525

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

Han

lin
g the U

expected

1. Remove the valve cap from the tire valve

stem.

2. Remove the sealant/air hose from the

packaging.

3. Attach the sealant/air hose onto the tire

valve stem. Screw it until it is tight.

■

Injecting Sealant and Air

Injecting Sealant and Air

In cold temperatures, the sealant may not flow easily.
In this situation, warm it up for five minutes before
using.

The sealant can permanently stain clothing and other
materials. Be careful during handling and wipe away
any spills immediately.

WARNING

Tire sealant contains substances that are
harmful and can be fatal if swallowed.

If accidentally swallowed, do not induce
vomiting. Drink plenty of water and get
medical attention immediately.

For skin or eye contact, flush with cool
water and get medical attention if
necessary.

Valve Stem

Valve Cap

Sealant/Air Hose

Valve Stem

Sealant/Air Hose

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

526

Han

lin
g the U

expected

4. Plug in the compressor to the accessory

power socket.

Be careful not to pinch the cord in a
door or window.

Do not plug any other electronic
devices into other accessory power
sockets.

2 Accessory Power Sockets P. 189

5. Turn the power system on.

Keep the power system on while
injecting sealant and air.

6. Turn the selector knob to REPAIR

SEALANT/AIR

, PRODUIT ANTIFUITE/

AIR

*1: U.S. models
*2: Canadian models

Injecting Sealant and Air

NOTICE

Do not operate the temporary tire repair kit
compressor for more than 15 minutes. The
compressor can overheat and become permanently
damaged.

There are two accessory power sockets:

•

In the back of the console compartment

•

In the console panel

2 Accessory Power Sockets P. 189

WARNING

Running the engine with the vehicle in an
enclosed or even partly enclosed area can
cause a rapid build-up of toxic carbon
monoxide.

Breathing this colorless, odorless gas can
cause unconsciousness and even death.
Only run the engine to power the air
compressor with the vehicle outdoors.

U.S.

Canada

Continued

527

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

Han

lin
g the U

expected

7. Press the inflator switch to turn on the

compressor.

The compressor starts injecting sealant
and air into the tire.

When the sealant injection is complete,
continue to add air.

8. After the air pressure reaches 36 psi (250

kPa), turn off the kit.

To check the pressure, occasionally turn
off the compressor, and read the
gauge.

9. Unplug the power plug from the accessory

power socket.

10. Unscrew the sealant/air hose from the tire

valve stem. Reinstall the valve cap.

11. Press the pressure relief button until the

gauge returns to 0 psi (0 kPa).

OFF

Pressure Gauge

Injecting Sealant and Air

Until the sealant injection is complete, the pressure
shown on the pressure gauge will appear higher than
actual. After the sealant injection is complete the
pressure will drop and then begin to rise again as the
tire is inflated with air. This is normal. To accurately
measure the air pressure using the gauge, turn the air
compressor off only after the sealant injection is
complete.

If the required air pressure is not reached within 10
minutes, the tire may be too severely damaged for
the kit to provide the necessary seal, and your vehicle
will need to be towed.

See an authorized Honda Clarity Plug-In Hybrid
dealer for a replacement sealant bottle and proper
disposal of an empty bottle.

Sealant/Air
Hose

Valve Stem

528

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

Han

lin
g the U

expected

12. Apply the repair notification label to the

flat surface of the wheel.

The wheel surface must be clean to
ensure the label adheres properly.

1. Apply the speed restriction label to the

location as shown.

2. Drive the vehicle for about 10 minutes.

Do not exceed 50 mph (80 km/h).

3. Stop the vehicle in a safe place.

Repair Notification Label

U.S.

Canada

■

Distributing the Sealant in the Tire

Speed Restriction Label

U.S.

Canada

Honda Clarity Plug-in Hybrid (2018 year). Instruction - part 33
