Honda Odyssey 2004. Manual - part 586





01

02

S0X4AZBK791000R612XFAAT00

’03-04 Models

DTC 61-2x (61-20 to 61-29, 61-2A to 61-2F):

YES

NO

YES

NO

23-286

SRS

DTC Troubleshooting (cont’d)

A

DRIVER’S SEAT BELT BUCKLE SWITCH
3P CONNECTOR

BLU

BLK

BLK

GRY

Short in Driver’s Seat Belt Buckle Switch

1. Erase the DTC memory (see page 23-39).

2. Turn the ignition switch ON (II), then buckle and

unbuckle the driver’s seat belt several times.

3. Read the DTC (see page 23-38).

Go to step 4.

Intermittent failure, system is OK at this time.

Go to Troubleshooting Intermittent Failures (see
page 23-39).

4. Turn the ignition switch OFF.

5. Disconnect the driver’s seat belt buckle switch 3P

connector (A).

6. Buckle the driver’s seat belt.

• Check resistance between the No. 1 and No. 3

terminals of the driver’s seat belt buckle switch
3P connector. There should be 0

1

.

• Check resistance between the No. 1 and No. 2

terminals of the same connector. There should
be an open circuit, or at least 1 M

.

Go to step 7.

Replace the driver’s seat belt buckle assembly,

then clear the DTC.

Terminal side of male terminals

Terminal side of male terminals

Is DT C 61-2x indicated?

Ar e the r esistance r eadings as specif ied?

03/07/29 10:39:48 61S0X050_230_0286

*01

04

05

YES

NO

23-287

BLK

BLU

BLK

GRY

DRIVER’S SEAT BELT BUCKLE SWITCH
3P CONNECTOR

A

B

7. Unbuckle the driver’s seat belt.

• Check resistance between the No. 1 and No. 2

terminals of the driver’s seat belt buckle switch
3P connector. There should be 0

1

.

• Check resistance between the No. 1 and No. 3

terminals of the same connector. There should
be an open circuit, or at least 1 M

.

Go to step 8.

Replace the driver’s seat belt buckle assembly,

then clear the DTC.

8. Disconnect the negative cable from the battery.

9. Disconnect both seat belt tensioner 2P connectors

from the side wire harness (A).

10. Disconnect SRS unit connector B (28P) from the

SRS unit, dashboard wire harness connector C
(16P) from the gauge assembly, and the driver’s
multiplex control unit from the driver’s under-dash
fuse/relay box.

(cont’d)

Terminal side of male terminals

Terminal side of male terminals

Is the r esistance as specif ied?

03/07/29 10:39:49 61S0X050_230_0287

06

07

YES

NO

YES

NO

23-288

SRS

DTC Troubleshooting (cont’d)

RED/BLU

DRIVER’S SEAT WIRE HARNESS 3P CONNECTOR
(WITH POWER SEAT)
LEFT SIDE WIRE HARNESS 3P CONNECTOR
(WITHOUT POWER SEAT)

BLU

DRIVER’S SEAT WIRE HARNESS 3P CONNECTOR
(WITH POWER SEAT)
LEFT SIDE WIRE HARNESS 3P CONNECTOR
(WITHOUT POWER SEAT)

11. Check resistance between the No. 2 terminal of the

driver’s seat wire harness (with power seat) or left
side wire harness (without power seat) 3P
connector and body ground. There should be an
open circuit, or at least 1 M

.

Go to step 12.

Short to ground in the driver’s seat wire

harness (with power seat), left side wire harness,
dashboard wire harness A, SRS main harness, SRS
floor harness or multiplex control unit, or gauge
assembly; replace the faulty harness or part.

12. Check resistance between the No. 3 terminal of the

driver’s seat wire harness (with power seat) or left
side wire harness (without power seat) 3P
connector and body ground. There should be an
open circuit, or at least 1 M

.

Replace the SRS unit (see page 23-384).

Short to ground in the driver’s seat wire

harness (with power seat), dashboard wire harness
A, SRS main harness or SRS floor harness; replace
the faulty harness.

Wire side of female terminals

Wire side of female terminals

Is the r esistance as specif ied?

Is the r esistance as specif ied?

03/07/29 10:39:49 61S0X050_230_0288

01

02

S0X4AZBK791000R621XFAAT00

’03-04 Models

DTC 62-1x (62-10 to 62-19, 62-1A to 62-1F):

YES

NO

YES

NO

23-289

A

FRONT PASSENGER’S SEAT BELT
BUCKLE SWITCH 3P CONNECTOR

BLK

BLU

BLK

GRY

Open in Front Passenger’s Seat Belt Buckle
Switch

1. Erase the DTC memory (see page 23-39).

2. Turn the ignition switch ON (II), then buckle and

unbuckle the front passenger’s seat belt several
times.

3. Read the DTC (see page 23-38).

Go to step 4.

Intermittent failure, system is OK at this time.

Go to Troubleshooting Intermittent Failures (see
page 23-39).

4. Turn the ignition switch OFF.

5. Disconnect the front passenger’s seat belt buckle

switch 3P connector (A).

6. Buckle the front passenger’s seat belt.

• Check resistance between the No. 1 and No. 3

terminals of the front passenger’s seat belt
buckle switch 3P connector. There should be
0

1

.

• Check resistance between the No. 1 and No. 2

terminals of the same connector. There should
be an open circuit, or at least 1 M

.

Go to step 7.

Replace the front passenger’s seat belt buckle

assembly, then clear the DTC.

(cont’d)

Terminal side of male terminals

Terminal side of male terminals

Is DT C 62-1x indicated?

Is the r esistance as specif ied?

03/07/29 10:39:50 61S0X050_230_0289
