22-112
Exterior Lights
Component Location Index
HEADLIGHTS/
FRONT PARKING LIGHTS
FRONT TURN SIGNAL/FRONT SIDE MARKER LIGHT
DAYTIME RUNNING LIGHTS RELAY
TAILLIGHT RELAY
INTERIOR LIGHTS RELAY
HIGH MOUNT BRAKE LIGHT
LICENSE PLATE LIGHT
TAILLIGHTS and BRAKE LIGHT
INNER TAILLIGHT
LOW BEAM CUT RELAY
Replacement, page 22-129
Replacement, page 22-129
Wire colors: RED/ORN, WHT/RED,
RED/WHT and ORN/BLK
(Canada)
Wire colors: RED/ORN, RED/WHT,
RED/GRN and RED/YEL
(With automatic light off feature)
Wire colors: RED/GRN, RED/YEL,
RED/GRN and RED/BLK
Wire colors: WHT/BLU,
LT GRN, BLK/BLU and BLK
Replacement, page 22-133
Replacement, page 22-133
Replacement, page 22-132
Replacement, page 22-132
Test, page 22-88
Test, page 22-88
Test, page 22-88
Test, page 22-88
(Canada)
