*01

S0X4A00J54283251701DBAT00

Roof Wire Harness

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

22-60

Connectors and Harnesses

Connector to Harness Index (cont’d)

ROOF WIRE HARNESS

1

2

3

4

5

6

7

8

9

10

11

12

13

14

16

15

Cargo area light

3

3

Roof area

Driver’s vanity mirror light

9

2

Left front side of roof area

Front ceiling light

8

3

Roof area

Left front individual map light

6

3

Left side of roof area

Left rear individual map light

4

3

Left side of roof area

Passenger’s vanity mirror light

11

2

Right front side of roof area

Rear ceiling light

15

3

Roof area

Except ’04 model

Rear controller and screen

5

26

Middle of roof

Rear heater-A/C passenger’s control
panel

7

10

Roof area

Right front individual map light

16

3

Right side of roof area

Right rear individual map light

2

3

Right side of roof area

Front individual map light

10

3

Roof area

C510

13

6

Left quarter panel

Left side wire harness (see page
22-48)

C511

14

16

Left quarter panel

Left side wire harness (see page
22-48)

C512

12

6

Behind right kick panel

Dashboard wire harness A (see
page 22-40)

’03-04 models

C582

1

14

Right side of floor

Right side wire harness:
’99-01 models (see page 22-52),
’02-04 models (see page 22-54)

Rear Heater-A/C

C582

1

3

Right side of floor

Right side wire harness:
’99-01 models (see page 22-52),
’02-04 models (see page 22-54)

Except ’04 model

: With rear entertainment system

03/07/29 10:19:44 61S0X050_220_0062

01

S0X4AZ4J54283256701DBAT20

SRS Main Harness (’99-01 models)

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

22-61

1

2

3

4

6

5

7

8

9

SRS MAIN HARNESS

Cable reel

1

2

Behind steering column

Driver’s under-dash fuse/relay box
connector N (see page 22-76)

9

2

Behind left kick panel

Front passenger’s airbag assembly

2

2

Behind glove box

Memory erase signal (MES) connector

7

2

Behind left kick panel

SRS unit

4

18

Middle of floor

C503

6

3

Behind left kick panel

Dashboard wire harness A (see
page 22-38)

C551

8

2

Behind left kick panel

Left side wire harness (see page
22-48)

C581

3

2

Behind right kick panel

Right side wire harness (see
page 22-52)

G801

5

Middle of floor

Body ground via SRS main
harness

03/07/29 10:19:44 61S0X050_220_0063

S0X4AZ3J54283256701DBAT61

SRS Main Harness (’02 model)

SRS Floor Harness (’02 model)

SRS Floor Subharness (’02 model)

OPDS Unit Harness (’02 model)

Left Side Wire Harness (SRS branch) (’02 model)

Right Side Wire Harness (SRS branch) (’02 model)

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

Connector or Terminal

Ref

Cavities

Location

Connects to

Notes

22-62

Connectors and Harnesses

Connector to Harness Index (cont’d)

Cable reel

1

4

Behind steering column

Driver’s under-dash fuse/relay box
connector N (see page 22-76)

26

2

Behind left kick panel

Front passenger’s airbag inflator

5

4

Behind glove box

Memory erase signal (MES) connector

25

2

Behind left kick panel

C205

6

4

Behind right kick panel

Right engine compartment
wire harness (see page 22-26)

C304

23

4

Behind left kick panel

Left engine compartment wire
harness (see page 22-28)

C503

27

8

Behind left kick panel

Dashboard wire harness A
(see page 22-40)

C551

24

2

Behind left kick panel

Left side wire harness

C581

7

2

Under right side of dash

Right side wire harness

C851

22

28

Under middle of dash

SRS floor harness

SRS unit connector A

2

8

Under middle of dash

SRS unit connector B

3

18

Under middle of dash

SRS unit connector C

4

18

Under middle of dash

C851

22

28

Under middle of dash

SRS main harness

C852

21

28

Under middle of dash

SRS floor subharness

G851

19

Under middle of dash

Body ground via SRS floor
harness

C556

15

2

Under driver’s seat

Left side wire harness

C557

16

2

Under driver’s seat

Left side wire harness

C583

14

2

Under front passenger’s seat

Right side wire harness

C584

13

2

Under front passenger’s seat

Right side wire harness

C852

21

28

Under middle of dash

SRS floor harness

OPDS unit

11

4

In front passenger’s seat

C861

12

4

Under front passenger’s seat

Right side wire harness

Driver’s seat belt tensioner

17

2

Left B-pillar

Driver’s side airbag inflator

20

2

Under driver’s seat

Driver’s side impact sensor

18

2

Left B-pillar

C551

24

2

Behind left kick panel

SRS main harness

C556

15

2

Under driver’s seat

SRS floor subharness

C557

16

2

Under driver’s seat

SRS floor subharness

Front passenger’s side airbag inflator

8

2

Under front passenger’s seat

Passenger’s seat belt tensioner

10

2

Right B-pillar

Passenger’s side impact sensor

9

2

Right B-pillar

C581

7

2

Behind right kick panel

SRS main harness

C583

14

2

Under front passenger’s seat

SRS floor subharness

C584

13

2

Under front passenger’s seat

SRS floor subharness

C861

12

4

Under front passenger’s seat

OPDS unit harness

03/07/29 10:19:45 61S0X050_220_0064

01

22-63

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

7

8

6

5

4

3

2

SRS MAIN HARNESS

SRS FLOOR HARNESS

SRS FLOOR SUBHARNESS

RIGHT SIDE WIRE
HARNESS

OPDS UNIT HARNESS

LEFT SIDE WIRE HARNESS

1

03/07/29 10:19:45 61S0X050_220_0065
