Honda Odyssey 2004. Manual - part 112





01

01

02

S0X4AZ1K77100090325FAAT00

DTC P0325

’01 Model:

YES

NO

YES

NO

YES

NO

YES

NO

11-146

PGM-FI System

DTC Troubleshooting (cont’d)

PCM CONNECTOR A (31P)

KS
(RED/BLU)

KNOCK SENSOR SUBHARNESS
1P CONNECTOR (C103)

JUMPER WIRE

KS
(RED/BLU)

PCM CONNECTOR A (31P)

KS
(RED/BLU)

Knock Sensor Circuit

Malfunction

1. Reset the PCM (see page 11-4).

2. Start the engine. Hold the engine at 3,000 rpm with

no load (in Park or neutral) until the radiator fan
comes on, then let it idle.

3. Hold the engine at 3,000

4,000 rpm for at least 60

seconds.

Go to step 4.

Intermittent failure, system is OK at this time.

Check for poor connections or loose terminals at
the knock sensor and the PCM.

4. Turn the ignition switch OFF.

5. Disconnect the C103 knock sensor connector.

6. Check for continuity between PCM connector

terminal A9 and body ground.

Repair short in the wire between the PCM

(A9) and the C103 knock sensor connector.

Go to step 7.

7. Connect C103 knock sensor connector terminal

No. 1 to body ground with a jumper wire.

8. Check for continuity between PCM connector

terminal A9 and body ground.

Go to step 9.

Repair open in the wire between the PCM (A9)

and the C103 knock sensor connector.

9. Check the knock sensor subharness between C103

and the knock sensor for an open or short. If it’s OK,
substitute a known-good knock sensor and recheck.

Substitute a known-good PCM and recheck

(see page 11-5). If the symptom/indication goes
away, replace the original PCM.

Replace the original knock sensor and/or

knock sensor subharness.

Wire side of female terminals

Wire side of female terminals

Wire side of female terminals

Is DT C P0325 indicated?

Is ther e continuity?

Is ther e continuity?

Is DT C P0325 indicated?

03/07/29 09:21:32 61S0X050_110_0146

01

02

03

S0X4AZ6K77100090335FAAT00

DTC P0335

’99-00, ’02-04 Models:

DTC P0336

’99-00, ’02-04 Models:

YES

NO

YES

NO

YES

NO

YES

NO

11-147

CKP SENSOR 2P CONNECTOR

CKP

CKP

CKP SENSOR 2P CONNECTOR

CKP

CKP

PCM CONNECTOR C (31P)

CKP
(BLU)

CKP
(WHT)

CKP

Sensor Circuit No Signal

CKP

Sensor Circuit Intermittent Interruption

1. Reset the PCM (see page 11-4).

2. Start the engine.

Go to step 3.

Intermittent failure, system is OK at this time.

Check for poor connections or loose terminals at
the CKP sensor and the PCM.

3. Turn the ignition switch OFF.

4. Disconnect the CKP sensor 2P connector.

5. Measure resistance between CKP sensor 2P

connector terminals No. 1 and No. 2.

Go to step 6.

Replace the CKP sensor (see page 6-61).

6. Check for continuity between body ground and CKP

sensor 2P connector terminals No. 1 and No. 2
individually.

Replace the CKP sensor (see page 6-61).

Go to step 7.

7. Reconnect the CKP sensor 2P connector.

8. Disconnect PCM connector C (31P).

9. Measure resistance between PCM connector

terminals C8 and C9.

Go to step 10.

Repair open in the wire between the PCM

(C8, C9) and the CKP sensor.

(cont’d)

Terminal side of male terminals

Terminal side of male terminals

Wire side of female terminals

Is DT C P0335 and/ or P0336 indicated?

Is ther e 1,850

2,450

?

Is ther e continuity?

Is ther e 1,850

2,450

?

03/07/29 09:21:33 61S0X050_110_0147

04

01

S0X4AZ1K77100090335FAAT00

YES

NO

YES

NO

YES

NO

DTC P0335

’01 Model:

DTC P0336

’01 Model:

11-148

11-148

PGM-FI System

DTC Troubleshooting (cont’d)

PCM CONNECTOR C (31P)

CKP
(BLU)

CKP SENSOR 2P CONNECTOR

CKP

CKP

10. Check for continuity between body ground and

PCM connector terminal C8.

Repair short in the wire between the PCM

(C8) and the CKP sensor.

Substitute a known-good PCM and recheck

(see page 11-5). If the symptom/indication goes
away, replace the original PCM.

1. Reset the PCM (see page 11-4).

2. Start the engine.

Go to step 3.

Intermittent failure, system is OK at this time.

Check for poor connections or loose terminals at
the CKP sensor and the PCM.

3. Turn the ignition switch OFF.

4. Disconnect the CKP sensor 2P connector.

5. Measure resistance between CKP sensor 2P

connector terminals No. 1 and No. 2.

Go to step 6.

Replace the CKP sensor (see page 6-61).

CKP Sensor Circuit

No Signal

CKP Sensor Circuit

Intermittent Interruption

Wire side of female terminals

Terminal side of male terminals

Is ther e continuity?

Is DT C P0335 and/ or P0336 indicated?

Is ther e 1,850

2,450

?

03/07/29 09:21:33 61S0X050_110_0148

02

03

04

YES

NO

YES

NO

YES

NO

11-149

CKP SENSOR 2P CONNECTOR

CKP

CKP

PCM CONNECTOR A (31P)

CKP

(BLU)

CKP

(WHT)

PCM CONNECTOR A (31P)

CKP

(BLU)

6. Check for continuity between body ground and CKP

sensor 2P connector terminals No. 1 and No. 2
individually.

Replace the CKP sensor (see page 6-61).

Go to step 7.

7. Reconnect the CKP sensor 2P connector.

8. Disconnect PCM connector A (31P).

9. Measure resistance between PCM connector

terminals A12 and A24.

Go to step 10.

Repair open in the wire between the PCM

(A12, A24) and the CKP sensor.

10. Check for continuity between body ground and

PCM connector terminal A12.

Repair short in the wire between the PCM

(A12) and the CKP sensor.

Substitute a known-good PCM and recheck

(see page 11-5). If the symptom/indication goes
away, replace the original PCM.

Terminal side of male terminals

Wire side of female terminals

Wire side of female terminals

Is ther e continuity?

Is ther e 1,850

2,450

?

Is ther e continuity?

03/07/29 09:21:34 61S0X050_110_0149
