Mercury Milan Hybrid (2010 year). Manual

AM/FM Radio

/ VOL (Power/Volume): Press to turn the radio on/off. Turn the

knob to increase/decrease volume.

If the volume is set above a certain level and the ignition is turned off,
the volume will come back on at a nominal listening level when the
ignition switch is turned back on.

AM/FM: Press repeatedly to select AM/FM1/FM2 frequency band.

TUNE: Turn the knob to go
up/down the frequency band in
individual increments.

DIRECT: Press DIRECT and then select the desired radio frequency
(i.e. 93.9) using the memory preset numbers (0–9).

SEEK/TRACK: Press

SEEK/TRACK

to access the

previous/next strong radio station.

SCAN: Press for a brief sampling of all strong radio stations.

MEMORY PRESETS (0–9): When
tuned to any station, press and hold
a preset button until sound returns
and PRESET # SAVED appears in
the display. You can save up to 30
stations, 10 in AM, 10 in FM1 and FM2.

Saving presets automatically– Autoset allows you to set the strongest
local radio stations without losing your original manually set preset
stations for AM/FM1/FM2.

To activate the autoset feature: Press MENU repeatedly until AUTO
PRESET ON/OFF appears in the display. Use

SEEK/TRACK

toggle AUTO PRESET to ON, and either wait five seconds for the search
to initiate or press OK to immediately initiate the search. If you press
another control within those five seconds, the search will not initiate.
The 10 strongest stations will be filled and the station stored in preset 1
will begin playing.

If there are fewer then 10 strong stations, the system will store the last
one in the remaining presets.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

RDS (Radio Data System) Radio

Available only in FM mode. This feature allows you to search
RDS-equipped stations for a certain category of music format: CLASSIC,
COUNTRY, JAZZ/RB, ROCK, etc.

To activate: Press MENU repeatedly until RDS (ON/OFF) appears in the
display. Use

SEEK/TRACK

to toggle RDS ON/OFF. When RDS is

OFF, you will not be able to search for RDS equipped stations or view
the station name or type.

CAT/FOLD(Category/Folder): This feature allows you to select from
various music categories.

To change RDS categories: Press MENU repeatedly until RDS ON/OFF
appears in the display. Use

to toggle RDS to ON. Press CAT.

PRESS UP OR DOWN TO CHANGE RDS CATEGORY will appear in the
display. Press

to scroll through all possible categories. When the

desired category appears in the display, press

SEEK/TRACK

find the next station playing that selection or press SCAN for a brief
sampling of all stations playing that category of music.

CD/MP3 Player

CD: Press to enter CD/MP3 mode. If a disc is already loaded into the
system, CD/MP3 play will begin where it ended last. If no CD is loaded,
NO DISC will appear in the display.

LOAD:
For a single CD system– This control is not operational. To load a CD,
simply insert the disc, label side up, into the CD slot.
For a CD6 system– Press LOAD. When the display reads SELECT
SLOT, choose the desired slot number using memory presets 1–6. When
the display reads LOAD CD#, load the desired disc, label side up. If you
do not choose a slot within five seconds, the system will choose for you.
Once loaded, the first track will begin to play.

To auto load up to six discs– Press and hold LOAD until the display
reads AUTOLOAD#. Load the desired disc, label side up. The system will
prompt you to load discs for the remaining available slots. Insert the
discs, one at a time, label side up, when prompted. Once loaded, the disc
in preset #1 will begin to play.

Press the number preset buttons (1–6) to choose the disc you want to
play.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

EJECT:
For a single CD system– press EJECT to eject the CD.
For a CD6 system– press EJECT and select the desired CD slot by
pressing the corresponding memory preset #. The display will read
EJECTING #. When the system has ejected the CD, the display will read
REMOVE CD #. Remove the CD. If you do not remove the CD, the
system will reload the disc.
To auto eject all loaded discs– Press and hold EJECT. The system will
eject all discs and prompt you when to remove them.

Play/Pause: Press to

play/pause a track when playing a
CD.

SEEK/TRACK: Press

SEEK/TRACK

to access the

previous/next track.

CAT (Category) / FOLD (Folder):

In MP3 mode only– Press CAT/FOLD and then press
SEEK/TRACK

to access the previous/next folder.

SCAN: Press for a brief sampling of all tracks on the current disc or
MP3 folder.

DIRECT:

In CD mode– Press DIRECT. The display will read DIRECT TRACK
MODE SELECT TRACK. Enter the desired track number using the
memory preset buttons (0–9). The system will then begin playing that
track.

In MP3 folder mode– Press DIRECT and the memory preset buttons
(0–9) of the desired folder. The system will advance to that specific
folder.

TEXT:

In MP3 mode only– Press TEXT repeatedly to view Album (AL), Folder
(FL), Song (SO) and Artist (AR) in the display, if available.

In TEXT MODE: Sometimes the display requires additional text to be
displayed. When the < / > indicator is active, press TEXT and then
press

SEEK/TRACK

to view the additional display text.

COMPRESSION: Press MENU repeatedly until COMPRESSION ON/OFF
appears in the display. Use

SEEK/TRACK

to toggle between

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

ON/OFF. When COMPRESSION is ON, the system will bring the soft and
loud CD passages together for a more consistent listening level.

SHUFFLE: Press MENU repeatedly until SHUFFLE ON/OFF appears in

the display. Use

SEEK/TRACK

to toggle between ON/OFF. If

you wish to engage shuffle mode right away, press

SEEK/TRACK

to begin random play. Otherwise, random play will

begin when the current track is finished playing. The system will only
shuffle the currently playing disc.

Satellite Radio

Satellite radio is available only with a valid SIRIUS radio
subscription. Check with your authorized dealer for availability.

SIRIUS: Press repeatedly to access satellite radio mode, if equipped.
Press repeatedly to cycle through SAT1, SAT2 and SAT3 modes.

TUNE/OK: Turn the knob to go to
the next / previous available SIRIUS
satellite station.

DIRECT: Press DIRECT then enter the desired channel (i.e. 002) using
the memory preset buttons (0–9). If you only enter one digit, press OK
and the system will go to that satellite channel. If you enter three digits,
the system will automatically go to that channel, if available. You may
cancel your entry by pressing DIRECT. If an invalid station number is
entered, INVALID CHANNEL will appear in the display and the system
will continue playing the current station.

SEEK/TRACK: Press

SEEK/TRACK

to seek to the

previous/next channel. If a specific category is selected, (Jazz, Rock,

News, etc.), press

SEEK/TRACK

to seek to the previous/next

channel in the selected category. Press and hold

SEEK/TRACK

to fast seek through the previous/next channels.

SCAN: Press SCAN for a brief sampling of all available SIRIUS satellite
channels. If a specific category is selected, (Jazz, Rock, News, etc.) press
SCAN for a brief sampling of all available SIRIUS satellite channels within
the selected category.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

MEMORY PRESETS (0–9): There
are 30 available presets, 10 each for
SAT1, SAT2 and SAT3. To save
satellite channels in your memory
presets, tune to the desired channel
then press and hold a memory preset number (0–9) until sound returns.

TEXT: Press and release to display the artist and song title. While in
TEXT MODE, press again to scroll through the Artist (AR), Song (SO),
Channel (CH) and Category (CA).

In TEXT MODE: Sometimes the display requires additional text to be
displayed. When the < / > indicator is active, press TEXT and then
press

SEEK/TRACK

to view the additional display text.

CAT (Category) / FOLD (Folder): Press to toggle between turning
the most recently selected satellite radio category on or off. The category
icon (CAT) will illuminate in the display when a specific category is
selected (the icon will not illuminate during CATEGORY ALL). If no
category has ever been selected, NO CATEGORY SELECTED will display.

Note: Separate categories can be set for SAT1, SAT2 or SAT3.
Refer to Satellite radio menu for further information on selecting a
satellite radio category.

SATELLITE RADIO MENU: Press MENU when satellite radio mode is
active to access. Press OK to enter into the satellite radio menu.
Press

to cycle through the following options:

• CATEGORY MENU- Press OK to enter category mode.

Press

to scroll through the list of available SIRIUS channel

Categories (Pop, Rock, News, etc.) Press OK when the desired
category appears in the display. After a category is selected,
press

to search for that specific category of channels only

(i.e. ROCK). You may also select CATEGORY ALL to seek all available
SIRIUS categories and channels. Press OK to close and return to the
main menu.

• SONG SEEK MENU- Press OK to enter song seek menu.

Press

to scroll through the following options:

a. SAVE THIS SONG: Press OK to save the currently playing song’s
title in the system’s memory. (If you try to save something other than
a song, CANT SAVE will appear in the display.) When the chosen song
is playing on any satellite radio channel, the system will alert you with
an audible prompt. Press OK while SONG ALERT is in the display and

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

the system will take you to the channel playing the desired song. You
can save up to 20 song titles. If you attempt to save more than 20
titles, the display will read REPLACE SONG? Press OK to access the
saved titles and press

to cycle through the saved titles. When

the song title appears in the display that you would like to replace,
press OK. SONG REPLACED will appear in the display.
b. DELETE A SONG: Press OK to delete a song from the system’s
memory. Press

to cycle through the saved songs. When the

song appears in the display that you would like to delete, press OK.
The song will appear in the display for confirmation. Press OK again
and the display will read SONG DELETED. If you do not want to
delete the currently listed song, press

to select either

RETURN or CANCEL.
Note: If there are no songs presently saved, the display will read NO
SONGS.
c. DELETE ALL SONGS: Press OK to delete all song’s from the
system’s memory. The display will read ARE YOU SURE ? Press OK to
confirm deletion of all saved songs and the display will read ALL
DELETED.
Note: If there are no songs presently saved, the display will read NO
SONGS.
d. DISABLE ALERTS/ENABLE ALERTS: Press OK to
enable/disable the satellite alert status which alerts you when your
selected songs are playing on a satellite radio channel. (The system
default is disabled.) SONG ALERTS ENABLED/DISABLED will appear
in the display. The menu listing will display the opposite state. For
example, if you have chosen to enable the song alerts, the menu
listing will read DISABLE as the alerts are currently on, so your other
option is to turn them off.

• CHANNEL LOCKOUT MENU- Press OK to enter the Channel

Lockout menu. Press the

to scroll through the following

options:
a. LOCK/UNLOCK THIS CHANNEL: Press OK when
LOCK/UNLOCK THIS CHANNEL is displayed and the display will read
ENTER PIN. Enter your four-digit PIN number (initial PIN is 1234)
and the system will lock/unlock the channel and CHANNEL LOCKED
or UNLOCKED will be displayed.
Note: you must be tuned to the specific channel you want to
lock/unlock when using this feature.
b. CHANGE PIN: Press OK when CHANGE PIN is displayed. The
display will read ENTER OLD PIN. Enter your current (old) PIN

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

number and when the system accepts your entry it will display
ENTER NEW PIN. Enter your new four-digit PIN and the system will
save the new PIN and PIN SAVED will display.
c. UNLOCK ALL CHANNELS: Press OK when UNLOCK ALL
CHANNELS is displayed and the display will read ENTER PIN. Enter
your four-digit PIN and the system will unlock all channels and the
display will read CHANNEL UNLOCKED.
d. RESET PIN: Press OK when RESET PIN is displayed. The display
will read ARE YOUR SURE. Press OK again to automatically reset the
PIN number to its initial password setting (1234). PIN RESET TO
DEFAULT PIN will be displayed.
e. RETURN: Press OK when RETURN is displayed and the system
will exit back to the satellite radio menu.

Sound Adjustments

Press SOUND repeatedly to cycle through the following features:

BASS: Press

SEEK/TRACK

to adjust the level of bass.

TREBLE: Press

SEEK/TRACK

to adjust the level of treble.

BALANCE: Press

SEEK/TRACK

to adjust the audio between

the left (L) and right (R) speakers.

FADE: Press

SEEK/TRACK

to adjust the audio between the

back (B) and front (F) speakers.

SPEED COMPENSATED VOLUME: With this feature on, radio volume
automatically gets louder with increasing vehicle speed to compensate
for road and wind noise.

The default setting is off.

Use

SEEK/TRACK

to adjust between SPEED OFF and levels

1–7: Increasing the level from 1 (lowest setting) to 7 (highest setting)
allows the radio volume to automatically change slightly with vehicle
speed to compensate for road and wind noise.

Recommended level is 1–3; SPEED OFF turns the feature off and level 7
is the maximum setting.

ALL SEATS (Occupancy mode, if equipped): Press SOUND
repeatedly to reach the Occupancy mode setting. Press
SEEK/TRACK

to select and optimize sound for ALL SEATS,

DRIVERS SEAT or REAR SEATS.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

Extra Features

AUX: Press repeatedly to cycle through LINE IN (auxiliary audio mode),
and SYNC.

For location and further information on auxiliary audio mode, refer to
Auxiliary input jack later in this chapter.

Refer to your SYNC supplemental information for more information.

OK: Your vehicle may be equipped
with special phone and media
features which will require you to
confirm commands by pressing OK.
For further information, refer to
your SYNC supplemental
information.

Press to access SYNC PHONE features. For further information,

please refer to your SYNC supplemental information.

Auxiliary input jack (Line in)

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

drivers use extreme caution when using any device that may take their
focus off the road. The driver’s primary responsibility is the safe
operation of their vehicle. Only use cell phones and other devices not
essential to the driving task when it is safe to do so.

Your vehicle is equipped with an
Auxiliary Input Jack (AIJ). The
Auxiliary Input Jack provides a way
to connect your portable music
player to the in-vehicle audio
system. This allows the audio from a
portable music player to be played
through the vehicle speakers with
high fidelity. To achieve optimal
performance, please observe the
following instructions when
attaching your portable music device to the audio system.
If your vehicle is equipped with a navigation system, refer to Auxiliary
input jack section in the Audio features chapter of your Navigation
system supplement.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

Required equipment:

1. Any portable music player designed to be used with headphones

2. An audio extension cable with stereo male 1/8 in. (3.5 mm)
connectors at each end

To play your portable music player using the auxiliary input jack:

1. Begin with the vehicle parked and the radio turned off.

2. Ensure that the battery in your portable music player is new or fully
charged and that the device is turned off.

3. Attach one end of the audio extension cable to the headphone output
of your player and the other end of the audio extension cable to the AIJ
in your vehicle.

4. Turn the radio on, using either a tuned FM station or a CD loaded into
the system. Adjust the volume to a comfortable listening level.

5. Turn the portable music player on and adjust the volume to 1/2 the
volume.

6. Press AUX on the vehicle radio repeatedly until LINE, LINE IN or
SYNC LINE IN appears in the display.
You should hear audio from your portable music player, although it may
be low.

7. Adjust the sound on your portable music player until it reaches the
level of the FM station or CD by switching back and forth between the
AUX and FM or CD controls.

Troubleshooting:

1. Do not connect the audio input jack to a line level output. Line level
outputs are intended for connection to a home stereo and are not
compatible with the AIJ. The AIJ will only work correctly with devices
that have a headphone output with a volume control.

2. Do not set the portable music player’s volume level higher than is
necessary to match the volume of the CD or FM radio in your audio
system as this will cause distortion and will reduce sound quality. Many
portable music players have different output levels, so not all players
should be set at the same levels. Some players will sound best at full
volume and others will need to be set at a lower volume.

3. If the music sounds distorted at lower listening levels, turn the
portable music player volume down. If the problems persists, replace or
recharge the batteries in the portable music player.

4. The portable music player must be controlled in the same manner
when it is used with headphones as the AIJ does not provide control
(play, pause, etc.) over the attached portable music player.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

5. For safety reasons, connecting or adjusting the settings on your
portable music player should not be attempted while the vehicle is
moving. Also, the portable music player should be stored in a secure
location, such as the center console or the glove box, when the vehicle is
in motion. The audio extension cable must be long enough to allow the
portable music player to be safely stored while the vehicle is in motion.

USB port

WARNING: Driving while distracted can result in loss of vehicle
control, accident and injury. Ford strongly recommends that

Your vehicle is equipped with a USB
port inside your center console. This
feature allows you to plug in media
playing devices, memory sticks, and
also to charge devices if they
support this feature. For further
information on this feature, refer to
Accessing and using your USB
port in the SYNC supplement or
Navigation system supplement.

GENERAL AUDIO INFORMATION

Radio frequencies:

AM and FM frequencies are established by the Federal Communications
Commission (FCC) and the Canadian Radio and Telecommunications
Commission (CRTC). Those frequencies are:

AM: 530, 540–1700, 1710 kHz

FM: 87.7, 87.9–107.7, 107.9 MHz

Radio reception factors:

There are three factors that can affect radio reception:
• Distance/strength: The further you travel from an FM station, the

weaker the signal and the weaker the reception.

• Terrain: Hills, mountains, tall buildings, power lines, electric fences,

traffic lights and thunderstorms can interfere with your reception.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

• Station overload: When you pass a broadcast tower, a stronger signal

may overtake a weaker one and play while the weak station frequency
is displayed.

CD/CD player care

Do:
• Handle discs by their edges only.

(Never touch the playing
surface).

• Inspect discs before playing.
• Clean only with an approved CD

cleaner.

• Wipe discs from the center out.

Don’t:
• Expose discs to direct sunlight or heat sources for extended periods

of time.

• Clean using a circular motion.
CD units are designed to play commercially pressed 4.75 in
(12 cm) audio compact discs only. Due to technical
incompatibility, certain recordable and re-recordable compact
discs may not function correctly when used in Ford CD players.

Do not use any irregular shaped
CDs or discs with a scratch
protection film attached.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

CDs with homemade paper
(adhesive) labels should not be
inserted into the CD player as
the label may peel and cause the
CD to become jammed. It is
recommended that homemade
CDs be identified with
permanent felt tip marker rather
than adhesive labels. Ballpoint pens may damage CDs. Please
contact your authorized dealer for further information.

Audio system warranty and service

Refer to the Warranty Guide/Customer Information Guide for audio
system warranty information. If service is necessary, see your dealer or
qualified technician.

MP3 track and folder structure

Your MP3 system recognizes MP3 individual tracks and folder structure
as follows:
• There are two different modes for MP3 disc playback: MP3 track mode

(system default) and MP3 folder mode. For more information on track
and folder mode, refer to Sample MP3 structure in the following
section.

• MP3 track mode ignores any folder structure on the MP3 disc. The

player numbers each MP3 track on the disc (noted by the .mp3 file
extension) from T001 to a maximum of T255.
Note: The maximum number of playable MP3 files may be less
depending on the structure of the CD and exact model of radio
present.

• MP3 folder mode represents a folder structure consisting of one level

of folders. The CD player numbers all MP3 tracks on the disc (noted
by the .mp3 file extension) and all folders containing MP3 files, from
F001 (folder) T001 (track) to F253 T255.

• Creating discs with only one level of folders will help with navigation

through the disc files.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

Sample MP3 structure

If you are burning your own MP3
discs, it is important to understand
how the system will read the
structures you create. While various
files may be present, (files with
extensions other than mp3), only
files with the .mp3 extension will be
played. Other files will be ignored
by the system. This enables you to
use the same MP3 disc for a variety
of tasks on your work computer,
home computer and your in vehicle
system.

In track mode, the system will display and play the structure as if it were
only one level deep (all .mp3 files will be played, regardless of being in a
specific folder). In folder mode, the system will only play the .mp3 files
in the current folder.

Satellite radio information

Satellite radio channels: SIRIUS broadcasts a variety of music, news,
sports, weather, traffic and entertainment satellite radio channels. For
more information and a complete list of SIRIUS satellite radio channels,
visit www.sirius.com in the United States, www.sirius-canada.ca in
Canada, or call SIRIUS at 1–888–539–7474.

Satellite radio reception factors: To receive the satellite signal, your
vehicle has been equipped with a satellite radio antenna located on the
roof of your vehicle. The vehicle roof provides the best location for an
unobstructed, open view of the sky, a requirement of a satellite radio
system. Like AM/FM, there are several factors that can affect satellite
radio reception performance:
• Antenna obstructions: For optimal reception performance, keep the

antenna clear of snow and ice build-up and keep luggage and other
material as far away from the antenna as possible.

.mp3

.doc

.ppt

.xls

.mp3

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

• Terrain: Hills, mountains, tall buildings, bridges, tunnels, freeway

overpasses, parking garages, dense tree foliage and thunderstorms can
interfere with your reception.

• Station overload: When you pass a ground based broadcast repeating

tower, a stronger signal may overtake a weaker one and result in an
audio mute.

Unlike AM/FM audible static, you will hear an audio mute when there is
a satellite radio signal interference. Your radio display may display NO
SIGNAL to indicate the interference.

SIRIUS satellite radio service: SIRIUS Satellite Radio is a subscription
based satellite radio service that broadcasts music, sports, news and
entertainment programming. A service fee is required in order to receive
SIRIUS service. Vehicles that are equipped with a factory installed
SIRIUS Satellite Radio system include:
• Hardware and limited subscription term, which begins on the date of

sale or lease of the vehicle.

• Use of online media player providing access to all SIRIUS music

channels over the internet using any computer connected to the
internet (U.S. customers only)

For information on extended subscription terms, contact SIRIUS at
1–888–539–7474.

Note: SIRIUS reserves the unrestricted right to change, rearrange, add
or delete programming including canceling, moving or adding particular
channels, and its prices, at any time, with or without notice to you. Ford
Motor Company shall not be responsible for any such programming
changes.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

Satellite Radio Electronic Serial Number (ESN): This 12-digit
Satellite Serial Number is needed to activate, modify or track your
satellite radio account. You will need this number when communicating
with SIRIUS. While in Satellite Radio mode, you can view this number on
the radio display by pressing the SIRIUS and Preset 1 buttons at the
same time.

Radio Display

Condition

Action Required

ACQUIRING

Radio requires

more than two

seconds to

produce audio for

the selected

channel.

No action required. This

message should disappear

shortly.

SAT FAULT

Internal module

or system failure

present.

If this message does not clear

within a short period of time, or

with an ignition key cycle, your

receiver may have a fault. See

your authorized dealer for

service.

INVALID CHNL

Channel no

longer available.

This previously available channel

is no longer available. Tune to

another channel. If the channel

was one of your presets, you

may choose another channel for

that preset button.

UNSUBSCRIBED

Subscription not
available for this

channel.

Contact SIRIUS at

1–888–539–7474 to subscribe to

the channel or tune to another

channel.

NO TEXT

Artist information

not available.

Artist information not available

at this time on this channel. The

system is working properly.

NO TEXT

Song title

information not

available.

Song title information not

available at this time on this

channel. The system is working

properly.

2010 Milan Hybrid (hmv)
Owners Guide, 1st Printing
USA (fus)

Entertainment Systems

Radio Display

Condition

Action Required

NO TEXT

Mercury Milan Hybrid (2010 year). Manual - part 4
