Fig. 57: Identifying Special Tool(s) (1 Of 2)
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup



Fig. 58: Identifying Special Tool(s) (2 Of 2)
Courtesy of FORD MOTOR CO.

Removal

1. Remove the front drive axle assembly. For additional information, refer to AXLE ASSEMBLY-FRONT

DRIVE in this section.

2. Position the cover bushing removal tools.

1. Position the Bushing Remover Adapter.

2. Position the Bushing Cup Remover/Replacer.

3. Position the Drawbolt.

4. Thread the Bushing Remover on the Drawbolt.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup



Fig. 59: Positioning Cover Bushing Removal Tools
Courtesy of FORD MOTOR CO.

3. Tighten the Drawbolt to remove the cover bushing.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup



Fig. 60: Removing Cover Bushing
Courtesy of FORD MOTOR CO.

Installation

1. Position the differential cover bushing and differential cover bushing tools.

1. Position the differential cover bushing.

2. Position the Bushing Collect Replacer.

3. Position the Bushing Cup Remover/Replacer.

4. Position the Drawbolt.

5. Position the Bushing Adapter Replacer.

6. Thread the Bushing Replacer on the Drawbolt.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Front Drive Axle/Differential - Ford 8.8-Inch - F150 Pickup
