Fig. 42: Installing Brake Pedal-To-Accelerator Pedal Cable
Courtesy of FORD MOTOR CO.

12. Slide the stoplight switch, booster push rod and the bushing on the brake pedal pin.



2003 Ford Pickup F150

2003 BRAKES Hydraulic Brake Actuation - F150 Pickup



Fig. 43: Installing Stoplight Switch, Booster Push Rod & Bushing
Courtesy of FORD MOTOR CO.

13. Install the stoplight switch hairpin clip.



2003 Ford Pickup F150

2003 BRAKES Hydraulic Brake Actuation - F150 Pickup



Fig. 44: Installing Stoplight Switch Hairpin Clip
Courtesy of FORD MOTOR CO.

14. Install the steering column support bracket.



2003 Ford Pickup F150

2003 BRAKES Hydraulic Brake Actuation - F150 Pickup



Fig. 45: Installing Steering Column Support Bracket
Courtesy of FORD MOTOR CO.

15. Install the instrument panel opening cover (04459). For additional information, refer to INSTRUMENT

PANEL AND CONSOLE .

BRAKE PEDAL - ADJUSTABLE

Removal

1. Disconnect the battery ground cable (14301). For additional information, refer to BATTERY,

CAUTION: The brake pedal (2453) and the accelerator pedal (9725) must be in

the same position when installing a new cable or a new pedal. The
pedals must be in the all the way forward or all the way rearward
position.
