Ford F150 Pickup. Instruction - part 414

Fig. 14: Removing Clutch Master Cylinder
Courtesy of FORD MOTOR CO.

4. Remove the stoplight switch self-locking pin.

2003 Ford Pickup F150

2003 BRAKES Hydraulic Brake Actuation - F150 Pickup

Fig. 15: Removing Stoplight Switch Self-Locking Pin
Courtesy of FORD MOTOR CO.

5. Slide the stoplight switch and the booster push rod off the brake pedal pin.

2003 Ford Pickup F150

2003 BRAKES Hydraulic Brake Actuation - F150 Pickup

Fig. 16: Removing Stoplight Switch & Booster Push Rod
Courtesy of FORD MOTOR CO.

6. Remove the bulkhead sound insulator.

2003 Ford Pickup F150

2003 BRAKES Hydraulic Brake Actuation - F150 Pickup

Fig. 17: Installing Brake Pedal Bracket Nuts
Courtesy of FORD MOTOR CO.

7. Remove the two brake pedal bracket bolts.

2003 Ford Pickup F150

2003 BRAKES Hydraulic Brake Actuation - F150 Pickup
