Fig. 24: Removing Tilt Wheel Handle & Shank
Courtesy of FORD MOTOR CO.

3. Release the four clips and remove the steering column opening cover.



2003 Ford Pickup F150

2003 STEERING Steering Column Switches - F150 Pickup



Fig. 25: Removing Steering Column Opening Cover
Courtesy of FORD MOTOR CO.

4. Remove the upper and lower steering column shrouds.

1. Remove the three screws.

2. Remove the lower steering column shroud.

3. Remove the upper steering column shroud.



2003 Ford Pickup F150

2003 STEERING Steering Column Switches - F150 Pickup



Fig. 26: Removing Upper & Lower Steering Column Shrouds
Courtesy of FORD MOTOR CO.

5. Remove the key release button.

1. Remove the bolt.

2. Remove the spring.

3. Remove the key release button.



2003 Ford Pickup F150

2003 STEERING Steering Column Switches - F150 Pickup



Fig. 27: Removing Key Release Button
Courtesy of FORD MOTOR CO.

Installation

1. To install, reverse the removal procedure.
