Fig. 16: Removing Upper & Lower Steering Column Shrouds
Courtesy of FORD MOTOR CO.

6. Remove the multi function switch.

1. Remove the two screws.

2. Disconnect the electrical connectors.

3. Remove the multi function switch.



2003 Ford Pickup F150

2003 STEERING Steering Column Switches - F150 Pickup



Fig. 17: Removing Multi Function Switch
Courtesy of FORD MOTOR CO.

Installation

NOTE:

When the battery (10655) is disconnected and reconnected, some
abnormal drive symptoms may occur while the vehicle relearns its
adaptive strategy. The vehicle may need to be driven 16 km (10 mi) or
more to relearn the strategy.



2003 Ford Pickup F150

2003 STEERING Steering Column Switches - F150 Pickup



Fig. 18: Installing Multi Function Switch
Courtesy of FORD MOTOR CO.

1. To install, reverse the removal procedure.

IGNITION SWITCH

Removal

1. Disconnect the battery ground cable (14301).

2. Remove the instrument panel steering column cover; refer to INSTRUMENT PANEL AND

CONSOLE - F150 PICKUP .

3. Disconnect the ignition switch electrical connector.

1. Loosen the bolt.

2. Disconnect the electrical connector.



2003 Ford Pickup F150

2003 STEERING Steering Column Switches - F150 Pickup



Fig. 19: Disconnecting Electrical Connector
Courtesy of FORD MOTOR CO.

4. Remove the ignition switch.

1. Remove the screws.

2. Remove the ignition switch.



2003 Ford Pickup F150

2003 STEERING Steering Column Switches - F150 Pickup
