Fig. 30: Installing Bolts
Courtesy of FORD MOTOR CO.

6. Remove the pins.

7. Install the roof opening panel. Refer to ROOF OPENING PANEL .

ROOF OPENING PANEL FRAME

Removal and Installation

1. Remove the headliner. Refer to HEADLINER .

2. Remove the overhead console bracket.

1. Remove the screws.

2. Remove the overhead console bracket.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Roof Opening Panel - F150 Pickup



Fig. 31: Removing Overhead Console Bracket
Courtesy of FORD MOTOR CO.

3. Disconnect the electrical connector and remove it from the bracket.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Roof Opening Panel - F150 Pickup



Fig. 32: Disconnecting Electrical Connector
Courtesy of FORD MOTOR CO.

4. Remove the roof opening panel frame.

1. Disconnect the four roof opening panel drain hoses.

2. Remove the ten bolts.

3. Remove the roof opening panel frame.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Roof Opening Panel - F150 Pickup



Fig. 33: Removing Roof Opening Panel Frame
Courtesy of FORD MOTOR CO.

4. To install, reverse the removal procedure.

ROOF OPENING PANEL MODULE

Removal and Installation

1. Close the roof opening panel.

2. Disconnect the battery ground cable (14301).

3. Lower the rear of the headliner. Refer to HEADLINER .

4. Slide the roof opening panel module from the retaining bracket.

NOTE:

Rear side brackets are to be reattached to the new roof opening
panel frame.
