Ford F150 Pickup. Instruction - part 249

Fig. 334: Removing Hog Rings
Courtesy of FORD MOTOR CO.

6. Invert the seat back trim cover to the upper row of hog rings.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 335: Inverting Seat Back Trim Cover To Upper Row Of Hog Rings
Courtesy of FORD MOTOR CO.

7. Remove the headrest, lift the seat back trim cover and remove the headrest guide pins.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 336: Removing Headrest Guide Pins
Courtesy of FORD MOTOR CO.

8. Remove the seat back trim cover.

1. Remove the hog rings.

2. Remove the seat back trim cover.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 337: Removing Seat Back Trim Cover
Courtesy of FORD MOTOR CO.

9. Remove the front seat back frame from the front seat back foam.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
