Fig. 192: Removing Screws Securing Seat Adjuster Tracks To Seat Pedestal Frame
Courtesy of FORD MOTOR CO.

Installation

All seats

1. Place the seat tracks on the seat pedestal frame and install the seven screws (four outboard side, three

inboard side).



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 193: Placing Seat Tracks On Seat Pedestal Frame
Courtesy of FORD MOTOR CO.

Power seats

2. Connect the seat actuator motor electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 194: Connecting Seat Actuator Motor Electrical Connector
Courtesy of FORD MOTOR CO.

60 percent seat

3. Install the tube frame to the seat track.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 195: Installing Tube Frame To Seat Track
Courtesy of FORD MOTOR CO.

4. Install the two rear bolts for the LATCH.
