Ford F150 Pickup. Instruction - part 1997

Fig. 147: Locating Transmission Mount-To-Crossmember Nuts
Courtesy of FORD MOTOR CO.

20. Remove the six crossmember-to-frame nuts and bolts.

2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup

Fig. 148: Removing Crossmember-To-Frame Nuts & Bolts
Courtesy of FORD MOTOR CO.

21. Remove the transmission mount-to-crossmember nuts and the crossmember.

2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup

Fig. 149: Removing Transmission Mount-To-Crossmember Nuts
Courtesy of FORD MOTOR CO.

22. Remove the transmission mount and the exhaust hanger.

2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup

Fig. 150: Removing Transmission Mount
Courtesy of FORD MOTOR CO.

23. Position a suitable jack stand under the extension housing.

2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup
