Ford F150 Pickup. Instruction - part 1965

Fig. 22: Installing Gearshift Lever Cover
Courtesy of FORD MOTOR CO.

4. Install the gearshift lever boot.

1. Position the gearshift lever boot.

2. Install the four gearshift lever boot screws.

3. Install the gearshift lever knob.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 23: Installing Gearshift Lever Boot
Courtesy of FORD MOTOR CO.

INDICATOR SWITCH - SHIFT RANGE SELECTOR

Removal

1. Remove the center instrument panel trim plate.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 24: Removing Center Instrument Panel Trim Plate
Courtesy of FORD MOTOR CO.

2. Remove the shift range selector switch.

1. Remove the shift range selector switch knob.

2. Disconnect the shift range selector switch electrical connector.

3. Remove the two shift range selector switch bolts.

4. Remove the shift range selector switch.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 25: Removing Shift Range Selector Switch
Courtesy of FORD MOTOR CO.

Installation

1. Install the shift range selector switch.

1. Position the shift range selector switch.

2. Install the bolts.

3. Install the electrical connector.

4. Install the knob.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup
