Fig. 108: Installing Pin-Type Retainers
Courtesy of FORD MOTOR CO.

43. Install the weather-stripping and the passenger door scuff elate.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 109: Installing Weather-stripping And Passenger Door Scuff Elate
Courtesy of FORD MOTOR CO.

44. Install the passenger side corner upper trim panel. Refer to TRIM PANEL -- CORNER, UPPER .

45. Install the passenger side safety belt guide.

1. Position the safety belt guide.

2. Install the nut.

WARNING:

Make sure that the safety belt webbing is not twisted prior to
installation.

CAUTION: Inspect the shoulder safety belt guide cover for damage. If the

shoulder safety belt guide cover is damaged or if it does not
remain closed, install a new shoulder safety belt guide cover.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 110: Closing Safety Belt Guide Cover
Courtesy of FORD MOTOR CO.

3. Close the safety belt guide cover.

All vehicles

46. Remove the restraint system diagnostic tool from the vehicle harness side of the passenger air bag

electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 111: Removing Restraint System Diagnostic Tool From Vehicle Harness Side Passenger Air
Bag Electrical Connector
Courtesy of FORD MOTOR CO.

47. Connect the passenger air bag module electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
