Fig. 100: Connecting Driver Side Safety Belt Retractor Pretensioner Electrical Connector
Courtesy of FORD MOTOR CO.

34. Position the safety belt through the driver side lower corner trim panel.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 101: Identifying Position Of Safety Belt Through Driver Side Lower Corner Trim Panel
Courtesy of FORD MOTOR CO.

35. Position the driver side lower corner trim panel and push in near the door jamb, seating the retaining

clips. Install the three pin-type retainers.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 102: Installing Pin-Type Retainers
Courtesy of FORD MOTOR CO.

36. Install the weather-stripping and the driver door scuff plate.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 103: Installing Weather-stripping And Driver Door Scuff Plate
Courtesy of FORD MOTOR CO.

37. Install the driver side corner upper trim panel. Refer to TRIM PANEL -- CORNER, UPPER .

38. Install the driver side safety belt guide.

1. Position the safety belt guide.

2. Install the nut.

WARNING:

Make sure that the safety belt webbing is not twisted prior to
installation.

CAUTION: Inspect the shoulder safety belt guide cover for damage. If the

shoulder safety belt guide cover is damaged or if it does not
remain closed, install a new shoulder safety belt guide cover.
