Fig. 80: Connecting Driver Side Safety Belt Retractor Pretensioner Electrical Connector
Courtesy of FORD MOTOR CO.

4. Align the driver side B-pillar trim panel and push in, seating the B-pillar trim panel retaining clips.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 81: Aligning Driver Side B-Pillar Trim Panel
Courtesy of FORD MOTOR CO.

5. Install the driver side B-pillar assist handle.

1. Position the B-pillar assist handle.

2. Install the screws.

3. Install the caps.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 82: Installing Driver Side B-Pillar Assist Handle
Courtesy of FORD MOTOR CO.

6. Install the B-pillar weathers tripping.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 83: Installing B-Pillar Weather Stripping
Courtesy of FORD MOTOR CO.

WARNING:

Make sure that the safety belt webbing is not twisted prior to
installation.

CAUTION: Inspect the shoulder safety belt guide cover for damage. If the
