Fig. 83: Installing Lower Instrument Panel Steering Column Cover
Courtesy of FORD MOTOR CO.

52. Install the central junction box panel cover.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 84: Installing Central Junction Box Panel Cover
Courtesy of FORD MOTOR CO.

53. Install the upper instrument panel steering column cover.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 85: Installing Upper Instrument Panel Steering Column Cover
Courtesy of FORD MOTOR CO.

54. Connect the battery ground cable. For additional information, refer to BATTERY, MOUNTING AND

CABLES - F150 PICKUP .

55. With all the restraint system diagnostic tools removed, prove out the Supplemental Restraint System

(SRS). For additional information, refer to AIR BAG RESTRAINT SYSTEMS - F150 PICKUP .

56. Check the active restraints system for correct operation. For additional information, refer to SAFETY

BELT SYSTEM - F150 PICKUP .

REMOVAL & INSTALLATION

WHEEL

Special Tool(s)

WARNING:

The restraint system diagnostic tool is for restraint system service
only. Remove from vehicle prior to road use. Failure to remove could
result in injury and possible violation of vehicle safety standards.



2003 Ford Pickup F150

2003 STEERING Steering Column - F150 Pickup



Fig. 86: Identifying Special Tool(s)
Courtesy of FORD MOTOR CO.

Removal & Installation

1. Turn the steering wheel to the straight-ahead position and turn the ignition switch to the OFF position.

2. Disconnect the battery ground cable (14301) and wait at least one minute to allow the depletion of the

restraint system backup power supply.

3. Deactivate the Supplemental Restraint System (SRS). For additional information, refer to

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEACTIVATION AND REACTIVATION .

4. Remove the driver air bag. For additional information, refer to DRIVER-SIDE AIR BAG MODULE .

5. Remove the steering wheel bolt.

WARNING:

To reduce the risk of serious personal injury, read and follow all
warnings, cautions and notes in the deactivation procedure.

WARNING:

To avoid the risk of serious personal injury, read and follow all
warnings, cautions, notes and instructions in the driver air bag
removal and installation procedure.
