Fig. 35: Removing Mirror Glass
Courtesy of FORD MOTOR CO.

4. Remove the friction pins from the mirror backing plate.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 36: Removing Friction Pins From Mirror Backing Plate
Courtesy of FORD MOTOR CO.

Installation

1. Install the friction pins into the mirror backing plate by using the special tool to warm the mirror backing

plate sockets at the top and outboard positions.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 37: Installing Friction Pins Into Mirror Backing Plate By Using Special Tool
Courtesy of FORD MOTOR CO.

NOTE:

Rotate the power mirror jackscrews in the mirror housing with the locator
tabs facing the center of the housing.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 38: Pushing Power Mirror Jackscrews Into Mirror Housing Until Bottom Out
Courtesy of FORD MOTOR CO.

2. Push the power mirror jackscrews into the mirror housing until they bottom out.

3. Using the special tool, warm the power mirror motor jackscrew and center mirror backing plate sockets.
