Fig. 27: Locating Mirror Glass To Obtain Gap At Inboard Edge
Courtesy of FORD MOTOR CO.

4. Release the mirror cover inboard clip.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 28: Releasing Mirror Cover Inboard Clip
Courtesy of FORD MOTOR CO.

5. Position the mirror glass to obtain a gap at the outboard edge of the mirror assembly.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 29: Locating Mirror Glass To Obtain Gap At Outboard Edge
Courtesy of FORD MOTOR CO.

6. Remove the mirror cover.

z

Release the mirror cover outboard clip.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 30: Releasing Mirror Cover Outboard Clip
Courtesy of FORD MOTOR CO.

Signal Mirror

7. Remove the mirror cover.

z

Disconnect the signal mirror electrical connector.

Installation

1. Install the mirror cover.

z

If equipped, connect the electrical connector.

z

Apply sufficient force to the mirror cover until it snaps into place.
