Fig. 31: Installing Mirror Cover
Courtesy of FORD MOTOR CO.

MIRROR - GLASS, EXTERIOR REAR VIEW MIRROR

Special Tool(s)



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 32: Identifying Special Tool
Courtesy of FORD MOTOR CO.

Removal

1. Position the mirror glass to obtain a gap at the lower inboard edge of the mirror assembly.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 33: Locating Mirror Glass To Obtain Gap At Lower Inboard Edge
Courtesy of FORD MOTOR CO.

2. Disengage the power mirror motor jackscrews from the mirror backing plate.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Rear View Mirrors - F150 Pickup



Fig. 34: Disengage Power Mirror Motor Jackscrews From Mirror Backing Plate
Courtesy of FORD MOTOR CO.

3. Remove the mirror glass by grasping the outboard edge of the glass and separate it from the mirror

housing.

z

If equipped, disconnect the electrical connector.

WARNING:

Place a shop towel between the mirror glass and the hand to avoid
personal injury in the instance of glass breakage.
