Ford F150 Pickup. Instruction - part 149

Fig. 150: Installing Tailgate Access Panel
Courtesy of FORD MOTOR CO.

1. To install, reverse the removal procedure.

DOOR LOCK ACTUATOR

Removal and Installation

1. Remove the front door latch. Refer to FRONT DOOR LATCH or FRONT DOOR LATCH-

SUPERCREW .

2. Remove the door lock actuator.

3. To install, reverse the removal procedure.

DOOR LOCK ACTUATOR - REAR, SUPERCREW

Removal and Installation

1. Remove the rear door latch. Refer to REAR DOOR LATCH-SUPERCREW .

2. Remove the rear door lock actuator.

3. To install, reverse the removal procedure.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



DOOR AJAR SWITCH

Removal and Installation

1. Remove the door latch. Refer to FRONT DOOR LATCH , FRONT DOOR LATCH-SUPERCREW

or REAR DOOR LATCH-SUPERCREW .

2. Remove the door ajar switch.

1. Lift the locking tab.

2. Rotate the door ajar switch counterclockwise.

3. Remove the door ajar switch.

Fig. 151: Removing Door Ajar Switch
Courtesy of FORD MOTOR CO.

3. To install, reverse the removal procedure.

KEYLESS ENTRY KEYPAD

Removal and Installation



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



1. Remove the driver door trim panel. Refer to FRONT DOOR TRIM PANEL .

2. Remove the keyless entry keypad.

1. Remove the screw.

2. Remove the speed nuts.

3. Remove the keyless entry keypad.

z

Disconnect the electrical connector.

Fig. 152: Removing Keyless Entry Keypad
Courtesy of FORD MOTOR CO.

3. To install, reverse the removal procedure.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



2003 ACCESSORIES AND EQUIPMENT

Rear View Mirrors - F150 Pickup

SPECIFICATIONS

GENERAL SPECIFICATIONS

Fig. 1: General Specifications
Courtesy of FORD MOTOR CO.

TORQUE SPECIFICATIONS

Fig. 2: Torque Specifications
Courtesy of FORD MOTOR CO.

DESCRIPTION AND OPERATION

REAR VIEW MIRRORS

The inside rear view mirror (17700):

z

is windshield mounted
