Fig. 93: Locating Supercharger By-Pass Solenoid Actuator Bolts
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Fig. 94: Removing Supercharger By-Pass Solenoid Actuator Rod
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Fig. 95: Installing Actuator Adjustment Tool
Courtesy of FORD MOTOR CO.

FUEL SYSTEMS

FUEL SYSTEM SAFETY PRECAUTIONS

Safe Fuel Handling Practices

Fire

CAUTION: Fuel in fuel system remains under high pressure even when engine is not

running. To avoid injury or fire, release fuel pressure from fuel system
before disconnecting any fuel line. To release pressure from system
perform

FUEL SYSTEM PRESSURE RELEASE

 procedure. To avoid

unnecessary fuel spillage and fire hazard, any time fuel lines are
disconnected, ignition switch must be in OFF position unless fuel pump
operation is required for test purposes.

WARNING:

Use care to prevent combustion from fuel spillage. No smoking, open
flames or any kind of arcing.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



z

Report all fires to proper authorities.

z

Flames from methanol or methanol-gasoline blends can be invisible.

z

Know locations of portable fire extinguishers, fire blankets, fire alarms and eye/wash shower facilities
and learn how to use them.

z

Use a "B" or "AFFF" (light water) type fire extinguisher to fight flammable liquid fires.

First Aid

z

If gasoline has been swallowed, do not induce vomiting. Seek medical attention immediately!

z

If methanol or a methanol/gasoline blend has been swallowed, induce vomiting under the direction of a
physician or Poison Control Center. Seek medical attention immediately!

z

When overcome by vapors, if safe, move victim to fresh air. If not breathing, give artificial respiration or
Cardiopulmonary Resuscitation (CPR) as appropriate. Seek medical attention immediately!

z

If splashed in eyes, flush with large amounts of water for 15 minutes. Remove contact lenses, if worn.
Seek medical attention.

z

If splashed on skin, remove contaminated clothing. Wash skin thoroughly with soap and water.

Health

z

All fuels can be harmful or fatal if swallowed.

z

Be aware, if fuel is swallowed, onset of serious health effects can be delayed 12 to 24 hours.

z

Fuels and products containing methanol (e.g. windshield washer fluid) can cause blindness if swallowed.

z

All fuel vapors can be harmful if inhaled.

z

All fuels can be harmful if absorbed through skin.

z

All fuels are irritating to eyes and respiratory system.

z

Some fuels made with gasoline contain benzene which is a cancer causing agent.

Handling

z

Use flammable liquid handling precautions.

z

Wear chemical goggles and nitrile gloves (additional protective clothing and equipment may be necessary
in some instances).

z

Keep flammable liquids in approved, labeled, closed containers.

z

Use in well ventilated areas and control vapors. Be aware that vapors are not visible, are heavier than air,
can travel along floor, and will settle in lower areas.

z

When transferring flammable liquids, bond receiving container to source and ground source to earth.

z

DO NOT smoke or use heat or spark producing equipment near vapors.

z

DO NOT eat, smoke or drink where these products are handled, processed or stored.

z

Never siphon by mouth.

z

Wash hands thoroughly after handling any fuel.
