Fig. 75: Positioning Front Door Latch
Courtesy of FORD MOTOR CO.

11. Disconnect the door ajar switch electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 76: Disconnecting Door Ajar Switch Electrical Connector
Courtesy of FORD MOTOR CO.

12. Remove the front door latch.

z

Disconnect the cable from the latch.

z

Transfer all necessary components.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 77: Removing Front Door Latch
Courtesy of FORD MOTOR CO.

13. To install, reverse the removal procedure.

z

If necessary, use Multi-Purpose Grease Spray F5AZ-19G209-AA or equivalent meeting Ford
specification ESR-M1C159-A to lubricate the latches.

REAR DOOR LATCH - LOWER

Removal



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



1. Remove the rear door trim panel. Refer to TRIM PANEL -- REAR DOOR .

2. Remove the rear door radio speaker (18808).

1. Remove the screws.

2. Disconnect the electrical connector.

3. Remove the rear door radio speaker.

Fig. 78: Removing Rear Door Radio Speaker
Courtesy of FORD MOTOR CO.

3. Remove the watershield.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup
